2405-6232TB

.100″ and .100″  .100″ Pin Strip Header Straight & Right Angle, Solder Tail 2400 Series S One and two row versions S Straight and right angle versions S Break to length for faster delivery, lower inventory costs, and faster prototyping S Tapered tip does not cut the socket wipe during insertion, reducing operational failures and repairs S Solder standoffs facilitate wash of flux residue, reducing costly rework S Board pin retention feature available Date Modified: December 28, 1999 14 TS-0767-03 Sheet 1 of 3 Physical Insulation Material: Flammability: Color: Contact Material: Plating Underplate: Wiping Area: Solder Tails: Glass Filled Polyester (PBT) UL 94V-0 Gray Copper Alloy 100 µ″ [ 2.54 µm ] Nickel — QQ-N-290, Class 2 30 µ″ [ 0.76 µm ] Gold — MIL-G-45204, Type II, Grade C 200 µ″ [ 5.08 µm ] 90/10 Tin Lead — MIL-P-81728 Electrical Current Rating: 3 A Insulation Resistance: > 1 × 109 Ω at 500 Vdc Withstanding Voltage: 1000 Vrms at Sea Level Environmental Temperature Rating: –55°C to +105°C UL File No.: E68080 3M Interconnect Solutions Division 6801 River Place Blvd. Austin, TX 78726-9000 For technical, sales or ordering information call 800-225-5373 .100″ and .100″  .100″ Pin Strip Header Straight & Right Angle, Solder Tail Straight C +.020 –.005 (See note 1) .096 [2.44] .04 [1.0] .100 [2.54] .048 [1.22] .048 [1.22] 2400 Series Pin Quantity One Row 01 02 03 04 05 06 07 08 04 06 08 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52 54 56 58 60 62 64 66 68 70 72 74 76 78 80 Two Row Dimension C 0.09 [ 2.3] 0.19 [ 4.8] 0.29 [ 7.4] 0.39 [ 9.9] 0.49 [12.4] 0.59 [15.0] 0.69 [17.5] 0.79 [20.1] 0.89 [22.6] 0.99 [25.1] 1.09 [27.7] 1.19 [30.2] 1.29 [32.8] 1.39 [35.3] 1.49 [37.8] 1.59 [40.4] 1.69 [42.9] 1.79 [45.5] 1.89 [48.0] 1.99 [50.5] 2.09 [53.1] 2.19 [55.6] 2.29 [58.2] 2.39 [60.7] 2.49 [63.2] 2.59 [65.8] 2.69 [68.3] 2.79 [70.9] 2.89 [73.4] 2.99 [75.9] 3.09 [78.5] 3.19 [81.0] 3.29 [83.6] 3.39 [86.1] 3.49 [88.6] 3.59 [91.2] 3.69 [93.7] 3.79 [96.3] 3.89 [98.8] 3.98 [101.1] ® ® .100 [2.54] A  .008 A  .008 09 10 11 12 .100 [2.54] B  .010 .04 [1.0] .015 ± .002 [ 0.38 ] .196 [4.98] R .0075 Ref [ 0.190 ] B  .008 13 14 15 16 17 18 19 20 .028 ± .001 [ 0.71 ] C +.020 – .005 (See Note 1) .0245 ± .0005 [ 0.622 ] 21 22 23 24  .035  .003 [0.89] (See Note 2) .100  .003 [2.54] .100  .003 [2.54] Pin Cross Section 25 26 27 28 29 ∅ .035 ± .003 [0.89 ] (See Note 2) Inch [mm] Tolerance Unless Noted 30 31 32 33 34 35 36 37 38 39 40 .100 ± .003 Typ [ 2.54 ] .0 Inch [ .00 .000 ± .1 ± .01 ± .005 Recommended Mounting Hole Pattern ] Dimensions for Reference Only Notes; 1. This part is molded in the 40 contact quantity version. Parts that require fewer contacts are broken to length. Dimension “C” is measured from a “Molded End” to the “Center of the Break Point” beyond the desired quantity. On Pin Strips, which have break points on both ends, “C” = .100″ x contact quantity per row. 2. The recommended PCB hole size for the kinked tail positions on the .112″ solder tail connector is .035″ ± .002. Refer to TS-0971 for the number of tails kinked and the position kinked. Ordering Information Pin Quantity: (See Table) One Row (01–40) Two Row (04–80) Pin Length (Dim A) 1 = .235″ 2 = .318″ 24XX-6XXXTB Tail (Dim B) One Row 12=.112″ Solder Tails 13=.155″ Solder Tails 32=.112″ Kinked Solder Tails Two Row 22=.112″ Solder Tails 23=.155″ Solder Tails 72=.112″ Kinked Solder Tails TS-0767-03 Sheet 2 of 3 3M Interconnect Solutions Division 6801 River Place Blvd. Austin, TX 78726-9000 For technical, sales or ordering information call 800-225-5373 .100″ and .100″  .100″ Pin Strip Header Straight & Right Angle, Solder Tail Right Angle .04 [1.0] C +.020 –.005 (See Note 1) 2400 Series Pin Quantity One Row 01 Two Row 02 04 06 08 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52 54 56 58 60 62 64 66 68 70 72 74 76 78 80 Dimension C 0.09 [ 2.3] 0.19 [ 4.8] 0.29 [ 7.4] 0.39 [ 9.9] 0.49 [12.4] 0.59 [15.0] 0.69 [17.5] 0.79 [20.1] 0.89 [22.6] 0.99 [25.1] 1.09 [27.7] 1.19 [30.2] 1.29 [32.8] 1.39 [35.3] 1.49 [37.8] 1.59 [40.4] 1.69 [42.9] 1.79 [45.5] 1.89 [48.0] 1.99 [50.5] 2.09 [53.1] 2.19 [55.6] 2.29 [58.2] 2.39 [60.7] 2.49 [63.2] 2.59 [65.8] 2.69 [68.3] 2.79 [70.9] 2.89 [73.4] 2.99 [75.9] 3.09 [78.5] 3.19 [81.0] 3.29 [83.6] 3.39 [86.1] 3.49 [88.6] 3.59 [91.2] 3.69 [93.7] 3.79 [96.3] 3.89 [98.8] 3.98 [101.1] .119 [3.02] ® ® .045 ± .002 B  .010 [ 1.14 ] .100 [2.54] .071 [1.80] 02 03 R .0075 Ref [0.190] 04 05 06 .0245 ± .0005 [ 0.622 ] 07 .028 ± .001 [ 0.71 ] 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 A  .008 .100 [2.54] Pin Cross Section .07 [1.8] C +.020 – .005 (See Note 1) .045 ± .002 [ 1.14 ] ∅ .035 ± .003 [ 0.89 ] ( See Note 2 ) .100  .003 [2.54] .219 [5.56] .100  .003 [2.54] ∅ .035 ± .003 [0.89 ] (See Note 2) .100 ± .003 Typ [ 2.54 ] .100 [2.54] .071 [1.80] A  .008 B  .010 .04 [1.0] .100 [2.54] .100 [2.54] Recommended Mounting Hole Pattern 27 28 29 30 31 32 33 34 35 36 37 38 39 40 .07 [1.8] .100 [2.54] Inch Notes: 1. This part is molded in the 40 contact quantity version. Parts that require fewer contacts are broken to length. Dimension “C’’ is measured from a ‘‘Molded End’’ to the ‘‘Center of the Break Point’’ beyond the desired quantity. On Pin Strips, which have break points on both ends, ‘‘C’’ = .100″ x contact quantity per row. 2. The recommended PCB hole size for the kinked tail positions on the .112″ solder tail connector is .035″ ± .002. Refer to ts–0971 for the number of tails kinked and the position kinked. [mm] Tolerance Unless Noted .0 Inch ± .1 .00 .000 ± .01 ± .005 [ ] Dimensions for Reference only Ordering Information Pin Quantity: (See Table) One Row (01-40) Two Row (02–80) 24XX-5XXXTB Pin Length (Dim A) 1 = .235″ 2 = .318″ Tail (Dim B) One Row 12=.112″ Solder Tails 13=.155″ Solder Tails 32=.112″ Kinked Solder Tails Two Row 22=.112″ Solder Tails 23=.155″ Solder Tails 72=.112″ Kinked Solder Tails TS-0767-03 Sheet 3 of 3 3M Interconnect Solutions Division 6801 River Place Blvd. Austin, TX 78726-9000 For technical, sales or ordering information call 800-225-5373
