深圳市代禾铖电子有限公司
精密金属膜电阻器
METAL FILM RESISTORS
编号
DHC-R-01
版本
A
页次
第 1 页 共 7 页
承 认 书
客户名称:
精密金属膜电阻器
产品品名:
规格描述:
MF1/8W-5W ±1%
客户料号:
30K,2W,1%,100PPM/℃
备
注:
100Ω,1/4W,1%,100ppm/℃
2022-09-30
送样日期:
制造厂商:
核准
Approval
林学东
全系列承认
客户承认:
确认
Check By
邢兰兵
审核
Prepared By
核准
Approval
确认
Check By
审核
Prepared By
闵小江
公
公
司
司
章
章
联系方式:闵先生 15976878116
网址:http://www.gddaihec.com
ISO9001:2015
ROHS&REACH
1
深圳市代禾铖电子有限公司
精密金属膜电阻器
METAL FILM RESISTORS
编号
DHC-R-01
版本
A
页次
第 2 页 共 7 页
1. General Instruction
General Specifications
Normal Type
Rated Power
MF-0204
1/8W
MF-0207
1/4W
MF-0410
1/2W
MF-0414
1W
MF-0617
2W
MF-0718
3W
MF-0207S
1/4WS
MF-0410S
1/2WS
MF-0414S
1WS
MF-0617S
2WS
MF-0718S
3WS
MF-0925S
5WS
3.5 ± 1.0
1.7 ± 1.0
27±2.0
0.40±0.05
6.5 ± 1.0
2.3 ± 1.0
26±2.0
0.40±0.05
9.0 ± 1.0
3.2 ± 1.0
25±2.0
0.50±0.05
11 ± 1.0
4.5 ± 1.0
30±2.0
0.60±0.05
15 ± 1
5.0 ± 0.5
28±2.0
0.60±0.05
17 ± 1
6 ± 0.5
32±2.0
0.70±0.05
0204
0207
0410
0414
200
250
350
500
400
500
700
1000
0.1Ω-1MΩ
0.1Ω-1MΩ
0.1Ω-1MΩ
0.1Ω-1MΩ
100Ω-511KΩ 100Ω-511KΩ 100Ω-511KΩ 100Ω-51KΩ
0617
500
1000
0.1Ω-1MΩ
100Ω-51KΩ
0718
500
1000
0.1Ω-1MΩ
100Ω-51KΩ
Mini Type
Rated Power
Standard Dimensions (mm)
Body Length (L)
Body Diameter (D)
Lead Length (H) ± 2
Lead Diameter (d) ± 0.05
Electrical Specification
Din Size
Maximum Working Voltage (V)
Maximum Overload Voltage (V)
Resistance Range ( ±1%(F))
( ±0.5%(D))
*L esser of
P R o r m a x im u m w o r k i n g v o lta g e .
Operating Temperature. Range: -55℃~ +155℃.
S=Miniature Type. For Example:0207S the body size of 1/8W but with rated power of 1/4W.
The taping dimension other than the standard is also available as per our taping specifications.
The resistance range of lower than 10Ω and higher than 1MΩ and / or the tolerance is lower
than 0.5% are available on special request.
Color of Body: Normal
type is Blue.
Packaging: Taped / Box and Bulk.
Forming: P / M / MB / MK / F / FK1 / FK2 & FKK .
Standard: JIS-C-5202
Power Derating Curve
ISO9001:2015
ROHS&REACH
2
深圳市代禾铖电子有限公司
精密金属膜电阻器
METAL FILM RESISTORS
Power Load (%)
-55℃
100
编号
DHC-R-01
版本
A
页次
第 3 页 共 7 页
70℃
80
60
40
20
0
-60 -40
155℃
-20
0
20
40
60
80
100 120 140 160 180
Ambient Temperature(℃)
2. Performance Specifications
Characteristics
Standard
1.
Resistance
Temperature
Coefficient
(PPM/℃)
2.
Dielectric
Withstanding
Voltage
±100 PPM/℃
±50 PPM/℃
±25 PPM/℃
Test Methods
Natural resistance
centigrade.
change
per
temperature
degree
R 2 R1
10 6 (PPM/℃)
R1(T 2 T 1)
R1: Resistance value at reference temperature. (T1)
R2: Resistance value at reference temperature. (T2)
T1: Room Temperature
T2 : T1±100℃
Resistors shall be subjected to an approximately sinusoidal
test potential (as below) 60Hz applied between both
No evidence of flashover, terminals connected together and a 90° V-Block extending
mechanical damage or arcing beyond the end of the resistor.
or, insulation break down.
Resistor Wattage
DC Volts
1/8W (1/4WSi)
150
1/4W (1/2WS)
350
1/2W 1W,2W Above
600
3.
