H8116 Synchronous Step-Up DCDC Converter with PFM Control
Features
External parts:Coil, capacitor
Accuracy of ±2%
Output voltage: Settable to between 2.1V to
High efficiency :95%
5.5V in 0.1V steps
Package: SOT23,SOT23-3 and TO92
Maximum Oscillation frequency :300KHz
Applications
Digital cameras
Cameras , video equipment
Electronic notebooks and PDAS
Communications equipment
Portable CD/MD players
Power supply for microcomputers
General Description
The H8116 Series is a Synchronous step-up
coil, capacitor. The built-in MOSFET is turned off
DC/DC Converter with PFM Control.With the
by a protection circuit when the voltage at the LX
H8116 Series, a step-up switching DC/DC
pin exceeds the limit to prevent it from being
converter can be configured by using an external
damaged.
SI
PR
O
IN
Block Diagram
Order Information
H8116①②③④⑤
Designator
①
②③
④
⑤
Ver1.3
Symbol
Description
A
Integer
Standard
Output Voltage (2.1V~5.5V)
e.g:3.0V=②:3;③:0
T
Package:TO-92
M
N
R
Package:SOT23-3
Package:SOT23
RoHS / Pb Free
G
Halogen Free
1/7
Shanghai Siproin Microelectronics Co.
H8116 Synchronous Step-Up DCDC Converter with PFM Control
Pin Assignment
Table1 H8116A
SOT23 or SOT23-3
series (SOT23/SOT23-3 PKG)
1
2
PIN NO.
PIN NAME
FUNCTION
1
VOUT
Output voltage pin
2
Vss
GND pin
3
LX
External inductor connection pin
3
Table2 H8116A
TO92
PIN NAME
1
2
3
FUNCTION
3
Vss
GND pin
VOUT
Output voltage pin
LX
External inductor connection pin
PR
O
1 2
PKG)
IN
PIN NO.
series (TO92
Absolute Maximum Ratings
(Unless otherwise specified, Ta=25℃)
SYMBOL
RATINGS
UNITS
VOUT Pin Voltage
VOUT
VSS-0.3~VSS+8
V
EN Pin Voltage
EN
VSS-0.3~VSS+8
V
LX Pin Voltage
VLX
VSS-0.3~VSS+8
V
LX Pin Current
ILX
1000
mA
250
mW
250
mW
500
mW
SI
PARAMETER
SOT23
Power
Dissipation
SOT23-3
PD
TO-92
Operating Temperature
TOPR
-40~+85
℃
Storage Temperature
TSTG
-40~+125
℃
Soldering Temperature & Time
TSOLDER
260℃,10s
Note: These are stress ratings only. Stresses exceeding the range specified under “Absolute Maximum
Ratings” may cause substantial damage to the device. Functional operation of this device at other
conditions beyond those listed in the specification is not implied and prolonged exposure to extreme
conditions may affect device reliability.
Ver1.3
2/7
Shanghai Siproin Microelectronics Co.
H8116 Synchronous Step-Up DCDC Converter with PFM Control
Electrical Characteristics
(Unless otherwise specified,Ta = 25℃)
SYMBOL
Output Voltage
VOUT
Input Voltage
VIN
Operation Start Voltage
VST1
Operation Start Voltage
V ST1
Input Current At No Load
ISS
Current Consumption 2
ISS2
ISSS
Current Consumption
During Shutdown
Maximum Oscillation
Frequency
MIN
VOUT(S)
×0.98
-
Efficiency
EFF1
VOUT(S)
×1.02
UNITS
CONDITION
V
-
7.5
V
-
-
0.9
V
IOUT=1mA VOUT=2.2V~4.2V
-
1.2
V
IOUT=1mA VOUT=4.2V~5.5V
15
25
uA
VIN=1.8V, VOUT=3.0V
25
35
uA
VIN=0.9V, VOUT=3.0V
-
6
10
uA
VOUT=VOUT +0.5V
-
-
1.0
uA
VEN=0V
-
300
70
78
KHz
85
90
PR
O
Duty1
VOUT
MAX
-
fosc
Duty Ratio1
TYP
IN
PARAMETER
%
VOUT=0.95xVOUT, measure
Waveform at LX pin
VOUT=0.95xVOUT
%
VOUT=0.95xVOUT, judge
VSH
0.75
-
-
V
VSL1
-
-
0.3
V
Shutdown Pin input
ISH
-0.1
-
0.1
uA
VEN=6V
Current
ISL
-0.1
-
0.1
uA
VEN=0V
Shutdown Pin Input
VOUT=0.95xVOUT, judge
stop at LX pin
SI
Voltage
Oscillation at LX pin
Remark: VOUT(S) specified above is the set output voltage value,and VOUT is the typical value of the
actual output voltage
Application Circuits
H8116A
Ver1.3
3/7
Shanghai Siproin Microelectronics Co.
H8116 Synchronous Step-Up DCDC Converter with PFM Control
TYPICAL PERFORMANCE CHARACTERISTICS
SI
PR
O
IN
(Cin=Cout=100uF,L=47uH)
Ver1.3
4/7
Shanghai Siproin Microelectronics Co.
H8116 Synchronous Step-Up DCDC Converter with PFM Control
Package Information
SI
PR
O
IN
3-pin SOT23 Outline Dimensions
Ver1.3
5/7
Shanghai Siproin Microelectronics Co.
H8116 Synchronous Step-Up DCDC Converter with PFM Control
SI
PR
O
IN
3-pin SOT23-3 Outline Dimensions
Ver1.3
6/7
Shanghai Siproin Microelectronics Co.
H8116 Synchronous Step-Up DCDC Converter with PFM Control
SI
PR
O
IN
3-pin TO92 Outline Dimensions
Ver1.3
7/7
Shanghai Siproin Microelectronics Co.
