MMDTA114EE
PNP Silicon
Epitaxial Planar Transistor
for switching and interface circuit and drive circuit
applications
Collector
(Output)
Base
(Input)
Features
• With built-in bias resistors
• Simplify circuit design
• Reduce a quantity of parts and
manufacturing process
R1
R2
Emitter
(Common)
Absolute Maximum Ratings (Ta = 25℃)
Parameter
Symbol
Value
VCEO
-50
Collector Emitter Voltage
Unit
V
Input Voltage
VI
Collector Current
IC
-100
Power Dissipation
Ptot
150
mW
Tj
150
℃
Tstg
- 55 to + 150
℃
Junction Temperature
Storage Temperature Range
+10 to - 40
V
mA
Characteristics at Ta = 25℃
Parameter
Symbol
Min.
Typ.
Max.
Unit
DC Current Gain
at VCE =-5V, IC =-5mA
hFE
30
-
-
-
Collector Base Cutoff Current
at VCB =-50V
ICBO
-
-
-500
nA
Emitter Base Cutoff Current
at VEB =-5V
IEBO
-
-
-0.88
mA
VCE(sat)
-
-
-0.3
V
Input on Voltage
at VCE =-0.3V, IC =-10mA
VI(on)
-
-
-3
V
Input off Voltage
at VCE =-5V, IC =-100uA
VI(off)
-0.5
-
V
Transition frequency
at VCE =-10V, I E=-5mA, f=-100MHz
fT
-
250
-
MHz
Input Resistance
R1
7
10
13
KΩ
Resistance Ratio
R 2 / R1
0.8
1
1.2
-
Input Resistance
R1 +R2
20
22
KΩ
Collector Emitter Saturation Voltage
at IC =-10mA, IB=-0.5mA
Page 1 of 3
-
2/21/2014
MMDTA114EE
Page 2 of 3
2/21/2014
Page 3 of 3
2/21/2014
