FCE-20-SG

.100" IDC CARD EDGE Adam Technologies, Inc. FCE C .394 [10.00] .100 [2.54] A B .100" [2.54] CENTERLINE FCE SERIES .394 [10.00] .677 [17.2] FCE-20-SG .670 [17.00] After Assembly .630 [16.0] FCE WITH MOUNTING EAR OPTION .126 [3.20] E .420 [10.67] .100 [2.54] A B D .705 [17.9] .197 [5.00] FCE-20-SG-E .050 [1.27] DIMENSIONS POSITIONS A B C D E 10 .400 [10.16] .604 [15.34] .872 [22.15] 1.300 [33.02] 1.500 [38.10] 14 .600 [15.24] .804 [20.42] 1.072 [27.23] 1.500 [38.10] 1.700 [43.18] 16 .700 [17.78] .904 [22.96] 1.172 [29.77] 1.600 [40.64] 1.800 [45.72] 20 .900 [22.86] 1.1040 [28.04] 1.372 [34.85] 1.800 [45.72] 2.000 [50.80] 26 1.200 [22.86] 1.404 [35.66] 1.672 [42.47] 2.100 [53.34] 2.300 [58.42] 34 1.600 [40.64] 1.804 [45.82] 2.072 [52.63] 2.500 [63.50] 2.700 [68.58] 40 1.900 [48.26] 2.104 [53.44] 2.372 [60.25] 2.800 [71.12] 3.000 [76.20] 50 2.400 [60.96] 2.604 [66.14] 2.872 [72.95] 3.300 [83.82] 3.500 [88.90] 60 2.900 [73.66] 3.104 [78.84] 3.372 [85.65] 3.800 [96.52] 4.000 [101.60] 62 3.000 [76.20] 3.204 [81.38] 3.472 [88.19] N/A N/A 64 3.100 [78.74] 3.304 [83.92] 3.304 [90.73] 4.000 [101.60] 4.200 [106.68] 909 Rahway Avenue • Union, New Jersey 07083 • T: 908-687-5000 • F: 908-687-5710 • WWW.ADAM-TECH.COM 323
