ES-200-80

ES-200-80 Attachable SBC Integrated System Box with Intel® Pentium® 4 processor Features  Mates to Advantech SBC board-PCM-9580F  Built-in 180 watt power supply  Two PCI expansion slots  One 3.5” HDD can be installed  One built-in slim type CD-ROM  Multiple I/O interfaces for versatile applications  Includes attachable open-frame mechanical brackets with OFPC ES-3000 series LCD monitors (ES-3112/ES-3115/ES-3117) Introduction ES-200-80 is an SBC system box integrated with Advantech’s 5.25", PCM-9580F SBC. This system configuration accommodates various open-frame LCD monitors, offering a flexible OFPC, perfect for kiosk applications. Networking Four serial ports and a 10/100Base-T Ethernet controller give the ES-200-80 Series advanced networking capability and provides the best solution for versatile applications. Extended Capability The ES-200-80 is designed with one expansion slot for a PCI card, two USB ports, and one 3.5" HDD. Various different display size monitors can be attached to create an OFPC. With such diverse expansion capabilities, the ES-200-80 not only functions as a system box, but establishes a computing center for solid application building. Specifications  CPU        Supports socket 478 CPU Intel® Pentium® 4/Celeron® up to 3.06 GHz Memory Two 184-pin DIMM sockets, supports Non-ECC DDR 266 up to to 2GB HDD 3.5" IDE HDD x 1 supported CD-ROM drive Slim type Compact 24X or above Combo drive Slim type Compact 24X/10X/24X and DVD 8X or above. Graphic Intel 845GV Expansion Interface Two expansion slots for half-size PCI card I/O port - 1 x VGA port - 1 x parallel port - 4 x serial ports : RS-232 3, RS-232/422/485 x 1 - 2 x USB ports : Support USB1.1 and 2.0 - 2 x PS/2 ports : 1 x keyboard and 1 x mouse - 1 x RJ-45 port : Supports 10/100Base-T Ethernet - 3 x audio port : Supports 1 x line-in/1 x line-out/ 1 x mic-in - 1 x DC output: Supports 12 V = 10 A output Dimensions (W x H x D) 353.6 x 225.6 x 115 mm Weight 3.4 kg Power  Input voltage  Output voltage  Output rating AC 100 ~ 240 V, 4 - 2 A, 50 ~ 60 Hz DC 3.3 V = 16.8 A, 5 V = 12 A , 12 V = 10 A, 5 V = 2 A, -12 V = 0.8 A 180 W (including ES-200-80 system box and related DC device) Environment       Operating Temperature Storage Temperature Humidity Shock EMC Approved Safety Approved 0 ~ 45° C -20 ~ 60° C 5 - 95% @ 40° C, non-condensing 10 G peak acceleration (11 msec duration) CE FCC UL I/O Layout   Online Download www.advantech.com/products All product specifications are subject to change without notice Last updated : 20-Mar-2006 ES-200-80 Dimensions Unit: mm Ordering Information  ES-200-80 Attachable 5.25” based SBC integrated system box for Socket 478 compatible Pentium 4 CPU Digital Signage & Display Solutions Digital
