AD7768BSTZ

8-/4-Channel, 24-Bit, Simultaneous Sampling ADCs with Power Scaling, 110.8 kHz BW AD7768/AD7768-4 Data Sheet FEATURES Linear phase digital filter Low latency sinc5 filter Wideband brick wall filter: ±0.005 dB ripple to 102.4 kHz Analog input precharge buffers Power supply AVDD1 = 5.0 V, AVDD2 = 2.25 V to 5.0 V IOVDD = 2.5 V to 3.3 V or IOVDD = 1.8 V 64-lead LQFP package, no exposed pad Temperature range: −40°C to +105°C Precision ac and dc performance 8-/4-channel simultaneous sampling 256 kSPS maximum ADC ODR per channel 108 dB dynamic range 110.8 kHz maximum input bandwidth (−3 dB BW) −120 dB THD, typical ±2 ppm of full-scale range (FSR) integral nonlinearity (INL), ±50 μV offset error, ±30 ppm gain error Optimized power dissipation vs. noise vs. input bandwidth Selectable power, speed, and input bandwidth Fast (highest speed): 110.8 kHz BW, 51.5 mW per channel Median (half speed): 55.4 kHz BW, 27.5 mW per channel Low power (lowest power): 13.8 kHz BW, 9.375 mW per channel Input BW range: dc to 110.8 kHz Programmable input bandwidth/sampling rates CRC error checking on data interface Daisy-chaining APPLICATIONS Data acquisition systems: USB/PXI/Ethernet Instrumentation and industrial control loops Audio testing and measurement Vibration and asset condition monitoring 3-phase power quality analysis Sonar High precision medical electroencephalogram (EEG)/ electromyography (EMG)/electrocardiogram (ECG) FUNCTIONAL BLOCK DIAGRAM BUFFERED VCM VCM VCM AIN0+ CH 0 AIN0– P AIN1+ CH 1 AIN1– P P P AIN2+ CH 2 AIN2– P AIN3+ CH 3 AIN3– P AIN4+ P AIN4– P AIN5+ P AIN5– P AIN6+ P AIN6– P AIN7+ P AIN7– P CH 4* CH 5* P P CH 6* CH 7* AVDD2A, REGCAPA, AVDD2B REGCAPB REFx+ REFx– ×8 Σ-∆ ADC DGND 1.8V LDO PRECHARGE REFERENCE BUFFERS DREGCAP 1.8V LDO SYNC_IN SYNC_OUT START OFFSET, GAIN PHASE CORRECTION DIGITAL FILTER ENGINE RESET FORMAT1* FORMAT0 OFFSET, GAIN PHASE CORRECTION Σ-∆ ADC SINC5 LOW LATENCY FILTER Σ-∆ ADC IOVDD ADC OUTPUT DATA SERIAL INTERFACE OFFSET, GAIN PHASE CORRECTION WIDEBAND LOW RIPPLE FILTER Σ-∆ ADC OFFSET, GAIN PHASE CORRECTION Σ-∆ ADC OFFSET, GAIN PHASE CORRECTION Σ-∆ ADC OFFSET, GAIN PHASE CORRECTION Σ-∆ ADC OFFSET, GAIN PHASE CORRECTION ×16 ANALOG INPUT PRECHARGE BUFFERS (P) AVSS DCLK DOUT0 DOUT1 DOUT2 DOUT3 DOUT4* DOUT5* DOUT6*, DIN DOUT7* OFFSET, GAIN PHASE CORRECTION Σ-∆ ADC DRDY SPI CONTROL INTERFACE ST0/CS ST1*/SCLK DEC0/SDO DEC1/SDI PIN/SPI AD7768/AD7768-4 XTAL2/MCLK *THESE CHANNELS/PINS EXIST ONLY ON THE AD7768. XTAL1 MODE3/GPIO3 TO MODE0/GPIO0 FILTER/GPIO4 14001-001 AVDD1A, AVDD1B Figure 1. Rev. B Document Feedback Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other rights of third parties that may result from its use. Specifications subject to change without notice. No license is granted by implication or otherwise under any patent or patent rights of Analog Devices. Trademarks and registered trademarks are the property of their respective owners. One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A. Tel: 781.329.4700 ©2016–2018 Analog Devices, Inc. All rights reserved. Technical Support www.analog.com AD7768/AD7768-4 Data Sheet TABLE OF CONTENTS Features .............................................................................................. 1  AD7768 Register Map Details (SPI Control).............................. 78  Applications ....................................................................................... 1  AD7768 Register Map................................................................ 78  Functional Block Diagram .............................................................. 1  Channel Standby Register ......................................................... 80  Revision History ............................................................................... 3  Channel Mode A Register ......................................................... 80  General Description ......................................................................... 5  Channel Mode B Register ......................................................... 81  Specifications..................................................................................... 6  Channel Mode Select Register .................................................. 81  1.8 V IOVDD Specifications ..................................................... 13  Power Mode Select Register ...................................................... 82  Timing Specifications ................................................................ 17  General Device Configuration Register .................................. 83  1.8 V IOVDD Timing Specifications ....................................... 18  Absolute Maximum Ratings.......................................................... 22  Data Control: Soft Reset, Sync, and Single-Shot Control Register ........................................................................................ 83  Thermal Resistance .................................................................... 22  Interface Configuration Register.............................................. 84  ESD Caution ................................................................................ 22  Digital Filter RAM Built In Self Test (BIST) Register............ 85  Pin Configurations and Function Descriptions ......................... 23  Status Register ............................................................................. 85  Typical Performance Characteristics ........................................... 31  Revision Identification Register ............................................... 85  Terminology .................................................................................... 41  GPIO Control Register .............................................................. 86  Theory of Operation ...................................................................... 42  GPIO Write Data Register ......................................................... 86  Clocking, Sampling Tree, and Power Scaling ............................. 42  GPIO Read Data Register .......................................................... 87  Noise Performance and Resolution.......................................... 43  Analog Input Precharge Buffer Enable Register Channel 0 to Channel 3 .................................................................................... 87  Applications Information .............................................................. 45  Power Supplies ............................................................................ 46  Analog Input Precharge Buffer Enable Register Channel 4 to Channel 7 .................................................................................... 87  Device Configuration ................................................................ 47  Positive Reference Precharge Buffer Enable Register ............ 88  Pin Control .................................................................................. 47  Negative Reference Precharge Buffer Enable Register .......... 88  SPI Control .................................................................................. 50  Offset Registers ........................................................................... 89  SPI Control Functionality ......................................................... 51  Gain Registers ............................................................................. 89  SPI Control Mode Extra Diagnostic Features ........................ 54  Sync Phase Offset Registers ...................................................... 90  Circuit Information ........................................................................ 55  ADC Diagnostic Receive Select Register ................................ 90  Core Signal Chain....................................................................... 55  ADC Diagnostic Control Register ........................................... 91  Analog Inputs .............................................................................. 56  Modulator Delay Control Register........................................... 91  VCM ............................................................................................. 58  Chopping Control Register ....................................................... 91  Reference Input ........................................................................... 58  AD7768-4 Register Map Details (SPI Control) .......................... 92  Clock Selection ........................................................................... 58  AD7768-4 Register Map ............................................................ 92  Digital Filtering ........................................................................... 58  Channel Standby Register ......................................................... 94  Decimation Rate Control .......................................................... 62  Channel Mode A Register ......................................................... 94  Antialiasing ................................................................................. 62  Channel Mode B Register ......................................................... 95  Calibration ................................................................................... 64  Channel Mode Select Register .................................................. 95  Data Interface .................................................................................. 66  Power Mode Select Register ...................................................... 95  Setting the Format of Data Output .......................................... 66  General Device Configuration Register .................................. 96  ADC Conversion Output: Header and Data .......................... 67  Functionality ................................................................................... 77  Data Control: Soft Reset, Sync, and Single-Shot Control Register ........................................................................................ 97  GPIO Functionality .................................................................... 77  Interface Configuration Register.............................................. 97  Rev. B | Page 2 of 105 Data Sheet AD7768/AD7768-4 Digital Filter RAM Built In Self Test (BIST) Register ............98  Negative Reference Precharge Buffer Enable Register .........101  Status Register..............................................................................98  Offset Registers..........................................................................102  Revision Identification Register ................................................99  Gain Registers ............................................................................102  GPIO Control Register ...............................................................99  Sync Phase Offset Registers .....................................................102  GPIO Write Data Register ...................................................... 100  ADC Diagnostic Receive Select Register ...............................102  GPIO Read Data Register ....................................................... 100  ADC Diagnostic Control Register ..........................................103  Analog Input Precharge Buffer Enable Register Channel 0 and Channel 1 ........................................................................... 100  Modulator Delay Control Register .........................................104  Analog Input Precharge Buffer Enable Register Channel 2 and Channel 3 ........................................................................... 101  Outline Dimensions ......................................................................105  Positive Reference Precharge Buffer Enable Register .......... 101  Chopping Control Register......................................................104  Ordering Guide .........................................................................105  REVISION HISTORY 7/2018—Rev. A to Rev. B Changed Eco Mode to Low Power Mode .................. Throughout Changes to General Description Section ....................................... 5 Changes to Table 1 ............................................................................ 6 Changes to Table 9 ..........................................................................24 Changes to Table 10 ........................................................................28 Changes to Figure 73 ......................................................................45 Changes to MCLK Source Selection Section ...............................53 Changes to Analog Inputs Section ................................................56 Added Figure 87 and Table 28; Renumbered Sequentially ........57 Changes to Table 27 ........................................................................57 Added Figure 88 ..............................................................................58 Added Filter Settling Time Section ...............................................59 Moved Table 29 ................................................................................60 Moved Table 30 ................................................................................61 Changes to Modulator Saturation Point Section ........................64 Added Figure 94 ..............................................................................64 Changes to Data Interface: Standard Conversion Operation Section ..............................................................................................68 Added Figure 102 ............................................................................69 Added Figure 106 ............................................................................71 Changes to Daisy-Chaining Section and Synchronization Section ..............................................................................................73 Changes to CRC Check on Data Interface Section.....................74 Added Table 38 ................................................................................74 Changes to Table 43 ........................................................................81 Change to Analog Input Precharge Buffer Enable Register Channel 0 to Channel 3 Section and Analog Input Precharge Buffer Enable Register Channel 4 to Channel 7 Section.................85 Change to Analog Input Precharge Buffer Enable Register Channel 0 and Channel 1 Section .................................................98 Change to Analog Input Precharge Buffer Enable Register Channel 2 and Channel 3 ...............................................................99 3/2016—Rev. 0 to Rev. A Added AD7768-4 ............................................................... Universal Changed Precharge Analog Input Reference to Analog Input Precharge ........................................................................ Throughout Changes to General Description Section ....................................... 5 Changes to Table 1 ............................................................................ 6 Changes to Table 2 .......................................................................... 12 Changes to Table 3 and t30 Parameter, Table 4............................. 16 Changes to Table 5 .......................................................................... 17 Changes to t30 Parameter, Table 6 and Figure 2 ........................... 18 Changes to Figure 4 and Figure 7 ................................................. 19 Changes to Figure 8 and Figure 9 ................................................. 20 Changes to Figure 10 and Table 9 ................................................. 22 Added Figure 11 and Table 10; Renumbered Sequentially ........ 26 Changes to Typical Performance Characteristics Section ......... 30 Changes to Theory of Operation Section and Clocking, Sampling Tree, and Power Scaling Section .................................. 41 Changes to Table 11 ........................................................................ 42 Added Example of Power vs. Noise Performance Optimization Section and Clocking Out the ADC Conversion Results (DCLK) Section ............................................................................... 42 Changes to Applications Information Section and Figure 73 ... 44 Changes to Table 14 and Power Supplies Section ....................... 45 Moved 1.8 V IOVDD Operation Section .................................... 46 Changes to Figure 75, Analog Supply Internal Connectivity Section, and Pin Control Section .................................................. 46 Added Figure 76 .............................................................................. 47 Changes to Channel Standby Section and Accessing the ADC Register Map Section ...................................................................... 49 Added Table 22 ................................................................................ 49 Changes to Channel Configuration Section ................................ 50 Changes to Channel Modes Section, Reset over SPI Control Interface Section, Sleep Mode Section, and Channel Standby Section .............................................................................................. 51 Changes to MCLK Source Selection Section, Interface Configuration Section, and ADC Synchronization over SPI Section .............................................................................................. 52 Added Figure 81 .............................................................................. 52 Changes to RAM Built In Self Test Section ................................. 53 Changes to Analog Inputs Section and Figure 85....................... 55 Added Figure 86 .............................................................................. 55 Added Table 27 ................................................................................ 56 Rev. B | Page 3 of 105 AD7768/AD7768-4 Data Sheet Changes to VCM Section, Reference Input Section, and Digital Filtering Section .............................................................................. 56 Changes to Figure 87, Figure 88, and Figure 89 ......................... 57 Changes to Antialiasing Section and Modulator Sampling Frequency Section .......................................................................... 58 Changes to Modulator Chopping Frequency Section and Table 29, and Modulator Saturation Point Section, ................... 59 Changes to Sync Phase Offset Adjustment Section ................... 60 Changes to Setting the Format of Data Output Section ............ 61 Added Table 32 and Figure 93 ...................................................... 61 Changes to Figure 94 Caption and ADC Conversion Output: Header and Data Section ............................................................... 62 Changes to Data Interface: Standard Conversion Operation Section .............................................................................................. 63 Changes to Figure 99 ...................................................................... 64 Added Figure 100 ........................................................................... 64 Added Figure 101 ........................................................................... 65 Changes to Daisy-Chaining Section and Figure 104 ................. 66 Added Figure 105 ........................................................................... 67 Changes to CRC Check on Data Interface Section .................... 68 Changes to Table 35 ........................................................................ 69 Changes to Table 36 ........................................................................ 70 Changes to GPIO Functionality Section and Figure 108 .......... 71 Added Figure 109 ........................................................................... 71 Changes to AD7768 Register Map Details (SPI Control) Section and Table 37 .................................................................................... 72 Changes to Channel Standby Register Section ........................... 74 Changes to Table 42 and Table 43 ................................................ 76 Changes to Table 44 ....................................................................... 77 Changes to Table 45 and Table 46 ................................................ 78 Changes to Table 49 ....................................................................... 79 Changes to Table 61 ....................................................................... 85 Added AD7768-4 Register Map Details (SPI Control) Section and Table 63 ...................................................................................................... 86 Added Table 64 and Table 65 ................................................................. 88 Added Table 66, Table 67, and Table 68 ............................................... 89 Added Table 69 ......................................................................................... 90 Added Table 70 and Table 71 ................................................................. 91 Added Table 72 and Table 73 ................................................................. 92 Added Table 74 and Table 75 ................................................................. 93 Added Table 76, Table 77, and Table 78 ............................................... 94 Added Table 79, Table 80, and Table 81 ............................................... 95 Added Table 82, Table 83, Table 84, and Table 85 .............................. 96 Added Table 86 and Table 87 ................................................................. 97 Added Table 88 ......................................................................................... 98 Changes to Ordering Guide ................................................................... 99 1/2016—Revision 0: Initial Version Rev. B | Page 4 of 105 Data Sheet AD7768/AD7768-4 GENERAL DESCRIPTION The AD7768/AD7768-4 are 8-channel and 4-channel, simultaneous sampling sigma-delta (Σ-Δ) analog-to-digital converters (ADCs), respectively, with a Σ-Δ modulator and digital filter per channel, enabling synchronized sampling of ac and dc signals. Within these filter options, the user can improve the dynamic range by selecting from decimation rates of ×32, ×64, ×128, ×256, ×512, and ×1024. The ability to vary the decimation filtering optimizes noise performance to the required input bandwidth. The AD7768/AD7768-4 achieve 108 dB dynamic range at a maximum input bandwidth of 110.8 kHz, combined with typical performance of ±2 ppm integral nonlinearity (INL), ±50 μV offset error, and ±30 ppm gain error. Embedded analog functionality on each ADC channel makes design easier, such as a precharge buffer on each analog input that reduces analog input current and a precharge reference buffer per channel reduces input current and glitches on the reference input terminals. The AD7768/AD7768-4 user can trade off input bandwidth, output data rate, and power dissipation, and select one of three power modes to optimize for noise targets and power consumption. The flexibility of the AD7768/AD7768-4 allows them to become reusable platforms for low power dc and high performance ac measurement modules. The AD7768/AD7768-4 have three modes: fast mode (256 kSPS maximum, 110.8 kHz input bandwidth, 51.5 mW per channel), median mode (128 kSPS maximum, 55.4 kHz input bandwidth, 27.5 mW per channel) and low power mode (32 kSPS maximum, 13.8 kHz input bandwidth, 9.375 mW per channel). The AD7768/AD7768-4 offer extensive digital filtering capabilities, such as a wideband, low ±0.005 dB pass-band ripple, antialiasing low-pass filter with sharp roll-off, and 105 dB attenuation at the Nyquist frequency. The device operates with a 5 V AVDD1A and AVDD1B supply, a 2.25 V to 5.0 V AVDD2A and AVDD2B supply, and a 2.5 V to 3.3 V or 1.8 V IOVDD supply (see the 1.8 V IOVDD Operation section for specific requirements for operating at 1.8 V IOVDD). The device requires an external reference; the absolute input reference voltage range is 1 V to AVDD1 − AVSS. For the purposes of clarity in this data sheet, the AVDD1A and AVDD1B supplies are referred to as AVDD1 and the AVDD2A and AVDD2B supplies are referred to as AVDD2. For the negative supplies, AVSS refers to the AVSS1A, AVSS1B, AVSS2A, AVSS2B, and AVSS pins. The specified operating temperature range is −40°C to +105°C. The device is housed in a 10 mm × 10 mm 64-lead LQFP package with a 12 mm × 12 mm printed circuit board (PCB) footprint. Frequency domain measurements can use the wideband linear phase filter. This filter has a flat pass band (±0.005 dB ripple) from dc to 102.4 kHz at 256 kSPS, from dc to 51.2 kHz at 128 kSPS, or from dc to 12.8 kHz at 32 kSPS. Throughout this data sheet, multifunction pins, such as XTAL2/MCLK, are referred to either by the entire pin name or by a single function of the pin, for example MCLK, when only that function is relevant. The AD7768/AD7768-4 also offer sinc response via a sinc5 filter, a low latency path for low bandwidth, and low noise measurements. The wideband and sinc5 filters can be selected and run on a per channel basis. Rev. B | Page 5 of 105 AD7768/AD7768-4 Data Sheet SPECIFICATIONS AVDD1A = AVDD1B = 4.5 V to 5.5 V, AVDD2A = AVDD2B = 2.0 V to 5.5 V, IOVDD = 2.25 V to 3.6 V, AVSS = DGND = 0 V, REFx+ = 4.096 V and REFx− = 0 V, MCLK = 32.768 MHz, analog input precharge buffers on, reference precharge buffers off, wideband filter, fCHOP = fMOD/32, TA = −40°C to +105°C, unless otherwise noted. See Table 2 for specifications at 1.8 V IOVDD. Table 1. Parameter ADC SPEED AND PERFORMANCE Output Data Rate (ODR), per Channel1 −3 dB Bandwidth (BW) Data Output Coding No Missing Codes2 DYNAMIC PERFORMANCE Fast Mode Dynamic Range Signal-to-Noise Ratio (SNR) Signal-to-Noise-andDistortion Ratio (SINAD) Total Harmonic Distortion (THD) Spurious-Free Dynamic Range (SFDR) Median Mode Dynamic Range SNR SINAD THD SFDR Low Power Mode Dynamic Range SNR SINAD THD SFDR INTERMODULATON DISTORTION (IMD)3 Test Conditions/Comments Min Fast mode 8 Median mode Low power mode Fast mode, wideband filter Median mode, wideband filter Low power mode, wideband filter 4 1 Typ Max Unit 256 kSPS 128 32 110.8 55.4 13.8 Twos complement, MSB first 24 Decimation by 32, 256 kSPS ODR Shorted input, wideband filter 1 kHz, −0.5 dBFS, sine wave input Sinc5 filter Wideband filter 1 kHz, −0.5 dBFS, sine wave input Decimation by 32, 32 kHz ODR Shorted input, wideband filter Sinc5 filter, 1 kHz, −0.5 dBFS, sine wave input