ATWINC1500-XSTK

WINC1500-XPRO WINC1500 Xplained Pro User's Guide Description The WINC1500-XPRO is an extension board to evaluate the performance of the ATWINC15x0-MR210xB ® IoT (Internet of Things) module that supports an IEEE 802.11 b/g/n standard. The WINC1500 Xplained ® Pro extension board is designed to provide Wi-Fi functionality in the 2.4 GHz ISM band to the Xplained Pro evaluation platform. This kit provides access to the features of the ATWINC15x0-MR210xB wireless module and explains how to integrate the module in a custom design. Figure 1. WINC1500 Xplained Pro Extension Board © 2017 Microchip Technology Inc. User Guide DS50002616A-page 1 WINC1500-XPRO Table of Contents Description.......................................................................................................................1 1. Introduction................................................................................................................3 1.1. 1.2. Features....................................................................................................................................... 3 Kit Overview................................................................................................................................. 4 2. Getting Started.......................................................................................................... 5 2.1. 2.2. Xplained Pro Quick Start.............................................................................................................. 5 Design Documentation and Relevant Links................................................................................. 5 3. Xplained Pro.............................................................................................................. 7 3.1. 3.2. Hardware Identification System....................................................................................................7 Xplained Pro Standard Extension Header....................................................................................7 4. Hardware Specifications............................................................................................9 4.1. 4.2. 4.3. Headers and Connectors............................................................................................................. 9 WINC1500-XPRO Peripherals................................................................................................... 11 Hardware Revision History.........................................................................................................12 5. Ordering Information................................................................................................13 6. Document Revision History..................................................................................... 14 The Microchip Web Site................................................................................................ 15 Customer Change Notification Service..........................................................................15 Customer Support......................................................................................................... 15 Microchip Devices Code Protection Feature................................................................. 15 Legal Notice...................................................................................................................16 Trademarks................................................................................................................... 