PL-32

PL-11, -12, -13, -14, -32, -33, -34 Vishay Dale Low Power Transformers Single Primary, Input 115 Volts Dual Secondary: PL-11 thru -14, Single Secondary: PL-32 thru -34 FEATURES • PC pin mounting • Provides isolation from power line • Mounting frames and bobbin standoff are RoHS available COMPLIANT • Modification to these standard itmes are available as specially products • Laminated construction for low-cost industrial applications, including power supplies, controls and instrumentation • PL-11, PL-12, PL-13, PL-14: Dual secondaries for series connection to obtain twice voltage with center tap or parallel connection for twice current rating • PL-32, PL-33, PL-34: Single secondary and lower cost construction. Recognized under the Component Program of Underwriters Laboratories, Inc., U.L. Files E71961. For general purpose transformers (U.L. Standard 506). ELECTRICAL SPECIFICATIONS Input Voltage: 115 V, 60 Hz Output Power Rating: PL-11 = 0.75 VA PL-12, PL-32 = 1.50 VA PL-13, PL-33 = 4.50 VA PL-14, PL-34 = 10.0 VA Dielectric Strength: All models are 1500 V, 60 Hz from primary to secondary winding and all windings to core Temperature Class: Insulation Class A, + 105 °C MECHANICAL SPECIFICATIONS Terminals Brass, solder coated Weight: (reference) PL-11 = 35 grams PL-12, PL-32 = 100 grams PL-13, PL-33 = 160 grams PL-14, PL-34 = 240 grams SCHEMATICS Basic Style PL-11, PL-12, PL-13, PL-14 1 3 115 V 50 - 60 Hz 4 5 2 6 Options PL-11, PL-12, PL-13, PL-14 PL-32, PL-33, PL-34 1 3 1 3 4 5 6 Series Connected Volts Output 4 5 2 6 Parallel Connected 1 115 V 50 - 60 Hz Volts Output 3 4 Volts Output 5 2 www.vishay.com 2 For technical questions contact magnetics@vishay.com Document Number: 34071 Revision: 10-Aug-06 PL-11, -12, -13, -14, -32, -33, -34 Vishay Dale OUTPUT VOLTAGE TABLE OUTPUT VOLTAGE SERIES DUAL SECONDARY OUTPUT CURRENT (mA) PARALLEL SERIES PARALLEL SINGLE SECONDARY MODEL PL-32-01 PL-33-01 PL-34-01 PL-11-01 PL-12-01 PL-13-01 PL-14-01 PL-11-02 PL-12-02 PL-13-02 PL-14-02 PL-11-03 PL-12-03 PL-13-03 PL-14-03 PL-11-04 PL-12-04 PL-13-04 PL-14-04 PL-11-05 PL-12-05 PL-13-05 PL-14-05 PL-11-06 PL-12-06 PL-13-06 PL-14-06 PL-11-07 PL-12-07 PL-13-07 PL-14-07 PL-11-08 PL-12-08 PL-13-08 PL-14-08 PL-11-09 PL-12-09 PL-13-09 PL-14-09 PL-11-10 PL-12-10 PL-13-10 PL-14-10 PL-12-11 PL-13-11 PL-14-11 PL-12-12 PL-13-12 PL-14-12 PL-12-13 PL-13-13 PL-14-13 PL-12-14 PL-13-14 PL-14-14 8 VCT 10 VCT 12.6 VCT 15 VCT 16 VCT 20 VCT 24 VCT 30 VCT 34 VCT 40 VCT 54 VCT 56 VCT 76 VCT 88 VCT 4V 94 188 562 940 75 120 440 1000 60 100 350 800 50 100 300 500 47 75 260 640 38 60 220 500 31 50 180 450 25 50 150 250 22 35 125 300 19 30 110 250 28 84 140 20 80 180 20 60 100 15 50 120 188 376 1124 1880 150 240 880 2000 120 200 700 1600 100 200 600 1000 94 150 520 1280 76 120 440 1000 62 100 360 900 50 100 300 500 44 70 250 600 38 60 220 500 56 168 280 40 160 360 40 120 200 30 100 240 OUTPUT VOLTAGE 6.4 V OUTPUT CURRENT (mA) 200 700 1300 MODEL 5V PL-32-02 PL-33-02 PL-34-02 PL-32-03 PL-33-03 PL-34-03 PL-32-04 PL-33-04 PL-33-04 10 V 120 450 800 100 350 650 80 300 550 