CAS-D20A1

SLIDE SWITCHES (SMD) RoHS compliant CAS INTERNAL STRUCTURE ① ② ⑤ ③ ⑥ ④ Part name Material ■ FEATURES ① Cover Polyphenylenesulphide ● RoHS compliant ● Compatible with most automatic pick & place machinery ● Compact and space saving SMD type ● Excellent contact stability by twin Gold-plated contact ● Low profile design of 2.5 mm ② Slider Polyamide ③ Housing ④ Slider contact ⑤ Fixed contact ⑥ Terminal pin Flammability UL94V-0 Polyphenylenesulphide Copper alloy, Gold-plated ■ PART NUMBER DESIGNATION C A S - 1 2 0 T B 1 Series name No. of poles 1：(SPDT)　1 pole、2：(2PDT)　2 poles D：(Dual SPDT)　Dual Structure 1：Non-washable type (Without seal tape) Standard type 2：Non-washable type (With seal tape) Blank : Washable type (With seal tape) No. of contacts 2：2 contacts Setting position 0：Top setting Form of packaging T：Taping (Reel) Blank：Bulk in plastic bag SPDT : Single Pole Double Throw　　2PDT : Two Poles Double Throw ※ Please refer to the LIST OF PART NUMBERS when placing orders. Shape of terminal A：J-hook B：Gull wing — CAS SLIDE SWITCHES (SMD) ■ LIST OF PART NUMBERS No. of poles No. of contacts Setting position Form of packaging Non-washable type (Without seal tape) J-hook A (　　　　) Non-washable type (With seal tape) Gull wing ) A (　　　　) J-hook B(　　　　　　 Gull wing ) B(　　　　　　 Pieces in package Taping CAS-120TA1 CAS-120TB1 CAS-120TA2 CAS-120TB2 1000pcs./reel Plastic bag CAS-120A1 CAS-120B1 CAS-120A2 CAS-120B2 100pcs./pack Taping CAS-220TA1 CAS-220TB1 CAS-220TA2 CAS-220TB2 1000pcs./reel Plastic bag CAS-220A1 CAS-220B1 CAS-220A2 CAS-220B2 100pcs./pack Taping CAS-D20TA1 CAS-D20TB1 CAS-D20TA2 CAS-D20TB2 1000pcs./reel Plastic bag CAS-D20A1 CAS-D20B1 CAS-D20A2 CAS-D20B2 100pcs./pack 1 2 2 Top setting Dual No. of poles No. of contacts Setting position Form of packaging Washable type (With seal tape) J-hook A (　　　　) Gull wing ) B(　　　　　　 Pieces in package Taping CAS-120TA CAS-120TB 1000pcs./reel Plastic bag CAS-120A CAS-120B 100pcs./pack Taping CAS-220TA CAS-220TB 1000pcs./reel Plastic bag CAS-220A CAS-220B 100pcs./pack Taping CAS-D20TA CAS-D20TB 1000pcs./reel Plastic bag CAS-D20A CAS-D20B 100pcs./pack 1 2 2 Top setting Dual ※ Verify the above part numbers when placing orders. Taping version can be supplied only in reel unit. CAS SLIDE SWITCHES (SMD) ■ STANDARD SPECIFICATIONS Operating temp. range Storage temp. range Sealing Net weight ■ ELECTRICAL CHARACTERISTICS Contact rating Non-switching Switching Minimum − 40 ~ 85 °C Washable type available with seal tape Contact resistance Approx. 0.05g (CAS-120) Approx. 0.08g (CAS-220/D20) Insulation resistance Dielectric strength ■ MECHANICAL CHARACTERISTICS Operating force DC50 V 100 mA DC6 V, 100 mA DC24 V, 25 mA DC20 mV 1 μ A 50 m Ω maximum 1000 M Ω (DC100 V) minimum AC500 V, 60 s ■ ENVIRONMENTAL CHARACTERISTICS 0.5 ~ 5 N {0.05 ~ 0.51 kgf} Vibration (Amplitude) 1.5 mmor (Acceleration) 98 m/s2, 10-500 Hz, 3 directions for 10 cycles each Stop strength 10 N {1.02 kgf}, 60 s Shock 490 m/s2, 11 ms 6 directions for 3 times each Solderability 245 ± 3 °C, 2 ~ 3 s Load life Continuous load 2000 cycles, DC6 ± 0.5 V, 100 ± 10 mA Reflow：255 °C (Peak temperature) （Please refer to the profile below） Humidity Soldering heat − 10 ~ 65 °C, Relative humidity 0 ~ 96 %, 24 h for 10 cycles Manual soldering：350 ± 10 °C, 3 ~ 4 s High temp. exposure 85 °C, 96 h Shear (Adhesion) 5 N {0.51 kgf} 10 s Low temp. exposure − 40 °C, 96 h Substrate bending Width 90 mm, bend 3 mm, 5 s, 1 time Pull-off strength Thermal shock 5 N {0.51 kgf} 10 s { } : Reference only 〈Reflow