16 Quality Management System Certified by DNV.............................................................17 Worldwide Sales and Service........................................................................................18 © 2017 Microchip Technology Inc. User Guide DS50002616A-page 2 WINC1500-XPRO 1. Introduction 1.1 Features • Compliant Wi-Fi module with IEEE 802.11 b/g/n standard specifications: – Supports 20 MHz single spatial stream (1x1), up to 72.2 Mbps PHY rate in the 2.4 GHz ISM band – Supported network features: TCP, UDP, DHCP, ARP, HTTP, SSL, and DNS – Supports host interface through SPI • Integrated Power Amplifier (PA), Tx/Rx switch and Printed Circuit Board (PCB) antenna • Supports very low input level (sensitivity) and long range • Supports on-chip network stack to offload MCU • Integrated flash memory for system software • Debug I2C and UART header footprints • Extension port and RESET switch footprints • Current measurement header • Crypto authentication (optional) • Xplained Pro extension hardware identification system • Supports an operating temperature range from -40°C to +85°C • Supports footprint compatible modules shown in the table below. The kit contains the ATWINC1510-MR210PB module by default Table 1-1. Wireless Modules Model Number No. of Pins Description Regulatory Certification ATWINC1500-MR210PB 28 Certified Module with ATWINC1500B chip (4Mb Flash) and PCB printed antenna FCC, IC, CE ATWINC1500-MR210UB 28 Certified Module with ATWINC1500B chip (4Mb Flash) and u.FL connector FCC, IC ATWINC1510-MR210PB 28 Certified Module with ATWINC1510B chip (8Mb Flash) and PCB printed antenna FCC, IC, CE ATWINC1510-MR210UB 28 Certified Module with ATWINC1510B chip (8Mb Flash) and u.FL connector Planned • Approved regulatory certification IDs for ATWINC1510-MR210PB: – United States/FCC ID: 2ADHKATWINC1510 – Canada • IC ID: 20266-ATWINC1510 • HVIN: ATWINC1510-MR210PB – Europe - CE © 2017 Microchip Technology Inc. User Guide DS50002616A-page 3 WINC1500-XPRO 1.2 Kit Overview The WINC1500-XPRO is an extension board for the SmartConnect-ATWINC15x0-MR210xB Wi-Fi module for the Xplained Pro platform. It connects to any Xplained Pro standard extension header on any Xplained Pro MCU board to provide Wi-Fi functionality. Figure 1-1. WINC1500-XPRO Overview © 2017 Microchip Technology Inc. User Guide DS50002616A-page 4 WINC1500-XPRO 2. Getting Started The WINC1500-XPRO is designed to connect with an Xplained Pro extension header marked as EXT1. However, it is compatible with all Xplained Pro EXT headers. Refer to the pin description of the Xplained Pro evaluation kit to find out the suitable EXT headers of the Xplained Pro. 2.1 Xplained Pro Quick Start Steps to start exploring the Xplained Pro platform: 1. Download and install Atmel Studio. 2. Launch Atmel Studio. The operating system installs the driver software automatically the first time the Xplained Pro evaluation ® ® kit is connected to a PC. This driver supports 32-bit and 64-bit versions of Microsoft Windows XP, ® Windows Vista , Windows 7, Windows 8, Windows 10, and Windows Server 2012. When the Xplained Pro MCU board is powered, the power LED (green) glows and Atmel Studio automatically detects the specific Xplained Pro MCU and extension board(s) that are connected. The kit landing page in Atmel Studio comes with an option to launch Atmel Software Framework (ASF) and Atmel START example application codes for the kit. The target device is programmed and debugged by the on-board Embedded Debugger and therefore no external programmer or debugger tool is required. 2.2 Design Documentation and Relevant Links The following list contains the link to the relevant documents and software for the WINC1500-XPRO: • • • • • • • • • • • • • • • • • WINC1500-XPRO - Product page WINC1500-XPRO Design Documentation - Package containing schematics, BOM, assembly drawings, 3D plots, layer plots, etc. ATWINC15x0-MR210xB - Wireless module datasheet WINC1500 - Wireless chip datasheet ATECC508A-MAHDA-T - Crypto Authentication Device datasheet ATWINC1500B Hardware Design Guidelines - IEEE 802.11 b/g/n IoT Module - Hardware Design Guide Getting Started Guide for ATWINC1500 Wi-Fi using SAM D21 Xplained Pro - User Guide Software Programming Guide for ATWINC1500 Wi-Fi using SAM D21 Xplained Pro Programming Guide