Wideband filter, 1 kHz, −0.5 dBFS, sine wave input 1 kHz, −0.5 dBFS, sine wave input 1 kHz, −0.5 dBFS, sine wave input Bits 106.2 108 dB 109 106 104.7 111 107.8 107.5 dB dB dB 1 kHz, −0.5 dBFS, sine wave input Decimation by 32, 128 kHz ODR Shorted input, wideband filter Sinc5 filter, 1 kHz, −0.5 dBFS, sine wave input Wideband filter, 1 kHz, −0.5 dBFS, sine wave input 1 kHz, −0.5 dBFS, sine wave input 1 kHz, −0.5 dBFS, sine wave input kSPS kSPS kHz kHz kHz −120 −107 dB 128 dBc 106.2 109 108 111 dB dB 106 107.8 dB 105.8 107.5 −120 128 −113 dB dB dBc 106.2 109 108 111 dB dB 106 107.8 dB 105.8 107.5 −120 128 −113 dB dB dBc fINA = 9.7 kHz, fINB = 10.3 kHz Second order Third order −125 −125 Rev. B | Page 6 of 105 dB dB Data Sheet Parameter ACCURACY INL Offset Error4 Offset Error Drift Gain Error4 Gain Drift vs. Temperature2 VCM PIN Output Load Regulation Voltage Regulation Short-Circuit Current ANALOG INPUTS Differential Input Voltage Range Input Common-Mode Range2 Absolute Analog Input Voltage Limits2 Analog Input Current Unbuffered Precharge Buffer On5 Input Current Drift Unbuffered Precharge Buffer On EXTERNAL REFERENCE Reference Voltage Absolute Reference Voltage Limits2 Average Reference Current Average Reference Current Drift Common-Mode Rejection DIGITAL FILTER RESPONSE Low Ripple Wideband Filter Decimation Rate Group Delay Settling Time Pass-Band Ripple2 Pass Band Stop Band Frequency Stop Band Attenuation AD7768/AD7768-4 Test Conditions/Comments Min Typ Max Unit Endpoint method DCLK frequency ≤ 24 MHz 24 MHz to 32.768 MHz DCLK frequency2 DCLK frequency ≤ 24 MHz 24 MHz to 32.768 MHz DCLK frequency TA = 25°C ±2 ±50 ±75 ±250 ±750 ±30 ±0.5 ±7 ±115 ±150 ppm of FSR μV μV nV/°C nV/°C ppm of FSR ppm/°C With respect to AVSS (AVDD1 − AVSS)/2 400 5 μV/mA μV/V 30 mA ∆VOUT/∆IL Applies to the following VCM output options only: VCM = ∆VOUT/∆(AVDD1 − AVSS)/2; VCM = 1.65 V; and VCM = 2.5 V See the Analog Inputs section VREF = (REFx+) − (REFx−) −VREF AVSS AVSS Differential component Common-mode component ±70 ±1 V +VREF AVDD1 AVDD1 V V V ±48 ±17 −20 μA/V μA/V μA ±5 ±31 nA/V/°C nA/°C VREF = (REFx+) − (REFx−) Precharge reference buffers off 1 AVSS − 0.05 AVDD1 − AVSS AVDD1 + 0.05 V V Precharge reference buffer on Fast mode; see Figure 63 Precharge reference buffers off Precharge reference buffers on Fast mode; see Figure 63 Precharge reference buffers off Precharge reference buffers on AVSS AVDD1 V FILTER = 0 Up to six selectable decimation rates Latency Complete settling From dc to 102.4 kHz at 256 kSPS ±0.005 dB bandwidth −0.1 dB bandwidth −3 dB bandwidth Attenuation > 105 dB ±72 ±16 μA/V/channel μA/V/channel ±1.7 ±49 95 nA/V/°C nA/V/°C dB 32 Rev. B | Page 7 of 105 1024 34/ODR 68/ODR ±0.005 0.4 × ODR 0.409 × ODR 0.433 × ODR 0.499 × ODR 105 sec sec dB Hz Hz Hz Hz dB AD7768/AD7768-4 Parameter Sinc5 Filter Decimation Rate Group Delay Settling Time Pass Band REJECTION AC Power Supply Rejection Ratio (PSRR) AVDD1 AVDD2 IOVDD DC PSRR AVDD1 AVDD2 IOVDD Analog Input Common-Mode Rejection Ratio (CMRR) DC AC Crosstalk CLOCK Crystal Frequency External Clock (MCLK) Duty Cycle MCLK Pulse Width2 Logic Low Logic High CMOS Clock Input Voltage High, VINH Low, VINL LVDS Clock2 Differential Input Voltage Common-Mode Input Voltage Absolute Input Voltage ADC RESET2 ADC Start-Up Time After Reset6 Minimum RESET Low Pulse Width LOGIC INPUTS Input Voltage2 High, VINH Data Sheet Test Conditions/Comments FILTER = 1 Up to six selectable decimation rates Latency Complete settling −3 dB bandwidth Min Typ 32 Max Unit 1024 3/ODR 7/ODR 0.204 × ODR sec sec Hz 90 100 75 dB dB dB 100 118 90 dB dB dB 95 −120 dB dB dB VIN = 0.1 V, AVDD1 = 5 V, AVDD2 = 5 V, IOVDD = 2.5 V VIN = 1 V VIN = 0.1 V Up to 10 kHz −0.5 dBFS input on adjacent channels See the Clocking Selections section for performance functionality 95 8 32.768 32.768 50:50 34 12.2 12.2 MHz MHz % ns ns See the Logic Inputs parameter RL = 100 Ω 100 800 Time to first DRDY, fast mode, decimation by 32 tMCLK = 1/MCLK 1.58 650 1575 mV mV 1.88 V 1.66 ms 2 × tMCLK V 0.65 × IOVDD Low, VINL Hysteresis2 Leakage Current RESET pin7 0.04 −10 −10 Rev. B | Page 8 of 105 +0.03 0.7 0.09 +10 +10 V V μA μA Data Sheet Parameter LOGIC OUTPUTS Output Voltage2 High, VOH Low, VOL Leakage Current Output Capacitance SYSTEM CALIBRATION2 Full-Scale Calibration Limit Zero-Scale Calibration Limit Input Span POWER REQUIREMENTS Power Supply Voltage AVDD1 − AVSS AVDD2 − AVSS AVSS − DGND IOVDD − DGND POWER SUPPLY CURRENTS AD7768 Fast Mode AVDD1 Current AVDD2 Current IOVDD Current Median Mode AVDD1 Current AVDD2 Current IOVDD Current Low Power Mode AVDD1 Current AVDD2 Current IOVDD Current AD7768-4 Fast Mode AVDD1 Current AVDD2 Current IOVDD Current Median Mode AVDD1 Current AVDD2 Current IOVDD Current AD7768/AD7768-4 Test Conditions/Comments See Table 2 for 1.8 V operation Min ISOURCE = 200 μA ISINK = 400 μA Floating state Floating state 0.8 × IOVDD Typ −10 Max Unit 0.4 +10 V V μA pF 10 1.05 × VREF 2.1 × VREF V V V 2.5 to 3.3 5.5 5.5 0 3.6 V V V V 36/57.5 37.5 63 27 40/64 40 67 29 mA mA mA mA 18.5/29 21.3 34 16 20.5/32.5 23 37 18 mA mA mA mA 5.1/8 9.3 12.5 8 5.8/9 10.1 13.7 9 mA mA mA mA 18.2/28.8 18.8 43.5 37 20.3/32.5 20.3 46.8 40 mA mA mA mA 17 18.6 mA 9.3/14.7 10.7 24.4 21 10.5/16.6 11.7 26.4 23 mA mA mA mA 11 12.3 mA −1.05 × VREF 0.4 × VREF See Table 2 for 1.8 V operation Maximum output data rate, CMOS MCLK, eight DOUTx signals, all supplies at maximum voltages, all channels in Channel Mode A Eight channels active 4.5 2.0 −2.75 2.25 Precharge reference buffers off/on Wideband filter Sinc5 filter Precharge reference buffers off/on Wideband filter Sinc5 filter Precharge reference buffers off/on Wideband filter Sinc5 filter Four channels active Precharge reference buffers off/on Wideband filter2 Wideband filter, SPI mode only; Channel Mode A set to sinc5 filter8 Sinc5 filter2 Reference precharge buffers off/on Wideband filter2 Wideband filter, SPI mode only; Channel Mode A set to sinc5 filter8 Sinc5 filter2 Rev. B | Page 9 of 105 5.0 2.25 to 5.0 AD7768/AD7768-4 Parameter Low Power Mode AVDD1 Current AVDD2 Current IOVDD Current AD7768 and AD7768-4—Two Channels Active2 Fast Mode AVDD1 Current AVDD2 Current IOVDD Current Median Mode AVDD1 Current AVDD2 Current IOVDD Current Low Power Mode AVDD1 Current AVDD2 Current IOVDD Current Standby Mode Sleep Mode2 Crystal Excitation Current POWER DISSIPATION Full Operating Mode AD7768 Wideband Filter Fast Mode Data Sheet Test Conditions/Comments Min Precharge reference buffers off/on Wideband filter2 Wideband filter, SPI mode only; Channel Mode A set to sinc5 filter8 Sinc5 filter2 Serial peripheral interface (SPI) control mode only; see the Channel Standby section for details on disabling channels Precharge reference buffers off/on Wideband filter Wideband filter; disabled channels in Channel Mode A, and set to sinc5 filter mode8 Sinc5 filter Precharge reference buffers off/on Wideband filter Wideband filter; disabled channels in Channel Mode A, and set to sinc5 filter mode8 Sinc5 filter Precharge reference buffers off/on Wideband filter Wideband filter; disabled channels in Channel Mode A, and set to sinc5 filter mode8 Sinc5 filter All channels disabled (sinc5 filter enabled) Full power-down (SPI control mode only) Extra current in IOVDD when using an external crystal compared to using the CMOS MCLK External CMOS MCLK, all channels active, MCLK = 32.768 MHz, all channels in Channel Mode A except where otherwise specified Analog precharge buffers on AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V, precharge reference buffers off2 AVDD1 = 5 V, AVDD2 = IOVDD = 3.3 V, precharge reference buffers on2 AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off Rev. B | Page 10 of 105 Typ Max Unit 2.7/4.1 4.7 10 9 3.1/4.7 5.3 11.1 10 mA mA mA mA 6.5 7.6 mA 9.3/14.7 9.5 33.7 23.4 10.5/16.6 10.5 36.3 25.5 mA mA mA mA 11.9 13.3 mA 4.8/7.5 5.5 19.4 14.1 5.5/8.6 6.2 21.1 15.5 mA mA mA mA 8.5 9.6 mA 1.52/2.2 2.4 8.6 7.2 1.77/2.6 3 9.7 8 mA mA mA mA 5.8 6.5 0.73 540 6.7 8 1.2 mA mA mA μA 412 446 mW 600 645 mW 631 681 mW Data Sheet Parameter Median Mode Low Power Mode Sinc5 Filter Fast Mode Median Mode Low Power Mode AD7768-4 Wideband Filter Fast Mode Median Mode AD7768/AD7768-4 Test Conditions/Comments AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V, precharge reference buffers off2 AVDD1 = 5 V, AVDD2 = IOVDD = 3.3 V, precharge reference buffers on2 AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V, precharge reference buffers off2 AVDD1 = 5 V, AVDD2 = IOVDD = 3.3 V, precharge reference buffers on2 AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off Min AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V, precharge reference buffers off2 AVDD1 = 5 V, AVDD2 = IOVDD = 3.3 V, precharge reference buffers on2 AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V, precharge reference buffers off2 AVDD1 = 5 V, AVDD2 = IOVDD = 3.3 V, precharge reference buffers on2 AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V, precharge reference buffers off2 AVDD1 = 5 V, AVDD2 = IOVDD = 3.3 V, precharge reference buffers on2 AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V, precharge reference buffers off AVDD1 = 5 V, AVDD2 = IOVDD = 3.3 V, precharge reference buffers on AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off2 SPI mode only; AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off, Channel Mode A set to sinc5 filter8 AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V, precharge reference buffers off AVDD1 = 5 V, AVDD2 = IOVDD = 3.3 V, precharge reference buffers on AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off2 SPI mode only; AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off, Channel Mode A set to sinc5 filter8 Rev. B | Page 11 of 105 Typ 220 Max 240 Unit mW 320 345 mW 341 372 mW 75 85 mW 107 118 mW 124 137 mW 325 355 mW 475 525 mW 501 545 mW 175 195 mW 260 285 mW 277 304 mW 65 72 mW 95 105 mW 108 120 mW 235 mW 336 mW 360 392 mW 337 368 mW 127 mW 181 mW 198 218 mW 186 205 mW AD7768/AD7768-4 Parameter Low Power Mode Sinc5 Filter Fast Mode Median Mode Low Power Mode Standby Mode Sleep Mode2 Data Sheet Test Conditions/Comments AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V, precharge reference buffers off AVDD1 = 5 V, AVDD2 = IOVDD = 3.3 V, precharge reference buffers on AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off2 SPI mode only; AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off, Channel Mode A set to sinc5 filter8 Min AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V, precharge reference buffers off AVDD1 = 5 V, AVDD2 = IOVDD = 3.3 V, precharge reference buffers on AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V, precharge reference buffers off AVDD1 = 5 V, AVDD2 = IOVDD = 3.3 V, precharge reference buffers on AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V, precharge reference buffers off AVDD1 = 5 V, AVDD2 = IOVDD = 3.3 V, precharge reference buffers on AVDD1 = 5.5 V, AVDD2 = 5.5 V, IOVDD = 3.6 V, precharge reference buffers off All channels disabled (sinc5 filter enabled), AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V2 AVDD1 = 5 V, AVDD2 = IOVDD = 3.3 V2 AVDD1 = AVDD2 = 5.5 V, IOVDD = 3.6 V Full power-down (SPI control mode), AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V AVDD1 = 5 V, AVDD2 = IOVDD = 3.3 V AVDD1 = AVDD2 = 5.5 V, IOVDD = 3.6 V Typ 49 Max 66 Unit mW mW 77 87 mW 73 83 mW 168 mW 248 mW 265 291 mW 94 mW 137 mW 150 167 mW 40 mW 55 mW 64 1.8 2.5 2.7 74 mW 18 26 29 mW mW mW 4 5 6.5 mW mW mW 1 The output data rate ranges refer to the programmable decimation rates available on the AD7768/AD7668-4 for a fixed MCLK rate of 32.768 MHz. Varying MCLK rates allow users a wider variation of ODR. These specifications are not production tested but are supported by characterization data at initial product release. 3 See the Terminology section for more information about the fa and fb input frequencies. 4 Following a system zero-scale calibration, the offset error is in the order of the noise for the programmed output data rate selected. A system full-scale calibration reduces the gain error to the order of the noise for the programmed output data rate. 5 −25 μA is measured when the analog input is close to either the AVDD1 or AVSS rail. The input current reduces as the common-mode voltage approaches (AVDD1 − AVSS)/2. The analog input current scales with the MCLK frequency and device power mode. See Figure 85 and Figure 86 for more details on how the analog input current scales with input voltage. 6 For lower MCLK rates or higher decimation rates, use Table 28 and Table 29 to calculate any additional delay before the first DRDY pulse. 7 The RESET pin has an internal pull-up device to IOVDD. 8 Configuring Channel Mode A to the sinc5 filter and/or assigning disabled channels to Channel Mode A allows a lower power consumption to be achieved. To do this, the user must be operating in SPI control mode because it requires assigning channels to different channel modes (only possible in SPI control mode). If using pin control mode, all channels, whether active or in standby, are assigned to the same channel group and use the same filter type. This means that, in pin control mode, a higher current consumption is seen from disabled channels than can be achieved in SPI mode. See the Channel Modes section for more details. 2 E E Rev. B | Page 12 of 105 Data Sheet AD7768/AD7768-4 1.8 V IOVDD SPECIFICATIONS AVDD1A = AVDD1B = 4.5 V to 5.5 V, AVDD2A = AVDD2B = 2.0 V to 5.5 V, IOVDD = 1.72 V to 1.88 V, AVSS = DGND = 0 V, REFx+ = 4.096 V and REFx− = 0 V, MCLK = 32.76 8 MHz, analog precharge buffers on, reference precharge buffers off, wideband filter, fCHOP = fMOD/32, TA = −40°C to +105°C, unless otherwise noted. Table 2. Parameter DYNAMIC PERFORMANCE Fast Mode Dynamic Range SNR SINAD1 THD SFDR Median Mode Dynamic Range SNR SINAD THD SFDR Low Power Mode Dynamic Range SNR SINAD THD SFDR ACCURACY1 INL Offset Error2 Offset Error Drift Gain Error2 Gain Drift vs. Temperature LOGIC INPUTS Input Voltage1 High, VINH Low, VINL Hysteresis1 Leakage Current Test Conditions/Comments For dynamic range and SNR across all decimation rates, see Table 12 and Table 13 Decimation by 32, 256 kSPS ODR Shorted input, wideband filter Sinc5 filter, 1 kHz, −0.5 dBFS, sine wave input Wideband filter, 1 kHz, −0.5 dBFS, sine wave input 1 kHz, −0.5 dBFS, sine wave input 1 kHz, −0.5 dBFS, sine wave input Decimation by 32, 128 kHz ODR Shorted input, wideband filter 1 kHz, −0.5 dBFS, sine wave input Sinc5 filter Wideband filter 1 kHz, −0.5 dBFS, sine wave input 1 kHz, −0.5 dBFS, sine wave input Decimation by 32, 32 kHz ODR Shorted input, wideband filter Sinc5 filter, 1 kHz, −0.5 dBFS, sine wave input Wideband filter, 1 kHz, −0.5 dBFS, sine wave input 1 kHz, −0.5 dBFS, sine wave input 1 kHz, −0.5 dBFS, sine wave input Typ 106.2 109 106 103.8 108 111 107.8 107.5 −120 128 Max −107 dB 109 106 105.8 111 107.8 107.5 −120 128 dB dB dB dB dBc 106.2 109 106 105.8 108 111 107.8 107.5 −120 128 −113 −113 ±7 DCLK frequency ≤ 24 MHz 24 MHz to 32.768 MHz DCLK frequency DCLK frequency ≤ 24 MHz 24 MHz to 32.768 MHz DCLK frequency TA = 25°C ±50 ±75 ±250 ±750 ±60 ±0.5 ±115 ±170 0.04 −10 −10 +0.03 ±120 ±2 0.4 0.2 +10 +10 V V V μA μA 0.8 × IOVDD 0.4 +10 −10 10 Rev. B | Page 13 of 105 dB dB dB dB dB dBc ppm of FSR μV μV nV/°C nV/°C ppm/FSR ppm/°C 0.65 × IOVDD ISOURCE = 200 μA ISINK = 400 μA Floating state Floating state dB dB dB dB dB dBc 108 ±2 E Unit 106.2 Endpoint method RESET pin LOGIC OUTPUTS Output Voltage1 High, VOH Low, VOL Leakage Current Output Capacitance Min V V μA pF AD7768/AD7768-4 Parameter POWER REQUIREMENTS Power Supply Voltage AVDD1 − AVSS AVDD2 − AVSS AVSS − DGND IOVDD − DGND POWER SUPPLY CURRENTS1 AD7768 Fast Mode AVDD1 Current AVDD2 Current IOVDD Current Median Mode AVDD1 Current AVDD2 Current IOVDD Current Low Power Mode AVDD1 Current AVDD2 Current IOVDD Current AD7768-4 Fast Mode AVDD1 Current AVDD2 Current IOVDD Current Median Mode AVDD1 Current AVDD2 Current IOVDD Current Low Power Mode AVDD1 Current AVDD2 Current IOVDD Current Data Sheet Test Conditions/Comments DREGCAP shorted to IOVDD Maximum output data rate, CMOS MCLK, eight DOUTx signals, all supplies at maximum voltages, all channels in Channel Mode A except where otherwise specified Eight channels active Reference precharge buffers off/on Wideband filter Sinc5 filter Reference precharge buffers off/on Wideband filter Sinc5 filter Reference precharge buffers off/on Wideband filter Sinc5 filter Four channels active Reference precharge buffers off/on Wideband filter Wideband filter, SPI mode only; Channel Mode A set to sinc5 filter3 Sinc5 filter Reference precharge buffers off/on Wideband filter Wideband filter, SPI mode only; Channel Mode A set to sinc5 filter3 Sinc5 filter Reference precharge buffers off/on Wideband filter Wideband filter, SPI mode only; Channel Mode A set to sinc5 filter3 Sinc5 filter Rev. B | Page 14 of 105 Min Typ Max Unit 4.5 2.0 −2.75 1.72 5.0 2.25 to 5.0 1.8 5.5 5.5 0 1.88 V V V V 36/57.5 37.5 63 26 40/64 40 69 28.4 mA mA mA mA 18.5/29 21.3 34 15 20.5/32.5 23 36.8 16.8 mA mA mA mA 5.1/8 9.3 11.6 7 5.8/9 10.1 12.9 8.1 mA mA mA mA 18.2/28.8 18.8 43.9 36.8 20.3/32.5 20.3 47.7 41 mA mA mA mA 16 17.7 mA 9.3/14.7 10.7 24 20.4 10.5/16.6 11.7 26.1 22.7 mA mA mA mA 10 11.3 mA 2.7/4.1 4.7 9 8.1 3.1/4.7 5.3 10.2 9.2 mA mA mA mA 5.5 6.5 mA Data Sheet Parameter AD7768 and AD7768-4— Two Channels Active Fast Mode AVDD1 Current AVDD2 Current IOVDD Current Median Mode AVDD1 Current AVDD2 Current IOVDD Current Low Power Mode AVDD1 Current AVDD2 Current IOVDD Current Standby Mode Sleep Mode Crystal Excitation Current POWER DISSIPATION1 Full Operating Mode AD7768 Wideband Filter Fast Mode Median Mode Low Power Mode Sinc5 Filter Fast Mode Median Mode Low Power Mode AD7768/AD7768-4 Test Conditions/Comments SPI control mode only; see the Channel Standby section for details on disabling channels Typ Max Unit 9.3/14.7 9.5 33.8 23.1 10.5/16.6 10.5 36.7 25.6 mA mA mA mA 11 12.3 mA 4.8/7.5 5.5 18.9 13.4 5.5/8.6 6.2 20.6 15.1 mA mA mA mA 7.4 8.6 mA 1.52/2.2 2.4 7.6 6.3 1.77/2.6 3 8.8 7.2 mA mA mA mA 4.8 6.5 0.73 540 5.8 8 1.2 mA mA mA μA Reference precharge buffers off Reference precharge buffers on Reference precharge buffers off Reference precharge buffers on Reference precharge buffers off Reference precharge buffers on 524 638 284 342 98.5 118 571 704 309 375 109 130 mW mW mW mW mW mW Reference precharge buffers off Reference precharge buffers off Reference precharge buffers off 455 248 94 495 271 105 mW mW mW Reference precharge buffers off/on Wideband filter Wideband filter, SPI mode only; disabled channels in Channel Mode A, and set to sinc5 filter3 Sinc5 filter Reference precharge buffers off/on Wideband filter Wideband filter, SPI mode only; disabled channels in Channel Mode A, and set to sinc5 filter3 Sinc5 filter Precharge reference buffers off/on Wideband filter Wideband filter, SPI mode only; disabled channels in Channel Mode A, and set to sinc5 filter3 Sinc5 filter All channels disabled (sinc5 filter enabled) Full power-down (SPI control mode) Extra current in IOVDD when using an external crystal compared to using the CMOS MCLK External CMOS MCLK, all channels active, AVDD1 = AVDD2 = 5.5 V, IOVDD = 1.88 V, MCLK = 32.768 MHz, all channels in Channel Mode A except where otherwise noted Analog precharge buffers on Eight channels active Rev. B | Page 15 of 105 Min AD7768/AD7768-4 Parameter AD7768-4 Wideband Filter Fast Mode Median Mode Low Power Mode Sinc5 Filter Fast Mode Median Mode Low Power Mode Standby Mode Sleep Mode Data Sheet Test Conditions/Comments Four channels active Min Typ Max Unit Reference precharge buffers off Reference precharge buffers on Reference precharge buffers off Reference precharge buffers on Reference precharge buffers off Reference precharge buffers on 287 345 156 185 58 66 314 381 172 206 66 75 mW mW mW mW mW mW Reference precharge buffers off Reference precharge buffers off Reference precharge buffers off All channels disabled (sinc5 filter enabled) Full power-down (SPI control mode) 234 129 51 257 144 59 17 4.5 mW mW mW mW mW 1 1.5 These specifications are not production tested but are supported by characterization data at initial product release. Following a system zero-scale calibration, the offset error is in the order of the noise for the programmed output data rate selected. A system full-scale calibration reduces the gain error to the order of the noise for the programmed output data rate. 3 This configuration of setting Channel Mode A to the sinc5 filter and/or assigning disabled channels to Channel Mode A allows a lower power consumption to be achieved due to the disabling of internal clocks on the disabled only and sinc5 only channel modes. This configuration requires assigning sinc5 and wideband filters to different channels, or channel modes, and is only available in SPI control mode. In pin control mode, all channels, whether active or in standby, effectively use the same channel mode. See the Channel Modes section for more details. 2 Rev. B | Page 16 of 105 Data Sheet AD7768/AD7768-4 TIMING SPECIFICATIONS AVDD1A = AVDD1B = 5 V, AVDD2A = AVDD2B = 5 V, IOVDD = 2.25 V to 3.6 V, Input Logic 0 = DGND, Input Logic 1 = IOVDD; CLOAD = 10 pF on the DCLK pin, CLOAD = 20 pF on the other digital outputs; REFx+ = 4.096 V, TA = −40°C to +105°C. See Table 5 and Table 6 for timing specifications at 1.8 V IOVDD. Table 3. Data Interface Timing1 Parameter MCLK fMOD Description Master clock Modulator frequency t1 t2 t3 t4 t5 t6 t7 t8 t10 t11 DRDY high time DCLK rising edge to DRDY rising edge DCLK rising to DRDY falling DCLK rise to DOUTx valid DCLK rise to DOUTx invalid DOUTx valid to DCLK falling DCLK falling edge to DOUTx invalid DCLK high time, DCLK = MCLK/1 t8a = DCLK = MCLK/2 t8b = DCLK = MCLK/4 t8c = DCLK = MCLK/8 DCLK low time DCLK = MCLK/1 t9a = DCLK = MCLK/2 t9b = DCLK = MCLK/4 t9c = DCLK = MCLK/8 MCLK rising to DCLK rising Setup time (daisy-chain inputs) t12 Hold time (daisy-chain inputs) t13 t14 START low time MCLK to SYNC_OUT valid t9 t15 t16 1 SYNC_IN setup time SYNC_IN hold time Test Conditions/Comments Fast mode Median mode Low power mode tDCLK = t8 + t9 Min 1.15 Typ 14 Unit MHz Hz Hz Hz ns ns ns ns ns ns ns ns ns ns ns ns ns ns ns ns ns 0 ns 1 × tMCLK ns tDCLK − 10% Max 34 MCLK/4 MCLK/8 MCLK/32 28 2 0 1.5 −3.5 50:50 CMOS clock tMCLK = 1/MCLK 50:50 CMOS clock CMOS clock DOUT6 and DOUT7 on the AD7768, DIN on the AD7768-4 DOUT6 and DOUT7 on the AD7768, DIN on the AD7768-4 CMOS clock SYNC_OUT RETIME_EN bit disabled; measured from falling edge of MCLK SYNC_OUT RETIME_EN bit enabled; measured from rising edge of MCLK CMOS clock CMOS clock −3 9.5 9.5 tDCLK/2 (tDCLK/2) − 5 tDCLK/2 tDCLK/2 tDCLK/2 tMCLK 2 × tMCLK 4 × tMCLK tMCLK/2 tMCLK 2 × tMCLK 4 × tMCLK (tDCLK/2) + 5 tDCLK/2 30 4.5 22 ns 9.5 27.5 ns 0 10 ns ns These specifications are not production tested but are supported by characterization data at initial product release. Table 4. SPI Control Interface Timing1 Parameter t17 t18 t19 t20 t21 t22 t23 t24 t25 t26 t27 Description SCLK period CS falling edge to SCLK rising edge SCLK falling edge to CS rising edge CS falling edge to data output enable SCLK high time SCLK low time SCLK falling edge to SDO valid SDO hold time after SCLK falling SDI setup time SDI hold time SCLK enable time Test Conditions/Comments Min 100 26.5 27 22.5 20 20 Typ Max 40.5 50 50 15 7 0 6 0 Rev. B | Page 17 of 105 Unit ns ns ns ns ns ns ns ns ns ns ns AD7768/AD7768-4 Parameter t28 t29 t30 1 Description SCLK disable time CS high time CS low time Data Sheet Test Conditions/Comments Min 0 10 1.1 × tMCLK 2.2 × tMCLK 8.8 × tMCLK fMOD = MCLK/4 fMOD = MCLK/8 fMOD = MCLK/32 Typ Max Unit ns ns ns ns ns These specifications are not production tested but are supported by characterization data at initial product release. 