SLVU2.8-4N
ESD Protection Diode Array
»
Features
■
240Watts peak pulse power (tp =
8/20μs,Pin1,8-2,7 Pin3,6-4,5)
■
SOP8 package
■
Solid-state silicon-avalanche technology
■
Low clamping voltage
■
Low leakage current
■
Protection four data/power line
■
IEC 61000-4-2 ±30V contact ±30kV air
■
1.2/50μs 12ohm 2kV (GbE PHY side)
■
10/700μs 40ohm 4kV (GbE PHY side)
»
Applications
■
10/100/1000 Ethernet
■
LAN/WAN Equipment
■
Security Cameras
■
»
Mechanical Data
■
SOP8 package
■
Molding compound flammability rating:
UL 94V-0
Notebook and PC Computers
■
Packaging: Tape and Reel
■
Integrated magnetics/RJ-45 connectors
■
RoHS/WEEE Compliant
■
Industry Control
»
Schematic & PIN Configuration
Revision 2018
8
7
6
5
1
2
3
4
www.born-tw.com
1/5
SLVU2.8-4N
»
Absolute Maximum Rating
Rating
Symbo
Peak Pulse Power ( tp =8/20μs )
Value
Units
PPP
Pin1,8-2,7 Pin3,6-4,5
240
W
Ipp
Pin1,8-2,7 Pin3,6-4,5
16
A
30
30
kV
Peak Pulse Current ( tp =8/20μs ) (note1)
ESD per IEC 61000-4-2 (Air)
ESD per IEC 61000-4-2 (Contact)
Conditions
VESD
Lead Soldering Temperature
TL
260(10seconds)
℃
Junction Temperature
TJ
-55 to + 125
℃
Storage Temperature
Tstg
-55 to + 125
℃
»
Electrical Characteristics
Parameter
Symbol
Reverse Stand-Off Voltage
Conditions
Min
Typical
VRWM
Max
Units
5.0
V
VBR
IT=1mA
Reverse Leakage Current
IR
VRWM=5V,T=25℃
0.2
0.5
uA
Clamping Voltage
VC
IPP=16A,tp=8/20μs
Pin1,8-2,7,Pin3,6-4,5
12
15
V
Junction Capacitance
Cj
VR = 0V, f = 1MHz
Pin1,8-2,7 Pin3,6-4,5
1.2
1.4
pF
Reverse Breakdown Voltage
»
6
8.0
V
Electrical Parameters (TA = 25°C unless otherwise noted)
Symbol
IPP
Maximum Reverse Peak Pulse Current
VC
Clamping Voltage @ IPP
VRWM
IR
VBR
IT
I
Parameter
IPP
Working Peak Reverse Voltage
VC VBR
Maximum Reverse Leakage Current @ V RWM
VRWM
IT
IR
I
IT R
VRWM
VBR VC
V
Breakdown Voltage @ IT
Test Current
IPP
Note:. 8/20μs pulsewaveform.
Revision 2018
www.born-tw.com
2/5
SLVU2.8-4N
»
Typical Characteristic Curves
Fig.1 Peak Pulse Power RatingCurve
Fig.2 Pulse Derating Curve
Percent of Rated Power for Ipp
Peak Pulse Power –PPP(KW)
10
240w 8/20μswaveform
1
0.1
0.01
0.1
1
10
100
110
100
8
0
6
0
40
2
0
0
1000
0
Pulse Duration tp(μs)
Fig.3 PulseWaveform-8/20μs
120
Fig.4 PulseWaveform-ESD(IEC61000-4-2)
100%IPP , 8μS
100%
90%
30ns
80
50%IPP, 20μS
e-t
60
Percent of IPP
Percent of IPP
100
40
20
0
150
25
50
75
100
1
Ambient Temperature—TA(℃)
60ns
10%
0
5
10
15
20
25
30
tr 0.7 to 1ns
0
30
Time (μs)
Fig.5 Eye Diagram - HDMI mask at 5.0Gbpsper
channel
60
Time (ns)
Fig.6 Insertion LossS21
2
3.2GHz @ -1dB
Horizontal: 50 ps/div
Vertical: 200 mV/div
Insertion Loss (dB)
0
-2
-4
5GHz @ -3dB
-6
-8
-10
100k
1M
10M
100M
1G
10G
Frequency (Hz)
Revision 2018
www.born-tw.com
3/5
SLVU2.8-4N
»
Application Information
Lightning Surge Test Results for Gigabit Ethernet
During the metallic (line-to-line) surge test, the line being stressed is tied to the surge generator with
the remaining lines tied together and connected to the generator ground. Current will flow through the
line transformer transferring energy to the PHY side of the transformer. Figure 7 shows the test set-up
for measuring the clamping voltage of the device. This set up is designed to test the surge in an
actual gigabit Ethernet (GbE) circuit. Two 4.7 Ohm resistors is used for decoupling. The clamping voltage
of the SLVU2.8-4N for a metallic mode 4000V (100A) 10/700μs surge. The clamping voltage, measured at
less than 13 volts, provides sufficient clamping margin to minimize electrical stress and is well below the
failure voltage range of typical GbE PHY chips (Figure 8 ).
Ipp
RL =4.7Ω
+
+
Vin
Vc
R L =4.7 Ω
-
Gigabit
Ethernet
Phy
-
Figure 7 - Clamping Voltage Test Set-Up
RJ-45
1
2
3
4
5
6
7
8
Gigabit
Ethernet
PHY
Figure 8 - GbE Protection to Lightning, ESD, and CDE
Revision 2018
www.born-tw.com
4/5
SLVU2.8-4N
»
Outline Drawing – SOP8
Ref.
(mm)
A
a1
a2
b
b1
C
D
E
e
e3
F
L
M
»
C
Min.
Typ.
0.10
0.35
0.19
4.80
5.80
3.80
0.40
0.50
1.27
3.81
0.85
Max.
5.00
6.20
b1
A a2
1.75
0.25
1.65
0.48
0.25
45°
b
e
e3
8°
a1
L
D
E
F
4.00
1.27
0.6
M
Marking
SLVU2.8
-4L
»
Ordering information
Order code
SLVU2.8-4N
Revision 2018
Package
SOP8
Base qty
2500
www.born-tw.com
Delivery mode
Tape and reel
5/5