ATWINC1500 Wi-Fi Network Controller - Software Design Guide - Design Guide ATWINC1500 AT Command Reference Guide - Command Reference Guide ATWINC1500 Wi-Fi Network Controller - AP Provision Mode - Application Note ATWINC1500 Wi-Fi Network Controller - Station Mode - Application Note ATWINC1500 Wi-Fi Network Controller - P2P Mode - Application Note ATWINC1500 Wi-Fi Network Controller - HTTP Provision Mode - Application Note TCP Client and Server Operation using ATWINC1500 - Application Note ATWINC1500 Weather Client Example - Application Note Xplained Pro products - The Xplained Pro is a series of small-sized and easy-to-use evaluation kits for microcontrollers and other products. It consists of a series of low-cost MCU boards for evaluation and demonstration of features and capabilities of different MCU families © 2017 Microchip Technology Inc. User Guide DS50002616A-page 5 WINC1500-XPRO • • • Atmel Studio - Atmel Studio provides a free Atmel IDE for development of C/C++ and assembler code for microcontrollers, and relevant documentation Atmel Data Visualizer - Atmel Data Visualizer is a program used for processing and visualizing data. Data Visualizer can receive data from various sources such as the Embedded Debugger Data Gateway Interface found on Xplained Pro boards and COM ports EDBG User Guide - User guide containing more information about the on-board Embedded Debugger © 2017 Microchip Technology Inc. User Guide DS50002616A-page 6 WINC1500-XPRO 3. Xplained Pro Xplained Pro is an evaluation platform which contains a series of microcontroller boards (evaluation kits) and extension boards. Atmel Studio is used to program and debug the microcontrollers on these boards. Atmel Studio includes ASF and Atmel START, which has drivers and demo code, and Data Visualizer, which supports data streaming and advanced debugging. Xplained Pro evaluation kits can be connected to a wide range of Xplained Pro extension boards through standardized headers and connectors. Xplained Pro extension boards have identification (ID) chips to uniquely identify which boards are connected to the Xplained Pro evaluation kits. 3.1 Hardware Identification System All Xplained Pro extension boards come with an identification chip (ATSHA204A CryptoAuthentication chip) to uniquely identify the boards that are connected to the Xplained Pro evaluation kit. This chip contains information that identifies the extension with its name and some extra data. When an Xplained Pro extension is connected to an Xplained Pro evaluation kit, the information is read and sent to Atmel Studio. The following table shows the data fields stored in the ID chip with example content. Table 3-1. Xplained Pro ID Chip Content 3.2 Data Field Data Type Example Content Manufacturer ASCII string Atmel'\0' Product Name ASCII string Segment LCD1 Xplained Pro'\0' Product Revision ASCII string 02'\0' Product Serial Number ASCII string 1774020200000010’\0’ Minimum Voltage [mV] uint16_t 3000 Maximum Voltage [mV] uint16_t 3600 Maximum Current [mA] uint16_t 30 Xplained Pro Standard Extension Header All Xplained Pro kits have one or more dual row, 20-pin, 100-mil extension header. The Xplained Pro MCU boards have male headers, while the Xplained Pro extensions have their female counterparts. All connected pins follow the defined pin description in the table. Info:  All pins are not always connected on all extension headers. The extension headers can be used to connect a variety of Xplained Pro extensions to Xplained Pro MCU boards or to access the pins of the target microcontroller on Xplained Pro MCU boards directly. © 2017 Microchip Technology Inc. User Guide DS50002616A-page 7 WINC1500-XPRO Table 3-2. Xplained Pro Standard Extension Header Pin Number Pin Name Description 1 ID Pin to communicate with the ID chip on an extension board 2 GND Ground 3 ADC(+) Analog-to-Digital Converter; alternatively, a pin for the positive terminal of