1.8 V IOVDD TIMING SPECIFICATIONS AVDD1A = AVDD1B = 5 V, AVDD2A = AVDD2B = 5 V, IOVDD = 1.72 V to 1.88 V (DREGCAP tied to IOVDD), Input Logic 0 = DGND, Input Logic 1 = IOVDD, CLOAD = 10 pF on DCLK pin, CLOAD = 20 pF on other digital outputs, TA = −40°C to +105°C. Table 5. Data Interface Timing1 Parameter MCLK fMOD Description Master clock Modulator frequency t1 t2 t3 t4 t5 t6 t7 t8 t10 t11 DRDY high time DCLK rising edge to DRDY rising edge DCLK rising to DRDY falling DCLK rise to DOUTx valid DCLK rise to DOUTx invalid DOUTx valid to DCLK falling DCLK falling edge to DOUTx invalid DCLK high time, DCLK = MCLK/1 t8a = DCLK = MCLK/2 t8b = DCLK = MCLK/4 t8c = DCLK = MCLK/8 DCLK low time DCLK=MCLK/1 t9a = DCLK = MCLK/2 t9b = DCLK = MCLK/4 t9c = DCLK = MCLK/8 MCLK rising to DCLK rising Setup time (daisy-chain inputs) t12 Hold time (daisy-chain inputs) t13 t14 START low time MCLK to SYNC_OUT valid t9 t15 t16 1 SYNC_IN setup time SYNC_IN hold time Test Conditions/Comments Min 1.15 14 Unit MHz Hz Hz Hz ns ns ns ns ns ns ns ns ns ns ns ns ns ns ns ns ns 0 ns 1 × tMCLK ns Fast mode Median mode Low power mode tDCLK − 10% Typ MCLK/4 MCLK/8 MCLK/32 28 2 0 2.0 −4.5 50:50 CMOS clock −4 8.5 8.5 tDCLK/2 50:50 CMOS clock (tDCLK/2) − 5 CMOS clock DOUT6 and DOUT7 on the AD7768, DIN on the AD7768-4 DOUT6 and DOUT7 on the AD7768, DIN on the AD7768-4 CMOS clock SYNC_OUT RETIME_EN bit disabled; measured from falling edge of MCLK SYNC_OUT RETIME_EN bit enabled; measured from rising edge of MCLK CMOS clock CMOS clock tDCLK/2 tDCLK/2 tDCLK/2 tMCLK 2 × tMCLK 4 × tMCLK tMCLK/2 tMCLK 2 × tMCLK 4 × tMCLK (tDCLK/2) + 5 (tDCLK/2 37 10 31 ns 15 37 ns 0 11 These specifications are not production tested but are supported by characterization data at initial product release. Rev. B | Page 18 of 105 Max 34 ns ns Data Sheet AD7768/AD7768-4 Table 6. SPI Control Interface Timing1 Parameter t17 t18 t19 t20 t21 t22 t23 t24 t25 t26 t27 t28 t29 t30 1 Description SCLK period CS falling edge to SCLK rising edge SCLK falling edge to CS rising edge CS falling edge to data output enable SCLK high time SCLK low time SCLK falling edge to SDO valid SDO hold time after SCLK falling SDI setup time SDI hold time SCLK enable time SCLK disable time CS high time CS low time Test Conditions/Comments Min 100 31.5 30 29 20 20 Typ Max 54 50 50 16 7 0 10 0 0 10 1.1 × tMCLK 2.2 × tMCLK 8.8 × tMCLK fMOD = MCLK/4 fMOD = MCLK/8 fMOD = MCLK/32 These specifications are not production tested but are supported by characterization data at initial product release. Timing Diagrams t1 tODR DRDY t2 t8 DCLK t3 MSB LSB 14001-002 LSB t9 t6 t7 Figure 2. Data Interface Timing Diagram MCLK t10 t8a DCLK = MCLK/2 t9a t8b DCLK = MCLK/4 t9b t8c DCLK = MCLK/8 t9c Figure 3. MCLK to DCLK Divider Timing Diagram Rev. B | Page 19 of 105 14001-003 DOUTx t5 t4 Unit ns ns ns ns ns ns ns ns ns ns ns ns ns ns ns ns AD7768/AD7768-4 Data Sheet tODR DRDY DCLK t11 DOUT6 AND DOUT7 14001-004 t12 Figure 4. Daisy-Chain Setup and Hold Timing Diagram MCLK START t14 14001-005 t13 SYNC_OUT Figure 5. Asynchronous START and SYNC_OUT Timing Diagram MCLK t15 t16 14001-006 SYNC_IN t15 Figure 6. Synchronous SYNC_IN Pulse Timing Diagram E t30 CS t18 t17 t19 t21 SCLK SDO MSB t20 t24 Figure 7. SPI Serial Read Timing Diagram Rev. B | Page 20 of 105 t23 14001-007 t22 Data Sheet AD7768/AD7768-4 t30 CS t18 SCLK t25 MSB 14001-008 SDI t26 LSB Figure 8. SPI Serial Write Timing Diagram t29 CS t28 t27 Figure 9. SCLK Enable and Disable Timing Diagram Rev. B | Page 21 of 105 14001-009 SCLK AD7768/AD7768-4 Data Sheet ABSOLUTE MAXIMUM RATINGS THERMAL RESISTANCE Table 7. Parameter AVDD1, AVDD2 to AVSS1 AVDD1 to DGND IOVDD to DGND IOVDD, DREGCAP to DGND (IOVDD Tied to DREGCAP for 1.8 V Operation) IOVDD to AVSS AVSS to DGND Analog Input Voltage to AVSS Reference Input Voltage to AVSS Digital Input Voltage to DGND Digital Output Voltage to DGND Operating Temperature Range Storage Temperature Range Pb-Free Temperature, Soldering Reflow (10 sec to 30 sec) Maximum Junction Temperature Maximum Package Classification Temperature 1 Thermal performance is directly linked to PCB design and operating environment. Careful attention to PCB thermal design is required. Rating −0.3 V to +6.5 V −0.3 V to +6.5 V −0.3 V to +6.5 V −0.3 V to +2.25 V Table 8. Thermal Resistance −0.3 V to +7.5 V −3.25 V to +0.3 V −0.3 V to AVDD1 + 0.3 V −0.3 V to AVDD1 + 0.3 V −0.3 V to IOVDD + 0.3 V −0.3 V to IOVDD + 0.3 V −40°C to +105°C −65°C to +150°C 260°C Package Type ST-64-2 1 θJA 38 θJC 9.2 Unit °C/W JEDEC Board Layers 2P2S1 2P2S is a JEDEC standard PCB configuration per JEDEC Standard JESD51-7. ESD CAUTION 150°C 260°C Transient currents of up to 100 mA do not cause silicon controlled rectifier (SCR) latch-up. Stresses at or above those listed under Absolute Maximum Ratings may cause permanent damage to the product. This is a stress rating only; functional operation of the product at these or any other conditions above those indicated in the operational section of this specification is not implied. Operation beyond the maximum operating conditions for extended periods may affect product reliability. Rev. B | Page 22 of 105 Data Sheet AD7768/AD7768-4 AIN4+ AIN4– AVSS2B REGCAPB AVDD2B AVSS FORMAT1 FORMAT0 PIN/SPI CLK_SEL VCM AVDD2A REGCAPA AVSS2A AIN0– AIN0+ PIN CONFIGURATIONS AND FUNCTION DESCRIPTIONS 64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 AIN1– 1 48 AIN5– AIN1+ 2 47 AIN5+ AVSS1A 3 46 AVSS1B AVDD1A 4 45 AVDD1B REF1– 5 44 REF2– REF1+ 6 43 REF2+ AIN2– 7 42 AIN6– AIN2+ 8 41 AIN6+ AIN3– 9 40 AIN7– AIN3+ 10 39 AIN7+ FILTER/GPIO4 11 38 SYNC_OUT MODE0/GPIO0 12 37 START MODE1/GPIO1 13 36 SYNC_IN MODE2/GPIO2 14 35 IOVDD MODE3/GPIO3 15 34 DREGCAP ST0/CS 16 33 DGND AD7768 TOP VIEW (Not to Scale) XTAL2/MCLK XTAL1 RESET DRDY DCLK DOUT0 DOUT1 DOUT2 SUPPLY AND GROUND PINS DIGITAL PINS 14001-010 ANALOG INPUTS AND OUTPUTS DECOUPLING CAPACITOR PINS DOUT3 DOUT4 DOUT5 DOUT6 DOUT7 DEC0/SDO DEC1/SDI ST1/SCLK 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 Figure 10. AD7768 Pin Configuration Table 9. Pin Function Descriptions Pin No. 1 2 3 4 5 Mnemonic AIN1− AIN1+ AVSS1A AVDD1A REF1− Type1 AI AI P P AI 6 REF1+ AI 7 8 9 10 11 AIN2− AIN2+ AIN3− AIN3+ FILTER/GPIO4 AI AI AI AI DI/O Description Negative Analog Input to ADC Channel 1. Positive Analog Input to ADC Channel 1. Negative Analog Supply. This pin is nominally 0 V. Analog Supply Voltage, 5 V ± 10% with Respect to AVSS. Reference Input, Negative. REF1− is the negative reference terminal for Channel 0 to Channel 3. The REF1− voltage range is from AVSS to (AVDD1 − 1 V). Decouple this pin to AVSS with a high quality capacitor, and maintain a low impedance between this capacitor and Pin 3. Reference Input, Positive. REF1+ is the positive reference terminal for Channel 0 to Channel 3. The REF1+ voltage range is from (AVSS + 1 V) to AVDD1. Apply an external differential reference voltage between REF1+ and REF1− in the range from 1 V to |AVDD1 − AVSS|. Decouple this pin to AVSS with a high quality capacitor, and maintain a low impedance between this capacitor and Pin 3. Negative Analog Input to ADC Channel 2. Positive Analog Input to ADC Channel 2. Negative Analog Input to ADC Channel 3. Positive Analog Input to ADC Channel 3. Filter Select/General-Purpose Input/Output 4. In pin control mode, this pin selects the filter type. Set this pin to Logic 1 for the sinc5 filter. This sinc5 filter is a low latency filter, and is best for dc applications or when a user has specialized postfiltering implemented off chip. Set this pin to Logic 0 for the wideband low ripple filter response. This filter has a steep transition band and 105 dB stop band attenuation. Full attenuation at Nyquist (ODR/2) means that no aliasing occurs at ODR/2 out to the first chopping zone. In SPI control mode, this pin can be used as a general-purpose input/output (GPIO4). For further information on GPIO configuration, see the GPIO Functionality section. In SPI control mode, when not used as a GPIO pin and when a crystal is used as the clock source, this pin must be set to 1. Rev. B | Page 23 of 105 AD7768/AD7768-4 Data Sheet Pin No. 12, 13, 14, 15 Mnemonic MODE0/GPIO0, MODE1/GPIO1, MODE2/GPIO2, MODE3/GPIO3 Type1 DI/DI/O 16 ST0/CS DI 17 ST1/SCLK DI 18 DEC1/SDI DI 19 DEC0/SDO DI/O 20 DOUT7 DI/O 21 DOUT6 DI/O 22 23 24 25 26 27 28 DOUT5 DOUT4 DOUT3 DOUT2 DOUT1 DOUT0 DCLK DO DO DO DO DO DO DO 29 DRDY DO 30 RESET DI Description Mode Selection/General-Purpose Input/Output Pin 0 to Pin 3. In pin control mode, the MODEx pins set the mode of operation for all ADC channels, controlling power consumption, DCLK frequency, and the ADC conversion type, allowing one-shot conversion operation. In SPI control mode, the GPIOx pins, in addition to the FILTER/GPIO4 pin, form five generalpurpose input/output pins (GPIO4 to GPIO0). Standby 0/Chip Select Input. In pin control mode, a Logic 1 places Channel 0 to Channel 3 into standby mode. In SPI control mode, this pin is the active low chip select input to the SPI control interface. The VCM voltage output is associated with the Channel 0 circuitry. If Channel 0 is put into standby mode, the VCM voltage output is also disabled for maximum power savings. Channel 0 must be enabled while VCM is being used externally to the AD7768. Standby 1/Serial Clock Input. In pin control mode, a Logic 1 on this pin places Channel 4 to Channel 7 into standby mode. The crystal excitation circuitry is associated with the Channel 4 circuitry. If Channel 4 is placed into standby mode, the crystal circuitry is also disabled for maximum power savings. Channel 4 must be enabled while the external crystal is used on the AD7768. In SPI control mode, this pin is the serial clock input pin for the SPI control interface. Decimation Rate Control Input 1/Serial Data Input. In pin control mode, the DEC0 and DEC1 pins configure the decimation rate for all ADC channels. See Table 17 in the Setting the Decimation Rate section for more information. In SPI control mode, this pin is the serial data input pin used to write data to the AD7768 register bank. Decimation Rate Control Input 0/Serial Data Output. In pin control mode, the DEC0 and DEC1 pins configure the decimation rate for all ADC channels. See Table 17 in the Setting the Decimation Rate section for more information. In SPI control mode, this pin is the serial data output pin, allowing readback from the AD7768 registers. Conversion Data Output 7. This pin is synchronous to DCLK and framed by DRDY. This pin acts as a digital input from a separate AD7768 device if configured in a synchronized multidevice daisy chain when the FORMATx pins are configured as 01. To use the AD7768 in a daisy chain, hardwire the FORMATx pins as 01, 10, or 11, depending on the best interfacing format for the application. When FORMATx is set to 01, 10, or 11, and daisy-chaining is not used, connect this pin to ground through a pull-down resistor. Conversion Data Output 6. This pin is synchronous to DCLK and framed by DRDY. This pin acts as a digital input from a separate AD7768 device if configured in a synchronized multidevice daisy chain. To use this pin in a daisy chain, hardwire the FORMATx pins as 01, 10, or 11, depending on the best interfacing format for the application. When FORMATx is set to 01, 10, or 11, and daisy chaining is not used, connect this pin to ground through a pull-down resistor. Conversion Data Output 5. This pin is synchronous to DCLK and framed by DRDY. Conversion Data Output 4. This pin is synchronous to DCLK and framed by DRDY. Conversion Data Output 3. This pin is synchronous to DCLK and framed by DRDY. Conversion Data Output 2. This pin is synchronous to DCLK and framed by DRDY. Conversion Data Output 1. This pin is synchronous to DCLK and framed by DRDY. Conversion Data Output 0. This pin is synchronous to DCLK and framed by DRDY ADC Conversion Data Clock. This pin clocks conversion data out to the digital host (digital signal processor (DSP)/field-programmable gate array (FPGA)). This pin is synchronous with DRDY and any conversion data output on DOUT0 to DOUT7 and is derived from the MCLK signal. This pin is unrelated to the control SPI interface. Data Ready. DRDY is a periodic signal output framing the conversion results from the eight ADCs. This pin is synchronous to DCLK and DOUT0 to DOUT7. Hardware Asynchronous Reset Input. After the device is fully powered up, it is recommended to perform a hard reset using this pin or, alternatively, to perform a soft reset by issuing a reset over the SPI control interface E E Rev. B | Page 24 of 105 Data Sheet AD7768/AD7768-4 Pin No. 31 Mnemonic XTAL1 Type1 DI 32 XTAL2/MCLK DI 33 34 DGND DREGCAP P AO 35 IOVDD P 36 SYNC_IN DI 37 START DI 38 SYNC_OUT DO 39 40 41 42 AIN7+ AIN7− AIN6+ AIN6− AI AI AI AI Description Input 1 for Crystal or Connection to an LVDS Clock. When CLK_SEL is 0, connect XTAL1 to DGND. In SPI control mode, when using a crystal source, the FILTER pin must be set to Logic 1 for correct operation. The crystal excitation circuitry is associated with the Channel 4 circuitry. If Channel 4 is put into standby mode, the crystal circuitry is also disabled for maximum power savings. Channel 4 must be enabled while the external crystal is used on the AD7768. When used with an LVDS clock, connect this pin to one trace of the LVDS signal pair. When used as an LVDS input, a rising edge on this pin is detected as a rising MCLK edge by the AD7768. Input 2 for CMOS or Crystal/LVDS Sampling Clock. See the CLK_SEL pin for the details of this configuration. External crystal: XTAL2 is connected to the external crystal. In SPI control mode, when using a crystal source, the FILTER pin must be set to Logic 1 for correct operation. LVDS clock: when used with an LVDS clock, connect this pin to the second trace of the LVDS signal pair. CMOS clock: this pin operates as an MCLK input. This pin is a CMOS input with a logic level of IOVDD/DGND. When used as a CMOS clock input, a rising edge on this pin is detected as a rising MCLK edge by the AD7768. The crystal excitation circuitry is associated with the Channel 4 circuitry. If Channel 4 is put into standby mode, the crystal circuitry is also disabled for maximum power savings. Channel 4 must be enabled while the external crystal is used on the AD7768. Digital Ground. This pin is nominally 0 V. Digital Low Dropout (LDO) Regulator Output. Decouple this pin to DGND with a high quality, low equivalent series resistance (ESR), 10 μF capacitor. For optimum performance, use a decoupling capacitor with an ESR specification of less than 400 mΩ. This pin is not for use in circuits external to the AD7768. For 1.8 V IOVDD operation, connect this pin to IOVDD via an external trace to provide power to the digital processing core. Digital Supply. This pin sets the logic levels for all interface pins. IOVDD also powers the digital processing core via the digital LDO when IOVDD is at least 2.25 V. For 1.8 V IOVDD operation, connect this pin to DREGCAP via an external trace to provide power to the digital processing core. Synchronization Input. SYNC_IN receives the synchronous signal from SYNC_OUT. It is used in the synchronization of any AD7768 that requires simultaneous sampling or is in a daisy chain. Ignore the START and SYNC_OUT functions if the SYNC_IN pin is connected to the system synchronization pulse. This signal pulse must be synchronous to the MCLK clock domain. In a daisy-chained system of AD7768 devices, two successive synchronization pulses must be applied to guarantee that all ADCs are synchronized. Two synchronization pulses are also required in a system of more than one AD7768 device sharing a single MCLK signal, where the DRDY pin of only one device is used to detect new data. Start Signal. The START pulse synchronizes the AD7768 to other devices. The signal can be asynchronous. The AD7768 samples the input and then outputs a SYNC_OUT pulse. This SYNC_OUT pulse must be routed to the SYNC_IN pin of this device, and any other AD7768 devices that must be synchronized together. This means that the user does not need to run the ADCs and their digital host from the same clock domain, which is useful when there are long traces or back planes between the ADC and the controller. If this pin is not used, it must be tied to a Logic 1 through a pull-up resistor. In a daisy-chained system of AD7768 devices, two successive synchronization pulses must be applied to guarantee that all ADCs are synchronized. Two synchronization pulses are also required in a system of more than one AD7768 device sharing a single MCLK signal, where the DRDY pin of only one device is used to detect new data. Synchronization Output. This pin operates only when the START input is used. When using the START input feature, the SYNC_OUT pin must be connected to SYNC_IN via an external trace. SYNC_OUT is a digital output that is synchronous to the MCLK signal; the synchronization signal driven in on START is internally synchronized to the MCLK signal and is driven out on SYNC_OUT. SYNC_OUT can also be routed to other AD7768 devices requiring simultaneous sampling and/or daisy-chaining, ensuring synchronization of devices related to the MCLK clock domain. It must then be wired to drive the SYNC_IN pin on the same AD7768 and on the other AD7768 devices. Positive Analog Input to ADC Channel 7. Negative Analog Input to ADC Channel 7. Positive Analog Input to ADC Channel 6. Negative Analog Input to ADC Channel 6. Rev. B | Page 25 of 105 AD7768/AD7768-4 Data Sheet Pin No. 43 Mnemonic REF2+ Type1 AI 44 REF2− AI 45 46 47 48 49 50 51 52 53 54 55, 56 AVDD1B AVSS1B AIN5+ AIN5− AIN4+ AIN4− AVSS2B REGCAPB AVDD2B AVSS FORMAT1, FORMAT0 P P AI AI AI AI P AO P P DI 57 PIN/SPI DI 58 CLK_SEL DI 59 VCM AO 60 61 62 63 64 AVDD2A REGCAPA AVSS2A AIN0− AIN0+ P AO P AI AI 1 Description Reference Input, Positive. REF2+ is the positive reference terminal for Channel 4 to Channel 7. The REF2+ voltage range is from (AVSS + 1 V) to AVDD1. Apply an external differential reference voltage between REF2+ and REF2− in the range from 1 V to |AVDD1 − AVSS|. Decouple this pin to AVSS with a high quality capacitor, and maintain a low impedance between this capacitor and Pin 46. Reference Input, Negative. REF2− is the negative reference terminal for Channel 4 to Channel 7. The REF2− voltage range is from AVSS to (AVDD1 − 1 V). Decouple this pin to AVSS with a high quality capacitor, and maintain a low impedance between this capacitor and Pin 46. Analog Supply Voltage. This pin is 5 V ± 10% with respect to AVSS. Negative Analog Supply. This pin is nominally 0 V. Positive Analog Input to ADC Channel 5. Negative Analog Input to ADC Channel 5. Positive Analog Input to ADC Channel 4. Negative Analog Input to ADC Channel 4. Negative Analog Supply. This pin is nominally 0 V. Analog LDO Regulator Output. Decouple this pin to AVSS with a 1 μF capacitor. Analog Supply Voltage. This pin is 2 V to 5.5 V with respect to AVSS. Negative Analog Supply. This pin is nominally 0 V. Format Selection Pins. Hardwire the FORMATx pins to the required values in pin control and SPI control mode. These pins set the number of DOUTx pins used to output ADC conversion data. The FORMATx pins are checked by the AD7768 on power-up; the AD7768 then remains in this data output configuration (see Table 33). Pin Control/SPI Control. This pin sets the control method. Logic 0 = pin control mode for the AD7768. Pin control mode allows a pin strapped configuration of the AD7768 by tying logic input pins to required logic levels. Tie the logic pins (MODE0 to MODE4, DEC0 and DEC1, and FILTER) as required for the configuration. See the Pin Control section for more details. Logic 1 = SPI control mode for the AD7768. Use the SPI control interface signals (CS, SCLK, SDI, and SDO) for reading and writing to the AD7768 memory map. Clock Select. Logic 0 = pull this pin low for the CMOS clock option. The clock is applied to Pin 32 (Connect Pin 31 to DGND). Logic 1 = pull this pin high for the crystal or LVDS clock option. The crystal or LVDS clock is applied to Pin 31 and Pin 32. The LVDS option is available only in SPI control mode. A write is required to enable the LVDS clock option. Common-Mode Voltage Output. This pin outputs (AVDD1 − AVSS)/2 V, which is 2.5 V by default in pin control mode. Configure this pin to (AVDD1 − AVSS)/2 V, 2.5 V, 2.14 V, or 1.65 V in SPI control mode. When driving capacitive loads larger than 0.1 μF, it is recommended to place a 50 Ω series resistor between this pin and the capacitive load for stability. The VCM voltage output is associated with the Channel 0 circuitry. If Channel 0 is put into standby mode, the VCM voltage output is also disabled for maximum power savings. Channel 0 must be enabled while VCM is being used externally to the AD7768. Analog Supply Voltage. This pin is 2 V to 5.5 V with respect to AVSS. Analog LDO Regulator Output. Decouple this pin to AVSS with a 1 μF capacitor. Negative Analog Supply. This pin is nominally 0 V. Negative Analog Input to ADC Channel 0. Positive Analog Input to ADC Channel 0. AI is analog input, P is power, DI/O is digital input/output, DI is digital input, DO is digital output, and AO is analog output. Rev. B | Page 26 of 105 AIN2+ AIN2– AVSS2B REGCAPB AVDD2B AVSS DGND FORMAT0 PIN/SPI CLK_SEL VCM AVDD2A REGCAPA AVSS2A AIN0– AD7768/AD7768-4 AIN0+ Data Sheet 64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 AIN1– 1 48 AIN3– AIN1+ 2 47 AIN3+ AVSS1A 3 46 AVSS1B AVDD1A 4 45 AVDD1B REF1– 5 44 REF2– REF1+ 6 43 REF2+ AVSS 7 42 AVSS AVSS 8 41 AVSS AVSS 9 40 AVSS AVSS 10 39 AVSS FILTER/GPIO4 11 38 SYNC_OUT MODE0/GPIO0 12 37 START MODE1/GPIO1 13 36 SYNC_IN MODE2/GPIO2 14 35 IOVDD MODE3/GPIO3 15 34 DREGCAP 33 DGND ST0/CS AD7768-4 TOP VIEW (Not to Scale) 16 XTAL2/MCLK XTAL1 RESET DRDY DCLK DOUT0 DOUT1 DOUT2 DOUT3 SUPPLY AND GROUND PINS DIGITAL PINS NOTES 1. DNC = DO NOT CONNECT. DO NOT CONNECT TO THIS PIN. 14001-011 ANALOG INPUTS AND OUTPUTS DECOUPLING CAPACITOR PINS DNC DNC DIN DNC/DGND DEC0/SDO SCLK DEC1/SDI 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 Figure 11. AD7768-4 Pin Configuration Table 10. AD7768-4 Pin Function Descriptions Pin No. 1 2 3 4 5 Mnemonic AIN1− AIN1+ AVSS1A AVDD1A REF1− Type1 AI AI P P AI 6 REF1+ AI 7 to 10, 39 to 42, 54 11 AVSS AI FILTER/GPIO4 DI/O Description Negative Analog Input to ADC Channel 1. Positive Analog Input to ADC Channel 1. Negative Analog Supply. This pin is nominally 0 V. Analog Supply Voltage, 5 V ± 10% with respect to AVSS. Reference Input Negative. REF1− is the negative reference terminal for Channel 0 and Channel 1. The REF1− voltage range is from AVSS to (AVDD1 − 1 V). Decouple this pin to AVSS with a high quality capacitor, and maintain a low impedance between this capacitor and Pin 3. Reference Input Positive. REF1+ is the positive reference terminal for Channel 0 and Channel 1. The REF1+ voltage range is from (AVSS + 1 V) to AVDD1. Apply an external differential reference voltage between REF1+ and REF1− in the range from 1 V to |AVDD1 − AVSS|. Decouple this pin to AVSS with a high quality capacitor, and maintain a low impedance between this capacitor and Pin 3. Negative Analog Supply. This pin is nominally 0 V. Filter Select/General-Purpose Input/Output 4. In pin control mode, this pin selects the filter type. Set this pin to Logic 1 for the sinc5 filter. This sinc5 filter is a low latency filter, and is best for dc applications or where a user has specialized postfiltering implemented off chip. Set this pin to Logic 0 for the wideband low ripple filter response. This filter has a steep transition band and 105 dB stop band attenuation. Full attenuation at Nyquist (ODR/2) means that no aliasing occurs at ODR/2 out to the first chopping zone. In SPI control mode, this pin can be used as a general-purpose input/output (GPIO4). For further information on GPIO configuration, see the GPIO Functionality section. In SPI control mode, when not used as a GPIO pin, and when a crystal will be used as the clock source, this pin must be set to 1. Rev. B | Page 27 of 105 AD7768/AD7768-4 Data Sheet Pin No. 12, 13, 14, 15 Mnemonic MODE0/GPIO0, MODE1/GPIO1, MODE2/GPIO2, MODE3/GPIO3 Type1 DI/DI/O 16 ST0/CS DI 17 SCLK DI 18 DEC1/SDI DI 19 DEC0/SDO DI/O 20 DNC/DGND DO/DI 21 DIN DI 22, 23 24 25 26 27 28 DNC DOUT3 DOUT2 DOUT1 DOUT0 DCLK DO DO DO DO DO DO 29 DRDY DO 30 RESET DI 31 XTAL1 DI Description Mode Selection/General-Purpose Input/Output Pin 0 to Pin 3. In pin control mode, the MODEx pins set the mode of operation for all ADC channels, controlling power consumption, DCLK frequency, and the ADC conversion type, allowing one-shot conversion operation. In SPI control mode, the GPIOx pins, in addition to the FILTER/GPIO4 pin, form five generalpurpose input/output pins (GPIO4 to GPIO0). See Table 75 for more details. Standby 0/Chip Select Input. In pin control mode, a Logic 1 on this pin places Channel 0 to Channel 3 into standby mode. In SPI control mode, this pin is the active low chip select input to the SPI control interface. The VCM voltage output is associated with the Channel 0 circuitry. If Channel 0 is put into standby mode, the VCM voltage output is also disabled for maximum power savings. Channel0 must be enabled while VCM is being used externally to the AD7768-4. The crystal excitation circuitry is associated with the Channel 2 circuitry. If Channel 2 is put into standby mode, the crystal circuitry is also disabled for maximum power savings. Channel 2 must be enabled while the external crystal is used on the AD7768-4. Serial Clock Input. In SPI control mode, this pin is the serial clock input pin for the SPI control interface. In pin control mode, tie this pin to a Logic 0 or DGND. Decimation Rate Control Input 1/Serial Data Input. In pin control mode, the DEC0 and DEC1 pins configure the decimation rate for all ADC channels. See Table 17 in the Setting the Decimation Rate section. In SPI control mode, this pin is the serial data input pin used to write data to the AD7768-4 register bank. Decimation Rate Control Input 0/Serial Data Output. In pin control mode, the DEC0 and DEC1 pins configure the decimation rate for all ADC channels. See Table 17 in the Setting the Decimation Rate section. In SPI control mode, this pin is the serial data output pin, allowing readback from the AD7768-4 registers. Do Not Connect/Digital Ground. This is an unused pin. Leave this pin floating if FORMAT0 is tied to logic low. If FORMAT0 is tied to logic high, connect this pin to DGND through a pulldown resistor. Data Input Daisy Chain. This pin acts as a digital input from a separate AD7768-4 device if configured in a synchronized multidevice daisy-chain. To use this pin in a daisy-chain, hardwire the FORMAT0 pin to logic high. If FORMAT0 is tied to logic low, or the daisy chaining input pin is not used, then tie this pin to DGND through a pull-down resistor. Do Not Connect. Do not connect to this pin. Conversion Data Output 3. This pin is synchronous to DCLK and framed by DRDY. Conversion Data Output 2. This pin is synchronous to DCLK and framed by DRDY. Conversion Data Output 1. This pin is synchronous to DCLK and framed by DRDY. Conversion Data Output 0. This pin is synchronous to DCLK and framed by DRDY ADC Conversion Data Clock. This pin clocks conversion data out to the digital host (DSP/FPGA). This pin is synchronous with DRDY and any conversion data output on DOUT0 to DOUT3 and is derived from the MCLK signal. This pin is unrelated to the control SPI interface. Data Ready. DRDY is a periodic signal output framing the conversion results from the four ADCs. This pin is synchronous to DCLK and DOUT0 to DOUT3. Hardware Asynchronous Reset Input. After the device is fully powered up, it is recommended to perform a hard reset using this pin or, alternatively, to perform a soft reset by issuing a reset over the SPI control interface Input 1 for Crystal or Connection to an LVDS Clock. When CLK_SEL is 0, connect XTAL1 to DGND. In SPI control mode, when using a crystal source, the FILTER pin must be set to Logic 1 for correct operation. When used with an LVDS clock, it is recommended that this pin be connected to one trace of the LVDS signal pair. When used as an LVDS input, a rising edge on this pin is detected as a rising MCLK edge by the AD7768-4. Rev. B | Page 28 of 105 Data Sheet AD7768/AD7768-4 Pin No. 32 Mnemonic XTAL2/MCLK Type1 DI 33 34 DGND DREGCAP P AO 35 IOVDD P 36 SYNC_IN DI 37 START DI Description Input 2 for CMOS/Crystal/LVDS Sampling Clock. See the CLK_SEL pin for the details of this configuration. External crystal: XTAL2 is connected to the external crystal. In SPI control mode, when using a crystal source, the FILTER pin must be set to Logic 1 for correct operation. LVDS: when used with an LVDS clock, connect this pin to the second trace of the LVDS signal pair. CMOS clock: this pin operates as an MCLK input. This pin is a CMOS input with logic level of IOVDD/DGND. When used as a CMOS clock input, a rising edge on this pin is detected as a rising MCLK edge by the AD7768-4. Digital Ground. Nominally GND (0 V). Digital LDO Regulator Output. Decouple this pin to DGND with a high quality, low ESR, 10 μF capacitor. For optimum performance, use a decoupling capacitor with an ESR specification of less than 400 mΩ. This pin is not for use in circuits external to the AD7768-4. For 1.8 V IOVDD operation, connect this pin to IOVDD via an external trace to provide power to the digital processing core. Digital Supply. This pin sets the logic levels for all interface pins. IOVDD also powers the digital processing core, via the digital LDO, when IOVDD is at least 2.25 V. For 1.8 V IOVDD operation, connect this pin to DREGCAP via an external trace to provide power to the digital processing core. Synchronization Input. SYNC_IN receives the synchronous signal from SYNC_OUT. It is used in the synchronization of any AD7768-4 that requires simultaneous sampling or is in a daisy chain. The user can ignore the START and SYNC_OUT function if the AD7768-4 SYNC_IN pin is connected to the system synchronization pulse. This signal pulse must be synchronous to the MCLK clock domain. Start Signal. The START pulse acts to synchronize the AD7768-4 to other devices. The signal can be asynchronous. The AD7768-4 samples the input and then outputs a SYNC_OUT pulse. This SYNC_OUT pulse must be routed to the SYNC_IN pin of this device, and any other AD7768-4 devices that must be synchronized together. This means that the user does not need to run the ADCs and their digital host from the same clock domain, which is useful when there are long traces or back planes between the ADC and the controller. If this pin is not used, it must be tied to a Logic 1 through a pull-up resistor. In a daisy-chained system of AD7768-4 devices, two successive synchronization pulses must be applied to guarantee that all ADCs are synchronized. Two synchronization pulses are also required in a system of more than one AD7768-4 device sharing a single MCLK signal, where the DRDY pin of only one device is used to detect new data. Synchronization Output. This pin operates only when the START input is used. When using the START input feature, the SYNC_OUT must be connected to SYNC_IN via an external trace. SYNC_OUT is a digital output that is synchronous to the MCLK signal; the synchronization signal driven in on START is internally synchronized to the MCLK signal and is driven out on SYNC_OUT. SYNC_OUT can also be routed to other AD7768-4 devices requiring simultaneous sampling and/or daisy-chaining, ensuring synchronization of devices related to the MCLK clock domain. It must then be wired to drive the SYNC_IN pin on the same AD7768-4 and on the other AD7768-4 devices. Reference Input Positive. REF2+ is the positive reference terminal for Channel 2 and Channel 3. The REF2+ voltage range is from (AVSS + 1 V) to AVDD1. Apply an external differential reference voltage between REF2+ and REF2− in the range from 1 V to |AVDD1 − AVSS|. Decouple this pin to AVSS with a high quality capacitor, and maintain a low impedance between this capacitor and Pin 3. Reference Input Negative. REF2− is the negative reference terminal for Channel 2 and Channel 3. The REF2− voltage range is from AVSS to (AVDD1 − 1 V). Decouple this pin to AVSS with a high quality capacitor, and maintain a low impedance between this capacitor and Pin 3. Analog Supply Voltage. This pin is 5 V ± 10% with respect to AVSS. Negative Analog Supply. This pin is nominally 0 V. Positive Analog Input to ADC Channel 3. Negative Analog Input to ADC Channel 3. Positive Analog Input to ADC Channel 2. Negative Analog Input to ADC Channel 2. Negative Analog Supply. This pin is nominally 0 V. E 38 SYNC_OUT DO 43 REF2+ AI 44 REF2− AI 45 46 47 48 49 50 51 AVDD1B AVSS1B AIN3+ AIN3− AIN2+ AIN2− AVSS2B P P AI AI AI AI P Rev. B | Page 29 of 105 AD7768/AD7768-4 Data Sheet Pin No. 52 53 55 56 Mnemonic REGCAPB AVDD2B DGND FORMAT0 Type1 AO P P DI 57 PIN/SPI DI 58 CLK_SEL DI 59 VCM AO 60 61 62 63 64 AVDD2A REGCAPA AVSS2A AIN0− AIN0+ P AO P AI AI 1 Description Analog LDO Regulator Output. Decouple this pin to AVSS with a 1 μF capacitor. Analog Supply Voltage. 