ES-2110

ES-2110/2210 NEW Features 10.4" Open Frame and Rugged Panel Mount Monitor  10.4" LCD supports 800 x 600 pixels and operating temperature (-0 ~ 50° C)  Resistive & Capacitive, SAW, IR touchscreen and 3 mm tempered glass options  Versatile mounting brackets  Modular architecture for efficient integration  Special back cover designed for 3.5"/ 5.25" SBCs and ARK-1000/3000/4000 series box computer  Sunlight readable (optional)  Ultra-high brightness up to 1000 cd/m2 with LED backlight (optional)  Rugged aluminum front bezel design (ES-2210)  VGA or LVDS interface (S-Video: optional) ES-2110 ES-2210 RoHS COMPLIANT 2002/95/EC Introduction The Advantech ES-2110/2210 Embedded Open Frame and rugged panel mount monitor series offer flexible options for LCD, touchscreen, signal interface and chassis mounting. The back cover has mounting holes for industry standard 3.5" or 5.25" SBCs; or Advantech DSA-2102, DSA-3400 digital signage player, DVS-355 mobile digital video platform, and ARK-1000/ ARK-3000/ ARK-4000 series embedded box computers. The series supports panel and VESA mounting, and is supplied with four versatile mounting brackets for different integration applications. The Advantech Display Solutions Selection Wizard (http://www.advantech.com.tw/ePlatform/DS/DisplaySolution.asp) enables easy selection of model numbers by choosing the required options. Specifications I/O Ports Display Input Signal Multi-Scan Mode Processor System OSD Control Power Dimensions (W x H x D) Weight Operating Temperature Storage Temperature Humidity Shock EMC Approved Feature Size Resolution (pixels) Number of Colors Viewing Angle (L/R/U/D) Brightness (cd/m2) Contrast Ratio Response Time (ms) Lamp Life (hrs) Long-term Support Anti-reflection Type Thickness Resolution Light Transmission Controller Interface Power Consumption Durability (Touches) Driver OS Support 15-pin D-sub, DC power input, RS-232 port, Power Switch and OSD keys (Auto-tune, menu, decrease, increase) Analog RGB, 0.7 VP-P / 75 0hm, optional LVDS Multi-Scan Mode supports VGA, SVGA Keys: Auto-tune, menu, decrease and increase Functions: Brightness, Contrast, Clock, Phase, Horizontal Position, Vertical Position and Sharpness External 50 W power adapter, with AC 100 ~ 240 V input and DC +12 V @ 4.16 A output Please refer to the product dimension diagram on next page ES-2110: 3.0 kg ES-2210: 3.8 kg ( -20 ~ 70° C optional) (-4 ~ 158° F optional) -20 ~ 60° C (-4 ~ 140° F) for standard LCDs 5 ~ 95% @ 40° C, non-condensing 10 G peak acceleration (11 ms duration) CE FCC Standard / (OEM) Sunlight Readable Ultra-high Brightness 10.4" 10.4" 10.4" 800 x 600 SVGA 800 x 600 SVGA 800 x 600 SVGA 262 K 262 K 262 K 60°/60°/35°/65° 60°/60°/35°/65° 70°/70°/60°/60° 230 / 400 600 1000 500:1 500:1 700:1 35 25 4 20,000 / 50,000 50,000 50,000 Yes Yes Yes N/A Yes Yes Analog Resistive Capacitive SAW Infrared 2.67 mm 3.18 mm 3.0 mm 3.0 mm 4096 x 4096 1024 x 1024 4096 x 4096 4096 x 4096 80% 85% 92% 92% RS-232/USB RS-232 RS-232/USB RS-232/USB +5 V @ 200 mA +5 V @ 100 mA +5 V @ 75 mA +5 V @ 150 mA 35 million hrs 225 million hrs 50 million hrs MTBF 100,000 hrs DOS, Linux, Mac, Windows 95/98/NT/ME/CE/2000/XP Environment Display Touchscreen Display Solutions ES-2110/2210 Dimensions ES-2110 42.0 26.0 50.0 135.0 115.0 (Resistive T/S) Unit: mm 4.4 46.4 (Capacitive T/S) 4.0 46.0 (SAW T/S) 4.0 46.0 (Infra Red Vandal Proof T/S) 7.0 49.0 28.79 75.00 238.0 220.0 292.0 310.0 130.0 46.8 38.1 75.0 50.0 50.0 M3 TAP 10.0 (For Mitsubishi panel) M3 TAP 10.0 (For AUO-G104SN05 panel) 50.0 26.0 125.0 10.0 125.0 26.0 125.0 10.0 125.0 26.0 125.0 10.0 M3 TAP 125.0 10.0 (For AUO-G104SN03 panel) 161.8 162.7 130.0 130.0 CUT OUT CUT OUT 130.0 CUT OUT 10.0 (For Mitsubishi panel) 215.4 10.0 10.0 (For AUO-G104SN02 panel) 215.6 10.0 10.0 (For AUO-G104SN03 panel) 215.0 10.0 ES-2210 320.00 24.70 10.00 50.70 248.00 263.00 292.00 Ordering Information P/N ES-2110G-VSAE ES-2110R-VSAE ES-2110C-VSAE ES-2110R-LSA-05E ES-2210R-VSAE ES-2210C-VSA-SRE ES-2110V-VVM-HE Type Open Frame Open Frame Open Frame Open Frame Rugged panel mount Rugged panel mount Open Frame Brightness (cd/m2) 230 / 400 230 / 400 230 / 400 230 / 400 230 / 400 600 1000 Interface VGA VGA VGA LVDS VGA VGA VGA Touchscreen Tempered Glass 5-Wire Resistive Capacitive 5-Wire Resistive 5-Wire Resistive Capacitive Infrared Touch Interface N/A RS-232/USB RS-232 RS-232/USB RS-232/USB RS-232 RS-232 Anti-Reflection N/A N/A N/A N/A N/A Yes Yes Notes: 1.) Capacitive, SAW and Infrared touch panels are recommended for applications requiring sunlight readable outdoor solutions. 2.) The list above is of major part numbers for your reference. Other combinations of LCD, touchscreen and signal interface features can be found in the Advantech Display Solutions. The Selection Wizard (http://www.advantech.com.tw/ePlatform/DS/DisplaySolution.asp) or CTOS services can be used to get your demand configuration and part numbers to us for ordering. 3.) For special requests, we welcome you to use the Display Solution DTOS service. Online Download www.advantech.com/products 180.20 220.00 162.0
