CFS-50-A-SG-SMT-C

COMPACT FLASH SOCKETS Adam Technologies, Inc. 50 PIN COMPACT FLASH SOCKET STRADDLE MOUNT STRADDLE MOUNT & SURFACE MOUNT MP SERIES .025 [0.64 1.20 [30.48] .035 [0.89] .079 [2.00 .118 [3.00] .236 .118 [6.00] [3.00] 1.299 [33.00] 1.413 [35.90] Recommended PCB Layout 1.20 [30.48] .050 [1.27] .130 [3.30] POS 50 .045 [1.15] .100 [2.54] .013 [0.35] CFS-50-A-SG-SM 50 PIN COMPACT FLASH SOCKET SURFACE MOUNT 1.225 [31.11] .025 [0.635] .102 [2.60] .118 [3.00] .236 [6.00] .078 [2.00 1.225 [31.11] .025 [0.635] .016 [0.40] .039 [1.00] Recommended PCB Layout 1.299 [33.00] 1.413 [35.90] 1.20 [30.48] .050 [1.27] .130 [3.30] .051 [1.30] OFF-SET Part Nos. Available CFS-50-A-SG-SMT-A (No offset) CFS-50-A-SG-SMT-B (0.3mm offset) CFS-50-A-SG-SMT-C (0.6mm offset) CFS-50-A-SG-SMT-D (0.9mm offset) 68 PIN COMPACT FLASH SOCKET STRADDLE MOUNT 1.650 [41.91] .050 [1.27] .015 [0.40] .025 [0.64 1.650 [41.91] .035 [0.89] .079 [2.00 .118 [3.00] Recommended PCB Layout 1.750 [44.45] 1.828 [46.45] .100 [2.54] .051 1.65 [41.91] .130 [3.30] .013 [0.35] CFS-68-A-SG-SM 340 909 Rahway Avenue • Union, New Jersey 07083 • T: 908-687-5000 • F: 908-687-5710 • WWW.ADAM-TECH.COM