Solderability
90% Covered min.
The terminal lead shall be dipped into molten solder s at 3.2
to 4.8mm from the body of resistor. The temp. and time as
below:
a. 235±5℃ for 2±0.5 seconds
b. 270±10℃ for 2±0.5 seconds
No evidence of mechanical
damage
ΔR/R at ±0.5% Max
The terminal of the resistor is dipped into the molten solder
of 350±10℃ for 3±0.5 seconds. Then put the resistor in the
room temperature. For min.3 hours.
4.
Resistance to
Soldering
ISO9001:2015
ROHS&REACH
3
深圳市代禾铖电子有限公司
精密金属膜电阻器
METAL FILM RESISTORS
5.
Humidity Load Life
±1% Max/1000Hours
6.
Load Life
±1% Max /1000Hours
7.
编号
DHC-R-01
版本
A
页次
第 4 页 共 7 页
Resistance change after 1000 hours ( 1.5 hours on 0.5
hours off)at rated continuous working voltage in a humidity
chamber controlled at 40 ± 2 ℃ and 90~95% relative
humidity .
Permanent resistance change after 1000 hours operating
at rated continuous working voltage with a duly cycle of 1.5
hours on 0.5 hours off at 70 ± 2℃ ambient .
Resistance change after continuous five cycles for duty cycle
Temperature Cycling ±1% Max with no evidence as specified below.
of mechanical damage
Step
Temperature
Characteristics
Standard
Time
1
-30℃
30 Minutes
2
+25℃
10~15 Minutes
3
+85℃
30 Minutes
4
+25℃
10~15 Minutes
Test Methods
8.
Short Time
Overload
Δ R/R at ±0.5% Max. with no
evidence of arcing burning, or
charring
Permanent resistance change after the application of a
potential of 2.5 times rated continuous working voltage for
5 seconds at room temperature.
No evidence of mechanical
damage or loosening terminals
Direct load resistance to 2.5kg direct load 30±5 seconds
twist test, for axial leads unit only. Terminal lead shall be
bent through at a right angle at a point of 6.35mm from the
body edge of resistor and shall be rotated through at a
right angle about the original axis of the bent terminal in
alternating direction for a total 3 rotations.
9.
Terminal Strength
3. Marking
ISO9001:2015
ROHS&REACH
4
深圳市代禾铖电子有限公司
精密金属膜电阻器
METAL FILM RESISTORS
编号
DHC-R-01
版本
A
页次
第 5 页 共 7 页
4.Taping Dimension
Type
W±1.0
P±0.5
T±0.5
L1-L2
S
t
Z
T52
52
5
6
1.0 Max
3.2 Min
0.8 Max
1.2 Max
ISO9001:2015
ROHS&REACH
5
深圳市代禾铖电子有限公司
精密金属膜电阻器
METAL FILM RESISTORS
编号
DHC-R-01
版本
A
页次
第 6 页 共 7 页
F Type:
5.Packing
Taping Type:
Unit:mm/pcs
Type
T52
Watts
1/6W / 1/8W
1/4WS
1/4W/ 1/2WS
1/2W/ 1WS
1/16W
A
B
C
Q’ty
76
70
255
5000
76
100
255
5000
76
57
255
1000
ISO9001:2015
ROHS&REACH
6
深圳市代禾铖电子有限公司
精密金属膜电阻器
METAL FILM RESISTORS
编号
DHC-R-01
版本
A
页次
第 7 页 共 7 页
Bulk Type:
Unit:mm
Watts
A
B
C
1/8W,1/4W,1/2W
125
75
243
1W,2W,3W,5W
50
100
255
6.Part Number
MF - 0207 -
F
- 1000 -
F
1
3
-
5
-
2
1. Type
2. Power/Size
3. Tolerance
4. Value
5. Shape
-
4
-
MF = Metal Film Resistor
MFC = Metal Film Resistor and Lead Wire used Tinned copper Wire
Type
Power
0204
1/8W
Code
%
R15
Value
0.15Ω
Type
0207
1/4W
1/4W
F
±1%
E96
Code
0207s
1R54
1.54Ω
T
Taping
P
P Type
0410S
1/2W
0410
……
1/2W
……
D
±0.5%
1540
0925
5W
B
±0.1%
1541
1542
1543
154Ω
1.54KΩ
15.4KΩ
154KΩ
M
MB
MK
F
M
forming
MB
forming
MK
forming
F
forming
1544
1.54MΩ
1545
1546
15.4MΩ
154MΩ
FK1
FK2
FKK
FK1
forming
FK2
forming
FKK
forming
ISO9001:2015
ROHS&REACH
7
