USB-DIO-16A

PC/104 - USB Digital Module Fast USB-DIO-16H Series— USB Digital Waveform (Pattern) Generator Modules Feature 16 High-Speed Digital I/O Lines FEATURES • High-speed USB 2.0 device • 16 high-speed digital I/O lines feature continuous, sustained throughput up to 16 MB/s • Capable of 80 MB/s bursts with flexible synchronous clock and handshaking capabilities • Continuous streaming over USB with no maximum waveform length • On-board embedded FIFO memory up to 128 kByte • 18 additional digital I/O lines arranged in 4 programmable groups • All outputs buffered with 24 mA sink/source capabilities • Type B USB connector features high-retention design • Standard 68-pin SCSI high density latching connector • Custom high-speed function driver • Alternate embedded USB connector • All required power drawn from USB port, no external power adapter required • Small, (4" x 4" x 1.25") rugged industrial enclosure • PC/104 module size and mounting compatibility • Type B USB connector features industrial strength and highretention design adaptor • OEM (board only) version with PC/104 mounting holes and PCB footprint for added flexibility in embedded applications FACTORY OPTIONS • LVTTL for 3.3V applications • Input only, output only, and input/output versions • OEM version (board only) features PC/104 module size and mounting compatibility • External power for high current capabilities • Extended temperature and DIN rail mounting provisions • RoHS available, please contact us for ordering information FUNCTIONAL DESCRIPTION Model USB-DIO-16H features 16 high-speed buffered digital inputs or digital outputs at continuous, sustained streaming speeds up to 16 MB/s for fast, unlimited waveform length. The module is capable of 80 MB/s bursts with handshaking signals for synchronizing communications plus an additional 18 bits of general purpose digital I/O. The USB-DIO-16H is a port-powered high-speed USB 2.0 devices and offers hot swapping functionality for quick connect/disconnect whenever you need additional I/O on your USB port. The USB-DIO-16H includes a programmable clock capable of 1 kHz - 40 MHz transfers or you may choose to use your own external clock. In addition to the 16 high-speed I/O’s there are 18 standard TTL-compatible digital I/O channels configurable as 4 separate ports for input or output (see block diagram). All required power is normally supplied to the board via the USB cable, however for higher current sourcing capabilities, optional external power may be used. The I/O wiring connections for the units are via an industry standard high-density pin-in-socket SCSI connector. For external circuits, a jumper selection connects fused +5VDC power to the connector. This resettable fuse is rated at 0.5A. Advanced Digital Logic, Inc.; 4411 Morena Blvd., Suite 101; San Diego, CA 92117-4345 Ph. 858 490-0597 F. 858 490-0599; e-mail: sales@adl-usa.com; web: www.adl-usa.com PC/104 - USB Digital Module The series includes four models, choose from input only (USB-DI16A), output only (USB-DO16A), and input/output versions (USB-DIO-16A) with expandable FIFOs (USB-DIO-16H). These modules are especially useful where high-speed data needs to be captured or output for testing or stimulus/response applications. These include testing and debugging, laboratory automation, manufacturing test, image capture, process monitoring, datasource emulation, and many more which require the need for high-speed parallel data transfer. A type B USB connector is used on all models which features a high retention design that complies with the class 1, Div II minimum withdrawal requirement of over 3 pounds of force. This connector has an orange color-coded insulator to differentiate it from standard USB connectors. The USB-DIO-16H was designed to be used in rugged industrial environments but is small enough to fit nicely onto any desk or testing station. The board itself is PC/104 sized (3.550 by 3.775 inches) and ships with or without a steel powder-coated enclosure with an anti-skid bottom. A DIN rail mounting provision is available for installation in industrial environments. OEM USB/104 FORM FACTOR The OEM (board only) version is perfect for a variety of embedded applications. What makes the OEM option unique is that its PCB size and pre-drilled mounting holes match the PC/104 form factor (without the bus connections). This ensures easy installation using standard standoffs inside most enclosures or systems. The board can be added to any PC/104, PCI-104, or PCI/104-Express stack by connecting it to a USB 2.0 port usually included on-board with embedded CPU form factors such as EBX, EPIC, and PC/104. This