profile for soldering heat evaluation〉 Temperature (℃) 250 200 150 100 50 Peak : 250 +5 0 ℃ Over 230 ℃ 180 ℃ 150 ℃ Pre Heating Zone 90 ± 30 s 30 ± 10 s Heating time Soldering Zone Reflow : two times maximum − 40 (0.5 h) ~ 85 °C (0.5 h), 5 cycles CAS SLIDE SWITCHES (SMD) ■ OUTLINE DIMENSIONS Unless otherwise specified, tolerance : ± 0.3 (Unit : mm) ● CAS-120A1 ● CAS-120B1 3 – 0.6 +0.1 –0.05 C ② Production date code 2.5 2.5 max. ● CAS-220A1 0.4 min. 3.5 Production date code 6 – 0.6 +0.1 –0.05 C ④ ⑤ ⑥ Production date code 5.4 Stroke 0.6 0 0.1 –0.1 2.5 0.15 +0.1 –0.05 2.5 max. 0.15 +0.1 –0.05 1.75 ● CAS-D20A1 1.75 1.75 0.4 min. 0.4 min. ● CAS-D20B1 6 – 0.6 +0.1 –0.05 Production date code 6 – 0.6 +0.1 –0.05 C ④ ⑤ ⑥ Production date code 5.4 Stroke 0.6 5.6 3.9 2.5 0.15 +0.1 –0.05 0 0.1 –0.1 0.15 +0.1 –0.05 2.5 max. 0.3 0.3 5 0. 5 0. Terminal No.1 4.2 +0.3 0 3.9 ① ② ③ C Schematic C C 2.5 max. – – 1.75 C ④ ⑤ ⑥ 2 2 ① ② ③ C Schematic 5.4 Stroke 0.6 0.1 5.6 3.9 0.3 0.3 2.5 max. 0 0.1 –0.1 5 5 0. 0. Terminal No.1 4.2 +0.3 0 3.9 ① ② ③ C Schematic C C – – ① ② ③ C Schematic 5.4 Stroke 0.6 0 –0.1 C ④ ⑤ ⑥ 2 2 Terminal No.1 1.75 0.4 min. ● CAS-220B1 –0.05 6 – 0.6 +0.1 Terminal No.1 0.15 +0.1 –0.05 0.3 4.2 Stroke 0.6 0.15 +0.1 –0.05 0.3 2.5 max. 0 0.1 –0.1 5 5 5.4 2.5 1.1 ③ Schematic 2.8 +0.3 0 3.5 1.75 ① 0. 0. Schematic Terminal No.1 C C 5.4 Stroke 0.6 ③ 2– ① 2– Terminal No.1 C ② Production date code 0 0.1 –0.1 3 – 0.6 +0.1 –0.05 1.75 1.75 0.4 min. 0.4 min. CAS SLIDE SWITCHES (SMD) 3 –1 1.3 3 –1 3 –1 1.3 3 –1 1.6 1.6 ■ RECOMMENDED P.C.B. PAD OUTLINE DIMENSIONS ● CAS-120 2.6 1.3 1.3 2.6 3.5 3.5 1.3 2.6 3.50 2.6 1.3 1.6 0.7 0.7 1.6 3.5 0 0 0 3.5 1.3 3.5 0 1.3 1.6 3.5 0 3 –1 B type 3 –1 0 1.6 1.6 0.7 3 –1 0 0.7 1.6 A type (Unit : mm) 3 –1 3.5 ● CAS-220 • D20 0 1.75 1.75 6 –1 1.3 1.3 6 –B 1 type 6 –1 0 0 1.75 1.75 0 6 –1 1.3 4 0 4 1.3 1.75 0 6 –1 1.62.1 6 –1 4 1.3 1.6 6 –1 1.3 4 6 –1 2.11.6 2.11.6 1.62.1 1.6 A type 0 1.75 1.75 0 1.75 1.75 1.75 1.75 1.3 1.75 1.3 1.75 1.6 1.6 Note) The zero point is the center of mounting. 1.75 1.75 1.75 CAS SLIDE SWITCHES (SMD) ■ PACKAGING SPECIFICATIONS ● Taping version is packaged in 1000 pcs. per reel. Orders will be accepted for units of 1000 pcs., i.e., 1000, 2000, 3000 pcs., etc. ● Taping version is boxed with two reels (2000 pcs.). Maximum number of consecutive missing pieces=2 Leader length and reel dimension are shown in the diagrams below: ● Embossed tape dimensions ● Reel dimensions (Unit: mm) (Conforms to JIS C 0806-3) 17.4±1 Empty Filled φ 13±0.2 End 2±0.5 φ 254±2 φ 50 min. Empty Head 40 mm min. 20 pitches min. Leader 400 mm min. Direction of feed φ 21±0.8 21.4±1 ● CAS-120TA, TB ● CAS-220TA, TB • D20TA, TB (Unit: mm) φ 1.5 +0.1 0 Terminal No.1 2 ± 0.1 7.5 ± 0.1 （CAS-120B1） Installation example 8 ± 0.1 4 ± 0.1 1.75 ± 0.1 0.3 ± 0.1 0.3 ± 0.1 （CAS-D20B1） Installation example 16 2 ± 0.1 7.5 ± 0.1 8 ± 0.1 4 ± 0.1 16 φ 1.5 +0.1 0 1.75 ± 0.1 (Conforms to JIS C 0806-3) (In accordance with EIAJ ET-7200A) Terminal No.1 Direction of feed 3 ● Boxing of bulk pack in a plastic bag is performed with 100 pcs. (standard 500 pcs.) per box. Direction of feed 3 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Nidec: CAS-120TA1 CAS-220TA1 CAS-220TB1 CAS-220TB2 CAS-D20TA1 CAS-D20TA2 CAS-D20TB CAS-D20TB1 CAS-D20TB2 CAS-120TB1 CAS-120TB2 CAS-120A1 CAS-220B CAS-D20B CAS-120B1 CAS-220TA CAS220TB CAS-120A CAS-120TA CAS-D20TA CAS-120TB CAS-120B CAS-220A2 CAS-D20B1 CAS-D20A1 CAS220A1 CAS-220B1 CAS-120A2 CAS-120B2 CAS-120TA2 CAS-220A CAS-220B2 CAS-220TA2 CAS-D20A CASD20A2 CAS-D20B2