a differential ADC 4 ADC(-) Analog-to-Digital Converter; alternatively, a pin for the negative terminal of a differential ADC 5 GPIO1 General purpose I/O pin 6 GPIO2 General purpose I/O pin 7 PWM(+) Pulse width modulation; alternatively, a pin for the positive part of a differential PWM 8 PWM(-) Pulse width modulation; alternatively, a pin for the negative part of a differential PWM 9 IRQ/GPIO Interrupt request pin and/or general purpose I/O pin 10 SPI_SS_B/ GPIO Slave select pin for Serial Peripheral Interface (SPI) and/or general purpose I/O pin 11 I2C_SDA Data pin for I2C interface. Always connected, bus type 12 I2C_SCL Clock pin for I2C interface. Always connected, bus type 13 UART_RX Receiver pin of target device UART 14 UART_TX Transmitter pin of target device UART 15 SPI_SS_A Slave select for SPI. This pin should preferably not be connected to anything else. 16 SPI_MOSI SPI master out slave in pin. Always connected, bus type 17 SPI_MISO SPI master in slave out pin. Always connected, bus type 18 SPI_SCK SPI clock pin. Always connected, bus type 19 GND Ground pin for extension boards 20 VCC Power pin for extension boards © 2017 Microchip Technology Inc. User Guide DS50002616A-page 8 WINC1500-XPRO 4. Hardware Specifications 4.1 Headers and Connectors 4.1.1 WINC1500-XPRO Extension Header The WINC1500-XPRO implements one Xplained Pro Standard Extension Header marked with EXT in the PCB silkscreen. This header makes it possible to connect the board to any Xplained Pro MCU board. The following table provides pin descriptions for the extension header. Among the interfaces of wireless module, SPI is the only host interface; UART is for debug and I2C is for development debug. UART and I2C signals are accessed through debug connectors J103 and J104 respectively. So, UART_RXD and UART_TXD connections of wireless module with host can be separated by removing R117 and R118 to access them only at J103. To find the location of these resistors on board refer to WINC1500-XPRO Design Documentation in page 5. Similarly, I2C_SDA and I2C_SCL connections of the wireless module with the host can be separated by removing R107 and R108 respectively; I2C connection in J100 can be used to the control crypto device by the host. Table 4-1. WINC1500-XPRO Extension Header Pin Number Pin Name Description 1 ID_DATA Communication line to ID chip 2 GND Ground 3 NC - 4 NC - 5 RESET_N Active-low hard reset to the board 6 WAKE Active-high host wake control signal to the wireless module 7 NC - 8 NC - 9 IRQN Interrupt output from the wireless module to the host 10 CHIP_EN Active-high module enable signal to wireless module from host 11 I2C_SDA Data line for I2C interface 12 I2C_SCL Clock line for I2C interface 13 UART_RX Receive pin of target MCU UART interface 14 UART_TX Transmit pin of target MCU UART interface 15 SPI_SSN Active-low Slave select signal of the SPI interface to wireless module from host 16 SPI_MOSI Master out, Slave in signal of target MCU SPI interface 17 SPI_MISO Master in, Slave out signal of target MCU SPI interface 18 SPI_SCK Clock line of the SPI interface © 2017 Microchip Technology Inc. User Guide DS50002616A-page 9 WINC1500-XPRO 4.1.1.1 Pin Number Pin Name Description 19 GND Ground 20 VCC_TARGET Target +3.3V supply voltage from the host MCU board Power Measurement Header The current measurement header (J102) can be used to measure the total current consumed by the ATWINC15x0-MR210xB module using a voltmeter. To measure the total current consumption of the module, remove the jumper from J102 and connect a voltmeter across its pins. A 1Ω resistor available on-board across the jumper gives a 1:1 relationship between voltage drop and current consumption. 