ES-200-75-66

ES-200-75 Attachable Low Power Base SBC Integrated System Box Features  Mates to Advantech SBC board PCM-9575F  Built-in 180 watt power supply  One PC/104 card or one half-length PCI card extendible  Two 3.5" HDD can be installed  One built-in slim type CD-ROM  Multiple I/O interfaces for versatile applications  Includes attachable open-frame mechanical brackets with OFPC ES-3000 series LCD monitors (ES-3112/ES-3115/ES-3117)  Versatile combination solution with OFPC ES-3000 series LCD monitors Introduction ES-200-75 is a low power system box integrated with Advantech’s 5.25" SBC (PCM-9575F). The system configuration accommodates various open-frame LCD monitors to supply an OFPC with great flexibility, perfect for embedded applications with low noise requirements. This unit is designed without a faceplate for convenient embedding into a custom housing. Networking Four serial ports and a 10/100Base-T Ethernet controller give the ES-200-75 series advanced networking capability, providing the best solution for multiple applications. Extended Capability The ES-200-75 is designed with one expansion slot for PCI cards, two USB ports, one PC/104 card, and two 3.5" HDDs. Various different display size monitors can be attached to create an OFPC. With these expansion capabilities, the ES-200-75 not only functions as a system box, but sets up a computing center for solid application building. Specifications  CPU        Embedded VIA® low power Eden /Ezra processor up to 1 GHz Memory Supports SDRAM PC133 168-pin DIMM x 1, maximum up to 512 MB HDD 3.5" IDE HDD x 2 supported CD-ROM Drive Built in one slim type Compact CD-ROM 24X Combo Drive Slim type Compact 24X/10X/24X and DVD 8X or above (Optional) Graphic VIA® Twister chipset (VT8606) with integrated S3 Savage 4 supports 2D/3D 4x AGP graphics Expansion Interface One expansion slot for half-size PCI cards and PC/104 slot for PC/104 card expansion I/O Ports - 1 x VGA port - 1 x parallel port - 4 x serial ports : RS-232 3, RS-232/422/485 x 1 - 2 x USB ports : Support USB1.1 up to 20 Mb/sec - 2 x PS/2 ports : 1 x keyboard and 1 x mouse - 1 x RJ-45 port : Supports 10/100Base-T Ethernet - 4 x audio port : Supports 1 x line-in/1 x line-out/ 1 x mic-in/1 x speaker out - 1 x DC output: Supports 12 V =10 A output Dimensions (W x H x D) 353.6 x 225.6 x 100 mm Weight 3.4 kg Power  Input Voltage  Output Voltage  Output Rating AC 100 ~ 240 V, 4 ~ 2 A, 50 ~ 60 Hz DC 3.3 V = 16.8 A, 5 V = 12 A , 12 V = 10 A, 5 V = 2 A, -12 V = 0.8 A 180 W (including ES-200 system box and related DC device) Environment       Operating Temperature Storage Temperature Humidity Shock EMC Approved Safety Approved 0 ~ 45° C -20 ~ 60° C 5 ~ 95% @ 40° C, non-condensing 10 G peak acceleration (11 msec duration) CE FCC UL I/O Layout   Online Download www.advantech.com/products All product specifications are subject to change without notice Last updated : 20-Mar-2006 ES-200-75 Dimensions Unit: mm Ordering Information  ES-200-75-40  ES-200-75-66  ES-200-75-1G ES-200 system with 5.25" SBC embedded with VIA Eden 400 MHz CPU ES-200 system with 5.25" SBC embedded with VIA Eden 667 MHz CPU ES-200 system with 5.25" SBC embedded with VIA Ezra 1 GHz CPU Digital Signage & Display Solutions Digital