2 V to 5.5 V with respect to AVSS. Digital Ground. This pin is nominally 0 V. Format Selection. Hardwire the FORMAT0 pin to the required value in pin and SPI control mode. This pin sets the number of DOUTx pins used to output ADC conversion data. The FORMAT0 pin is checked by the AD7768-4 on power-up, the AD7768-4 then remains in this data output configuration. See Table 34. Pin Control/SPI Control. This pin sets the AD7768-4 control method. Logic 0 = pin control mode for the AD7768-4. Pin control mode allows pin strapped configuration of the AD7768-4 by tying logic input pins to required logic levels. Tie logic pins MODE0 to MODE4, DEC0 and DEC1, and FILTER as required for the configuration. See the Pin Control section for more details. Logic 1 = SPI control mode for the AD7768-4. Use the SPI control interface signals (CS, SCLK, SDI, and SDO) for reading and writing to the AD7768-4 memory map. Clock Select. Logic 0 = pull this pin low for the CMOS clock option. The clock is applied to Pin 32 (Connect Pin 31 to DGND). Logic 1 = pull this pin high for the crystal or LVDS clock option. The crystal or LVDS clock is applied to Pin 31 and Pin 32. The LVDS option is available only in SPI control mode. A write is required to enable the LVDS clock option. Common-Mode Voltage Output. This pin outputs (AVDD1 − AVSS)/2 V, which is 2.5 V by default in pin control mode. Configure this pin to (AVDD1 − AVSS)/2 V, 2.5 V, 2.14 V, or 1.65 V in SP control mode. When driving capacitive loads larger than 0.1 μF, it is recommended to place a 50 Ω series resistor between the pin and the capacitive load for stability. The VCM voltage output is associated with the Channel 0 circuitry. If Channel 0 is put into standby mode, the VCM voltage output is also disabled for maximum power savings. Channel 0 must be enabled while VCM is being used externally to the AD7768-4. Analog Supply Voltage. This pin is 2 V to 5.5 V with respect to AVSS. Analog LDO Regulator Output. Decouple this pin to AVSS with a 1 μF capacitor. Negative Analog Supply. This pin is nominally 0 V. Negative Analog Input to ADC Channel 0. Positive Analog Input to ADC Channel 0. AI is analog input, P is power, DI/O is digital input/output, DI is digital input, DO is digital output, and AO is analog output. Rev. B | Page 30 of 105 Data Sheet AD7768/AD7768-4 TYPICAL PERFORMANCE CHARACTERISTICS AVDD1 = 5 V, AVDD2 = 2.5 V, AVSS = 0 V, IOVDD = 2.5 V, VREF = 4.096 V, TA = 25°C, wideband filter, decimation = ×32, MCLK = 32.768 MHz, analog input precharge buffers on, precharge reference buffers off, unless otherwise noted. –40 –60 –60 –80 –100 –120 –80 –100 –120 –140 –140 –160 –160 –180 –180 100 1k FREQUENCY (Hz) 10k 100k –200 14001-012 10 10 Figure 12. FFT, Fast Mode, Wideband Filter, −0.5 dBFS 0 –60 AMPLITUDE (dB) –40 –60 –80 –100 –120 –160 –180 –180 –200 –200 10 –60 AMPLITUDE (dB) –60 –80 –100 –120 –100 –120 –140 –160 –160 –180 –180 10k 100k –80 –140 14001-016 AMPLITUDE (dB) –40 1k FREQUENCY (Hz) 10k SNR = 108.1dB THD = –129.7dB –20 –40 100 1k FREQUENCY (Hz) 0 SNR = 108.0dB THD = –129.7dB 10 100 Figure 16. FFT, Median Mode, Wideband Filter, −6 dBFS Figure 13. FFT, Median Mode, Wideband Filter, −0.5 dBFS –200 SNR = 108.1dB THD = –128.8dB –120 –140 –20 100k –100 –160 0 10k –80 –140 14001-014 AMPLITUDE (dB) 0 –20 –40 FREQUENCY (Hz) 1k FREQUENCY (Hz) Figure 15. FFT, Fast Mode, Wideband Filter, −6 dBFS SNR = 107.9dB THD = –129.3dB –20 100 14001-018 AMPLITUDE (dB) –40 –200 SNR = 107.9dB THD = –129.8dB –20 14001-020 –20 AMPLITUDE (dB) 0 SNR = 107.8dB THD = –126.4dB –200 10 100 1k FREQUENCY (Hz) 10k Figure 17. FFT, Low Power Mode, Wideband Filter, −6 dBFS Figure 14. FFT, Low Power Mode, Wideband Filter, −0.5 dBFS Rev. B | Page 31 of 105 14001-022 0 AD7768/AD7768-4 –40 –60 –60 –80 –100 –120 –80 –100 –120 –140 –140 –160 –160 –180 –180 100 1k FREQUENCY (Hz) 10k 100k –200 14001-013 10 10 Figure 18. FFT, Fast Mode, Sinc5 Filter, −0.5 dBFS 0 –60 AMPLITUDE (dB) –40 –60 –80 –100 –120 –80 –120 –140 –160 –160 –180 –180 –200 –200 10 AMPLITUDE (dB) –60 –80 –100 –120 –80 –120 –140 –160 –160 –180 –180 1k FREQUENCY (Hz) 10k 100k –100 –140 14001-017 AMPLITUDE (dB) –40 –60 100 10k SNR = 111.5dB THD = –131.7dB –20 –40 10 1k FREQUENCY (Hz) 0 SNR = 111.1dB THD = –130.1dB –200 100 Figure 22. FFT, Median Mode, Sinc5 Filter, −6 dBFS Figure 19. FFT, Median Mode, Sinc5 Filter, −0.5 dBFS 0 100k –100 –140 –20 10k SNR = 111.1dB THD = –130.2dB –20 14001-015 AMPLITUDE (dB) 0 –40 FREQUENCY (Hz) 1k FREQUENCY (Hz) Figure 21. FFT, Fast Mode, Sinc5 Filter, −6 dBFS SNR = 111.1dB THD = –128.8dB –20 100 14001-019 AMPLITUDE (dB) –40 –200 SNR = 111.1dB THD = –129.3dB –20 14001-021 –20 AMPLITUDE (dB) 0 SNR = 111.1dB THD = –126.5dB –200 10 100 1k FREQUENCY (Hz) 10k Figure 23. FFT, Low Power Mode, Sinc5 Filter, −6 dBFS Figure 20. FFT, Low Power Mode, Sinc5 Filter, −0.5 dBFS Rev. B | Page 32 of 105 14001-023 0 Data Sheet Data Sheet AD7768/AD7768-4 0 FAST MEDIAN LOW POWER SNR = 113.3dB THD = –130.8dB fS = 8.192kHz fIN = 1kHz –40 250 NUMBER OF OCCURRENCES –20 AMPLITUDE (dB) –60 –80 –100 –120 –140 –160 200 150 100 50 50 500 FREQUENCY (Hz) 5000 0 –45 –41 –38 –34 –31 –27 –23 –20 –16 –13 –9 –5 –2 2 5 9 13 16 20 23 27 31 34 38 41 45 5 14001-026 –200 SHORTED NOISE (µV) Figure 27. Shorted Noise, Sinc5 Filter Figure 24. FFT One-Shot-Mode, Sinc5 Filter, Median Mode, Decimation = ×64, −0.5 dBFS, SYNC_IN Frequency = MCLK/4000 SECOND-ORDER IMD = –135.2dB THIRD-ORDER IMD = –129.3dB 200 NUMBER OF OCCURRENCES 0 –20 –40 –60 AMPLITUDE (dB) 14001-029 –180 –80 –100 –120 –140 –40°C +25°C +105°C 150 100 50 –160 10k FREQUENCY (Hz) 100k 0 –50 –46 –42 –38 –34 –30 –26 –22 –18 –14 –10 –6 –2 2 6 10 14 18 22 26 30 34 38 42 46 50 1k 14001-276 –200 100 SHORTED NOISE (µV) 14001-057 –180 Figure 28. Shorted Noise vs. Temperature, Wideband Filter Figure 25. IMD with Input Signals at 9.7 kHz and 10.3 kHz 15 14 FAST MEDIAN LOW POWER 13 12 RMS NOISE (µV) 150 100 WIDEBAND 11 10 9 8 50 SINC5 7 TEMPERATURE (°C) Figure 29. RMS Noise vs. Temperature, Fast Mode Figure 26. Shorted Noise, Wideband Filter Rev. B | Page 33 of 105 14001-058 5 –40 –35 –30 –25 –20 –15 –10 –5 0 5 10 15 20 25 35 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 42 39 35 31 27 23 20 16 8 12 4 1 –3 –7 –11 –15 –18 –22 –26 –30 –37 –41 –34 SHORTED NOISE (µV) 14001-028 6 0 –45 NUMBER OF OCCURRENCES 200 AD7768/AD7768-4 Data Sheet 15 0 14 –20 13 –40 12 WIDEBAND 11 10 9 8 –60 AMPLITUDE (dB) –80 –100 –120 SINC5 –160 5 –180 TEMPERATURE (°C) 0 14001-059 –40 –35 –30 –25 –20 –15 –10 –5 0 5 10 15 20 25 35 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 6 1 2 3 4 5 6 7 CHANNEL SNR AND DYNAMIC RANGE (dB) 14 13 RMS NOISE (µV) 12 WIDEBAND 11 10 9 SINC5 7 100 SNR, FAST THD, FAST 90 6 fIN = 1kHz 80 TEMPERATURE (°C) 14001-060 –40 –35 –30 –25 –20 –15 –10 –5 0 5 10 15 20 25 35 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 5 Figure 31. RMS Noise vs. Temperature, Low Power Mode 0 5 10 15 20 25 30 35 40 MCLK FREQUENCY (MHz) Figure 34. SNR, Dynamic Range, THD, and THD +N vs. MCLK Frequency 12.0 0 11.8 –20 11.6 –40 11.4 –60 THD (dB) 11.2 VREF = 5.00V VREF = 4.096V VREF = 2.500V 11.0 10.8 –80 –120 10.4 –140 10.2 –160 10.0 0 1 2 3 4 5 6 CHANNEL Figure 32. RMS Noise per Channel for Various VREF Values 7 FAST MEDIAN LOW POWER –100 10.6 –180 14001-061 RMS NOISE (µV) DYNAMIC RANGE, FAST THD + N, FAST 0 –10 –20 –30 –40 –50 –60 –70 –80 –90 –100 –110 –120 –130 –140 –150 –160 –170 –180 14001-062 110 15 THD AND THD + N (dB) Figure 33. Crosstalk Figure 30. RMS Noise vs. Temperature, Median Mode 8 14001-175 –140 7 10 100 1k 10k INPUT FREQUENCY (Hz) 100k 14001-034 RMS NOISE (µV) fIN = 3.15kHz INTERFERER (1kHz) ON ALL OTHER CHANNELS Figure 35. THD vs. Input Frequency, Three Power Modes, Wideband Filter Rev. B | Page 34 of 105 Data Sheet AD7768/AD7768-4 0 120 –20 118 116 –40 114 FAST MEDIAN LOW POWER –80 SNR (dB) –100 –120 112 110 108 104 –160 102 10 100 1k 10k INPUT FREQUENCY (Hz) 100 –140 14001-035 –180 100k –60 –100 –80 –60 –40 –20 0 0V INPUT VOLTAGE (V) +VREF Figure 40. INL Error vs. Input Voltage for Various Voltage Reference (VREF) Levels, Fast Mode Figure 37. THD and THD + N vs. Input Amplitude, Wideband Filter 4 fIN = 1kHz FAST THD FAST THD + N MEDIAN THD MEDIAN THD + N LOW POWER THD LOW POWER THD + N 3 INL ERROR (ppm) 2 –80 –100 –120 VREF = 2.500V VREF = 4.096V VREF = 5.000V 1 0 –1 –2 –140 –3 –160 –120 –100 –80 –60 –40 –20 INPUT AMPLITUDE (dBFS) Figure 38. THD and THD + N vs. Input Amplitude, Sinc5 Filter 0 –4 –VREF 14001-308 THD AND THD + N (dB) –1 –4 –VREF 14001-307 –120 INPUT AMPLITUDE (dBFS) –180 –140 0 –3 –160 –60 1 –2 –140 –40 0 VREF = 2.500V VREF = 4.096V VREF = 5.000V 2 –120 –20 –20 3 –100 0 –40 4 fIN = 1kHz –80 –180 –140 –60 14001-052 THD AND THD + N (dB) –40 –80 Figure 39. SNR vs. Input Amplitude INL ERROR (ppm) –20 FAST THD FAST THD + N MEDIAN THD MEDIAN THD + N LOW POWER THD LOW POWER THD + N –100 INPUT AMPLITUDE (dBFS) Figure 36. THD vs. Input Frequency, Three Power Modes, Sinc5 Filter 0 –120 14001-309 106 –140 0V INPUT VOLTAGE (V) +VREF 14001-053 THD (dB) –60 FAST MODE, SINC5 FILTER FAST MODE, WIDEBAND FILTER MEDIAN MODE, SINC5 FILTER MEDIAN MODE, WIDEBAND FILTER LOW POWER MODE, SINC5 FILTER LOW POWER MODE, WIDEBAND FILTER Figure 41. INL Error vs. Input Voltage for Various Voltage Reference (VREF) Levels, Median Mode Rev. B | Page 35 of 105 AD7768/AD7768-4 Data Sheet 4 +105°C +25°C –40°C 50 3 INL ERROR (ppm) NUMBER OF OCCURRENCES VREF = 2.500V VREF = 4.096V VREF = 5.000V 2 1 0 –1 –2 40 30 20 10 +VREF 0 –60 –50 –40 –30 –20 –10 0 10 20 OFFSET ERROR (µV) Figure 45. Offset Error Distribution, DCLK = 24 MHz Figure 42. INL Error vs. Input Voltage for Various Voltage Reference (VREF) Levels, Low Power Mode 1.5 +105°C +25°C –40°C 50 FULL SCALE (–4.015V TO +4.015V) HALF SCALE (–2.008V TO +2.008V) QUARTER SCALE (–1.004V TO +1.004V) NUMBER OF OCCURRENCES 0.5 0 –0.5 –1.0 0V INPUT VOLTAGE (V) +VREF 30 20 10 0 14001-055 –1.5 –VREF 40 –140 –120 –100 –20 0 20 40 120 –40°C 0°C +25°C +85°C +105°C NUMBER OF OCCURRENCES 100 0 –1 80 60 40 20 –3 0 INPUT VOLTAGE (V) 14001-056 –2 –4.0 –3.7 –3.4 –3.1 –2.7 –2.4 –2.1 –1.8 –1.4 –1.1 –0.8 –0.5 –0.2 0.2 0.5 0.8 1.1 1.4 1.8 2.1 2.4 2.7 3.1 3.4 3.7 4.0 INL ERROR (ppm) –40 Figure 46. Offset Error Distribution, DCLK = 32 MHz 3 1 –60 OFFSET ERROR (µV) Figure 43. INL Error vs. Input Voltage, Full-Scale, Half-Scale, and Quarter-Scale Inputs 2 –80 –150 –100 –50 0 50 100 150 200 250 300 OFFSET ERROR DRIFT (nV/°C) Figure 47. Offset Error Drift, DCLK = 24 MHz Figure 44. INL Error vs. Input Voltage for Various Temperatures, Fast Mode Rev. B | Page 36 of 105 350 14001-401 INL ERROR (ppm) 1.0 14001-404 0V INPUT VOLTAGE (V) 14001-054 –4 –VREF 14001-403 –3 Data Sheet AD7768/AD7768-4 600 45 +105°C +25°C –40°C 40 NUMBER OF OCCURRENCES NUMBER OF OCCURRENCES 500 35 30 25 20 15 10 400 300 200 100 –350 –300 –250 –200 –150 –100 –50 0 50 100 150 200 250 300 350 OFFSET ERROR DRIFT (nV/°C) 0 14001-402 0 –40 –35 –30 –25 –20 –15 –10 –5 0 Figure 51. Gain Error Distribution 600 60 500 50 NUMEBER OF OCCURRENCES 400 1.8V IOVDD 2.5V IOVDD 200 100 40 30 20 10 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 DCLK FREQUENCY (MHz) 0 14001-040 0 2 3 4 5 6 7 8 9 10 GAIN ERROR (ppm) 11 14001-046 OFFSET DRIFT (nV/°C) 5 10 15 20 25 30 35 GAIN ERROR (ppm) Figure 48. Offset Error Drift, DCLK = 32 MHz 300 14001-405 5 12 Figure 52. Channel to Channel Gain Error Matching Figure 49. Offset Drift vs. DCLK Frequency 0 120 FAST MODE 60 MEDIAN MODE AC CMRR (dB) 80 –40 LOW POWER MODE 40 –60 –80 –100 –120 –140 20 0 –40 25 TEMPERATURE (°C) 105 –180 10 100 1k 10k 100k INPUT FREQUENCY (Hz) 1M Figure 53. AC CMRR vs. Input Frequency Figure 50. Channel Offset Error Matching Rev. B | Page 37 of 105 10M 14001-063 –160 14001-047 OFFSET ERROR MATCHING (µV) –20 100 AD7768/AD7768-4 0 –20 –30 –40 AMPLITUDE (dB) –20 –40 –50 CH0 CH4 –60 CH1 CH5 CH2 CH6 CH3 CH7 –80 –100 –70 –120 –80 –140 –90 –160 1k 10k 100k 1M 10M FREQUENCY (Hz) –180 14001-310 –100 100 0.1 0 0.5 0.7 0.9 1.1 1.3 1.5 Figure 57. Wideband Filter Profile, Amplitude vs. fIN/fODR DCLK = 32.768MHz AVDD2 = 5V + 100mV p-p –20 5 18000000 4 16000000 14000000 3 AIN DOUT –30 2 –40 1 10000000 AIN (V) AC PSRR (dB) 0.3 NORMALIZED INPUT FREQUENCY (fIN/fODR) Figure 54. AC PSRR vs. Frequency, AVDD1 –10 ECO MEDIAN FAST –60 –50 CH0 CH4 –60 CH1 CH5 CH2 CH6 14001-074 –10 AC PSRR (dB) 20 DCLK = 32.768MHz AVDD1 = 5V + 100mV p-p CH3 CH7 –70 –80 12000000 0 8000000 –1 6000000 –2 4000000 –3 2000000 DOUT (Code) 0 Data Sheet –90 10k 100k 1M 10M FREQUENCY (Hz) 0 10 40 50 60 70 0 80 Figure 58. Step Response, Wideband Filter 0 0.005 –10 0.004 –20 ECO MEDIAN LOW POWER 0.003 –40 DCLK = 32.768MHz, CH 7 DCLK = 32.768MHz, CH 7 DCLK = 8.192MHz, CH 7 DCLK = 8.192MHz, CH 7 0.002 AMPLITUDE (dB) IOVDD = 1.8V, IOVDD = 2.5V, IOVDD = 1.8V, IOVDD = 2.5V, –30 –50 –60 –70 0.001 0 –0.001 –0.002 –80 –0.003 –90 1k 10k 100k 1M FREQUENCY (Hz) 10M –0.005 0 0.05 0.10 0.15 0.20 0.25 0.30 0.35 Figure 59. Wideband Filter Ripple Figure 56. AC PSRR vs. Frequency, IOVDD Rev. B | Page 38 of 105 0.40 NORMALIZED INPUT FREQUENCY (fIN/fODR) 0.45 0.50 14001-072 –0.004 –100 14001-065 AC PSRR (dB) 30 SAMPLES Figure 55. AC PSRR vs. Frequency, AVDD2 –110 100 20 14001-071 1k 14001-311 –4 –100 100 Data Sheet AD7768/AD7768-4 –20 –40 –80 –100 –120 –140 MEASUREMENT LIMIT = 130dB –200 0 1 2 3 4 5 6 NORMALIZED INPUT FREQUENCY (fIN/fODR) 14001-073 –180 18000000 4 16000000 0 8000000 –1 6000000 –2 4000000 –3 2000000 5 10 15 20 NUMBER OF OCCURRENCES 10000000 25 DOUT (Code) 1 0 –60 –70 –80 –40 0 30 60 40 0 2.42 2.43 2.44 2.45 2.46 2.47 VCM (V) Figure 64. VCM Output Voltage Distribution 40 60 DIFFERENTIAL COMPONENT, NO PRECHARGE (µA/V) 35 FAST 40 SUPPLY CURRENT (mA) ANALOG INPUT CURRENT (µA) AVDD1 = 5V, AVSS = 0V VCM_VSEL = 10 PART TO PART DISTRIBUTION 80 Figure 61. Step Response, Sinc5 Filter 30 20 105 20 SAMPLES 50 25 100 14001-070 AIN (V) 12000000 –4 FAST WITH PRECHARGE FAST, NO PRECHARGE MEDIAN WITH PRECHARGE MEDIAN, NO PRECHARGE LOW POWER WITH PRECHARGE LOW POWER, NO PRECHARGE –50 120 14000000 2 –40 Figure 63. Reference Input Current vs. Temperature, Reference Precharge Buffers On/Off 5 AIN DOUT –30 TEMPERATURE (°C) Figure 60. Sinc5 Filter Profile, Amplitude vs. fIN/fODR 3 –20 14001-312 –160 –10 COMMON-MODE COMPONENT, NO PRECHARGE (µA/V) 10 0 –10 TOTAL CURRENT, PRECHARGE ON (µA) –20 25 20 MEDIAN 15 10 LOW POWER 5 25 TEMPERATURE (°C) 105 14001-051 –30 –40 –40 30 Figure 62. Analog Input Current vs. Temperature, Analog Input Precharge Buffers On/Off Rev. B | Page 39 of 105 0 –40 –25 –10 5 20 35 50 65 80 95 TEMPERATURE (°C) Figure 65. Supply Current vs. Temperature, AVDD1 110 14001-066 AMPLITUDE (dB) –60 0 14001-050 REFERENCE INPUT CURRENT (µA/V/CHANNEL) 0 AD7768/AD7768-4 Data Sheet 500 40 450 FAST 35 FAST, WIDEBAND FILTER 25 MEDIAN 20 15 10 LOW POWER 0 –40 –25 –10 5 20 35 50 65 80 95 110 TEMPERATURE (°C) 14001-067 5 70 40 30 20 10 0 –40 –25 –10 5 20 35 50 65 80 95 TEMPERATURE (°C) 110 14001-068 SUPPLY CURRENT (mA) FAST, SINC5 FAST, WIDEBAND MEDIAN, SINC5 MEDIAN, WIDEBAND LOW POWER, SINC5 LOW POWER, WIDEBAND 50 300 250 MEDIAN, WIDEBAND FILTER 200 150 MEDIAN, SINC5 FILTER 100 LOW POWER, WIDEBAND FILTER 50 LOW POWER, SINC5 FILTER 0 –40 25 TEMPERATURE (°C) Figure 68. Total Power vs. Temperature Figure 66. Supply Current vs. Temperature, AVDD2 60 FAST, SINC5 FILTER 350 Figure 67. Supply Current vs. Temperature, IOVDD Rev. B | Page 40 of 105 14001-069 30 TOTAL POWER (mW) SUPPLY CURRENT (mA) 400 105 Data Sheet AD7768/AD7768-4 TERMINOLOGY AC Common-Mode Rejection Ratio (AC CMRR) AC CMRR is defined as the ratio of the power in the ADC output at frequency, f, to the power of a sine wave applied to the commonmode voltage of AINx+ and AINx− at frequency, fS. AC CMRR (dB) = 10log(Pf/PfS) where: Pf is the power at frequency, f, in the ADC output. PfS is the power at frequency, fS, in the ADC output. Gain Error The first transition (from 100 … 000 to 100 … 001) occurs at a level ½ LSB above nominal negative full scale (−4.0959375 V for the ±4.096 V range). The last transition (from 011 … 110 to 011 … 111) occurs for an analog voltage 1½ LSB below the nominal full scale (+4.0959375 V for the ±4.096 V range). The gain error is the deviation of the difference between the actual level of the last transition and the actual level of the first transition from the difference between the ideal levels. Gain Error Drift Gain error drift is the gain error change due to a temperature change of 1°C. It is expressed in parts per million per degree Celsius. Integral Nonlinearity (INL) Error INL error refers to the deviation of each individual code from a line drawn from negative full scale through positive full scale. The point used as negative full scale occurs ½ LSB before the first code transition. Positive full scale is defined as a level 1½ LSB beyond the last code transition. The deviation is measured from the middle of each code to the true straight line. Intermodulation Distortion (IMD) With inputs consisting of sine waves at two frequencies, fa and fb, any active device with nonlinearities creates distortion products at the sum and difference frequencies of mfa and nfb, where m, n = 0, 1, 2, 3, and so on. Intermodulation distortion terms are those for which neither m or n are equal to 0. For example, the second-order terms include (fa + fb) and (fa − fb), and the third-order terms include (2fa + fb), (2fa − fb), (fa + 2fb), and (fa − 2fb). The AD7768/AD7768-4 are tested using the CCIF standard, where two input frequencies near to each other are used. In this case, the second-order terms are usually distanced in frequency from the original sine waves, and the third-order terms are usually at a frequency close to the input frequencies. As a result, the second-order and third-order terms are specified separately. The calculation of the intermodulation distortion is as per the THD specification, where it is the ratio of the rms sum of the individual distortion products to the rms amplitude of the sum of the fundamentals, expressed in decibels. Least Significant Bit (LSB) The least significant bit, or LSB, is the smallest increment that can be represented by a converter. For a fully differential input ADC with N bits of resolution, the LSB expressed in volts is as follows: LSB (V) = (2 × VREF)/2N For the AD7768/AD7768-4, VREF is the difference voltage between the REFx+ and REFx− pins, and N = 24. Offset Error Offset error is the difference between the ideal midscale input voltage (0 V) and the actual voltage producing the midscale output code. Power Supply Rejection Ratio (PSRR) Variations in power supply affect the full-scale transition but not the linearity of the converter. PSRR is the maximum change in the full-scale transition point due to a change in the power supply voltage from the nominal value. Signal-to-Noise Ratio (SNR) SNR is the ratio of the rms value of the actual input signal to the rms sum of all other spectral components below the Nyquist frequency, excluding harmonics and dc. The value for SNR is expressed in decibels. Signal-to-Noise-and-Distortion Ratio (SINAD) SINAD is the ratio of the rms value of the actual input signal to the rms sum of all other spectral components below the Nyquist frequency, including harmonics but excluding dc. The value for SINAD is expressed in decibels. Spurious-Free Dynamic Range (SFDR) SFDR is the difference, in decibels, between the rms amplitude of the input signal and the peak spurious signal (excluding the first five harmonics). Total Harmonic Distortion (THD) THD is the ratio of the rms sum of the first five harmonic components to the rms value of a full-scale input signal and is expressed in decibels. Rev. B | Page 41 of 105 AD7768/AD7768-4 Data Sheet THEORY OF OPERATION The AD7768 and AD7768-4 are 8-channel and 4-channel, simultaneously sampled, low noise, 24-bit ∑-Δ ADCs, respectively. CLOCKING, SAMPLING TREE, AND POWER SCALING Each ADC within the AD7768/AD7768-4 employs a Σ-Δ modulator whose clock runs at a frequency of fMOD. The modulator samples the inputs at a rate of 2 × fMOD to convert the analog input into an equivalent digital representation. These samples therefore represent a quantized version of the analog input signal. The Σ-Δ conversion technique is an oversampled architecture. This oversampled approach spreads the quantization noise over a wide frequency band (see Figure 69). To reduce the quantization noise in the signal band, the high order modulator shapes the noise spectrum so that most of the noise energy is shifted out of the band of interest (see Figure 70). The digital filter that follows the modulator removes the large out of band quantization noise (see Figure 71). For further information on the basics as well as more advanced concepts of Σ-Δ ADCs, see the MT-022 Tutorial and the MT-023 Tutorial. Digital filtering has certain advantages over analog filtering. First, it is insensitive to component tolerances and the variation of component parameters over time and temperature. Because digital filtering on the AD7768/AD7768-4 occurs after the analog to digital conversion, it can remove some of the noise injected during the conversion process; analog filtering cannot remove noise injected during conversion. Second, the digital filter combines low pass-band ripple with a steep roll-off, and high stop band attenuation, while also maintaining a linear phase response, which is difficult to achieve in an analog filter implementation. The AD7768/AD7768-4 include multiple ADC cores. Each of these ADCs receives the same master clock signal, MCLK. The MCLK signal can be sourced from one of three options: a CMOS clock, a crystal connected between the XTAL1 and XTAL2 pins, or in the form of an LVDS signal. The MCLK signal received by the AD7768/AD7768-4 defines the modulator clock rate, fMOD, and, in turn, the sampling frequency of the modulator of 2 × fMOD. The same MCLK signal is also used to define the digital output clock, DCLK. The fMOD and DCLK internal signals are synchronous with MCLK. Figure 72 illustrates the clock tree from the MCLK input to the modulator, the digital filter, and the DCLK output. There are divider settings for MCLK and DCLK. These dividers in conjunction with the power mode and digital filter decimation settings are key to AD7768/AD7768-4 operation. The AD7768/AD7768-4 have the ability to scale power consumption vs. the input bandwidth or noise desired. The user controls two parameters to achieve this: MCLK division and power mode. Combined, these two settings determine the clock frequency of the modulator (fMOD) and the bias current supplied to each modulator. The power mode (fast, median, or low power) sets the noise, speed capability, and current consumption of the modulator. The power mode is the dominant control for scaling the power consumption of the ADC. All settings of MCLK division and power mode apply to all ADC channels. DCLK_DIV 00: DCLK = MCLK/8 01: DCLK = MCLK/4 10: DCLK = MCLK/2 11: DCLK = MCLK/1 MCLK_DIV MCLK/4 MCLK/8 MCLK/32 QUANTIZATION NOISE ADC MODULATOR Figure 69. Σ-Δ ADC Quantization Noise (Linear Scale X-Axis) POWER MODES: FAST MEDIAN LOW POWER NOISE SHAPING fMOD/2 14001-177 DIGITAL FILTER CUTOFF FREQUENCY fMOD/2 DRDY DOUTx DECIMATION RATES = x32, x64, x128, x256, x512, x1024 The modulator clock frequency (fMOD) is determined by selecting one of three clock divider settings: MCLK/4, MCLK/8, or MCLK/32. Figure 70. Σ-Δ ADC Noise Shaping (Linear Scale X-Axis) BAND OF INTEREST DATA INTERFACE CONTROL Figure 72. Sampling Structure, Defined by MCLK, DCLK_DIV, and MCLK_DIV Settings 14001-176 BAND OF INTEREST DIGITAL FILTER 14001-076 BAND OF INTEREST DCLK 14001-075 fMOD/2 Figure 71. Σ-Δ ADC Digital Filter Cutoff Frequency (Linear Scale X-Axis) Although the MCLK division and power modes are independent settings, there are restrictions that must be adhered to. A valid range of modulator frequencies exists for each power mode. Table 11 describes this recommended range, which allows the device to achieve the best performance while minimizing power consumption. The AD7768/AD7768-4 specifications do not cover the performance and function beyond the maximum fMOD for a given power mode. Rev. B | Page 42 of 105 Data Sheet AD7768/AD7768-4 For example, in fast mode, to maximize the speed of conversion or input bandwidth, an MCLK of 32.768 MHz is required and MCLK_DIV = 4 must be selected for a modulator frequency of 8.192 MHz. Table 11. Recommended fMOD Range for Each Power Mode Power Mode Low Power Median Fast Recommended fMOD (MHz) Range, MCLK = 32.768 MHz 0.036 to 1.024 1.024 to 4.096 4.096 to 8.192 This configuration maximizes the available decimation rate (or oversampling ratio) for the bandwidth required and MCLK rate available. The decimation averages the noise from the modulator, maximizing the dynamic range. To minimize power, use the following settings: In SPI control mode, the user can program the power mode, MCLK divider (MCLK_DIV), and DCLK frequency using Register 0x04 and Register 0x07 (see Table 42 and Table 45 for register information for the AD7768 or Table 68 and Table 71 for the AD7768-4). Independent selection of the power mode and MCLK_DIV allows full freedom in the MCLK speed selection to achieve a target modulator frequency. In pin control mode, the MODEx pins determine the power mode, modulator frequency, and DCLK frequency. The modulator frequency tracks the power mode. This means that fMOD is fixed at MCLK/32 for low power mode, MCLK/8 for median mode, and MCLK/4 for fast mode (see Table 20). Example of Power vs. Noise Performance Optimization Depending on the bandwidth of interest for the measurement, the user can choose a strategy of either lowest current consumption or highest resolution. This choice is due to an overlap in the coverage of each power mode. The devices offer the ability to balance the MCLK division ratio with the rate of decimation (averaging) set in the digital filter. Lower power can be achieved by using lower modulator clock frequencies. Conversely, the highest resolution can be achieved by using higher modulator clock frequencies and maximizing the amount of oversampling. As an example, consider a system constraint with a maximum available MCLK of 16 MHz. The system is targeting a measurement bandwidth of approximately 25 kHz with the wideband filter, setting the output data rate of the AD7768/AD7768-4 to 62.5 kHz. Because of the low MCLK frequency available and system power budget, median power mode is used. In median power mode, this 25 kHz input bandwidth can be achieved by setting the MCLK division and decimation ratio to balance, using two configurations. This flexibility is possible in SPI control mode only.      