4.1.1.2 Debug Connectors The Debug UART Header (J103) is not mounted on the board. The following table provides connector and module pin descriptions. This connector should be mounted for debug using this UART. A USB HiSpeed to UART Cable like FTDI is needed to connect J103 with PC to print debug log. The following settings are recommended for making serial port setup for debug UART communication. To find the latest settings for serial port setup refer to Getting Started Guide for ATWINC1500 Wi-Fi using SAM D21 Xplained Pro in page 5 • Baud rate : 115200 • • • • Data : 8 bit Parity : none Stop : 1 bit Flow control : none Table 4-2. Debug UART Connector J103 Pin on UART Connector Pin on ATWINC15x0-MR210xB module Function 1 19 UART RX 2 14 UART TX 3 28 Ground The Debug I2C Header (J104) is not mounted on the board. The following table provides connector and module pin descriptions. This I2C connector should be mounted only for development debug. An I2C/SPI Host Adapter like Aardvark is needed to connect J104 with PC. Table 4-3. Debug I2C Connector J104 Pin on I2C connector Pin on ATWINC15x0-MR210xB module Function 1 2 I2C SCL 2 28 Ground 3 3 I2C SDA 4 - Not Connected The I2C and UART pins of the wireless module are also connected with Extension port receptacle J101. The connector can be used for connecting an extension board or for debugging purposes. It is currently not mounted on the board. © 2017 Microchip Technology Inc. User Guide DS50002616A-page 10 WINC1500-XPRO Table 4-4. Extension Port / Debug Connector J101 Pin on Extension Port Pin on ATWINC15x0-MR210xB module Function 1 3 I2C_SDA 2 - NC 3 2 I2C_SCL 4 19 UART_RXD 5 28 GND 6 14 UART_TXD 7 - NC 8 28 GND 9 4 RESET_N 10 23 and 20 VCC_MODULE (+3.3V) 4.2 WINC1500-XPRO Peripherals 4.2.1 ATWINC15x0-MR210xB Control Signals The ATWINC15x0-MR210xB main control pins are connected to the Xplained Pro extension header. SPI is the only host interface. Table 4-5. ATWINC15x0-MR210xB Control Signals 4.2.2 Pin on Extension Header Pin on ATWINC15x0-MR210xB module Function 5 4 RESET_N 6 11 WAKE 9 13 IRQ_N 10 22 CHIP_EN 15 16 SPI_SSN 16 15 SPI_MOSI 17 17 SPI_MISO 18 18 SPI_SCK LED There is one dual green/red LED on the Xplained Pro extension board that is controlled by the ATWINC15x0-MR210xB. These LEDs are used to show application status. © 2017 Microchip Technology Inc. User Guide DS50002616A-page 11 WINC1500-XPRO Table 4-6. LED Connection 4.2.3 Pin on ATWINC15x0-MR210xB module Function 27 GPIO 5 (Green LED) 1 GPIO 6 (Red LED) Crypto Device ™ The WINC1500-XPRO features a CryptoAuthentication device (ATECC508A). The same I2C interface lines are shared between the two slave devices (WINC1500 module and crypto device). Host MCU from the Xplained Pro MCU board will be the Master for this I2C. I2C connections of the wireless module with the host can be separated by removing R107 and R108 for communication between crypto device and MCU. If there is any issue in this communication , Pull-up resistors R104 and R105 should be mounted. Table 4-7. Crypto Device Connection Pin on ATWINC15x0-MR210xB module Function 3 I2C data 2 I2C clock 4.3 Hardware Revision History 4.3.1 Identifying Product ID and Revision The revision and product identifier of theWINC1500-XPRO can be found by looking at the sticker on the bottom side of the PCB. The identifier and revision are printed in plain text as A09-nnnn\rr, where nnnn is the identifier and rr is the revision. The label also contains a 10 digit serial number unique to each board. The product identifier for the WINC1500-XPRO is A09-2442. 4.3.2 Revision Revision 6 of the WINC1500 Xplained Pro is the initial released version. Revision 12 of the WINC1500 Xplained Pro is the latest released version. © 2017 Microchip Technology Inc. User Guide DS50002616A-page 12 WINC1500-XPRO 5. Ordering Information Following table describes the ordering details of the ATWINC1500-XPRO evaluation boards. Table 5-1. Ordering Details Model Number Ordering Code Kit Description WINC1500XPRO ATWINC1500XPRO ATWINC1500 Xplained ATWINC1500 Xplained Pro Extension Pro extension kit board WINC1500XSTK ATWINC1500XSTK ATWINC1500 Xplained SAMD21 Xplained Pro, WINC1500 Pro starter kit Xplained Pro Extension board, I/O1 Xplained Pro Extension board and Two USB Type A to Micro B Cables (1.5m) © 2017 Microchip Technology Inc. User Guide Package Contents DS50002616A-page 13 WINC1500-XPRO 6. Document Revision History Revision A (May 2017) • Initial release of this document using the Microchip format. Previously Released Atmel Revisions Doc. rev. Date Comment 42388B 17/11/2015 Wireless module part number updated. 