FRX015-90F

FUZETEC TECHNOLOGY CO., LTD. NO. Product Specification and Approval Sheet Version PQ16-101E 9 Page 1/4 Radial Leaded PTC Resettable Fuse : FRX90V Series 1. Summary (a) RoHS Compliant (Lead Free) Product (b) Applications : Telecom and wide variety of electronic equipment. (c) Product Features : Low hold current, Solid state, Radial leaded product ideal for up to 90VDC (d) Operation Current : 0.10A~3.75A (e) Maximum Voltage : Up to 90VDC (f) Temperature Range : -40℃ to 85℃ 2. Agency Recognition UL : C-UL: TÜ V: File No. E211981 File No. E211981 File No. R50004084 3. Electrical Characteristics (23℃) Part Number FRX010-90F FRX015-90F FRX017-90F FRX020-90F FRX025-90F FRX030-90F FRX035-90F FRX040-90F FRX050-90F FRX055-90F FRX065-90F FRX075-90F FRX090-90F FRX110-90F FRX135-90F FRX160-90F FRX185-90F FRX250-90F FRX300-90F FRX375-90F Resistance Hold Current Trip Current Max.Time to Trip Max. Current Rated Voltage Typ. Power RMIN R1MAX IH,A 0.10 0.15 0.17 0.20 0.25 0.30 0.35 0.40 0.50 0.55 0.65 0.75 0.90 1.10 1.35 1.60 1.85 2.50 3.00 3.75 IT,A 0.20 0.35 0.34 0.40 0.50 0.60 0.75 0.80 1.00 1.20 1.30 1.50 1.80 2.20 2.70 3.20 3.70 5.00 6.00 7.50 at 5XIH,S 4.0 10.0 3.0 2.2 2.5 3.0 10.0 3.8 4.0 10.0 5.3 6.3 7.2 8.2 9.6 11.4 12.6 15.6 19.8 24.0 IMAX,A 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 VMAX,VDC 72/90 72/90 72/90 72/90 72/90 72/90 72/90 72/90 72/90 72/90 72/90 72/90 72/90 72/90 72/90 72/90 72/90 72/90 72/90 72/90 Pd, W 0.38 0.70 0.48 0.41 0.45 0.49 1.30 0.56 0.77 1.50 0.88 0.92 0.99 1.50 1.70 1.90 2.10 2.50 2.80 3.20 Ohms 2.50 2.40 2.00 1.83 1.25 0.88 0.70 0.55 0.50 0.40 0.31 0.25 0.20 0.15 0.12 0.09 0.08 0.05 0.04 0.03 Ohms 7.50 7.00 8.00 4.40 3.00 2.10 2.50 1.29 1.17 1.50 0.72 0.60 0.47 0.38 0.30 0.22 0.19 0.13 0.10 0.08 IH=Hold current-maximum current at which the device will not trip at 23℃ still air. IT=Trip current-minimum current at which the device will always trip at 23℃ still air. V MAX=Maximum voltage device can withstand without damage at its rated current. I MAX= Maximum fault current device can withstand without damage at rated voltage (V MAX). Pd=Typical power dissipated from device when in tripped state in 23℃ still air environment. RMIN=Minimum device resistance at 23℃. R1MAX=Maximum device resistance at 23℃, 1 hour after tripping . Physical specifications: Lead material: FRX010-90F~FRX040-90F Tin plated copper clad steel, 24 AWG. FRX050-90F~FRX090-90F Tin plated copper, 24 AWG. FRX110-90F~FRX375-90F Tin plated copper, 20 AWG. Soldering characteristics:MIL-STD-202, Method 208E. Insulating coating:Flame retardant epoxy, meets UL-94V-0 requirement. NOTE : Specification subject to change without notice. 2019/11/12 NO. FUZETEC TECHNOLOGY CO., LTD. Product Specification and Approval Sheet Version PQ16-101E 9 Page 2/4 4. Production Dimensions (millimeter) FRX 010-90F ~ FRX 090-90F Lead Size : 24AWG Φ 0.51 mm Diameter FRX 110-90F ~ FRX 375-90F Lead Size : 20AWG Φ 0.81 mm Diameter Part A B C D E F Number Maximum Maximum Typical Minimum Maximum Typical FRX010-90F FRX015-90F FRX017-90F FRX020-90F FRX025-90F FRX030-90F FRX035-90F FRX040-90F FRX050-90F FRX055-90F FRX065-90F FRX075-90F FRX090-90F FRX110-90F FRX135-90F FRX160-90F FRX185-90F FRX250-90F FRX300-90F FRX375-90F 7.4 7.4 7.4 7.4 7.4 7.4 7.4 7.6 7.9 9.7 9.7 10.4 11.7 13.0 14.5 16.3 17.8 21.3 24.9 28.5 12.7 12.7 12.7 12.7 12.7 12.7 12.7 13.5 13.7 14.0 14.5 15.2 15.8 18.0 19.6 21.3 22.9 26.4 30.0 33.5 5.1 5.1 5.1 5.1 5.1 5.1 5.1 5.1 5.1 5.1 5.1 5.1 5.1 5.1 5.1 5.1 5.1 10.2 10.2 10.2 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.4 1.4 1.4 1.4 1.4 1.4 1.4 NOTE : Specification subject to change without notice. 2019/11/12 NO. FUZETEC TECHNOLOGY CO., LTD. Product Specification and Approval Sheet Version PQ16-101E 9 Page 3/4 5. Thermal Derating Curve Precent of Rated Hold and Trip Current FRX90V Series 200% 150% 100% 50% 0% -40 -20 0 20 40 60 80 Ambient Temperature (C) 6. Typical Time-To-Trip at 23℃ A B C D E FGH I J K L M NO PQ R S T 1000 100 Time-to-trip (S) A =FRX010-90F B =FRX015-90F C =FRX017-90F D =FRX020-90F E =FRX025-90F F =FRX030-90F G =FRX035-90F H=FRX040-90F I =FRX050-90F J =FRX055-90F K=FRX065-90F L =FRX075-90F M=FRX090-90F N =FRX110-90F O =FRX135-90F P =FRX160-90F Q =FRX185-90F R=FRX250-90F S =FRX300-90F T =FRX375-90F 10 1 0.1 0.01 0.001 0.1 1 10 100 Fault current (A) NOTE : Specification subject to change without notice. 2019/11/12 NO. FUZETEC TECHNOLOGY CO., LTD. Product Specification and Approval Sheet Version PQ16-101E 9 Page 4/4 7. Material Specification Lead material：FRX010-90F~FRX040-90F Tin plated copper clad steel, 24 AWG. FRX050-90F~FRX090-90F Tin plated copper, 24 AWG. FRX110-90F~FRX375-90F Tin plated copper, 20 AWG. Soldering characteristics: MIL-STD-202, Method 208E. Insulating coating:Flame retardant epoxy, meets UL-94V-0 requirement 8. Part Numbering and Marking System Part Numbering System Part Marking System FRX □ □ □ ─ □ □ F RoHS Compliant / Lead Free Voltage Rating Current Rating F9 RX75F 93AB F9 RX □ □ F Example Fuzetec Logo, 90V RoHS Compliant / Lead Free Part Identification Product Family □ □ □ □ Date Code/Lot Number Note: Font on Marking may look slightly different due to fine turnings of each Marking printer. NOTE : Specification subject to change without notice. 2019/11/12
