78-9100-7556-9

3M™ Sample Development Design Kits for High Speed 94XX Series Cabling and Connectors • 9401-9404 2 MM SCI Design Kits • SCI Cable Assemblies and Corresponding Boardmount Headers Purpose • Assist designers in evaluating signal integrity performance of 3M SCI cable assemblies — Eye Patterns — Crosstalk (Near end & Far end) — Attenuation • Support component engineers in technical specification development Date Modified: October 1, 2008 TS-2298-B Sheet 1 of 3 Physical See TS-2199 and TS-2105 Electrical See TS-2199 and TS-2105 Signal Data shown in white paper 2 mm High Speed Cable Assembly Environmental See TS-2199 and TS-2105 3 Electronic Solutions Division Interconnect Solutions http://www.3M.com/interconnects/ 3M and MetPak are trademarks of 3M Company. For technical, sales or ordering information call 800-225-5373 3M™ Sample Development Design Kits for High Speed 94XX Series Cabling and Connectors 9401 Sample Development Kit for 2 mm SCI Surface Mount Header without PCB Test Board Contents Qty 1 1 3 3 1 1 Description 2 x 25 Carrier 2 x 25 L/E Header-SMT 24 Inch Double-ended Twin-Ax Assy 24 Inch Double-ended Coax Assy White Paper Development Kit Instructions, 2 mm High Speed Cable Assembly Part Number (ref) 9350 155250-2400-RB 98-3030-058-024.0-0 98-2929-027-024.0-0 78-9100-7515-5 78-9100-7516-3 Tech Sheet TS-2105 TS-2199 TS-2105 TS-2105 N/A N/A 9402 Sample Development Kit for 2 mm SCI Surface Mount Header with PCB Test Board Contents Qty 1 1 3 3 1 1 Description 2 x 25 Carrier PCB with SMT 2 x 25 Header2 24 Inch Double-Ended Twin-Ax Assy 24 Inch Double-Ended Coax Assy White Paper Development Kit Instructions, 2 mm High Speed Cable Assembly Part Number (ref) 9350 78-9100-7555-1 98-3030-058-024.0-0 98-2929-027-024.0-0 78-9100-7515-5 78-9100-7516-3 Tech Sheet TS-2105 TS-2199 TS-2105 TS-2105 N/A N/A 9403 Sample Development Kit for 2 mm SCI Through-Hole Header without PCB Test Board Contents Qty 1 1 3 3 1 1 Description Part Number (ref) 2 x 25 L/E Header-TH 24 Inch Double-Ended Twin-Ax Assy 24 Inch Double-Ended Coax Assy White Paper Development Kit Instructions, 2 mm High Speed Cable Assembly Part Number (ref) 9350 155250-6402-RB 98-3030-058-024.0-0 98-2929-027-024.0-0 78-9100-7515-5 78-9100-7516-3 Tech Sheet TS-2105 TS-2199 TS-2105 TS-2105 N/A N/A 9404 Sample Development Kit for 2 mm SCI Through-Hole Header with PCB Test Board Contents Qty 1 1 3 3 1 1 Description Part Number (ref) PCB with TH 2 x 25 Header2 24 Inch Double-ended Twin-Ax Assy 24 Inch Double-ended Coax Assy White Paper Development Kit Instructions, 2 mm High Speed Cable Assembly Part Number (ref) 9350 78-9100-7556-9 98-3030-058-024.0-0 98-2929-027-024.0-0 78-9100-7515-5 78-9100-7516-3 Tech Sheet TS-2105 TS-2199 TS-2105 TS-2105 N/A N/A TS-2298-B Sheet 2 of 3 3 Electronic Solutions Division Interconnect Solutions http://www.3M.com/interconnects/ 3M and MetPak are trademarks of 3M Company. For technical, sales or ordering information call 800-225-5373 3M™ Sample Development Design Kits for High Speed 94XX Series Cabling and Connectors Test Board - SMT Header Test Board-TH Header TS-2298-B Sheet 3 of 3 3 Electronic Solutions Division Interconnect Solutions http://www.3M.com/interconnects/ 3M and MetPak are trademarks of 3M Company. For technical, sales or ordering information call 800-225-5373