42388A 15/04/2015 Initial document release. © 2017 Microchip Technology Inc. User Guide DS50002616A-page 14 WINC1500-XPRO The Microchip Web Site Microchip provides online support via our web site at http://www.microchip.com/. This web site is used as a means to make files and information easily available to customers. Accessible by using your favorite Internet browser, the web site contains the following information: • • • Product Support – Data sheets and errata, application notes and sample programs, design resources, user’s guides and hardware support documents, latest software releases and archived software General Technical Support – Frequently Asked Questions (FAQ), technical support requests, online discussion groups, Microchip consultant program member listing Business of Microchip – Product selector and ordering guides, latest Microchip press releases, listing of seminars and events, listings of Microchip sales offices, distributors and factory representatives Customer Change Notification Service Microchip’s customer notification service helps keep customers current on Microchip products. Subscribers will receive e-mail notification whenever there are changes, updates, revisions or errata related to a specified product family or development tool of interest. To register, access the Microchip web site at http://www.microchip.com/. Under “Support”, click on “Customer Change Notification” and follow the registration instructions. Customer Support Users of Microchip products can receive assistance through several channels: • • • • Distributor or Representative Local Sales Office Field Application Engineer (FAE) Technical Support Customers should contact their distributor, representative or Field Application Engineer (FAE) for support. Local sales offices are also available to help customers. A listing of sales offices and locations is included in the back of this document. Technical support is available through the web site at: http://www.microchip.com/support Microchip Devices Code Protection Feature Note the following details of the code protection feature on Microchip devices: • • • • Microchip products meet the specification contained in their particular Microchip Data Sheet. Microchip believes that its family of products is one of the most secure families of its kind on the market today, when used in the intended manner and under normal conditions. There are dishonest and possibly illegal methods used to breach the code protection feature. All of these methods, to our knowledge, require using the Microchip products in a manner outside the operating specifications contained in Microchip’s Data Sheets. Most likely, the person doing so is engaged in theft of intellectual property. Microchip is willing to work with the customer who is concerned about the integrity of their code. © 2017 Microchip Technology Inc. User Guide DS50002616A-page 15 WINC1500-XPRO • Neither Microchip nor any other semiconductor manufacturer can guarantee the security of their code. Code protection does not mean that we are guaranteeing the product as “unbreakable.” Code protection is constantly evolving. We at Microchip are committed to continuously improving the code protection features of our products. Attempts to break Microchip’s code protection feature may be a violation of the Digital Millennium Copyright Act. If such acts allow unauthorized access to your software or other copyrighted work, you may have a right to