RoHS
GBP3005 THRU GBP310
COMPLIANT
Bridge Rectifiers
Features
● UL recognition, file #E230084
● Glass passivated chip junction
● Ideal for printed circuit boards
● High surge current capability
● Solder dip 275 °C max. 7 s, per JESD 22-B106
Typical Applications
General purpose use in AC/DC bridge full wave
rectification for monitor, TV, printer, power supply, switching
mode power supply, adapter, audio equipment, and home
appliances applications.
Mechanical Data
+
~
~
● Package: GBP
Molding compound meets UL 94 V-0 flammability
rating, RoHS-compliant
● Terminals: Tin plated leads, solderable per
J-STD-002 and JESD22-B102
● Polarity: As marked on body
-
■Maximum Ratings (Ta=25℃ Unless otherwise specified)
PARAMETER
SYMBOL
UNIT
Device marking code
GBP3005
GBP301
GBP302
GBP304
GBP306
GBP308
GBP310
GBP3005
GBP301
GBP302
GBP304
GBP306
GBP308
GBP310
Maximum Repetitive Peak Reverse Voltage
VRRM
V
50
100
200
400
600
800
1000
Maximum RMS Voltage
VRMS
V
35
70
140
280
420
560
700
VDC
V
50
100
200
400
600
800
1000
IO
A
IFSM
A
Maximum DC blocking Voltage
Average rectified output current
@60Hz sine wave, R-load, Tc =120℃
Forward Surge Current (Non-repetitive)
@60Hz Half-sine wave,1 cycle, Tj=25℃
Forward Surge Current (Non-repetitive)
@1ms, square wave, 1 cycle, Tj=25℃
Current squared time
@1ms≤t≤8.3ms Tj=25℃, Rating of per diode
Dielectric strength
@ terminals to case, AC 1 minute
3.0
90
180
I2t
A2s
Vdis
KV
2
Storage temperature
Tstg
℃
-55 ~ +150
Junction temperature
Tj
℃
-55 ~ +150
33.6
1/4
S-B219
Rev. 2.3, 23-Apr-22
Yangzhou Yangjie Electronic Technology Co., Ltd.
www.21yangjie.com
GBP3005 THRU GBP310
■Electrical Characteristics(Ta=25℃ Unless otherwise specified)
PARAMETER
SYMBOL UNIT
Maximum instantaneous
forward voltage drop per diode
VF
V
Maximum DC reverse current
at rated DC blocking voltage
per diode
IR
μA
Typical junction capacitance
Cj
pF
TEST CONDITIONS GBP3005 GBP301 GBP302 GBP304 GBP306 GBP308 GBP310
IFM=1.5A
1.0
Tj =25℃
5
Tj =125℃
100
Measured at 1MHz
and Applied Reverse
Voltage of 4.0 V.D.C
27
■Thermal Characteristics (Ta=25℃ Unless otherwise specified)
PARAMETER
Thermal
Resistance
SYMBOL
Between junction and
ambient
RθJ-A
Between junction
and Case
RθJ-C
UNIT
GBP3005
GBP301
GBP302
GBP304
GBP306
GBP308
GBP310
45
℃/W
5
■Ordering Information (Example)
PREFERED P/N
PACKING
CODE
UNIT WEIGHT(g)
MINIIMUM
PACKAGE(pcs)
INNER BOX
QUANTITY(pcs)
OUTER CARTON
QUANTITY(pcs)
DELIVERY MODE
GBP3005-GBP310
B1
1.4
35
2100
4200
TUBE
■ Characteristics (Typical)
FIG2:Surge Forward Current Capability
FIG1:Io-Tc Curve
3.6
2.4
1.8
1.2
sine wave R-load
free in air
0.6
0
Half sine wave
120
0
IFSM
3.0
Peak Forward Surge Current(A)
Average Forward output Current(A)
140
8.3ms 8.3ms
1cycle
100
non-repetitive
Tj=25℃
90
80
60
40
20
0
40
80
120
Case Temperature(℃ )
160
0
1
2
5
10
20
Number of Cycles
50
100
2/4
S-B219
Rev. 2.3, 23-Apr-22
Yangzhou Yangjie Electronic Technology Co., Ltd.
www.21yangjie.com
GBP3005 THRU GBP310
FIG3: Typical Forward Voltage
60
FIG4:Typical Reverse Characteristics
100
20
Instantaneous Reverse Current (uA)
Instantaneous Forward Current(A)
40
10
5.0
2.0
1.0
0.5
0.2
0.1
0.6
1.0
0.1
Tj=25 ℃
0.01
1.6
0.8
1.0
1.2
1.4
Instantaneous Forward Voltage(V)
Tj=125 ℃
10
0
20
40
60
80
100
Percent of Rated Peak Reverse Voltage (%)
■ Outline Dimensions
GBP
GBP
A
H
C2.7
B
I
C
E
D
F
Dim
Min
A
14.25
Max
14.75
B
10.10
10.60
C
1.80
2.20
D
14.25
14.73
E
1.22
1.42
F
0.76
0.86
G
3.70
3.90
H
3.35
3.65
I
0.80
1.10
J
0.35
0.55
J
G
G
G
Dimensions in millimeters
3/4
S-B219
Rev. 2.3, 23-Apr-22
Yangzhou Yangjie Electronic Technology Co., Ltd.
www.21yangjie.com
GBP3005 THRU GBP310
Disclaimer
The information presented in this document is for reference only. Yangzhou Yangjie Electronic Technology Co., Ltd. reserves the
right to make changes without notice for the specification of the products displayed herein to improve reliability, function or design
or otherwise.
The product listed herein is designed to be used with ordinary electronic equipment or devices, and not designed to be used with
equipment or devices which require high level of reliability and the malfunction of with would directly endanger human life (such as
medical instruments, transportation equipment, aerospace machinery, nuclear-reactor controllers, fuel controllers and other safety
devices), Yangjie or anyone on its behalf, assumes no responsibility or liability for any damages resulting from such improper use
of sale.
This publication supersedes & replaces all information previously supplied. For additional information, please visit our website
http:// www.21yangjie.com , or consult your nearest Yangjie’s sales office for further assistance.
4/4
S-B219
Rev. 2.3, 23-Apr-22
Yangzhou Yangjie Electronic Technology Co., Ltd.
www.21yangjie.com