MCLK = 16 MHz Median power fMOD = MCLK/4 MCLK = 16 MHz Median power fMOD = MCLK/8 Decimation = ×32 (digital filter setting) ODR = 62.5 kHz This configuration reduces the clocking speed of the modulator and the digital filter. Compared to Configuration A, Configuration B saves 48 mW of power. The trade-off in the case of Configuration B is that the digital filter must run at a 2× lower decimation rate. This 2× reduction in decimation rate (or oversampling ratio) results in a 3 dB reduction in the dynamic range vs. Configuration A. Clocking Out the ADC Conversion Results (DCLK) The AD7768/AD7768-4 DCLK is a divided version of the master clock input. As shown in Figure 72, the DCLK_DIV setting determines the speed of the DCLK. DCLK is a continuous clock. The user can set the DCLK frequency rate to one of four divisions of MCLK: MCLK/1, MCLK/2, MCLK/4, and MCLK/8. Because there are eight channels and 32 bits of data per conversion, the conversion time and the setting of DCLK directly determine the number of data output lines that are required via the FORMAT0 and FORMAT1 pin settings on the AD7768, or the FORMAT0 pin on the AD7768-4. Thus, the intended minimum decimation and desired DCLK_DIV setting must be understood prior to choosing the setting of the FORMATx pins. NOISE PERFORMANCE AND RESOLUTION Table 12 and Table 13 show the noise performance for the wideband and sinc5 digital filters of the AD7768/AD7768-4 for various output data rates and power modes. The noise values and dynamic range specified are typical for the bipolar input range with an external 4.096 V reference (VREF). The rms noise is measured with shorted analog inputs, which are driven to (AVDD1 − AVSS)/2 using the on-board VCM buffer output. The dynamic range is calculated as the ratio of the rms shorted input noise to the rms full-scale input signal range. Dynamic Range (dB) = 20log10((2 × VREF/2√2)/(RMS Noise) To maximize the dynamic range, use the following settings:    Decimation = ×64 (digital filter setting) ODR = 62.5 kHz Configuration B Control of the settings for power mode, the modulator frequency and the data clock frequency differs in pin control mode vs. SPI control mode. Configuration A   The LSB size with 4.096 V reference is 488 nV, and is calculated as follows: LSB (V) = (2 × VREF)/224 Rev. B | Page 43 of 105 AD7768/AD7768-4 Data Sheet Table 12. Wideband Filter Noise: Performance vs. Output Data Rate (VREF = 4.096 V) Output Data Rate (kSPS) Fast Mode 256 128 64 32 16 8 Median Mode 128 64 32 16 8 4 Low Power Mode 32 16 8 4 2 1 −3 dB Bandwidth (kHz) Shorted Input Dynamic Range (dB) RMS Noise (μV) 110.8 55.4 27.7 13.9 6.9 3.5 107.96 111.43 114.55 117.58 120.56 123.5 11.58 7.77 5.42 3.82 2.72 1.94 55.4 27.7 13.9 6.9 3.5 1.7 108.13 111.62 114.75 117.79 120.8 123.81 11.36 7.6 5.3 3.74 2.64 1.87 13.9 6.9 3.5 1.7 0.87 0.43 108.19 111.69 114.83 117.26 120.88 123.88 11.28 7.54 5.25 3.71 2.62 1.85 Table 13. Sinc5 Filter Noise: Performance vs. Output Data Rate (VREF = 4.096 V) Output Data Rate (kSPS) Fast Mode 256 128 64 32 16 8 Median Mode 128 64 32 16 8 4 Low Power Mode 32 16 8 4 2 1 −3 dB Bandwidth (kHz) Shorted Input Dynamic Range (dB) RMS Noise (μV) 52.224 26.112 13.056 6.528 3.264 1.632 111.36 114.55 117.61 120.61 123.52 126.39 7.83 5.43 3.82 2.71 1.93 1.39 26.112 13.056 6.528 3.264 1.632 0.816 111.53 114.75 117.81 120.82 123.82 126.79 7.68 5.3 3.72 2.64 1.87 1.33 6.528 3.264 1.632 0.816 0.408 0.204 111.57 114.82 117.88 120.9 123.91 126.89 7.65 5.26 3.7 2.61 1.85 1.31 Rev. B | Page 44 of 105 Data Sheet AD7768/AD7768-4 APPLICATIONS INFORMATION    The AD7768/AD7768-4 offer users a multichannel platform measurement solution for ac and dc signal processing. Flexible filtering allows the AD7768/AD7768-4 to be configured to simultaneously sample ac and dc signals on a per channel basis. Power scaling allows users to trade off the input bandwidth of the measurement vs. the current consumption. This ability, coupled with the flexibility of the digital filtering, allows the user to optimize the energy efficiency of the measurement, while still meeting power, bandwidth, and performance targets.    Key capabilities that allow users to choose the AD7768/AD7768-4 as their platform high resolution ADC are highlighted as follows:      Eight fully differential or pseudo differential analog inputs on the AD7768 (four channels on the AD7768-4). Fast throughput simultaneous sampling ADCs catering for input signals up to 110.8 kHz. Three selectable power modes (fast, median, and low power) for scaling the current consumption and input bandwidth of the ADC for optimal measurement efficiency. Analog input precharge and reference precharge buffers reduce the drive requirements of external amplifiers. Control of reference and analog input precharge buffers on a per channel basis. AVDD1A, AVDD1B Refer to Figure 73 and Table 14 for the typical connections and minimum requirements to get started using the AD7768/AD7768-4. Table 15 shows the typical power and performance of the AD7768/AD7768-4 for the available power modes, for each filter type. AVDD2A, AVDD2B IOVDD SUGGESTED OP AMPS: FAST MODE: ADA4896-2 OR ADA4807-2 MEDIAN MODE: ADA4940-2 OR ADA4807-2 LOW PWER MODE: ADA4805-2 VCM DREGCAP REGCAPA, REGCAPB AD7768/AD7768-4 5V AIN0+ ADA4940-1/ ADA4940-2 AIN0– SINC5 LOW LATENCY FILTER AIN7+* 24-BIT Σ-∆ ADC AIN7–* ADC DATA SERIAL INTERFACE SPI CONTROL INTERFACE WIDEBAND LOW RIPPLE FILTER PRECHARGE BUFFERS ST0/CS ST1*/SCLK DEC0/SDO DEC1/SDI FILTER/GPIO4 REFx+ REFx– AVSS VIN XTAL2/MCLK – VIN VOUT ADR4540 SYNC_IN SYNC_OUT START RESET FORMATx DRDY DCLK DOUT0 DOUT1 DOUT2 DOUT3 DOUT4* DOUT5* DOUT6*, DIN DOUT7* XTAL1 PIN/SPI MODE3/GPIO3 TO MODE0/GPIO0 + ADA4841-1 14001-077  Wideband, low ripple, digital filter for ac measurement. Fast sinc5 filter for precision low frequency measurement. Two channel modes, defined by the user selected filter choice, and decimation ratios, can be defined for use on different ADC channels. This enables optimization of the input bandwidth versus the signal of interest. Option of SPI or pin strapped control and configuration. Offset, gain, and phase calibration registers per channel. Common-mode voltage output buffer for use by driver amplifier. On-board AVDD2 and IOVDD LDOs for the low power, 1.8 V, internal circuitry. *THESE PINS EXIST ONLY ON THE AD7768. Figure 73. Typical Connection Diagram Rev. B | Page 45 of 105 AD7768/AD7768-4 Data Sheet Table 14. Requirements to Operate the AD7768/AD7768-4 Requirement Power Supplies External Reference External Driver Amplifiers External Clock FPGA or DSP Description 5 V AVDD1 supply, 2.25 V to 5 V AVDD2 supply, 1.8 V or 2.5 V to 3.3 V IOVDD supply (ADP7104/ADP7118) 2.5 V, 4.096 V, or 5 V (ADR4525, ADR4540, or ADR4550) The ADA4896-2, the ADA4940-1/ADA4940-2, the ADA4805-2, and the ADA4807-2 Crystal or a CMOS/LVDS clock for the ADC modulator sampling Input/output voltage of 2.5 V to 3.6 V, or 1.8 V (see the 1.8 V IOVDD Operation section) Table 15. Speed, Dynamic Range, THD, and Power Overview; Eight Channels Active, Decimate by 321 Power Mode Fast Median Low Power Sinc5 Filter THD (dB) −115 −120 −120 Dynamic Range (dB) 111 111 111 Bandwidth (kHz) 52.224 26.112 6.528 Wideband Filter Power Dissipation (mW per channel) 41 22 8.5 Dynamic Range (dB) 108 108 108 Bandwidth (kHz) 110.8 55.4 13.9 Power Dissipation (mW per channel) 52 28 9.5 Analog precharge buffers on, reference precharge buffers and VCM disabled, typical values, AVDD1 = 5 V, AVDD2 = IOVDD = 2.5 V, VREF = 4.096 V, MCLK = 32.768 MHz, DCLK = MCLK/4, TA = 25°C. POWER SUPPLIES The AD7768/AD7768-4 have three independent power supplies: AVDD1 (AVDD1A and AVDD2A), AVDD2 (AVDD2A and AVDD2B), and IOVDD. The reference potentials for these supplies are AVSS and DGND. Tie all the AVSS supply pins (AVSS1A, AVSS1B, AVSS2A, AVSS2B, and AVSS) to the same potential with respect to DGND. AVDD1A, AVDD1B, AVDD2A, and AVDD2B are referenced to this AVSS rail. IOVDD is referenced to DGND. The supplies can be powered within the following ranges:      AVDD1 = 5 V ± 10%, relative to AVSS AVDD2 = 2 V to 5.5 V, relative to AVSS IOVDD (with internal regulator) = 2.25 V to 3.6 V, relative to DGND IOVDD (bypassing regulator) = 1.72 V to 1.88 V, relative to DGND AVSS = −2.75 V to 0 V, relative to DGND The AVDD1A and AVDD1B (AVDD1) supplies power the analog front end, reference input, and common-mode output circuitry. AVDD1 is referenced to AVSS, and all AVDD1 supplies must be tied to the same potential with respect to AVSS. If AVDD1 supplies are used in a ±2.5 V split supply configuration, the ADC inputs are truly bipolar. When using split supplies, reference the absolute maximum ratings, which apply to the voltage allowed between AVSS and IOVDD supplies. The AVDD2A and AVDD2B (AVDD2) supplies connect to internal 1.8 V analog LDO regulators. The regulators power the ADC core. AVDD2 is referenced to AVSS, and all AVDD2 supplies must be tied to the same potential with respect to AVSS. The voltage on AVDD2 can range from 2 V (minimum) to 5.5 V (maximum), with respect to AVSS. IOVDD powers the internal 1.8 V digital LDO regulator. This regulator powers the digital logic of the ADC. IOVDD also sets the voltage levels for the SPI interface of the ADC. IOVDD is referenced to DGND, and the voltage on IOVDD can vary from 2.25 V (minimum) to 3.6 V (maximum), with respect to DGND. IOVDD can also be configured to run at 1.8 V. In this case, IOVDD and DREGCAP must be tied together and must be within the range of 1.72 V (minimum) to 1.88 V (maximum), with respect to DGND. See the 1.8 V IOVDD Operation section for more information on operating the AD7768/AD7768-4 at 1.8 V IOVDD. Recommended Power Supply Configuration Analog Devices, Inc., has a wide range of power management products to meet the requirements of most high performance signal chains. An example of a power solution that uses the ADP7118 is shown in Figure 74. The ADP7118 provides positive supply rails for optimal converter performance, creating either a single 5 V, 3.3 V, or dual AVDD1x and AVDD2x/IOVDD, depending on the required supply configuration. The ADP7118 can operate from input voltages of up to 20 V. 12V INPUT ADP7118 5V: AVDD1x ADP7118 3.3V: AVDD2x/IOVDD LDO LDO 14001-078 1 Output Data Rate (kSPS) 256 128 32 Figure 74. Power Supply Configuration Alternatively, the ADP7112 or ADP7104 can be selected for powering the AD7768/AD7768-4. Refer to the AN-1120 Application Note for more information regarding low noise LDO performance and power supply filtering. Rev. B | Page 46 of 105 Data Sheet AD7768/AD7768-4 1.8 V IOVDD Operation DEVICE CONFIGURATION The AD7768/AD7768-4 contain an internal 1.8 V LDO on the IOVDD supply to regulate the IOVDD down to the operating voltage of the digital core. This internal LDO allows the internal logic to operate efficiently at 1.8 V and the input/output logic to operate at the level set by IOVDD. The IOVDD supply is rated from 2.25 V to 3.6 V for normal operation, and 1.8 V for LDO bypass setup. The AD7768/AD7768-4 have independent paths for reading data from the ADC conversions and for controlling the device functionality. 37 START 36 SYNC_IN 35 DREGCAP 34 DGND 33 1.8V IOVDD SUPPLY 14001-306 XTAL1 XTAL2/MCLK RESET DCLK DRDY Interface Data Format Figure 75. DREGCAP and IOVDD Connection Diagram for 1.8 V IOVDD Operation Users can bypass the LDO by shorting the DREGCAP pin to IOVDD (see Figure 75), which pulls the internal LDO out of regulation and sets the internal core voltage and input/output logic levels to the IOVDD level. When bypassing the internal LDO, the maximum operating voltage of the IOVDD supply is equal to the maximum operating voltage of the internal digital core, which is 1.72 V to 1.88 V. There are a number of performance differences to consider when operating at 1.8 V IOVDD. See the 1.8 V IOVDD Specifications section for detailed specifications while operating at 1.8 V IOVDD. Analog Supply Internal Connectivity The AD7768/AD7768-4 have two analog supply rails, AVDD1 and AVDD2, which are both referred to AVSS. These supplies are completely separate from the digital pins IOVDD, DREGCAP, and DGND. To achieve optimal performance and isolation of the ADCs, more than one device pin supplies these analog rails to the internal ADCs.    Pin control mode: pin strapped digital logic inputs (which allows a subset of the configurability options) SPI control mode: over a 3-wire or 4-wire SPI interface (complete configurability) On power-up, the state of the PIN/SPI pin determines the mode used. Immediately after power-up, the user must apply a soft or hard reset to the device when using either control mode. 28 29 30 31 32    38 SYNC_OUT IOVDD For control, the device can be configured in either of two modes. The two modes of configuration are AVSS1A (Pin 3) and AVSS2A (Pin 62) are internally connected. AVSS (Pin 54) is connected to the substrate, and is connected internally to AVSS1B (Pin 46) and AVSS2B (Pin 51). The following supply and reference input pins are separate on chip: AVDD1A, AVDD1B, AVDD2A, AVDD2B, REF1+, REF1−, REF2+, and REF2−. On the AD7768-4, the following AVSS pins are separate on chip: Pin 7, Pin 8, Pin 9, Pin 10, Pin 39, Pin 40, Pin 41, and Pin 42. The details of which individual supplies are shorted internally are given in this section for information purposes. In general, connect the supplies as described in the Power Supplies section. When operating the device, the data format of the serial interface is determined by the FORMAT0 and FORMAT1 pin settings on the AD7768, or the FORMAT0 pin on the AD7768-4. Table 33 shows that each ADC can be assigned a DOUTx pin, or, alternatively, the data can be arranged to share the DOUTx pins in a time division multiplexed manner. For more details, see the Data Interface section. PIN CONTROL Pin control mode eliminates the need for an SPI communication interface. When a single known configuration is required by the user, or when only limited reconfiguration is required, the number of signals that require routing to the digital host can be reduced using this mode. Pin control mode is useful in digitally isolated applications where minimal adjustment of the configuration is needed. Pin control offers a subset of the core functionality and ensures a known state of operation after power-up, reset, or a fault condition on the power supply. In pin control mode, the analog input precharge buffers are enabled by default for best performance. The reference input precharge buffers are disabled in pin control mode. After any change to the configuration in pin control mode, the user must provide a sync signal to the AD7768/AD7768-4 by applying the appropriate pulse to the START pin or SYNC_IN pin to ensure that the configuration changes are applied correctly to the ADC and digital filters. Setting the Filter The filter function chooses between the two filter settings. In pin control mode, all ADC channels use the same filter type, which is selected by the FILTER pin, as shown in Table 16. Table 16. FILTER Control Pin Logic Level 1 0 Rev. B | Page 47 of 105 Function Sinc5 filter selected Wideband filter selected AD7768/AD7768-4 Data Sheet Setting the Decimation Rate The MODEx pins map to 16 distinct settings. The settings are selected to optimize the use cases of the AD7768/AD7768-4, allowing the user to reduce the DCLK frequency for lower, less demanding power modes and selecting either the one-shot or standard conversion modes. Pin control mode allows selection from four possible decimation rates. The decimation rate is selected via the DEC1 and DEC0 pins. The chosen decimation rate is used on all ADC channels. Table 17 shows the truth table for the DECx pins. See Table 20 for the complete selection of operating modes that are available via the MODEx pins in pin control mode. Table 17. Decimation Rate Control Pins Truth Table DEC0 0 1 0 1 Decimation Rate ×32 ×64 ×128 ×1024 The power mode setting automatically scales the bias currents of the ADC and divides the applied MCLK signal to the correct setting for that mode. Note that this is not the same as using SPI control, where separate bit fields exist to control the bias currents of the ADC and MCLK division. Operating Mode In pin control mode, the modulator rate is fixed for each power mode to achieve the best performance. Table 19 shows the modulator division for each power mode. The MODE3 to MODE0 pins determine the configuration of all channels when using pin control mode. The variables controlled by the MODEx pins are shown in Table 18. The user selects how much current the device consumes, the sampling speed of the ADC (power mode), how fast the ADC result is received by the digital host (DCLK_DIV), and how the ADC conversion is initiated (conversion operation). Figure 76 illustrates the inputs used to configure the AD7768 in pin control mode, and Figure 77 illustrates the inputs used to configure the AD7768-4 in pin control mode. Table 19. Modulator Rate, Pin Control Mode Power Mode Fast Median Low Power Diagnostics Pin control mode offers a subset of diagnostics features. Internal errors are reported in the status header output with the data conversion results for each channel. Table 18. MODEx Pins: Variables for Control Control Variable Sampling Speed/Power Consumption Power Mode Data Clock Output Frequency (DCLK_DIV) Conversion Operation Possible Settings Fast mode Median mode Low Power mode DCLK = MCLK/1 DCLK = MCLK/2 DCLK = MCLK/4 DCLK = MCLK/8 Standard conversion One-shot conversion PIN CONTROL MODE PIN/SPI = LOW Internal cyclical redundancy check (CRC) errors, memory map flipped bits, and external clocks not detected are reported by Bit 7 of the status header and indicate that a reset is required. The status header also reports filter not settled, filter type, and filter saturated signals. Users can determine when to ignore data by monitoring these error flags. For more information on the status header, see the ADC Conversion Output: Header and Data section. CHANNEL STANDBY CH 0 TO CH 3 STANDBY CH 4 TO CH 7 STANDBY PIN/SPI ST0 ST1 OUTPUT DATA FORMAT 1 CHANNEL PER PIN 4 CHANNELS PER PIN 8 CHANNELS PER PIN FORMAT0 FORMAT1 DOUT0 DOUT1 OPTION TO SELECT BETWEEN FILTERS FILTER DEC0/ DEC1 Modulator Rate, fMOD MCLK/4 MCLK/8 MCLK/32 AD7768 TO DSP/ FPGA DOUT7 MODE0 MODE1 MODE2 MODE3 DECIMATION RATES /32 /64 /128 /1024 MODE CONFIGURATION MODE 0x0 TO MODE 0xF SET UP VIA 4 PINS Figure 76. AD7768 Pin Configurable Functions Rev. B | Page 48 of 105 14001-079 DEC1 0 0 1 1 Data Sheet AD7768/AD7768-4 PIN CONTROL MODE CHANNEL STANDBY CH 0 TO CH 3 STANDBY PIN/SPI = LOW PIN/SPI OUTPUT DATA FORMAT 1 CHANNEL PER PIN 4 CHANNELS PER PIN FORMAT0 ST0 DOUT0 DOUT1 FILTER AD7768-4 DOUT2 TO DSP/ FPGA DOUT3 MODE0 MODE1 MODE2 MODE3 DEC0/ DEC1 DECIMATION RATES /32 /64 /128 /1024 MODE CONFIGURATION MODE 0x0 TO MODE 0xF SET UP VIA 4 PINS 14001-300 OPTION TO SELECT BETWEEN FILTERS Figure 77. AD7768-4 Pin Configurable Functions Table 20. MODEx Selection Details: Pin Control Mode Mode Hex. 0x0 0x1 0x2 0x3 0x4 0x5 0x6 0x7 0x8 0x9 0xA 0xB 0xC 0xD 0xE 0xF MODE3 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 MODE2 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 MODE1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 MODE0 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 Configuration Example where: MCLK = 32.768 MHz. fMOD is MCLK/32 for low power mode (see Table 19). Decimation Ratio = 64. DCLK Frequency MCLK/1 MCLK/2 MCLK/4 MCLK/8 MCLK/1 MCLK/2 MCLK/4 MCLK/8 MCLK/1 MCLK/2 MCLK/4 MCLK/8 MCLK/1 MCLK/1 MCLK/2 MCLK/1 Data Conversion Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard One-shot One-shot One-shot One-shot Thus, for this example, where MCLK = 32.768 MHz, In the example shown in Table 23, the lowest current consumption is used, and the AD7768/AD7768-4 are connected to an FPGA. The FORMATx pins are set such that all eight data outputs, DOUT0 to DOUT7, connect to the FPGA. For the lowest power, the lowest DCLK frequency is used. The input bandwidth is set through the combination of selecting decimation by 64 and selecting the wideband filter. ODR = fMOD ÷ Decimation Ratio Power Mode Low power Low power Low power Low power Median Median Median Median Fast Fast Fast Fast Low power Median Fast Fast ODR = (32.768 MHz/32) ÷ 64 = 16 kHz Minimizing the DCLK frequency means selecting DCLK = MCLK/8, which results in a 4 MHz DCLK signal. The period of DCLK in this case is 1/4 MHz = 250 ns. The data conversion on each DOUTx pin is 32 bits long. The conversion data takes 32 × 250 ns = 8 μs to be output. All 32 bits must be output within the ODR period of 1/16 kHz, which is approximately 64 μs. In this case, the 8 μs required to read out the conversion data is well within the 64 μs between conversion outputs. Therefore, this combination, which is summarized in Table 23, is viable for use. Rev. B | Page 49 of 105 AD7768/AD7768-4 Data Sheet Channel Standby SPI CONTROL Table 21 and Table 23 show how the user can put channels into standby mode. Set either ST0 or ST1 to Logic 1 to place banks of four channels into standby mode. When in standby mode, the channels are disabled but still hold their position in the output data stream. The 8-bit header and 24-bit conversion result are set to all zeros when the ADC channels are set to standby. The AD7768/AD7768-4 have a 4-wire SPI interface that is compatible with QSPI™, MICROWIRE®, and DSPs. The interface operates in SPI Mode 0. In SPI Mode 0, SCLK idles low, the falling edge of CS clocks out the MSB, the falling edge of SCLK is the drive edge, and the rising edge of SCLK is the sample edge. This means that data is clocked out on the falling/drive edge and data is clocked in on the rising/sample edge. The crystal excitation circuitry is associated with the Channel 4 (Channel 2 on the AD7768-4) circuitry. If Channel 4 (Channel 2 on the AD7768-4) is put into standby mode, the crystal circuitry is also disabled for maximum power savings. Channel 4 must be enabled while the external crystal is used on the AD7768. Channel 2 must be enabled while the external crystal is used on the AD7768-4. Table 21. Truth Table for the AD7768 ST0 and ST1 Pins ST1 0 0 ST0 0 1 1 0 1 1 Function All channels operational. Channel 0 to Channel 3 in standby. Channel 4 to Channel 7 operational. Channel 4 to Channel 7 in standby. Channel 0 to Channel 3 operational. All channels in standby. SAMPLE EDGE Figure 78. SPI Mode 0 SCLK Edges Accessing the ADC Register Map To use SPI control mode, set the PIN/SPI pin to logic high. The SPI control operates as a 16-bit, 4-wire interface, allowing read and write access. Figure 80 shows the interface format between the AD7768/AD7768-4 and the digital host. The SPI serial control interface of the AD7768 is an independent path for controlling and monitoring the AD7768. There is no direct link to the data interface. The timing of MCLK and DCLK is not directly related to the timing of the SPI control interface. However, the user must ensure that the SPI reads and writes satisfy the minimum t30 specification (see Table 4 and Table 6) so that the AD7768/AD7768-4 can detect changes to the register map. SPI access is ignored during the period immediately after a reset. Allow the full ADC start-up time after reset (see Table 1) to elapse before accessing the AD7768/AD7768-4 over the SPI interface. Table 22. Truth Table for the AD7768-4 ST0 Pin ST0 0 1 DRIVE EDGE 14001-080 The VCM voltage output is associated with the Channel 0 circuitry. If Channel 0 is put into standby mode, the VCM voltage output is also disabled for maximum power savings. Channel 0 must be enabled while VCM is being used externally to the AD7768/AD7768-4. E Function All channels operational. Channel 0 to Channel 3 in standby. Table 23. MODEx Example Selection Mode Hex 0x3 MODE3 0 MODE2 0 MODE1 1 MODE0 1 Power Mode Low power Rev. B | Page 50 of 105 DCLK Frequency MCLK/8 Data Conversion Standard Data Sheet AD7768/AD7768-4 SPI Interface Details SPI Reset Configuration Each SPI access frame is 16 bits long. The MSB (Bit 15) of the SDI command is the R/W bit; 1 = read and 0 = write. Bits[14:8] of the SDI command are the address bits. After a power-on or reset, the AD7768/AD7768-4 default configuration is set to the following low current consumption settings: The SPI control interface uses an off frame protocol. This means that the master (FPGA/DSP) communicates with the AD7768/ AD7768-4 in two frames. The first frame sends a 16-bit instruction (R/W, address, and data) and the second frame is the response where the AD7768/AD7768-4 send 16 bits back to the master.     