sue for relief under that Act. Legal Notice Information contained in this publication regarding device applications and the like is provided only for your convenience and may be superseded by updates. It is your responsibility to ensure that your application meets with your specifications. MICROCHIP MAKES NO REPRESENTATIONS OR WARRANTIES OF ANY KIND WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL, STATUTORY OR OTHERWISE, RELATED TO THE INFORMATION, INCLUDING BUT NOT LIMITED TO ITS CONDITION, QUALITY, PERFORMANCE, MERCHANTABILITY OR FITNESS FOR PURPOSE. Microchip disclaims all liability arising from this information and its use. Use of Microchip devices in life support and/or safety applications is entirely at the buyer’s risk, and the buyer agrees to defend, indemnify and hold harmless Microchip from any and all damages, claims, suits, or expenses resulting from such use. No licenses are conveyed, implicitly or otherwise, under any Microchip intellectual property rights unless otherwise stated. Trademarks The Microchip name and logo, the Microchip logo, AnyRate, AVR, AVR logo, AVR Freaks, BeaconThings, BitCloud, CryptoMemory, CryptoRF, dsPIC, FlashFlex, flexPWR, Heldo, JukeBlox, KeeLoq, KeeLoq logo, Kleer, LANCheck, LINK MD, maXStylus, maXTouch, MediaLB, megaAVR, MOST, MOST logo, MPLAB, OptoLyzer, PIC, picoPower, PICSTART, PIC32 logo, Prochip Designer, QTouch, RightTouch, SAM-BA, SpyNIC, SST, SST Logo, SuperFlash, tinyAVR, UNI/O, and XMEGA are registered trademarks of Microchip Technology Incorporated in the U.S.A. and other countries. ClockWorks, The Embedded Control Solutions Company, EtherSynch, Hyper Speed Control, HyperLight Load, IntelliMOS, mTouch, Precision Edge, and Quiet-Wire are registered trademarks of Microchip Technology Incorporated in the U.S.A. Adjacent Key Suppression, AKS, Analog-for-the-Digital Age, Any Capacitor, AnyIn, AnyOut, BodyCom, chipKIT, chipKIT logo, CodeGuard, CryptoAuthentication, CryptoCompanion, CryptoController, dsPICDEM, dsPICDEM.net, Dynamic Average Matching, DAM, ECAN, EtherGREEN, In-Circuit Serial Programming, ICSP, Inter-Chip Connectivity, JitterBlocker, KleerNet, KleerNet logo, Mindi, MiWi, motorBench, MPASM, MPF, MPLAB Certified logo, MPLIB, MPLINK, MultiTRAK, NetDetach, Omniscient Code Generation, PICDEM, PICDEM.net, PICkit, PICtail, PureSilicon, QMatrix, RightTouch logo, REAL ICE, Ripple Blocker, SAM-ICE, Serial Quad I/O, SMART-I.S., SQI, SuperSwitcher, SuperSwitcher II, Total Endurance, TSHARC, USBCheck, VariSense, ViewSpan, WiperLock, Wireless DNA, and ZENA are trademarks of Microchip Technology Incorporated in the U.S.A. and other countries. SQTP is a service mark of Microchip Technology Incorporated in the U.S.A. Silicon Storage Technology is a registered trademark of Microchip Technology Inc. in other countries. GestIC is a registered trademark of Microchip Technology Germany II GmbH & Co. KG, a subsidiary of Microchip Technology Inc., in other countries. All other trademarks mentioned herein are property of their respective companies. © 2017, Microchip Technology Incorporated, Printed in the U.S.A., All Rights Reserved. © 2017 Microchip Technology Inc. User Guide DS50002616A-page 16 WINC1500-XPRO ISBN: 978-1-5224-1750-7 Quality Management System Certified by DNV ISO/TS 16949 Microchip received ISO/TS-16949:2009 certification for its worldwide headquarters, design and wafer fabrication facilities in Chandler and Tempe, Arizona; Gresham, Oregon and design centers in California ® ® and India. The Company’s quality system processes and procedures are for its PIC MCUs and dsPIC ® DSCs, KEELOQ code hopping devices, Serial EEPROMs, microperipherals, nonvolatile memory and analog products. In addition, Microchip’s quality system for the design and manufacture of development systems is ISO 9001:2000 certified. © 2017 Microchip Technology Inc. User Guide DS50002616A-page 17 Worldwide Sales and Service AMERICAS