APTDF400KK60G

APTDF400KK60G Dual Common Cathode diodes Power Module VRRM = 600V IC = 400A @ Tc = 80°C Application A1 • • • • K Uninterruptible Power Supply (UPS) Induction heating Welding equipment High speed rectifiers Features • • • • • • A2 • Ultra fast recovery times Soft recovery characteristics High blocking voltage High current Low leakage current Very low stray inductance - Symmetrical design - M5 power connectors High level of integration Benefits K • A2 • • • • • Outstanding performance at high frequency operation Low losses Low noise switching Direct mounting to heatsink (isolated package) Low junction to case thermal resistance RoHS Compliant Absolute maximum ratings Symbol VR VRRM IF(A V) Parameter Maximum DC reverse Voltage Maximum Peak Repetitive Reverse Voltage Maximum Average Forward Duty cycle = 50% Current IF(RMS) IFSM RMS Forward Current Duty cycle = 50% Non-Repetitive Forward Surge Current 8.3ms TC = 25°C TC = 80°C TC = 45°C TC = 45°C Max ratings Unit 600 V 500 400 500 3000 A These Devices are sensitive to Electrostatic Discharge. Proper Handing Procedures Should Be Followed. See application note APT0502 on www.microsemi.com www.microsemi.com 1-4 APTDF400KK60G – Rev 1 June, 2006 A1 APTDF400KK60G All ratings @ Tj = 25°C unless otherwise specified Symbol Characteristic VF Diode Forward Voltage IRM Maximum Reverse Leakage Current CT Junction Capacitance Dynamic Characteristics Symbol Characteristic trr Reverse Recovery Time trr Reverse Recovery Time Qrr Reverse Recovery Charge IRRM Reverse Recovery Current trr Qrr IRRM Reverse Recovery Time Reverse Recovery Charge Reverse Recovery Current Test Conditions IF = 400A IF = 800A IF = 400A Tj = 125°C Tj = 25°C VR = 600V Tj = 125°C Min IF = 400A VR = 400V Min Tj = 25°C 34 Tj = 25°C Tj = 125°C Tj = 25°C 160 220 1.16 Tj = 125°C Tj = 25°C 6.12 20 Tj = 125°C 52 Tj = 125°C di/dt = 4000A/µs Thermal and package characteristics Symbol RthJC VISOL TJ TSTG TC Characteristic Junction to Case Thermal Resistance Min RMS Isolation Voltage, any terminal to case t =1 min, I isol