6.3 V 12.6 V 7.5 V 15 V 8V 10 V PL-32-05 PL-33-05 PL-34-05 PL-32-06 PL-33-06 PL-34-06 PL-32-07 PL-33-07 PL-34-07Z 20 V 60 225 400 50 185 330 40 150 270 12 V 24 V 15 V 30 V 17 V 20 V 27 V 28 V 38 V 44 V PL-32-08 PL-33-08 PL-34-08 54 V 22 80 150 PL-32-09 PL-33-09 PL-34-09 PL-32-10 PL-33-10 PL-34-10 PL-32-11 PL-33-11 PL-34-11 76 V 88 V 115 V 16 60 110 14 50 90 10 40 70 PL-12-15 PL-13-15 PL-14-15 PL-12-16 PL-13-16 PL-14-16 PL-12-17 PL-13-17 PL-14-17 120 VCT 180 VCT 230 VCT 60 V 90 V 115 V 10 35 85 6 24 55 5 20 40 20 70 170 12 48 110 10 40 80 PL-32-12 PL-33-12 PL-34-12 PL-32-13 PL-33-13 PL-34-13 180 V 230 V 7 25 45 5 20 35 www.vishay.com 3 Document Number: 34071 Revision: 10-Aug-06 For technical questions contact magnetics@vishay.com PL-11, -12, -13, -14, -32, -33, -34 Vishay Dale DIMENSIONAL CONFIGURATIONS (Reference) [Numbers in brackets indicate millimeters] Basic Style A PL-11, PL-12, PL-13, PL-14 1 3 4 PL-32, PL-33, PL-34 3 2 1 B D E D E 0.150 [3.81] Min. 0.041 [1.04] Typ. C C PC Terminal (Plug in Mounting) 2 5 6 4 5 “A” Type of Mounting Frame F I 0.250 [6.35] Typ. J “B” Type of Mounting Frame F K Dia. 2 Holes G C L H MODEL PL-11 PL-12 PL-32 PL-13 PL-33 PL-14 PL-34 A 1.04 [26.42] 1.43 [36.32] 1.68 [42.67] 1.93 [49.02] B 0.860 [21.84] 1.20 [30.48] 1.38 [35.05] 1.64 [41.66] C 0.250 [6.35] 0.312 [7.92] 0.400 [10.16] 0.400 [10.16] D 0.920 [23.37] 1.19 [30.23] 1.30 [33.02] 1.48 [37.59] E 0.720 [18.29] 1.0 [25.40] 1.10 [27.94] 1.30 [33.02] F 1.07 [27.18] 1.50 [38.10] 1.75 [44.45] 2.0 [50.80] G 1.38 [35.05] 1.75 [44.45} 2.0 [50.80] 2.38 [60.45] H 1.69 [42.93] 2.12 [53.85] 2.44 [61.98] 2.88 [73.15] I 0.018 [0.457] 0.031 [0.787] 0.031 [0.787] 0.031 [0.787] J 0.125 [3.18] 0.125 [3.18] 0.125 [3.18] 0.188 [4.78] K 0.125 [3.18] 0.188 [4.78} 0.188 [4.78] 0.188 [4.78] MARKING - Dale - Mode - Date Code ORDERING INFORMATION PL-11 MODEL 01 OUTPUT VOLTAGE AND CURRENT A MOUNTING FRAME (If not required, leave blank) S BOBBIN STANDOFF (If not required, leave blank) EB PACKAGE CODE e2 JEDEC LEAD (Pb)-FREE STANDARD GLOBAL PART NUMBER P L 1 1 0 1 A MOUNTING FRAME (If not required, leave blank) S BOBBIN STANDOFF (If not required, leave blank) E B MODEL OUTPUT VOLTAGE AND CURRENT PACKAGE CODE www.vishay.com 4 For technical questions contact magnetics@vishay.com Document Number: 34071 Revision: 10-Aug-06 Legal Disclaimer Notice Vishay Disclaimer All product specifications and data are subject to change without notice. Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein or in any other disclosure relating to any product. Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any information provided herein to the maximum extent permitted by law. The product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed therein, which apply to these products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by any conduct of Vishay. The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for such applications. Product names and markings noted herein may be trademarks of their respective owners. Document Number: 91000 Revision: 18-Jul-08 www.vishay.com 1
