CP-40-1

a 40-Lead Lead Frame Chip Scale Package [LFCSP_VQ] 6 x 6 mm Body, Very Thin Quad (CP-40-1) Dimensions shown in millimeters 6.00 BSC SQ 0.60 MAX 0.60 MAX 31 30 40 1 PIN 1 INDICATOR PIN 1 INDICATOR TOP VIEW 5.75 BCS SQ 0.50 BSC 0.50 0.40 0.30 (BOTTOM VIEW) EXPOSED PAD 4.25 4.10 SQ 3.95 10 11 21 20 0.25 MIN 4.50 REF 12° MAX 0.80 MAX 0.65 TYP 0.05 MAX 0.02 NOM 1.00 0.85 0.80 COMPLIANT TO JEDEC STANDARDS MO-220-VJJD-2 101306-A SEATING PLANE 0.30 0.23 0.18 0.20 REF COPLANARITY 0.08
