Confidential
Customer Name :
Customer P/N
:
Frequency
:
Aker Approved P/N:
Aker MPN
:
Rev.
:
ISSUE DATE
MHz
24.000000
CXAF-024000-3-AL-25
CXAF-024000-3-AL-25
1
: Nov.23.2022
APPROVED
CHECKED
Xtal
PREPARED
Kiku
APPROVED BY CUSTOMER
AKER TECHNOLOGY CO., LTD.
ADDRESS : NO 11-3, Jianguo Rd., Tanzi Dist., Taichung City 427, Taiwan.
TEL:886-4-25335978
Web: www.aker.com.tw
FAX : 886-4-25336011
MSL:Level 1
RoHS compliant
IATF 16949 Certified
AEC-Q200 Qualified
Aker Approved P/N :
APPROVED
:
PREPARED
:
CXAF-024000-3-AL-25
SHEET : 1 of 8
Xtal
REV . : 1
Kiku
Confidential
Rev.
Date
Reviser
Revise contents
1
2022/11/23
Kiku
Initial Released
Aker Approved P/N :
APPROVED
:
PREPARED
:
CXAF-024000-3-AL-25
SHEET : 2 of 8
Xtal
REV . : 1
Kiku
Confidential
SMD CRYSTAL SPECIFICATION
1 . ELECTRICAL CHARACTERISTICS
Standard atmospheric conditions
Unless otherwise specified , the standard range of atmospheric conditions for making measurement
and tests are as follow :
Ambient temperature : 25±5℃
Relative humidity
: 40%~70%
If there is any doubt about the results , measurement shall be made within the following limits :
Ambient temperature : 25±3℃
Relative humidity
: 40%~70%
AKER Model : CXAF-321
Oscillation Mode : Fundamental
Cutting Mode : AT CUT
Measurement Equipment : 250B(Measured FL)
Insulation Resistance : More than 500M ohms at DC 100V
Electrical Spec
Parameters
Nominal Frequency
Symbol
Min.
FL
Typ.
Max.
24.000000
Notes
Units.
MHz
Frequency Tolerance
±10
ppm at 25℃ ± 3℃
Frequency Stability
±30
ppm -40~85℃ (Refer 25℃)
Frequency Stability
±80
ppm -40~125℃ (Refer 25℃)
Load Capacitance
CL
8
Aging
pF
±3
ppm First Year
Operating Temperature
-40
~
125
℃
Storage Temperature Range
-55
~
125
℃
Drive Level
DL
100
uW
Equivalent Series Resistance
ESR
50
Ω
C0
3
pF
Shunt Capacitance
@Series
*Please kindly be noted that AKER DO NOT guarantee parts quality which involves human security application.*
Aker Approved P/N :
APPROVED
:
PREPARED
:
CXAF-024000-3-AL-25
SHEET : 3 of 8
Xtal
REV . : 1
Kiku
Confidential
2 . MARKING :
Type I
24.0
AK Ay
AKER LOGO.
FREQUENCY code
Date Code:Please refer to the following table.
Internal identification code 1
Type II
24.0 C
AK Ay
AKER LOGO.
FREQUENCY code & Internal identification code 1
Date Code:Please refer to the following table.
Internal identification code 2
Date Code Table
3 . DIMENSION :
( Unit : mm )
Aker Approved P/N :
APPROVED
:
PREPARED
:
CXAF-024000-3-AL-25
SHEET : 4 of 8
Xtal
REV . : 1
Kiku
Confidential
4 . STRUCTURE ILLUSTRATION
A
C
B
D
G
N
I
K
R
A
M
E
Aker Approved P/N :
APPROVED
:
PREPARED
:
CXAF-024000-3-AL-25
SHEET : 5 of 8
Xtal
REV . : 1
Kiku
Confidential
5 . PACKING :
TAPE SPECIFICATION
( Unit : mm )
Feeding
180 ± 3
( Unit : mm )
60.5 ± 2
OUTLINE DIMENSION
13.2
9 ± 1.0
12 ± 1.5
2.5
Aker Approved P/N :
APPROVED
:
PREPARED
:
6. COVER TAPE ADHESION STRENGTH:
7 . SOLDERING REFLOW PROFILE
CXAF-024000-3-AL-25
SHEET : 6 of 8
Xtal
REV . : 1
Kiku
Confidential
Aker Approved P/N :
APPROVED
:
PREPARED
:
CXAF-024000-3-AL-25
SHEET : 7 of 8
Xtal
REV . : 1
Kiku
Confidential
8. PACKING :
185mm
183mm
36mm
BOX = 3000 PCS / REEL(MAX)
Stuff
210mm
625mm
390mm
SMD product packs 32 BOX=The outside box packs (3000 PCS *32 BOX = 96000 PCS)(MAX)
Aker Approved P/N :
APPROVED
:
PREPARED
:
CXAF-024000-3-AL-25
SHEET : 8 of 8
Xtal
REV . : 1
Kiku
Confidential
9 . MECHANICAL PERFORMANCE
TEST ITEMS
9.1 Temperature
Cycling
TEST METHODS AND TEST CONDITION
PERFORMANCE
-55±3℃/30min maximum~+125±3℃/30min maximum,
1000cycles
9.2 Operational Life 125℃±3°C,1000hrs±12hrs
9.3 Biased Humidity 85°C±5°C&85%±5%R.H.,1000±12hrs
9.4 Resistance To
Soldering Heat
Test
Reflow test 2 times.
9.5 High
Temperature
Exposure
150℃±3°C,1000hrs±12hrs
9.6 Vibration Test
Freq.range: 10~2000Hz,Peak to peak amplitude:1.52mm
Peak acceleration:5G (49m/s2),3 direction(X, Y,Z)
,20min 12cycles each of 3 orientations.
9.7 Mechanical
Shock
100G,6mS,3 times for each direction(X, Y, Z ),
3 cycles
9.8 Physical
Dimension
Verify physical dimensions to the applicable device
detail specification.
9.9 Solderability
260℃,Coated > 95%
9.10 Board Flex
PCB=100*40(mm),Bending=2 mm (min),
Duration=60+5/-0 sec
9.11 External Visual Inspect device construction and marking.
9.12 Terminal
Strength
A force of 17.7N for 60 seconds.
To satisfy the electrical
performance .
