LL5817 – LL5819
Taiwan Semiconductor
1A, 20 - 40V Schottky Barrier Surface Mount Rectifier
FEATURES
●
●
●
●
●
●
KEY PARAMETERS
Plastic package has carries underwriters
Ideal for automated placement
Surge overload rating to 25A peak
Reliable low cost construction utilizing molded
RoHS Compliant
Halogen-free according to IEC 61249-2-21
APPLICATIONS
● Inverters
● Converters
● Adapters
PARAMETER
VALUE
UNIT
IF
1
A
VRRM
20 - 40
V
IFSM
25
A
TJ MAX
125
°C
Package
MELF
Configuration
Single die
MECHANICAL DATA
●
●
●
●
Case: MELF
Meet JESD 201 class 1A whisker test
Polarity: Indicated by cathode band
Weight: 120.00mg (approximately)
MELF
ABSOLUTE MAXIMUM RATINGS (TA = 25°C unless otherwise noted)
PARAMETER
SYMBOL
LL5817
LL5818
LL5819
UNIT
Repetitive peak reverse voltage
VRRM
20
30
40
V
Reverse voltage, total rms value
VR(RMS)
14
21
28
V
VDC
20
30
40
V
DC blocking voltage
Forward current
Surge peak forward current 8.3ms
single half sine-wave superimposed
on rated load
Junction temperature
IF
1
A
IFSM
25
A
TJ
-65 to +125
°C
Storage temperature
TSTG
-65 to +125
°C
1
Version: I2006
LL5817 – LL5819
Taiwan Semiconductor
THERMAL PERFORMANCE
PARAMETER
SYMBOL
TYP
UNIT
RӨJA
80
°C/W
Junction-to-Ambient thermal resistance
ELECTRICAL SPECIFICATIONS (TA = 25°C unless otherwise noted)
PARAMETER
CONDITIONS
LL5817
Forward voltage
(1)
LL5818
LL5819
Reverse current @ rated VR
(2)
Junction capacitance
TYP
MAX
UNIT
IF = 1A
-
0.450
V
IF = 3A
-
0.750
V
-
0.550
V
-
0.875
V
IF = 1A
-
0.600
V
IF = 3A
-
0.900
V
-
0.5
mA
-
5
mA
110
-
pF
IF = 1A
SYMBOL
VF
IF = 3A
TJ = 25°C
IR
TJ = 100°C
1MHz, VR = 4.0V
CJ
Notes:
1. Pulse test with PW = 0.3ms
2. Pulse test with PW = 30ms
ORDERING INFORMATION
ORDERING CODE(1)
PACKAGE
PACKING
LL581x L0G
MELF
5,000/13” reel
Notes:
1. “x” defines voltage from 20V(LL5817) to 40V(LL5819)
2
Version: I2006
LL5817 – LL5819
Taiwan Semiconductor
CHARACTERISTICS CURVES
(TA = 25°C unless otherwise noted)
Fig.1 Forward Current Derating Curve
Fig.2 Maximum Non-Repetitive Peak
Forward Surge Current
30
Peak Forward Surge Current (A)
Average Forward Current (A)
1.25
1
0.75
0.5
0.25
0
8.3ms Single Half Sine Wave
25
20
15
10
5
0
0
25
50
75
100
125
1
10
Number of Cycles at 60HZ
Lead Temperature (OC)
Fig.4 Typical Reverse Characteristics
100
Instantaneous Reverse Current (mA)
Instantaneous Forward Current (A)
Fig.3 Typical Forward Characteristics
10
LL5817
LL5818-LL5819
1
Pulse Width=300μs
1% Duty Cycle
0.1
0.1 0.3 0.5 0.7 0.9 1.1 1.3 1.5 1.7 1.9 2.1
10
TJ=100°C
1
0.1
TJ=25°C
0.01
0
Forward Voltage (V)
20
40
60
80
100
120
140
Percent of Rated Peak Reverse Voltage (%)
Fig.5 Typical Junction Capacitance
Fig.6 Typical Transient Thermal Impedance
100
Transient Termal Impedance (oC/W)
1000
Junction Caoacitance (pF)
100
100
10
0.1
1
10
100
10
1
0.1
0.01
0.01
0.1
1
10
100
T, Pulse Duration (s)
Reverse Voltage (V)
3
Version: I2006
LL5817 – LL5819
Taiwan Semiconductor
PACKAGE OUTLINE DIMENSIONS
MELF
Unit (mm)
DIM
Unit (inch)
Min
Max
Min
Max
A
4.80
5.50
0.189
0.217
B
2.25
2.67
0.089
0.105
C
0.30
0.60
0.012
0.024
SUGGESTED PAD LAYOUT
Unit (mm)
Unit (inch)
TYP
TYP
C
4.80
0.189
G
3.30
0.130
X
1.50
0.059
X1
6.30
0.248
Y
2.70
0.106
DIM
4
Version: I2006
LL5817 – LL5819
Taiwan Semiconductor
Notice
Specifications of the products displayed herein are subject to change without notice. TSC or anyone on its behalf,
assumes no responsibility or liability for any errors or inaccuracies.
Purchasers are solely responsible for the choice, selection, and use of TSC products and TSC assumes no liability
for application assistance or the design of Purchasers’ products.
Information contained herein is intended to provide a product description only. No license, express or implied, to
any intellectual property rights is granted by this document. Except as provided in TSC’s terms and conditions of
sale for such products, TSC assumes no liability whatsoever, and disclaims any express or implied warranty,
relating to sale and/or use of TSC products including liability or warranties relating to fitness for a particular purpose,
merchantability, or infringement of any patent, copyright, or other intellectual property right.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications.
Customers using or selling these products for use in such applications do so at their own risk and agree to fully
indemnify TSC for any damages resulting from such improper use or sale.
5
Version: I2006