ASIA/PACIFIC ASIA/PACIFIC EUROPE Corporate Office Asia Pacific Office China - Xiamen Austria - Wels 2355 West Chandler Blvd. Suites 3707-14, 37th Floor Tel: 86-592-2388138 Tel: 43-7242-2244-39 Chandler, AZ 85224-6199 Tower 6, The Gateway Fax: 86-592-2388130 Fax: 43-7242-2244-393 Tel: 480-792-7200 Harbour City, Kowloon China - Zhuhai Denmark - Copenhagen Fax: 480-792-7277 Hong Kong Tel: 86-756-3210040 Tel: 45-4450-2828 Technical Support: Tel: 852-2943-5100 Fax: 86-756-3210049 Fax: 45-4485-2829 http://www.microchip.com/ Fax: 852-2401-3431 India - Bangalore Finland - Espoo support Australia - Sydney Tel: 91-80-3090-4444 Tel: 358-9-4520-820 Web Address: Tel: 61-2-9868-6733 Fax: 91-80-3090-4123 France - Paris www.microchip.com Fax: 61-2-9868-6755 India - New Delhi Tel: 33-1-69-53-63-20 Atlanta China - Beijing Tel: 91-11-4160-8631 Fax: 33-1-69-30-90-79 Duluth, GA Tel: 86-10-8569-7000 Fax: 91-11-4160-8632 France - Saint Cloud Tel: 678-957-9614 Fax: 86-10-8528-2104 India - Pune Tel: 33-1-30-60-70-00 Fax: 678-957-1455 China - Chengdu Tel: 91-20-3019-1500 Germany - Garching Austin, TX Tel: 86-28-8665-5511 Japan - Osaka Tel: 49-8931-9700 Tel: 512-257-3370 Fax: 86-28-8665-7889 Tel: 81-6-6152-7160 Germany - Haan Boston China - Chongqing Fax: 81-6-6152-9310 Tel: 49-2129-3766400 Westborough, MA Tel: 86-23-8980-9588 Japan - Tokyo Germany - Heilbronn Tel: 774-760-0087 Fax: 86-23-8980-9500 Tel: 81-3-6880- 3770 Tel: 49-7131-67-3636 Fax: 774-760-0088 China - Dongguan Fax: 81-3-6880-3771 Germany - Karlsruhe Chicago Tel: 86-769-8702-9880 Korea - Daegu Tel: 49-721-625370 Itasca, IL China - Guangzhou Tel: 82-53-744-4301 Germany - Munich Tel: 630-285-0071 Tel: 86-20-8755-8029 Fax: 82-53-744-4302 Tel: 49-89-627-144-0 Fax: 630-285-0075 China - Hangzhou Korea - Seoul Fax: 49-89-627-144-44 Dallas Tel: 86-571-8792-8115 Tel: 82-2-554-7200 Germany - Rosenheim Addison, TX Fax: 86-571-8792-8116 Fax: 82-2-558-5932 or Tel: 49-8031-354-560 Tel: 972-818-7423 China - Hong Kong SAR 82-2-558-5934 Israel - Ra’anana Fax: 972-818-2924 Tel: 852-2943-5100 Malaysia - Kuala Lumpur Tel: 972-9-744-7705 Detroit Fax: 852-2401-3431 Tel: 60-3-6201-9857 Italy - Milan Novi, MI China - Nanjing Fax: 60-3-6201-9859 Tel: 39-0331-742611 Tel: 248-848-4000 Tel: 86-25-8473-2460 Malaysia - Penang Fax: 39-0331-466781 Houston, TX Fax: 86-25-8473-2470 Tel: 60-4-227-8870 Italy - Padova Tel: 281-894-5983 China - Qingdao Fax: 60-4-227-4068 Tel: 39-049-7625286 Indianapolis Tel: 86-532-8502-7355 Philippines - Manila Netherlands - Drunen Noblesville, IN Fax: 86-532-8502-7205 Tel: 63-2-634-9065 Tel: 31-416-690399 Tel: 317-773-8323 China - Shanghai Fax: 63-2-634-9069 Fax: 31-416-690340 Fax: 317-773-5453 Tel: 86-21-3326-8000 Singapore Norway - Trondheim Tel: 317-536-2380 Fax: 86-21-3326-8021 Tel: 65-6334-8870 Tel: 47-7289-7561 Los Angeles China - Shenyang Fax: 65-6334-8850 Poland - Warsaw Mission Viejo, CA Tel: 86-24-2334-2829 Taiwan - Hsin Chu Tel: 48-22-3325737 Tel: 949-462-9523 Fax: 86-24-2334-2393 Tel: 886-3-5778-366 Romania - Bucharest Fax: 949-462-9608 China - Shenzhen Fax: 886-3-5770-955 Tel: 40-21-407-87-50 Tel: 951-273-7800 Tel: 86-755-8864-2200 Taiwan - Kaohsiung Spain - Madrid Raleigh, NC Fax: 86-755-8203-1760 Tel: 886-7-213-7830 Tel: 34-91-708-08-90 Tel: 919-844-7510 China - Wuhan Taiwan - Taipei Fax: 34-91-708-08-91 New York, NY Tel: 86-27-5980-5300 Tel: 886-2-2508-8600 Sweden - Gothenberg Tel: 631-435-6000 Fax: 86-27-5980-5118 Fax: 886-2-2508-0102 Tel: 46-31-704-60-40 San Jose, CA China - Xian Thailand - Bangkok Sweden - Stockholm Tel: 408-735-9110 Tel: 86-29-8833-7252 Tel: 66-2-694-1351 Tel: 46-8-5090-4654 Tel: 408-436-4270 Fax: 86-29-8833-7256 Fax: 66-2-694-1350 UK - Wokingham Canada - Toronto Tel: 44-118-921-5800 Tel: 905-695-1980 Fax: 44-118-921-5820 Fax: 905-695-2078 © 2017 Microchip Technology Inc. User Guide DS50002616A-page 18 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Microchip: ATWINC1500-XSTK ATWINC1500-XPRO