During the master write command, the SDO output contains eight leading zeros, followed by eight bits of data, as shown in Figure 80.  Figure 79 illustrates the off frame protocol. Register access responses are always offset by one CS frame. In Figure 79, the response (read RESP 1) to the first command (CMD 1) is output by the AD7768/AD7768-4 during the following CS frame at the same time as the second command (CMD 2) is being sent.   SPI CONTROL FUNCTIONALITY SPI control offers the superset of flexibility and diagnostics to the user. The following sections highlight the functionality and diagnostics offered when SPI control is used. SCLK CS CMD 1 After any change to these configuration register settings, the user must provide a sync signal to the AD7768/AD7768-4 through either the SPI_SYNC command, or by applying the appropriate pulse to the START pin or SYNC_IN pin to ensure that the configuration changes are applied correctly to the ADC and digital filters. CMD 2 14001-082 READ RESP 1 SDO Figure 79. Off Frame Protocol SPI Control Interface Error Handling The AD7768/AD7768-4 SPI control interface detects whether it has received an illegal command. An illegal command is a write to a read only register, a write to a register address that does not exist, or a read from a register address that does not exist. If any of these illegal commands are received by the AD7768/AD7768-4, the AD7768/AD7768-4 responds with an error output of 0x0E00. Channel Configuration The AD7768 has eight fully differential analog input channels. The AD7768-4 has four fully differential analog input channels. The channel configuration registers allow the channel to be individually configured to adapt to the measurement required on that channel. Channels can be enabled or disabled using the channel standby register, Register 0x00. Analog input and reference precharge buffers can be assigned per input terminal. Gain, offset, and phase calibration can be controlled on a per channel basis using the calibration registers. See the Per Channel Calibration Gain, Offset, and Sync Phase section for more information. SCLK CS SDI R/W SDO 0 A6 A5 A4 A3 A2 A1 A0 D7 D6 D5 D4 D3 D2 D1 D0 0 0 0 0 0 0 0 D7 D6 D5 D4 D3 D2 D1 D0 Figure 80. Write/Read Command Rev. B | Page 51 of 105 14001-081 SDI Low power mode with fMOD = MCLK/32. Interface configuration of DCLK = MCLK/8, header output enabled, and CRC disabled. Filter configuration of Channel Mode A and Channel Mode B is set to sinc5 and decimation = ×1024. Channel mode select is set to 0x00, and all channels are assigned to Channel Mode A. The analog input precharge buffers are enabled and the reference precharge buffers are disabled on all channels. The offset, gain, and phase calibration are set to the zero position. Continuous conversion mode is enabled. AD7768/AD7768-4 Data Sheet Channel Modes Table 25. Channel Mode Selection, Register 0x03 In SPI control mode, the user can set up two channel modes, Channel Mode A (Register 0x01), and Channel Mode B (Register 0x02). Each channel mode register can have a specific filter type and decimation ratio. Using the channel mode select register (Register 0x03), the user can assign each channel to either Channel Mode A or Channel Mode B, which maps that mode to the required ADC channels. These modes allow different filter types and decimation rates to be selected and mapped to any of the ADC channels. Bits [7:0] When different decimation rates are selected on different channels, the AD7768/AD7768-4 output a data ready signal at the fastest selected decimation rate. Any channel that runs at a lower output data rate is updated only at that slower rate. In between valid result data, the data for that channel is set to zero and the repeated data bit is set in the header status bits to distinguish it from a real conversion result (see the ADC Conversion Output: Header and Data section). On the AD7768, consider Channel Mode A as the primary group. In this respect, it is recommended that there always be at least one channel assigned to Channel Mode A. If all eight channels of the AD7768 are assigned to Channel Mode B, conversion data is not output on the data interface for any of the channels. This consideration does not affect the AD7768-4. On the AD7768-4, it is recommended that Channel Mode A be set to the sinc5 filter whenever possible. There is a small power saving in IOVDD current when Channel Mode A is set to the sinc5 filter compared to setting Channel Mode A to the wideband filter. For example, to assign two channels of the AD7768-4 to the wideband filter, and the remaining two channels to the sinc5 filter, it is recommended to assign the two sinc5 filter channels to Channel Mode A. Set Channel Mode A to the sinc5 filter, set Channel Mode B to the wideband filter, and assign the two wideband filter channels to Channel Mode B. Similarly, to assign all four channels of the AD7768-4 to wideband filter, assign all four channels to Channel Mode B. Set Channel Mode B to the wideband filter, and keep Channel Mode A set to the sinc5 filter. Assigning the channels in this way ensures that the lowest IOVDD current is achieved. Table 24. Channel Mode A/Channel Mode B, Register 0x01 and Register 0x02 Bits 3 Bit Name FILTER_TYPE_x Setting 0 1 [2:0] DEC_RATE_x 000 to 101 Description Filter output Wideband filter Sinc5 filter Decimation rate ×32 to ×1024 Reset 0x1 0x5 Access RW RW Bit Name CH_x_MODE Setting 0 1 Description Channel x Mode A Mode B Reset 0x0 Access RW Reset over SPI Control Interface Two successive commands must be written to the AD7768/ AD7768-4 data control register to initiate a full reset of the device over the SPI interface. This action fully resets all registers to the default conditions. Details of the commands and their sequence are shown in Table 44 for the AD7768 or Table 70 for the AD7768-4. After a reset over the SPI control interface, the AD7768/AD7768-4 respond to the first command sent to them with 0x0E00. This response, in addition to the fact that all registers have assumed their default values, indicates that the software reset succeeded. Sleep Mode Sleep mode puts the AD7768/AD7768-4 into their lowest power mode. In sleep mode, all ADCs are disabled and a large portion of the digital core is inactive. The AD7768/AD7768-4 SPI remains active and is available to the user when in sleep mode. Write to Register 0x04, Bit 7 to exit sleep mode. For the lowest power consumption, select the sinc5 filter before entering sleep mode. Channel Standby For efficient power usage, users can place the selected channels into standby mode, effectively disabling them, when not in use. Setting the bits in Register 0x00 disables the corresponding channel (see Table 38 for the AD7768 or Table 64 for the AD7768-4). For maximum power savings, switch disabled channels to the sinc5 filter using the channel mode configurations, which disables some clocks associated with the wideband filters of those channels. For highest power savings when disabling channels on the AD7768-4, set Channel Mode A to the sinc5 filter, and assign the disabled channels to Channel Mode A, while keeping any active channels in Channel Mode B. The VCM voltage output is associated with the Channel 0 circuitry. If Channel 0 is put into standby mode, the VCM voltage output is also disabled for maximum power savings. Channel 0 must be enabled while VCM is being used externally to the AD7768/AD7768-4. The crystal excitation circuitry is associated with the Channel 4 (Channel 2 on the AD7768-4) circuitry. If Channel 4 (Channel 2 on the AD7768-4) is put into standby mode, the crystal circuitry is also disabled for maximum power savings. Channel 4 must be enabled while the external crystal is used on the AD7768. Channel 2 must be enabled while the external crystal is used on the AD7768-4. Rev. B | Page 52 of 105 Data Sheet AD7768/AD7768-4 The internal modulator frequency (fMOD) that is used by each of the ADCs in the AD7768/AD7768-4 is derived from the externally applied MCLK signal. The MCLK division bits allow the user to control the ratio between the MCLK frequency and the internal modulator clock frequency. This control allows the user to select the division ratio that is best for their configuration. The appropriate clock configuration depends on the power mode, the decimation rate, and the base MCLK frequency available in the system. See the Clocking, Sampling Tree section for further information on setting MCLK_DIV correctly. MCLK Source Selection The following clocking options are available as the MCLK input source in SPI control mode:    LVDS External crystal CMOS input MCLK Setting CLK_SEL to logic low configures the AD7768/AD7768-4 for correct operation using a CMOS clock. Setting CLK_SEL to logic high enables the use of an external crystal. In SPI control mode, the FILTER pin must also be set to Logic 1 for operation of the external crystal. If CLK_SEL is set to logic high and Bit 3 of Register 0x04 is also set, the application of an LVDS clock signal to the MCLK pin is enabled. LVDS clocking is exclusive to SPI control mode and requires the register selection for operation (see Table 42 for the AD7768 or Table 68 for the AD7768-4). The DCLK rate is derived from MCLK. DCLK division (the ratio between MCLK and DCLK) is controlled in the interface configuration selection register, Register 0x07 (see Table 45 for the AD7768 or Table 71 for the AD7768-4). Interface Configuration The DCLK rate is a direct division of the MCLK input and can be controlled using Bits[1:0] of Register 0x07. The minimum DCLK rate can be calculated as DCLK (minimum) = Output Data Rate × Channels per DOUTx × 32 bits where MCLK ≥ DCLK. With eight ADCs enabled, an MCLK rate of 32.768 MHz, an ODR of 256 kSPS, and two DOUTx channels, DCLK (minimum) is 256 kSPS × 4 channels per DOUTx × 32 bits = 32.768 MHz where DCLK = MCLK/1. For more information on the status header, CRC, and interface configuration, see the Data Interface section. CRC Protection The AD7768/AD7768-4 can be configured to output a CRC message per channel every 4 or 16 samples. This function is available only with SPI control. CRC is enabled in the interface control register, Register 0x07 (see the CRC Check on Data Interface section). ADC Synchronization over SPI The ADC synchronization over SPI allows the user to request a synchronization pulse to the ADCs over the SPI interface. To initiate the synchronization in this manner, write to Bit 7 in Register 0x06 twice. First, the user must write a 0, which sets SYNC_OUT low, and then write a 1 to set the SYNC_OUT logic high again. The SPI_SYNC command is recognized after the last rising edge of SCLK in the SPI instruction, where the SPI_SYNC bit is changed from low to high. The SPI_SYNC command is then output synchronously to the AD7768/AD7768-4 MCLK signal on the SYNC_OUT pin. The user must connect the SYNC_OUT signal to the SYNC_IN pin on the PCB. IOVDD The data interface is a master output interface, where ADC conversion results are output by the AD7768/AD7768-4 at a rate based on the mode selected. The interface consists of a data clock (DCLK), the data ready (DRDY) framing output, and the data output pins (DOUT0 to DOUT7 for the AD7768, DOUT0 to DOUT3 for the AD7768-4). AD7768/ AD7768-4 E MASTER CLOCK START SYNCHRONIZATION LOGIC DIGITAL FILTER On the AD7768, the interface can be configured to output conversion data on one, two, or eight of the DOUTx pins. The DOUTx configuration for the AD7768 is selected using the FORMATx pins (see Table 33). On the AD7768-4, the interface can be configured to output conversion data on one or four of the DOUTx pins. The DOUTx configuration for the AD7768-4 is selected using the FORMAT0 pin (see Table 34). MCLK SPI INTERFACE SYNC_OUT DRDY DOUTx SYNC_IN DSP/ FPGA 14001-301 Clocking Selections Figure 81. Connection Diagram for Synchronization Using SPI_SYNC The SYNC_OUT pin can also be routed to the SYNC_IN pins of other AD7768/AD7768-4 devices, allowing simultaneous sampling to occur across larger channel count systems. Any daisy-chained system of AD7768/AD7768-4 devices requires that all ADCs be synchronized. Rev. B | Page 53 of 105 AD7768/AD7768-4 Data Sheet In a daisy-chained system of AD7768/AD7768-4 devices, two successive synchronization pulses must be applied to guarantee that all ADCs are synchronized. Two synchronization pulses are also required in a system of more than one AD7768/AD7768-4 device sharing a single MCLK signal, where the DRDY pin of only one device is used to detect new data. As per any synchronization pulse present on the SYNC_IN pin, the digital filters of the AD7768/AD7768-4 are reset by the SPI_SYNC command. The full settling time of the filters must then elapse before valid data is output on the data interface. Analog Input Precharge Buffers The AD7768/AD7768-4 contain precharge buffers on each analog input to ease the drive requirements on the external amplifier. Each analog input precharge buffer can be enabled or disabled using the analog input precharge buffer registers (see Table 52 and Table 53 for the AD7768 or Table 78 and Table 79 for the AD7768-4). When writing to these registers, the user must write the inverse of the required bit settings. For example, to clear Bit 1 of this register, the user must write 0x01 to the register. This clears Bit 1 and sets all other bits. If the user reads the register again after writing 0x01, the data read is 0xFE, as required. Reference Precharge Buffers The AD7768/AD7768-4 contain reference precharge buffers on each reference input to ease the drive requirements on the external reference and help to settle any nonlinearity on the reference inputs. Each reference precharge buffer can be enabled or disabled using the reference precharge buffer registers (see Table 54 and Table 55 for the AD7768 or Table 80 and Table 81 for the AD7768-4). Per Channel Calibration Gain, Offset, and Sync Phase The user can adjust the gain, offset, and sync phase of the AD7768/AD7768-4. These options are available only in SPI control mode. Further register information and calibration instructions are available in the Offset Registers section, the Gain Registers section, and the Sync Phase Offset Registers section. See the Calibration section for information on calibration equations. GPIOs The AD7768/AD7768-4 have five general-purpose input/output (GPIO) pins available when operating in SPI control mode. For further information on GPIO configuration, see the GPIO Functionality section. SPI CONTROL MODE EXTRA DIAGNOSTIC FEATURES RAM Built In Self Test The RAM built in self test (BIST) is a coefficient check for the digital filters. The AD7768/AD7768-4 DSP path uses some internal memories for storing data associated with filtering and calibration. A user may, if desired, initiate a built in self test (BIST) of these memories. Normal conversions are not possible while BIST is running. The test is started by writing to the BIST control register, Register 0x08. The results and status of the test are available in the status register, Register 0x09 (see Table 47 for the AD7768 or Table 73 for the AD7768-4). Normal ADC conversion is disrupted when this test is run. A synchronization pulse is required after this test is complete to resume normal ADC operation. Revision Identification Number The AD7768/AD7768-4 contain an identification register that can be accessed in SPI control mode, the revision identification register. This register is an excellent way to verify the correct operation of the serial control interface. Register information is available in the Revision Identification Register section. Diagnostic Meter Mode The diagnostic metering mode can be used to verify the functionality of each ADC by internally passing a positive fullscale, midscale, or negative full-scale voltage to the ADC. The user can then read the resulting ADC conversion result to determine that the ADC is operating correctly. To configure ADC conversion diagnostics, see the ADC Diagnostic Receive Select Register section and the ADC Diagnostic Control Register section. Rev. B | Page 54 of 105 Data Sheet AD7768/AD7768-4 CIRCUIT INFORMATION Table 11 shows the recommended fMOD frequencies for each power mode, and Table 42 shows the register information for the AD7768, and Table 68 shows the register information for the AD7768-4. ADC CODE (TWOS COMPLEMENT) Each ADC channel on the AD7768/AD7768-4 has an identical signal path from the analog input pins to the data interface. Figure 83 shows a top level implementation of the core signal chain. Each ADC channel has its own Σ-Δ modulator that oversamples the analog input and passes the digital representation to the digital filter block. The modulator sampling frequency (fMOD) ranges are explained in the Clocking, Sampling Tree, and Power Scaling section. The data is filtered, scaled for gain and offset (depending on user settings), and then output on the data interface. Control of the flexible settings for the signal chain is provided by either using the pin control or the SPI control set at power-up by the state of the PIN/SPI input pin. The AD7768/AD7768-4 can use up to a 5 V reference and converts the differential voltage between the analog inputs (AINx+ and AINx−) into a digital output. The analog inputs can be configured as either differential or pseudo differential inputs. As a pseudo differential input, either AINx+ or AINx− can be connected to a constant input voltage (such as 0 V, GND, AVSS, or some other reference voltage). The ADC converts the voltage difference between the analog input pins into a digital code on the output. Using a common-mode voltage of AVDD1/2 for the analog inputs, AINx+ and AINx−, maximizes the ADC input range. The 24-bit conversion result is in twos complement, MSB first, format. Figure 82 shows the ideal transfer functions for the AD7768/AD7768-4. +FS – 1LSB +FS – 1.5LSB ANALOG INPUT Figure 82. ADC Ideal Transfer Functions (FS is Full Scale) Table 26. Output Codes and Ideal Input Voltages Description FS − 1 LSB Midscale + 1 LSB Midscale Midscale − 1 LSB −FS + 1 LSB −FS SYNC_OUT SYNC_IN Analog Input (AINx+ − (AINx−)) VREF = 4.096 V +4.095999512 V +488 nV 0V −488 nV −4.095999512 V −4.096 V RESET SIGNAL CHAIN FOR SINGLE CHANNEL PRECHARGE BUFFER Σ-∆ MODULATOR AINx– ESD PROTECTION DATA INTERFACE CONTROL DIGITAL FILTER DRDY DOUTx DCLK CONTROL BLOCK PIN/SPI CONTROL OPTION PIN OR SPI PIN CONTROL FILTER/GPIO4 MODE3/GPIO3 TO MODE0/GPIO0 SPI CONTROL CS SCLK SDO SDI Figure 83. Top Level Core Signal Chain and Control Rev. B | Page 55 of 105 14001-182 AINx+ –FS + 1LSB –FS + 0.5LSB The AD7768/AD7768-4 have three selectable power modes. In pin control mode, the modulator rate and power mode are tied together for best performance. In SPI control mode, the user can select the power mode and modulator MCLK divider settings. The choice of power modes gives more flexibility to control the bandwidth and power dissipation for the AD7768/AD7768-4. START 100 ... 010 100 ... 001 100 ... 000 –FS ADC Power Modes MCLK 011 ... 111 011 ... 110 011 ... 101 14001-083 CORE SIGNAL CHAIN Digital Output Code, Twos Complement (Hex.) 0x7FFFFF 0x000001 0x000000 0xFFFFFF 0x800001 0x800000 AD7768/AD7768-4 Data Sheet ANALOG INPUTS 400 Figure 84 shows the AD7768/AD7768-4 analog front end. The ESD protection diodes that are designed to protect the ADC from some short duration overvoltage and ESD events are shown on the signal path. The analog input is sampled at twice the modulator sampling frequency, fMOD, which is derived from MCLK. By default, the ADC internal sampling capacitors, CS1 and CS2, are driven by a per channel analog input precharge buffer to ease the driving requirement of the external network. 300 200 AIN (µA) 100 0 –100 –200 BPS 0+ –300 UNBUFFERED AINx+ UNBUFFERED AINx– PHI 0 AIN0+ –400 CS1 0 PHI 1 1 2 3 4 INPUT VOLTAGE (VDIFF) AVSS BPS 0– CS2 PHI 0 0 PRECHARGE BUFFERED AINx+ PRECHARGE BUFFERED AINx– 14001-084 AIN0– AVSS 6 Figure 85. Analog Input Current (AIN) vs. Input Voltage, Analog Input Precharge Buffer Off, VCM = 2.5 V, fMOD = 8.192 MHz PHI 1 AVDD1 5 14001-191 AVDD1 –5 Figure 84. Analog Front End The analog input precharge buffers reduce the switching kickback from the sampling stage to the external circuitry. The precharge buffer reduces the average input current by a factor of eight, and makes the input current more signal independent, to reduce the effects of sampling distortion. This reduction in drive requirements allows pairing of the AD7768/AD7768-4 with lower power, lower bandwidth front end driver amplifiers such as the ADA4940-1/ ADA4940-2. –10 AIN (µA) –15 –20 –25 –30 0 1 2 3 INPUT VOLTAGE (VDIFF) 4 14001-192 The analog input precharge buffers, if enabled, will be enabled for a set period of time for each Fmod cycle. The period of time is dependent on the power mode of the AD7761. The precharge buffer is on for approximately 15 ns in fast mode, 29 ns in median mode, and 116 ns in low mode. For the initial rough charging of the switched capacitor network, the bypass switches, BPS 0+ and BPS 0−, remain open during this first phase. For the remaining phase, the bypass switches are closed, and the fine accuracy settling charge is provided by the external source. PHI 0 and PHI 1 represent the modulator clock sampling phases that switch the input signals onto the sampling capacitors, CS1 and CS2. Figure 86. Analog Input Current (AIN) vs. Input Voltage, Analog Input Precharge Buffer On, VCM = 2.5 V, fMOD = 8.192 MHz The analog input precharge buffers can be turned on/off by means of a register write to Register 0x11 and Register 0x12 (Precharge Buffer Register 1 and Precharge Buffer Register 2). When writing to these registers, the user must write the inverse of the required bit settings. For example, to clear Bit 1 of this register, the user must write 0x01 to the register. This clears Bit 1 and sets all other bits. If the user reads the register again after writing 0x01, the data read is 0xFE, as required. Each analog input precharge buffer is selectable per channel. In pin control mode, the analog input precharge buffers are always enabled for optimum performance. When the analog input precharge buffers are disabled, the analog input current is sourced completely from the analog input source. The unbuffered analog input current is calculated from two components: the differential input voltage on the analog input pair, and the analog input voltage with respect to AVSS. With the precharge buffers disabled, for 32.768 MHz MCLK in fast mode with fMOD = MCLK/4, the differential input current is approximately 48 μA/V and the current with respect to ground is approximately 17 μA/V. For example, if the precharge buffers are off, with AIN1+= 5 V, and AIN1− = 0 V, estimate the current in each input pin as follows: Rev. B | Page 56 of 105 Data Sheet AD7768/AD7768-4 RC network performs a variety of tasks. C1 and C2 are charge reservoirs to the ADC, providing the ADC with fast charge current to the sampling capacitors. Capacitor C3 removes common-mode errors between the AINx+ and AINx− inputs. These capacitors, in combination with RIN, form a low-pass filter to filter out glitches related to the input switching. The input resistance also stabilizes the amplifier when driving large capacitor loads and prevents the amplifier from oscillating. AIN1+ = 5 V × 48 μA/V + 5 V × 17 μA/V = 325 μA AIN1− = −5 V × 48 μA/V + 0 V × 17 μA/V = −240 μA When the precharge buffers are enabled, the absolute voltage with respect to AVSS determines the majority of the current. The maximum input current of approximately −25 μA is measured when the analog input is close to either the AVDD1 or AVSS rails. With either precharge buffers enabled or disabled, the analog input current scales linearly with the modulator clock rate. The analog input current versus input voltage is shown in Figure 85. The optimum driver amplifiers for each of these power, performance, and supply requirements are as follows: Full settling of the analog inputs to the ADC requires the use of an external amplifier. Pair amplifiers such as the ADA4805-2 for low power mode, the ADA4807-2 or ADA4940-1/ADA4940-2 for median mode, and the ADA4807-2 or ADA4896-2 for fast mode with the AD7768/AD7768-4 (see Figure 87 for details). Running the AD7768/AD7768-4 in median and low power modes or reducing the MCLK rate reduces the load and speed requirements of the amplifier; therefore, lower power amplifiers can be paired with the analog inputs to achieve the optimum signal chain efficiency.  The ADA4805-2 is suited for low power, particularly in low power mode. The ADA4940-1 is suited for single-supply operation and is also the recommended fully differential amplifier to drive the AD7768/AD7768-4. For optimum performance in fast power mode, the ADA4896-2 performs best, although the device does not consume the same power as the ADA4899-1. The ADA4896-2 is also suitable for a general-purpose DAQ module, which can be configured for all three power modes.   