ACT-SMPV-6

Tel : Fax : email : 0044 (0)118 979 1238 0044 (0)118 979 1283 info@actcrystals.com ACT-SMPV - 6 Surface Mount VCXO The ACTSMPV6 is a 6-pad surface mount Voltage Controlled Crystal Oscillators (VCXO) housed in a 14.0X10.3 mm PCB based package with a metal lid. These devices can be pulled between ±30ppm & ±100ppm from the nominal frequency by varying the voltage on pin 1(Dependent on Vdd). Outputs are available in PECL (5V Vdd), LVPECL and LVDS (3.3V Vdd). Applications include PLL circuits, Set Top Box, MP3 Players, Audio/Video modulations, Video Game Consoles, HDTV and many more. Specification Parameter Frequency Range Frequency Stability Temp Operating Range Storage Temp Range Supply Voltage Supply Current Voltage Control Output Output Load Output Voltage Symbol fo Δf/fo Topr Tstg Vdd Iop Vc N/CL VOH VOL Tw/t Δfc Specification Condition Duty Cycle Pulling Range Jitter tr/tf Rise & Fall Times Linearity Slope Polarity Modulation Bandwidth(±3dB) Input Impedance Aging Phase Noise Fa 19.44~180MHz @ 25±5°C std (Some higher frequencies available) Please Specify ±20ppm~±100ppm std (Some tighter stabilities available) Please Specify Please Specify 0~70°C Standard, -40~+85°C Option -55~+125°C 5.0V±5% 3.3V±5% Please Specify 80mA max 120mA max 1.65Vdc±1.65V 2.5Vdc±2.0V LVDS LVPECL PECL 100Ω Diff Vdd -2V to 50Ω Vdd -1.025Vdc min 1.375Vdc min 1.125V max Vdd -1.620Vdc min Please Specify 40/60% Standard, 45/55% Option ±30ppm~±100ppm 3.5ps RMS max 2nS max 20% to 80% of Waveform ±10% max Positive 10KHz min 50KΩ ±3ppm/yr See Phase Noise example on Page 2 DIMENSIONS (mm) Pin Connection #1 #2 #3 #4 #5 #6 V control Tri-State or N./C Ground Output Complementary Output Vdd Pad surface material Au Please note that all parameters can not necessarily be specified in the same device Customer to specify : Frequency, Frequency Tolerance, Operating Temperature Range, Supply Voltage, Output & Symmetry In line with our ongoing policy of product evolvement and improvement, the above specification may be subject to change without notice ISO9001:2000 Registered For quotations or further information please contact us at: 3 The Business Centre, Molly Millars Lane, Wokingham, Berkshire, RG41 2EY, UK Issue 2 D2 Date: 2/08/05 http://www.actcrystals.com 1 of 3 Tel : Fax : email : 0044 (0)118 979 1238 0044 (0)118 979 1283 info@actcrystals.com ACT-SMPV - 6 Surface Mount VCXO Example Phase Noise (120 MHz) In line with our ongoing policy of product evolvement and improvement, the above specification may be subject to change without notice ISO9001:2000 Registered For quotations or further information please contact us at: 3 The Business Centre, Molly Millars Lane, Wokingham, Berkshire, RG41 2EY, UK Issue 2 D2 Date: 10/08/05 http://www.actcrystals.com 2 of 3 Tel : Fax : email : 0044 (0)118 979 1238 0044 (0)118 979 1283 info@actcrystals.com ACT-SMPV - 6 Surface Mount VCXO Tape and Reel Dimensions (mm) REELS OF 500PCS A 10.8 B 14.8 C 1.5 D 11.5 E 5.5 F 4.0 G 8.0 H 24 J 330 K 13 L 23 M 60 Qty/Reel 500 In line with our ongoing policy of product evolvement and improvement, the above specification may be subject to change without notice ISO9001:2000 Registered For quotations or further information please contact us at: 3 The Business Centre, Molly Millars Lane, Wokingham, Berkshire, RG41 2EY, UK Issue 2 D2 Date: 10/08/05 http://www.actcrystals.com 3 of 3