is especially important since many newer CPU chipsets do not support ISA and have plenty of USB ports. The USB-DIO-16H OEM board can also be installed using standoffs inside other enclosures or systems. For embedded OEM type applications, an additional miniature USB input header is provided in parallel with the type B connector. High Retention USB Connector The ever-growing presence of USB in the industrial/military marketplace has driven the need for USB connections to be reliable, dependable, and unfailing. Gone are the days of loose USB connections. A type B USB connector is used on all USB/104 products which features a high retention design that complies with the class 1, Div II minimum withdrawal requirement of over 3 pounds of force (15 Newtons). This connector has an orange color-coded insulator to quickly differentiate it from standard USB connectors. Using these USB connectors increases reliability in your system and ensures a tight connection. For embedded OEM type applications, an additional miniature USB input header is provided in parallel with the type B connector. Applications • • • • • • • Testing and Debugging Laboratory Automation Manufacturing Test Image Capture Process Monitoring Datasource Emulation Embedded OEM ACCESSORIES Available accessories include a shielded, round-wire molded cable with latching connectors and a 68-pin screw terminal board for quick and easy connectivity. SOFTWARE The USB-DIO-16H utilizes a high-speed custom function driver optimized for maximum continuous data throughput of 16 MB/s that is hundreds to thousands of times faster than the USB human interface device (HID) driver used by many competing products. This approach maximizes the full functionality of the hardware along with capitalizing on the advantage of high-speed USB 2.0. The boards are supported for use in most USB supported operating systems and includes a free Windows 98se/Me/2000/XP/2003/Vista compatible software package. This package contains sample programs and source code in Visual Basic, Delphi, C++ Builder, and Visual C++ for Windows. Third party support includes a Windows standard DLL interface usable from the most popular application programs and includes example LabView VIs. Embedded OS support includes Windows XPe. Advanced Digital Logic, Inc.; 4411 Morena Blvd., Suite 101; San Diego, CA 92117-4345 Ph. 858 490-0597 F. 858 490-0599; e-mail: sales@adl-usa.com; web: www.adl-usa.com PC/104 - USB Digital Module Block Diagram Specifications TTL High-Speed Digital I/O’s (LVTTL Optional) Channels / Groups: 16 / 1 Configured as Inputs: Logic High: 2.0 to 5.0 VDC Logic Low: -0.5 to +0.8 VDC Configured as Outputs: Logic High: 4.4 VDC minimum, source 24 mA Logic Low: 0.44 VDC maximum, sink 24 mA TTL Standard Digital I/O’s (LVTTL Optional) Channels / Groups: 18 / 4 (see block diagram) Configured as Inputs: Logic High: 2.0 to 5.0 VDC Logic Low: -0.5 to +0.8 VDC Configured as Outputs: Logic High: 4.4 VDC minimum, source 24 mA Logic Low: 0.44 VDC maximum, sink 24 mA Internal Clock Frequency Range: External Clock Frequency: 1 kHz - 40 MHz 40 MHz maximum Data FIFOs Width: Depth: 16-bit USB-DIO-16H: 128 kByte USB-DIO-16A, USB-DI16A, USB-D016A: 8 kByte Commercial: 0° to 70°C Industrial: -40° to +85°C -40° to +85°C 5%-95%, non-condensing 3.550 x 3.775 inches 4.00 x 4.00 x 1.25 inches 100mA typical (no load) +5VDC via 0.5A resettable fuse +3.3VDC via 0.5A resettable fuse (with LVTTL Option) +5VDC provided via USB bus up to 500mA Environmental Operating Temperature Range: Storage Temperature Range: Humidity: Board Dimension: Box Dimension: Power Basic Unit: Auxiliary Output: Bus Powered: Advanced Digital Logic, Inc.; 4411 Morena Blvd., Suite 101; San Diego, CA 92117-4345 Ph. 858 490-0597 F. 858 490-0599; e-mail: sales@adl-usa.com; web: www.adl-usa.com PC/104 - USB Digital Module Ordering Information Item Code USB-DIO-16H USB-DIO-16A USB-DI16A USB-DO16A Accessories STB-68 C68PS18L MP104-DIN CUSB-EMB-6 Options -OEM -P -LV -T Description 16 High-Speed Digital I/Os, 18 standard I/Os, 128 kByte FIFO 16 High-Speed Digital I/Os, 18 standard I/Os, 8 kByte FIFO 16 High-Speed Digital Inputs, 18 standard I/Os, 8 kByte FIFO 16 High-Speed Digital Outputs, 18 standard I/Os, 8 kByte FIFO Screw terminal board 68-Pin SCSI 18" shielded cable DIN rail mounting provision 6' USB Cable with Type A to mini connector Board only (no enclosure) External power components and AC/DC adapter LVTTL Buffers Extended Temperature Operation Advanced Digital Logic, Inc.; 4411 Morena Blvd., Suite 101; San Diego, CA 92117-4345 Ph. 858 490-0597 F. 858 490-0599; e-mail: sales@adl-usa.com; web: www.adl-usa.com