There is a resistor/capacitor (RC) network between the amplifier output and the ADC input. Figure 87 shows a typical RC network used for the AD7768/AD7768-4 for most amplifier pairings. The For more details, refer to the AN-1384 Application Note. VCM AD7768/AD7768-4 ADA4896-2 RIN AINx+ C1 24-BIT Σ-∆ ADC C3 –INx RIN C2 AINx– PRECHARGE BUFFERS 14001-187 +INx Figure 87. Typical Input Structure for an RC Network Table 27. Amplifier Pairing Options Power Mode Fast Fast Median Low Power 1 Amplifier ADA4896-2 ADA4940-2 ADA4805-2 ADA4805-2 Amplifier Power (mW/channel)1 40.6 13.4 6.9 6.5 Analog Input Precharge Buffer On On On On Typical power at 25°C. Rev. B | Page 57 of 105 Total Power (Amplifier + AD7768) (mW/channel)1 87.9 64.9 34.4 15.9 AD7768/AD7768-4 Data Sheet VCM VIN In SPI control mode, configure the VCM potential using the general configuration register (Register 0x05). The output can be enabled or disabled, and set to (AVDD1 − AVSS)/2, 1.65 V, 2.14 V, or 2.5 V, with respect to AVSS. The VCM voltage output is associated with the Channel 0 circuitry. If Channel 0 is put into standby mode, the VCM voltage output is also disabled for maximum power savings. Channel 0 must be enabled while VCM is being used externally to the AD7768/AD7768-4. REFERENCE INPUT The AD7768/AD7768-4 have two differential reference input pairs. On the AD7768 REF1+ and REF1− are the reference inputs for Channel 0 to Channel 3, and REF2+ and REF2− are for Channel 4 to Channel 7. On the AD7768-4 REF1+ and REF1− are the reference inputs for Channel 0 and Channel 1, and REF2+ and REF2− are for Channel 2 and Channel 3. The absolute input reference voltage range is 1 V to AVDD1 − AVSS. Like the analog inputs, the reference inputs have a precharge buffer option. Each ADC has an individual buffer for each REFx+ and REFx−. The precharge buffers help reduce the burden on the external reference circuitry. In pin control mode, the reference precharge buffers are off by default. In SPI control mode, the user can enable or disable the reference precharge buffers. In the case of unipolar analog supplies, in SPI control mode, the user can achieve the best performance and power efficiency by enabling only the REFx+ buffers. The reference input current scales linearly with the modulator clock rate. For 32 MHz MCLK and MCLK/4 fast mode, the differential input current is ~72 μA/V per channel unbuffered, and ~16 μA/V per channel with the precharge buffers enabled. With the precharge buffers off, REFx+ = 5 V, and REFx− = 0 V, REFx± = 5 V × 72 μA/V = 360 μA VIN REFx+ VOUT ADR4540 ADA4841-1 AD7768/AD7768-4 REFx– Figure 88. Typical Reference Input Configuration Diagram CLOCK SELECTION The AD7768/AD7768-4 have an internal oscillator that is used for initial power-up of the device. After the AD7768/AD7768-4 have completed their start-up routine, the devices normally transfer control of the internal clocking to the externally applied MCLK. The AD7768/AD7768-4 count the falling edges of the external MCLK over a given number of internal clock cycles to determine if the clock is valid and at least a frequency of 1.15 MHz. If there is a fault with the external MCLK, the transfer of control does not occur, the AD7768/AD7768-4 output an error in the status header, and the clock error bit is set in the device status register. No conversion data is output and a reset is required to exit this error state. Three clock source input options are available to the AD7768/ AD7768-4: external CMOS, crystal oscillator, or LVDS. The clock is selected on power-up and is determined by the state of the CLK_SEL pin. If CLK_SEL = 0, the CMOS clock option is selected and the clock is applied to Pin 32 (Pin 31 is tied to DGND). If CLK_SEL = 1, the crystal or LVDS option is selected and the crystal or LVDS is applied to Pin 31 and Pin 32. The LVDS option is available only in SPI control mode. An SPI write to Bit 3 of Register 0x04 enables the LVDS clock option. DIGITAL FILTERING The AD7768/AD7768-4 offer two types of digital filters. In SPI control mode, these filters can be chosen on a per channel basis. In pin control mode, only one filter can be selected for all channels. The digital filters available on the AD7768/AD7768-4 are   Sinc5 low latency filter, −3 dB at 0.204 × ODR Wideband low ripple filter, −3 dB at 0.433 × ODR Both filters can be operated in one of six different decimation rates, allowing the user to choose the optimal input bandwidth and speed of the conversion versus the desired power mode or resolution. Sinc5 Filter With the precharge buffers on, REFx+ = 5 V, and REFx− = 0 V, REFx± = 5 V × 16 μA/V = 80 μA For the best performance and headroom, it is recommended to use a 4.096 V reference such as the ADR444 or the ADR4540. For the best performance at high sampling rates, it is recommended to use an external reference drive amplifier such as the ADA4841-1 or the AD8031. See Figure 88 for the configuration diagram of the reference connection. 14001-188 The AD7768/AD7768-4 provide a buffered common-mode voltage output on Pin 59. This output can bias up analog input signals. By incorporating the VCM buffer into the ADC, the AD7768/AD7768-4 reduce component count and board space. In pin control mode, the VCM potential is fixed to (AVDD1 − AVSS)/2, and is enabled by default. Most precision Σ-Δ ADCs use a sinc filter. The sinc5 filter offered in the AD7768/AD7768-4 enables a low latency signal path useful for dc inputs, for control loops, or where other specific postprocessing is required. The sinc5 filter path offers the lowest noise and power consumption. The sinc5 filter has a −3 dB BW of 0.204 × ODR. Table 13 contains the noise performance for the sinc5 filter across power modes and decimation ratios. Rev. B | Page 58 of 105 AD7768/AD7768-4 0.010 0.008 –40 0.006 –60 0.004 –80 –100 –120 0.002 0 –0.002 –140 –0.004 –160 –0.006 –180 –0.008 –200 0 2 4 6 8 10 12 14 16 NORMALIZED INPUT FREQUENCY (fIN/fODR) –0.010 0 0.05 0.10 0.15 0.20 0.25 0.30 0.35 0.40 0.45 14001-089 AMPLITUDE (dB) 0 –20 14001-086 AMPLITUDE (dB) Data Sheet 0.50 NORMALIZED INPUT FREQUENCY (fIN/fODR) Figure 89. Sinc5 Filter Frequency Response (Decimation = ×32) Figure 91. Wideband Filter Pass-Band Ripple 1.2 The settling times for the AD7768/AD7768-4 when using the sinc5 filter are shown in Figure 89. 1.0 Wideband Low Ripple Filter 0 –10 –20 –30 –50 –60 –70 –80 –90 –100 –110 –120 –130 –140 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 NORMALIZED INPUT FREQUENCY (fIN/fODR) 1.0 0.4 0.2 0 –0.2 0 10 20 30 40 50 60 OUTPUT DATA RATE SAMPLES 70 80 Figure 92. Wideband Filter Step Response Filter Settling Time The AD7768/AD7768-4 digital filters are resynchronized on the rising edge of the SYNC_IN signal. Provide this resynchronization after power-up in pin control mode or SPI control mode, and after any reconfiguration of the device in SPI control mode, prior to capturing ADC samples. After the SYNC_IN rising edge is provided, there is a deterministic delay until the first new conversion result is available, and until the first settled data is available. Table 28 and Table 29 provide these delays, measured in MCLK cycles, for the wideband and sinc5 filters, respectively, for each possible setting of MCLK_DIV. Each table provides the delays for configurations where all channels are using the exact same configuration (Group B unused), and for configurations where one or more channels have a different decimation rate applied (Group B is used). 14001-088 AMPLITUDE (dB) –40 0.6 14001-090 The wideband filter is a very high order digital filter with a group delay of approximately 34/ODR. After a synchronization pulse, there is an additional delay from the SYNC_IN rising edge to fully settled data. The settling times for the AD7768/ AD7768-4 when using the wideband filter are shown in Figure 90. See Table 12 for the noise performance of the wideband filter across power modes and decimation rates. 0.8 AMPLITUDE (dB) The wideband filter has a low ripple pass band, within ±0.005 dB of ripple, of 0.4 × ODR. The wideband filter has full attenuation at 0.499 × ODR (Nyquist), maximizing antialias protection. The wideband filter has a pass-band ripple of ±0.005 dB and a stop band attenuation of 105 dB from Nyquist out to fCHOP. For more information on antialiasing and fCHOP aliasing, see the Antialiasing section. Figure 90. Wideband Filter Frequency Response Rev. B | Page 59 of 105 AD7768/AD7768-4 Data Sheet For example, when the channels are configured with the wideband filter and MCLK_DIV = MCLK/4, with some channels are assigned to Group A with decimate by 32 and other channels to Group B with decimate by 64, then the delay until the first DRDY signal after the SYNC_IN signal is 758 MCLK periods. All active channels output the first data after 758 MCLK periods. However, due to differing decimation rates across channels, in this case, the first settled data is available for the Group A channels 8822 MCLK periods after the SYNC_IN signal, and after 17,014 MCLK periods for the Group B channels. Table 28. Wideband Filter SYNC_IN to Settled Data MCLK_DIV Setting MCLK/4 MCLK/8 Filter Type Group A Group B Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Decimation Factor Group A Group B 32 Unused 64 Unused 128 Unused 256 Unused 512 Unused 1024 Unused 32 32 32 64 32 128 32 256 32 512 32 1024 64 32 128 32 256 32 512 32 1024 32 32 Unused 64 Unused 128 Unused 256 Unused 512 Unused 1024 Unused 32 32 32 64 32 128 32 256 32 512 32 1024 64 32 128 32 256 32 512 32 1024 32 Delay from First MCLK Rise After SYNC_IN Rise to First DRDY Rise Delay from First MCLK Rise After SYNC_IN Rise to Earliest Settled Data DRDY Rise MCLK Periods 336 620 1187 2325 4601 9153 758 758 758 758 758 758 759 760 762 782 806 656 1225 2359 4635 9187 18,291 820 820 820 820 820 820 822 824 844 836 852 Group A 8400 16,748 33,443 66,837 133,625 267,201 8822 8822 8822 8822 8822 8822 17,015 33,528 66,938 133,646 267,302 16,784 33,481 66,871 133,659 267,235 534,387 16,948 16,948 16,948 16,948 16,948 16,948 33,590 66,872 133,708 267,332 534,612 Rev. B | Page 60 of 105 MCLK Periods Group B Not applicable Not applicable Not applicable Not applicable Not applicable Not applicable 8822 17,014 33,526 66,934 133,622 267,253 8823 8824 8826 8846 8870 Not applicable Not applicable Not applicable Not applicable Not applicable Not applicable 16,948 33,588 66,868 133,684 267,316 534,580 16,950 16,952 16,972 16,964 16,980 Data Sheet MCLK_DIV Setting MCLK/32 Filter Type Group A Group B Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband Wideband AD7768/AD7768-4 Decimation Factor Group A Group B 32 Unused 64 Unused 128 Unused 256 Unused 512 Unused 1024 Unused 32 32 32 64 32 128 32 256 32 512 32 1024 64 32 128 32 256 32 512 32 1024 32 Delay from First MCLK Rise After SYNC_IN Rise to First DRDY Rise Delay from First MCLK Rise After SYNC_IN Rise to Earliest Settled Data DRDY Rise MCLK Periods 2587 4855 9391 18,495 36,703 73,119 2587 2587 2587 2587 2587 2587 2587 2587 2587 2587 2587 Group A 67,099 133,879 267,439 534,591 1,068,895 2,137,503 67,099 67,099 67,099 67,099 67,099 67,099 134,683 267,803 535,067 1,069,595 2,137,627 MCLK Periods Group B Not applicable Not applicable Not applicable Not applicable Not applicable Not applicable 67,099 134,683 267,803 535,067 1,069,595 2,137,627 67,099 67,099 67,099 67,099 67,099 Table 29. Sinc5 Filter SYNC_IN to Settled Data MCLK_DIV Setting MCLK/4 MCLK/8 Filter Type Group A Group B Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Decimation Factor Group A Group B 32 Unused 64 Unused 128 Unused 256 Unused 512 Unused 1024 Unused 32 32 32 64 32 128 32 256 32 512 32 1024 64 32 1024 32 32 Unused 64 Unused 128 Unused 256 Unused 512 Unused 1024 Unused 32 32 32 64 32 128 32 256 32 512 32 1024 64 32 1024 32 Delay from First MCLK Rise After SYNC_IN Rise to First DRDY Rise MCLK Periods 199 327 583 1095 2119 4167 199 199 199 199 199 199 199 199 383 639 1151 2175 4223 8319 383 383 383 398 398 398 383 398 Rev. B | Page 61 of 105 Delay from First MCLK Rise After SYNC_IN Rise to Earliest Settled Data DRDY Rise Group A MCLK Periods 839 1607 3143 6215 12359 24,647 839 839 839 839 839 839 1607 24,647 1663 3199 6271 12,415 24,703 49,279 1663 1663 1663 1663 1663 1663 3199 49,279 Group B MCLK Periods Not applicable Not applicable Not applicable Not applicable Not applicable Not applicable 839 1607 3143 6215 12,359 24,647 839 839 Not applicable Not applicable Not applicable Not applicable Not applicable Not applicable 1663 3199 6271 12,415 24,703 49,279 1663 1663 AD7768/AD7768-4 MCLK_DIV Setting MCLK/32 Filter Type Group A Group B Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Sinc5 Data Sheet Decimation Factor Group A Group B 32 Unused 64 Unused 128 Unused 256 Unused 512 Unused 1024 Unused 32 32 32 64 32 128 32 256 32 512 32 1024 64 32 1024 32 Delay from First MCLK Rise After SYNC_IN Rise to First DRDY Rise MCLK Periods 1487 2511 4559 8655 16,847 33,231 1487 1487 1487 1487 1487 1487 1487 1487 Delay from First MCLK Rise After SYNC_IN Rise to Earliest Settled Data DRDY Rise Group A MCLK Periods 6607 12,751 25,039 49,615 98,767 197,071 6607 6607 6607 6607 6607 6607 12,751 197,071 Group B MCLK Periods Not applicable Not applicable Not applicable Not applicable Not applicable Not applicable 6607 12,751 25,039 49,615 98,767 197,071 6607 6607 DECIMATION RATE CONTROL ANTIALIASING The AD7768/AD7768-4 have programmable decimation rates for the digital filters. The decimation rates allow the user to reduce the measurement bandwidth, reducing the speed but increasing the resolution. When using the SPI control, control the decimation rate on the AD7768/AD7768-4 through the channel mode registers. These registers set two separate channel modes with a given decimation rate and filter type. Each ADC is mapped to one of these modes via the channel mode select register. Table 30 details both the decimation rates available, and the filter types for selection, within Mode A and Mode B. Because the AD7768/AD7768-4 are switched capacitor, discrete time ADCs, the user may wish to employ external analog antialiasing filters to protect against fold back of out of band tones. In pin control mode, the decimation ratio is controlled by the DEC0 and DEC1 pins; see Table 17 for decimation configuration in pin control mode. Name FILTER_TYPE_x [2:0] DEC_RATE_x Logic Value 0 1 000 001 010 011 100 101 110 111 When designing an antialiasing filter for the AD7768/AD7768-4, three main aliasing regions must be taken into account. After the alias requirements of each zone are understood, the user can design an antialiasing filter to meet the needs of the specific application. The three zones for consideration are related to the modulator sampling frequency, the modulator chopping frequency, and the modulator saturation point. Modulator Sampling Frequency Table 30. Channel x Mode Registers, Register 0x01 and Register 0x02 Bits 3 Within this section, an out of band tone refers to an input frequency greater than the pass band frequency specification of the digital filter that is applied at the analog input. Decimation Rate Wideband filter Sinc5 filter 32 64 128 256 512 1024 1024 1024 The AD7768/AD7768-4 modulator signal transfer function includes a notch, at odd multiples of fMOD, to reject tones or harmonics related to the modulator clock. The modulator itself attenuate signals at frequencies of fMOD, 3 × fMOD., 5 × fMOD, and so on. For an MCLK frequency of 32.768 MHz, the attenuation is approximately 35 dB in fast mode, 41 dB in median mode, and 53 dB in low power mode. Attenuation is increased by 6 dB across each power mode, with every halving of the MCLK frequency, for example, when reducing the clock from 32.768 MHz to 16.384 MHz. The modulator has no rejection to signals that are at frequencies in zones around 2 × fMOD and all even multiples of fMOD.. Signals at these frequencies are aliased by the AD7768/AD7768-4. For the AD7768/AD7768-4, the first of these zones that requires protection is at 2 × fMOD. Because typical switch capacitor, discrete time Σ-Δ modulators provide no protection to aliasing at the frequency, fMOD, the AD7768/AD7768-4 provide a distinct advantage in this regard. Rev. B | Page 62 of 105 Data Sheet AD7768/AD7768-4 Figure 93 shows the frequency response of the modulator and wideband digital filter to out of band tones at the analog input. Figure 93 shows the magnitude of an alias that is seen in band vs. the frequency of the signal sampled at the analog input. The relationship between the input signal and the modulator frequency is expressed in a normalized manner as a ratio of the input signal (fIN) to the modulator frequency (fMOD). This data demonstrates the ADC frequency response relative to out of band tones when using the wideband filter. The input frequency (fIN) is swept from dc to 20 MHz. In fast mode, using an 8.192MHz fMOD frequency, the x-axis spans ratios of fIN/fMOD from 0 to 2.44 (equivalent to fIN of 0 Hz to 20 MHz). A similar characteristic occurs in median mode and low power mode. The notch appears in Figure 93 with the input frequency (fIN) at fMOD (designated at fIN/fMOD = 1.00 on the x-axis). An input at this frequency is attenuated by 35 dB, which adds to the attenuation of any external antialiasing filter, thus reducing the frequency rolloff requirement of the external filter. If the plot is swept further in frequency, the notch is seen to recur at fIN/fMOD = 3.00. The point where fIN = 2 × fMOD (designated on the x-axis at 2.00) offers 0 dB attenuation, indicating that all signals falling at this frequency alias directly back into the ADC conversion results, in accordance with sampling theory. The AD7768/AD7768-4 wideband digital filter also offers an added protection against aliasing. Because the wideband filter has full attenuation at the Nyquist frequency (fODR/2, where fODR = fMOD/Decimation Rate), input frequencies, and in particular harmonics of input frequencies, that may fall close to fODR/2, do not fold back into the pass-band of the AD7768/AD7768-4. ALIAS MAGNITUDE (dB) WITH RESPECT TO IN-BAND MAGNITUDE –20 Figure 93 plots two scenarios that relate to the chopping frequency of the AD7768/AD7768-4 modulators. The AD7768/AD7768-4 use a chopping technique in the modulator similar to that of a chopped amplifier to remove offset, offset drift, and 1/f noise. The AD7768/AD7768-4 default chopping rate is fMOD/32. In pin control mode, the chop frequency is hardwired to fMOD/32. In SPI control mode, the user can select the chop frequency to be either fMOD/32 or fMOD/8. As shown in Figure 93, the stop band rejection of the digital filter is reduced at frequencies that relate to even multiples of the chopping frequency (fCHOP). All other out of band frequencies (excluding those already discussed relating to the modulator clock frequency fMOD) are rejected by the stop band attenuation of the digital filter. An out of band tone with a frequency in the range of (2 × fCHOP ) ± f3dB, where f3dB is the filter bandwidth employed, is attenuated to the envelope determined by the chop frequency setting (see Figure 93), and aliased into the pass band. Out of band tones near additional even multiples of fCHOP (that is, N × fCHOP, where N is an even integer), are attenuated and aliased in the same way. Chopping at fMOD/32 offers the best performance for noise, offset, and offset drift for the AD7768/AD7768-4. For ac performance it may be useful to select chopping at fMOD/8 as this moves the first chopping tone to a higher frequency. However, chopping at fMOD/8 may lead to slightly degraded noise (approximately 1 dB loss in dynamic range) and offset performance compared to the default chop rate of fMOD/32. Table 31 shows the aliasing achieved by different order antialiasing filter options at the critical frequencies of fMOD/32 and fMOD/8 for chop aliasing, fMOD/16 for modulator saturation, and 2 × fMOD for the first zone with 0 dB attenuation. It assumes the corner frequency of the antialiasing filter is at fMOD/64, which is just above the maximum input bandwidth that the AD7768/AD7768-4 digital filter can pass when using a decimate by 32 filter setting. 0 –10 Modulator Chopping Frequency fCHOP = fMOD/32 fCHOP = fMOD/8 –30 –40 –50 –60 –70 –80 –90 –100 Table 31. External Antialiasing Filter Attenuation –110 –120 –130 –140 2.500 2.250 2.375 2.000 2.125 1.750 1.875 14001-197 fIN/fMOD 1.500 1.625 1.250 1.375 1.125 0.875 1.000 0.625 0.750 0.375 0.500 0 0.125 0.250 –150 RC Filter First Order Second Order Third Order Figure 93. AD7768/AD7768-4 Rejection of Out of Band Input Tones, Wideband Filter, Decimation = ×32, fMOD = 8.192 MHz, Analog Input Sweep from DC to 20 MHz Rev. B | Page 63 of 105 fMOD/32 (dB) −6 −12 −18 fMOD/16 (dB) −12 −24 −36 fMOD/8 (dB) −18 −36 −54 2 × fMOD (dB) −42 −84 −126 AD7768/AD7768-4 Data Sheet Modulator Saturation Point A Σ-Δ modulator can be considered a standard control loop, employing negative feedback. The control loop works to ensure that the average processed error signal is very small over time. It uses an integrator to remember preceding errors and force the mean error to be zero. As the input signal rate of change increases with respect to the modulator clock, fMOD, a larger voltage feedback error is processed. Above a certain frequency, the error begins to saturate the modulator. For theAD7768/AD7768-4, the modulator may saturate for fullscale input frequencies greater than fMOD/16 (see Figure 94), depending on the rate of change of input signal, input signal amplitude, and reference input level. A half power input tone at fMOD/8 may also cause the modulator to saturate. In applications where there may be high amplitude and frequency out of band tones, a first-order antialiasing filter is required with a −3 dB corner frequency set at fMOD/16 to protect against modulator saturation. For example, if operating the AD7768/AD7768-4 at full speed and using a decimation rate of ×32 to achieve an output data rate of 256 kSPS, the modulator rate is equal to 8.192 MHz. In this instance, to protect against saturation, set the antialiasing filter −3 dB corner frequency to 512 kHz. 3 MAXIMUM SIGNAL MAXIMUM INPUT SIGNAL (dB) 0 Gain Adjustment Each ADC channel has an associated gain coefficient. The coefficient is stored in three single-byte registers split up as MSB, MID, and LSB. Each of the gain registers are factory programmed. Nominally, this gain is around the value 0x555555 (for an ADC channel). The user may overwrite the gain register setting. However, after a reset or power cycle, the gain register values revert to the hard coded programmed factory setting. Calculate the approximate result that is output using the following formula:  3  V IN  Gain 4 ,194 ,300  2 21  (Offset)   Data    V 4 2 42  REF  where: Offset is the offset register setting. Gain is the gain register setting. Sync Phase Offset Adjustment The AD7768/AD7768-4 have one synchronization signal for all channels. The sync phase offset register allows the user to vary the phase delay on each of the channels relative to the synchronization edge received on the SYNC_IN pin. By default, all ADC channels react simultaneously to the SYNC_IN pulse. The sync phase registers can be programmed to equalize known external phase differences on ADC input channels, relative to one another. The range of phase compensation is limited to a maximum of one conversion cycle, and the resolution of the correction depends on the decimation rate in use. –6 –9 FIRST ORDER (fMOD/64) –12 AD7768-4). After a reset or power cycle, the offset register values revert to the default factory setting. –15 –18 –21 Table 32 displays the resolution and register bits used for phase offset for each decimation ratio. –24 –27 0 0.004 0.040 FREQUENCY (Hz) 0.4 14001-394 Table 32. Phase Delay Resolution –30 Figure 94. Maximum Input Signal vs. Frequency CALIBRATION In SPI control mode, the AD7768/AD7768-4 offer users the ability to adjust offset, gain, and phase delay on a per channel basis. Offset Adjustment The CHx_OFFSET_MSB, CHx_OFFSET_MID, and CHx_ OFFSET_LSB registers are 24-bit, signed twos complement registers for channel offset adjustment. If the channel gain setting is at its ideal nominal value of 0x555555, an LSB of offset register adjustment changes the digital output by −4/3 LSBs. For example, changing the offset register from 0 to 100 changes the digital output by −133 LSBs. Because offset calibration occurs before gain calibration, the ratio of 4/3 changes linearly with gain adjustment via the Channel x gain registers (see Table 56 and Table 57 for the AD7768, or Table 82 and Table 83 for the Decimation Ratio ×32 ×64 ×128 ×256 ×512 ×1024 Resolution 1/fMOD 1/fMOD 1/fMOD 1/fMOD 2/fMOD 4/fMOD Steps 32 64 128 256 256 256 Phase Register Bits [7:3] [7:2] [7:1] [7:0] [7:0] [7:0] Adjusting the sync phase of channels can affect the time to the first DRDY pulse after the sync pulse, as well as the time to Bit 6 of the header status (filter not settled data bit) being cleared, that is, the time to settled data. Rev. B | Page 64 of 105 Data Sheet AD7768/AD7768-4 If all channels are using the Sinc5 filter, the time to the first DRDY pulse is not affected by the adjustment of the sync phase offset, assuming that at least one channel has zero sync phase offset adjustment. If all channels have a nonzero sync phase offset setting, the time to the first DRDY pulse is delayed according to the channel that has the least offset applied. Channels with a sync offset adjustment setting that delays the internal sync signal, relative to other channels, may not output settled data until after the next DRDY pulse. In other words, there may be a delay of one ODR period between the settled data being output by the AD7768/AD7768-4 for the channels with added phase delay. If all channels are using the wideband filter, the time to the first DRDY pulse and the time to settled data is delayed according to the channel with the maximum phase delay setting. In this case, the interface waits for the latest channel and outputs data for all channels when that channel is ready. Rev. B | Page 65 of 105 AD7768/AD7768-4 Data Sheet DATA INTERFACE with higher DCLK frequencies. For the best offset and offset drift performance, use the lowest DCLK frequency possible. The user can choose to reduce the DCLK frequency by an appropriate selection of MCLK frequency, DCLK divider, and/or the number of DOUTx lines used. Table 1 and Table 2 give the offset and offset drift specifications for ranges of DCLK frequency, and Figure 49 shows the typical offset drift over a range of DCLK frequencies. SETTING THE FORMAT OF DATA OUTPUT The data interface format is determined by setting the FORMATx pins. The logic state of the FORMATx pins are read on powerup and determine how many data lines (DOUTx) the ADC conversions are output on. Because the FORMATx pins are read on power-up of the AD7768 and the device remains in this output configuration, this function must always be hardwired and cannot be altered dynamically. Table 33, Figure 95, Figure 96, and Figure 98 show the formatting configuration for the digital output pins on the AD7768. Table 33. FORMATx Truth Table for the AD7768 Calculate the minimum required DCLK rate for a given data interface configuration as follows: FORMAT1 0 FORMAT0 0 0 1 1 X DCLK (minimum) = Output Data Rate × Channels per DOUTx × 32 where MCLK ≥ DCLK. For example, if MCLK = 32.768 MHz, with two DOUTx lines, DCLK (minimum) = 256 kSPS × 4 channels per DOUTx × 32 = 32.768 Mbps Description Each ADC channel outputs on its own dedicated pin. DOUT0 to DOUT7 are in use. The ADCs share the DOUT0 and DOUT1 pins: Channel 0 to Channel 3 output on DOUT0. Channel 4 to Channel 7 output on DOUT1. The ADC channels share data pins in time division multiplexed (TDM) output. DOUT0 and DOUT1 are in use. All channels output on the DOUT0 pin, in TDM output. Only DOUT0 is in use. Therefore, DCLK = MCLK/1. Table 34. FORMAT0 Truth Table for the AD7768-4 Alternatively, if MCLK = 32.768 MHz, with eight DOUTx lines, FORMAT0 0 DCLK (minimum) = 256 kSPS × 1 channel per DOUTx × 32 = 8.192 Mbps Description Each ADC channel outputs on its own dedicated pin. DOUT0 to DOUT3 are in use. All channels output on the DOUT0 pin, in TDM output. Only DOUT0 is in use. 1 Therefore, DCLK = MCLK/4. Higher DCLK rates make it easier to receive the conversion data from the AD7768/AD7768-4 with a lower number of DOUTx lines; however, there is a trade-off against ADC offset performance AD7768 DRDY DCLK EACH ADC HAS A DEDICATED DOUTx PIN FORMAT0 FORMAT1 0 0 DOUT0 CH 0 DOUT1 CH 1 CH 7 DAISY-CHAINING IS NOT POSSIBLE IN THIS FORMAT 14001-092 DOUT7 DGND Figure 95. AD7768 FORMATx = 00, Eight Data Output Pins AD7768 DRDY CHANNEL4 TO CHANNEL7 OUTPUT ON DOUT1 IOVDD DCLK 1 0 DOUT0 FORMAT0 FORMAT1 DOUT1 DGND DAISY-CHAINING IS POSSIBLE IN THIS FORMAT Figure 96. AD7768 FORMATx = 01, Two Data Output Pins Rev. B | Page 66 of 105 14001-193 CHANNEL0 TO CHANNEL3 OUTPUT ON DOUT0 Data Sheet AD7768/AD7768-4 AD7768-4 DRDY EACH ADC HAS A DEDICATED DOUTx PIN FORMAT0 0 DGND CH 0 DOUT1 CH 1 DOUT2 CH 2 DOUT3 CH 3 DAISY-CHAINING IS NOT POSSIBLE IN THIS FORMAT 14001-092 DCLK DOUT0 Figure 97. AD7768-4 FORMAT0 = 0, Four Data Output Pins AD7768 DRDY IOVDD 1 1 FORMAT0 FORMAT1 DCLK DOUT0 DAISY-CHAINING IS POSSIBLE IN THIS FORMAT 14001-194 CHANNEL0 TO CHANNEL7 OUTPUT ON DOUT0 Figure 98. AD7768 FORMATx = 10 or 11, or AD7768-4 FORMAT0 = 1, One Data Output Pin ADC CONVERSION OUTPUT: HEADER AND DATA ERROR_FLAGGED The AD7768 data is output on the DOUT0 to DOUT7 pins, depending on the FORMATx pins. The AD7768-4 data is output on the DOUT0 to DOUT3 pins, depending on the FORMAT0 pin. The actual structure of the data output for each ADC result is shown in Figure 99. Each ADC result comprises 32 bits. The first eight bits are the header status bits, which contain status information and the channel number. The names of each of the header status bits are shown in Table 35, and their functions are explained in the subsequent sections. This header is followed by a 24-bit ADC output in twos complement coding, MSB first. The error flagged bit indicates that a serious error has occurred. If this bit is set, a reset is required to clear this bit. This bit indicates that the external clock is not detected, a memory map bit has unexpectedly changed state, or an internal CRC error has been detected. DRDY N–1 HEADER N 8 BITS ADC DATA N 24 BITS Figure 99. ADC Output: 8-Bit Header, 24-Bit ADC Conversion Data Table 35. Header Status Bits Bit 7 6 5 4 3 [2:0] Bit Name ERROR_FLAGGED Filter not settled Repeated data Filter type Filter saturated Channel ID[2:0] 14001-093 DOUTx In the case where an external clock is not detected, the conversion results are output as all zeros regardless of the analog input voltages applied to the ADC channels. Filter Not Settled After power-up, reset, or synchronization, the AD7768/AD7768-4 clear the digital filters and begins conversion. Due to the weighting of the digital filters, there is a delay from the first conversion to fully settled data. The settling times for the AD7768/AD7768-4 when using the wideband and sinc5 filters are shown in Table 28 and Table 29, respectively. This bit is set if this settling delay has not yet elapsed. Repeated Data If different channels use different decimation rates, data outputs are repeated for the slower speed channels. In these cases, the header is output as normal with the repeated data bit set to 1, and the following repeated ADC result is output as all zeros. This bit indicates that the conversion result of all zeros is not real; it indicates that there is a repeated data condition because two different decimation rates are selected. This condition can only occur during SPI control of the AD7768/AD7768-4. Rev. B | Page 67 of 105 AD7768/AD7768-4 Data Sheet Filter Type In pin control mode, all channels operate using one filter selection. The filter selected in pin control mode is determined by the logic level of the FILTER pin. In SPI control mode, the digital filters can be selected on a per channel basis, using the mode registers. This header bit is 0 for channels using the wideband filter, and 1 for channels using the sinc5 filter. Filter Saturated The filter saturated bit indicates that the filter output is clipping at either positive or negative full scale. The digital filter clips if the signal goes beyond the specification of the filter; it does not wrap. The clipping may be caused by the analog input exceeding the analog input range, or by a step change in the input, which may cause overshoot in the digital filter. Clipping may also occur when the combination of the analog input signal and the channel gain register setting cause the signal seen by the filter to be higher than the analog input range. Channel ID The channel ID bits indicate the ADC channel from which the succeeding conversion data originates (see Table 36). Table 36. Channel ID vs. Channel Number Channel Channel 0 Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel ID 2 0 0 0 0 1 1 1 1 Channel ID 1 0 0 1 1 0 0 1 1 Channel ID 0 0 1 0 1 0 1 0 1 Data Interface: Standard Conversion Operation In standard mode operation, the AD7768/AD7768-4 operate as the master and stream data to the DSP or FPGA. The AD7768/ AD7768-4 supply the data, the data clock (DCLK), and a falling edge framing signal (DRDY) to the slave device. All of these signals are synchronous. The data interface connections to DSP/FPGA are shown in Figure 107. The FORMATx pins determine how the data is output from the AD7768/AD7768-4. Figure 100 through Figure 103 show the data interface operating in standard mode at the maximum data rate. In all instances, DRDY is asserted one clock cycle before the MSB of the data conversion is made available on the data pin. Each DRDY falling edge starts the output of the new ADC conversion data. The first eight bits output after the DRDY falling edge are the header bits; the last 24 bits are the ADC conversion result. Figure 100, Figure 101, Figure 102, and Figure 103, are distinct examples of the impact of the FORMATx pins on the AD7768 output operating in standard conversion operation. Figure 104, Figure 105, and Figure 106show examples of the AD7768-4 interface configuration. Figure 100 to Figure 103 represent running the AD7768 at maximum data rate for the three FORMATx options. Figure 100 shows FORMATx = 00 each ADC has its own data out pin running at the MCLK/4 bit rate. In pin control mode, this is achieved by selecting Mode 0xA (fast mode, DCLK = MCLK/4, standard conversion, see Table 20) with the decimation rate set as ×32. Figure 101 shows FORMATx = 01 share DOUT1 at the maximum bit rate. In pin control mode, this is achieved by selecting Mode 0x8 (fast mode, DCLK = MCLK/1, standard conversion) with a decimation rate of ×32. If running in pin control mode, the example shown in Figure 103 represents Mode 0x4 (median mode, DCLK = MCLK/1, standard conversion) with a decimation rate of ×32, giving the maximum output data capacity possible on one DOUTx pin. Figure 102 (AD7768) and Figure 106 (AD7768-4) show examples of one configuration where there can be long periods in which no data is output by the AD7768. This configuration depends on the FORMATx, MCLK, and decimation settings. In Figure 102, FORMATx = 01, meaning the channels share DOUT0 and DOUT1. In Figure 106, FORMAT0 = 1, meaning all channels share the DOUT0 pin. For both Figure 102 and Figure 106, DCLK = MCLK/4 and the decimation rate is 512.In pin control mode, this setup is achieved by selecting Mode 0x0A (fast mode, DCLK = MCLK/4, standard conversion mode). With a decimation rate of 512, the ratio of ODR to DCLK rate is high enough to show that only ¼ of the DRDY or ODR period is used with output data, and the other ¾ of the period DOUTx is low. Rev. B | Page 68 of 105 Data Sheet AD7768/AD7768-4 DCLK SAMPLE N SAMPLE N + 1 DOUT0 D0 D31 D30 D29 D28 D27 D... D5 D4 D3 D2 D1 D0 D31 D30 D29 D28 D27 D... D5 D4 D3 D2 D1 D0 DOUT1 D0 D31 D30 D29 D28 D27 D... D5 D4 D3 D2 D1 D0 D31 D30 D29 D28 D27 D... D5 D4 D3 D2 D1 D0 DOUT7 D0 D31 D30 D29 D28 D27 D... D5 D4 D3 D2 D1 D0 D31 D30 D29 D28 D27 D... D5 D4 D3 D2 D1 D0 14001-095 DRDY Figure 100. AD7768 FORMATx = 00: Each ADC Has a Dedicated Data Output Pin, Maximum Data Rate DCLK SAMPLE N SAMPLE N + 1 DRDY DOUT0 CH0 (N) CH1 (N) CH2 (N) CH3 (N) CH0 (N+1) CH1 (N+1) CH2 (N+1) CH3 (N+1) DOUT1 CH4 (N) CH5 (N) CH6 (N) CH7 (N) CH4 (N+1) CH5 (N+1) CH6 (N+1) CH7 (N+1) 14001-096 DOUT2 DOUT7 Figure 101. AD7768 FORMATx = 01: Channel 0 to Channel 3 Share DOUT0, and Channel 4 to Channel 7 Share DOUT1, Maximum Data Rate DCLK SAMPLE N DRDY DOUT0 CH0 (N) CH1 (N) CH2 (N) CH3 (N) DOUT1 CH4 (N) CH5 (N) CH6 (N) CH7 (N) 14001-102 DOUT2 DOUT7 Figure 102. AD7768 FORMATx = 01: Channel 0 to Channel 3 Share DOUT0, and Channel 4 to Channel 7 Share DOUT1, Decimation=512 Rev. B | Page 69 of 105 AD7768/AD7768-4 Data Sheet DCLK SAMPLE N SAMPLE N + 1 SAMPLE N + 2 DRDY DOUT0 14001-097 DOUT1 DOUT7 Figure 103. AD7768 FORMATx = 11 or 10: Channel 0 to Channel 7 Output on DOUT0 Only, Maximum Data Rate DCLK SAMPLE N SAMPLE N + 1 DOUT0 D0 D31 D30 D29 D28 D27 D... D5 D4 D3 D2 D1 D0 D31 D30 D29 D28 D27 D... D5 D4 D3 D2 D1 D0 DOUT1 D0 D31 D30 D29 D28 D27 D... D5 D4 D3 D2 D1 D0 D31 D30 D29 D28 D27 D... D5 D4 D3 D2 D1 D0 DOUT2 D0 D31 D30 D29 D28 D27 D... D5 D4 D3 D2 D1 D0 D31 D30 D29 D28 D27 D... D5 D4 D3 D2 D1 D0 DOUT3 D0 D31 D30 D29 D28 D27 D... D5 D4 D3 D2 D1 D0 D31 D30 D29 D28 D27 D... D5 D4 D3 D2 D1 D0 14001-395 DRDY Figure 104. AD7768-4 FORMAT0 = 0: Each ADC Has a Dedicated Data Output Pin, Maximum Data Rate DCLK SAMPLE N SAMPLE N + 1 SAMPLE N + 2 DRDY DOUT0 DOUT1 14001-302 DOUT2 DOUT3 Figure 105. AD7768-4 FORMAT0 = 1: Channel 0 to Channel 3 Output on DOUT0 Only, Maximum Data Rate Rev. B | Page 70 of 105 Data Sheet AD7768/AD7768-4 DCLK SAMPLE N DRDY DOUT0 CH0 (N) CH1 (N) CH2 (N) CH3 (N) DOUT1 14001-106 DOUT2 DOUT7 Figure 106. AD7768-4 FORMAT0 = 1: Channel 0 to Channel 3 Output on DOUT0 Only, Decimation =512 DSP/FPGA AD7768 DCLK DRDY 14001-094 DOUT0 TO DOUT7 MCLK Figure 107. Data Interface: Standard Conversion Operation, AD7768 = Master, DSP/FPGA = Slave SYNC_IN DOUT0 SETTLED DATA SETTLED DATA DOUT1 SETTLED DATA SETTLED DATA DOUT7 SETTLED DATA SETTLED DATA 32 DCLKs 32 DCLKs DRDY Figure 108. AD7768 One-Shot Mode Rev. B | Page 71 of 105 14001-098 tSETTLE AD7768/AD7768-4 Data Sheet Data Interface: One-Shot Conversion Operation Daisy-Chaining One-shot mode is available in both SPI and pin control modes. This conversion mode is available by selecting one of Mode 0xC to Mode 0xF when in pin control mode. In SPI control mode, set Bit 4 (one shot) of Register 0x06, the data control register. Figure 108 shows the device operating in one-shot mode. Daisy-chaining devices allows numerous devices to use the same data interface lines by cascading the outputs of multiple ADCs from separate AD7768/AD7768-4 devices. Only one ADC device has its data interface in direct connection with the digital host. In one-shot mode, the AD7768/AD7768-4 are pseudo slaves. Conversions occur on request by the master device, for example, the DSP or FPGA. The SYNC_IN pin initiates the conversion request. In one-shot mode, all ADCs run continuously; however, the rising edge of the SYNC_IN pin controls the point in time from which data is output. For the AD7768/AD7768-4, this connection can be implemented by cascading DOUT0 and DOUT1 through a number of devices, or just using DOUT0; whether two data output pins or only one data output pin is enabled depends on the FORMATx pins. The ability to daisy-chain devices and the limit on the number of devices that can be handled by the chain is dependent on the power mode, DCLK, and the decimation rate employed. When the master pulses SYNC_IN and the AD7768/AD7768-4 receive the rising edge of this signal, the digital filter is reset and the full settling time of the filter elapses before the data is available. The duration of the settling time depends on the filter path and decimation rate. Running one-shot mode with the sinc5 filter allows the fastest throughput, because this filter has a lower settling time than the wideband filter. As soon as settled data is available on any channel, the device outputs data from all channels. The contents of Bit 6 of the channel header status bits indicates whether the data is fully settled. The period before the data is settled on all channels (tSETTLE) is shown in Figure 108. . The settling (tSETTLE ) time for the AD7768 in one-shot mode is equivalent to the number of clock cycles specified as “Delay from the First MCLK Rise after SYNC_IN Rise to Earliest Settled Data, DRDY Rise” in Table 30. After the data has settled on all channels, DRDY is asserted high and the device outputs the required settled data on all channels before DRDY is asserted low. If the user configures the same filter and decimation rate on each ADC, the data is settled for all channels on the first DRDY output frame, which avoids a period of unsettled data prior to the settled data and ensures that all data is output at the same time on all ADCs. The device then waits for another SYNC_IN signal before outputting more data. The maximum usable DCLK frequency allowed when daisychaining devices is limited by the combination of timing specifications in Table 3 or Table 5, as well as by the propagation delay of the data between devices and any skew between the MCLK signals at each AD7768/AD7768-4 device. The propagation delay and MCLK skew are dependent on the PCB layout and trace lengths. This feature is especially useful for reducing component count and wiring connections, for example, in isolated multiconverter applications or for systems with a limited interfacing capacity. When daisy-chaining, on the AD7768, DOUT6 and DOUT7 become serial data inputs, and DOUT0 and DOUT1 remain as serial data outputs under the control of the FORMATx pins. For the AD7768-4 the DIN pin is the daisy chain serial data input pin and DOUT0 is the serial data output pin. AD7768 START MCLK SYNCHRONIZATION LOGIC DIGITAL FILTER DOUT6 DOUT7 SYNC_IN SYNC_OUT DRDY DOUT0 DOUT1 DSP/ FPGA IOVDD AD7768 START MASTER CLOCK Because all the ADCs are sampling continuously, one-shot mode affects the sampling theory of the AD7768/AD7768-4. Particularly, a user periodically sending a SYNC_IN pulse to the device is a form of subsampling of the ADC output. The subsampling occurs at the rate of the SYNC_IN pulses. The SYNC_IN pulse must be synchronous with the master clock to ensure coherent sampling and to reduce the effects of jitter on the frequency response. MCLK SYNCHRONIZATION LOGIC DIGITAL FILTER DOUT6 DOUT7 SYNC_IN SYNC_OUT DRDY DNC DNC DOUT0 DOUT1 IOVDD AD7768 START MCLK SYNCHRONIZATION LOGIC DIGITAL FILTER DOUT6 DOUT7 SYNC_IN SYNC_OUT DRDY DNC DNC DOUT0 DOUT1 Figure 109. Daisy-Chaining Multiple AD7768 Devices Rev. B | Page 72 of 105 14001-099 To receive data, the master must pulse the SYNC_IN pin to reset the filter and force DRDY low. DRDY subsequently goes high to indicate to the master device that the device has valid settled data available. Unlike standard mode, DRDY remains high for the number of clock periods of valid data before it goes low again; thus, in this conversion mode, it is an active high frame of the data. Data Sheet AD7768/AD7768-4 Figure 109 shows an example of daisy-chaining AD7768 devices, when FORMATx = 01. In this case, the DOUT0 and DOUT1 pins of the AD7768 devices are cascaded to the DOUT6 and DOUT7 pins, respectively, of the next device in the chain. Data readback is analogous to clocking a shift register where data is clocked on the rising edge of DCLK. The scheme operates by passing the output data of the DOUT0 and DOUT1 pins of an AD7768 upstream device to the DOUT6 and DOUT7 inputs, respectively, of the next AD7768 device downstream in the chain. The data then continues through the chain until it is clocked onto the DOUT0 and DOUT1 pins of the final downstream device in the chain. The devices in the chain must be synchronized by using one of the following methods:   Applying a synchronous signal to the SYNC_IN pin of all devices in the chain By routing the SYNC_OUT pin of the first device to the SYNC_IN pin of that same device and to the SYNC_IN pins of all other devices in the chain and applying an asynchronous signal to the START input. Issuing an SPI_SYNC command over the SPI control interface. Figure 109 shows the configuration where an asynchronous signal is applied to the START pin, and the SYNC_OUT pin of the first device is connected to the SYNC_IN pins of all devices in the chain Daisy chaining can be achieved in a similar manner on the AD7768 and AD7768-4 when using only the DOUT0 pin. In this case, only Pin 21 of the AD7768/AD7768-4 is used as the serial data input pin. In a daisy-chained system of AD7768/AD7768-4 devices, two successive synchronization pulses must be applied to guarantee that all ADCs are synchronized. Two synchronization pulses are also required in a system of more than one AD7768/AD7768-4 device sharing a single MCLK signal, where the DRDY pin of only one device is used to detect new data. Synchronization The basic provision for synchronizing multiple devices is that each device is clocked with the same base MCLK signal and that the user can provide a synchronization signal to at least one of the devices by one of the methods described in this section. The AD7768/AD7768-4 offer three options to allow ease of system synchronization. Choosing between the options depends on the system, but is determined by whether the user can supply a synchronization pulse that is truly synchronous with the base MCLK signal. Two synchronization pulses are required in a system of more than one AD7768/AD7768-4 device sharing a single MCLK signal, to ensure that all devices are in close phase alignment, or where the DRDY pin of only one device is used to detect new data. If the user cannot provide a signal that is synchronous to the base MCLK signal, one of the following two methods can be employed:  Apply a START pulse to the first AD7768 or AD7768-4 device. The first AD7768 or AD7768-4 device samples the asynchronous START pulse and generates a pulse on SYNC_OUT of the first device related to the base MCLK signal for distribution locally.  Use synchronization over SPI (only available in SPI control mode) to write a synchronization command to the first AD7768 or AD7768-4 device. Similarly to the START pin method, the SPI sync generates a pulse on SYNC_OUT of the first device related to the base MCLK signal for distribution locally. In both cases, route the SYNC_OUT pin of the first device to the SYNC_IN pin of that same device and to the SYNC_IN pins of all other devices that are to be synchronized (see Figure 110). The SYNC_OUT pins of the other devices must remain open circuit. Tie all unused START pins to a Logic 1 through pull-up resistors. AD7768/ AD7768-4 The maximum DCLK frequency that can be used when daisychaining devices is a function of the AD7768/AD7768-4 timing specifications (t4 and t11 in Table 3 and Table 5) and any timing differences between the AD7768/AD7768-4 devices due to layout and spacing of devices on the PCB. MCLK DIGITAL FILTER SYNC_IN Use the following formula to aid in determining the maximum operating frequency of the interface: f MAX  START SYNCHRONIZATION LOGIC SYNC_OUT DRDY DOUT0 DOUT1 DSP/ FPGA MASTER CLOCK IOVDD 1 2  (t11  t 4  t P  t SKEW ) AD7768/ AD7768-4 where: fMAX is the maximum useable DCLK frequency. t11 and t4 are the AD7768/AD7768-4 timing specifications (see Table 3 and Table 5). tP is the maximum propagation delay of the data between MCLK START SYNCHRONIZATION LOGIC DIGITAL FILTER SYNC_IN SYNC_OUT DRDY DNC DNC 14001-303  successive AD7768/AD7768-4 devices in the chain. tSKEW is the maximum skew in the MCLK signal seen by any pair of AD7768/AD7768-4 devices in the chain. Figure 110. Synchronizing Multiple AD7768/AD7768-4 Devices Using SYNC_OUT Rev. B | Page 73 of 105 AD7768/AD7768-4 Data Sheet If the user can provide a signal that is synchronous to the base MCLK, this signal can be applied directly to the SYNC_IN pin. Route the signal from a star point and connect it directly to the SYNC_IN pin of each AD7768/AD7768-4 device (see Figure 111). The signal is sampled on the rising MCLK edge; setup and hold times are associated with the SYNC_IN input are relative to the AD7768/AD7768-4 MCLK rising edge. In this case, tie the START pin to Logic 1 through a pull-up resistor; SYNC_OUT is not used and can remain open circuit. IOVDD AD7768/ AD7768-4 MCLK START SYNCHRONIZATION LOGIC DIGITAL FILTER SYNC_IN DRDY DOUT0 DOUT1 START DIGITAL FILTER SYNC_IN DRDY DOUT0 DOUT1 #include 14001-304 SYNCHRONIZATION LOGIC It is possible to have channels outputting at different rates (for example decimation by 32 on Channel 0 and decimation by 64 on Channel 1). In such cases, the CRC header still appears across all channels at the same time, that is, at every fourth DRDY pulse after a synchronization. For the channels operating at a relatively slower ODR, the CRC is still calculated and emitted every 4 or 16 DRDY cycles, even if this means that the nulled data is included. Therefore, a CRC is calculated for only nulled samples or for a combination of nulled samples and actual conversion data. The following code is a snippet of the C code which shows how the CRC value can be calculated for a given set of ADC conversion results. Running this code on sets of 4 or 16 conversion results gives the CRC value that the AD7768 generatse, per channel. The user can then compare the computed value from this code to the actual CRC value read from the AD7768, and so confirm that the data was read without error. IOVDD MCLK 5. The AD7768/AD7768-4 use a CRC polynomial to calculate the CRC message. The 8-bit CRC polynomial used is x8 + x2 + x + 1. DSP/ FPGA AD7768/ AD7768-4 CRC calculation includes the conversion data that is output immediately after the CRC header. The CRC register is then cleared back to 0xFF and the cycle begins again for the fifth to eighth samples after the synchronization pulse. FILE *fi1; Figure 111. Synchronizing Multiple AD7768/AD7768-4 Devices Using Only SYNC_IN FILE *fo1; CRC Check on Data Interface main(){ The AD7768/AD7768-4 deliver 32 bits per channel as standard, which by default consists of 8 status header bits and 24 bits of data. int num_data_bits=24; // 24 or 16 The header bits default per the description in Table 35. However, there is also the option to employ a CRC check on the ADC conversion data. This functionality is available only when operating in SPI control mode. The function is controlled by CRC_SELECT in the interface configuration register (Register 0x07). When employed, the CRC message is calculated internally by the AD7768/AD7768-4 on a per channel basis. The CRC then replaces the 8-bit header every four samples or every 16 samples. int data; The following is an example of how the CRC works for foursample mode (see Figure 112): bit_sel[23] = 0x800000; 1. bit_sel[21] = 0x200000; 2. 3. 4. After a synchronization pulse is applied to the AD7768/AD7768-4, the CRC register is cleared to 0xFF. The next four 24-bit conversion data samples (N to N + 3) for a given channel stream into the CRC calculation. For the first three samples that are output after the synchronization pulse (N to N + 2), the header contains the normal status bits. For the fourth sample after the synchronization pulse (N + 3), the 8-bit CRC is sent out instead of the normal header status bits, followed by the sample conversion data. This int num_data_words=4; //4 or 16 int crc[8],crc_new[8]; int i,j,n,k,num,bit,result; const int num_crc_bits=8; int bit_sel[num_data_bits]; bit_sel[22] = 0x400000; bit_sel[20] = 0x100000; bit_sel[19] = 0x080000; bit_sel[18] = 0x040000; bit_sel[17] = 0x020000; bit_sel[16] = 0x010000; bit_sel[15] = 0x008000; bit_sel[14] = 0x004000; Rev. B | Page 74 of 105 Data Sheet AD7768/AD7768-4 bit_sel[13] = 0x002000; fprintf(fo1,"--------------------------------\n"); bit_sel[12] = 0x001000; fprintf(fo1,"ADC Data values\n"); bit_sel[11] = 0x000800; fprintf(fo1,"--------------------------------\n"); bit_sel[10] = 0x000400; fscanf(fi1,"%x\n",&num); bit_sel[9] = 0x000200; fprintf(fo1,"0x%.06X\n",num); bit_sel[8] = 0x000100; fprintf(fo1,"--------------------------------\n"); bit_sel[7] = 0x000080; fprintf(fo1,"CRC values\n"); bit_sel[6] = 0x000040; fprintf(fo1,"--------------------------------\n"); bit_sel[5] = 0x000020; for (k=num_data_bits-1;k>=0;k--){ bit_sel[4] = 0x000010; //for (i=7;i>=0;i--){ bit_sel[3] = 0x000008; // printf("%1d",crc[i]); bit_sel[2] = 0x000004; //} bit_sel[1] = 0x000002; bit = (num & bit_sel[k]); // msb first bit_sel[0] = 0x000001; data = bit>>(k); printf(" bit_sel is: %.06X - data is : %X ",bit_sel[k], data); fi1 = fopen("adcdata.txt", "r"); crc_new[0]=data^crc[7]; fo1 = fopen("crc_out.txt", "w"); //debug printf(" qq(0) = %1d ",qq[0]); j = 1; crc_new[1]=data^crc[7]^crc[0]; crc_new[2]=data^crc[7]^crc[1]; //initialise CRC to FF crc_new[3]=crc[2]; for (i=0;i
