PC-104

PC/104 Isolated RS-232/422/ 485 Module Dual-port RS-422/485 Module 4-port RS-232 High-Speed Module u PCM-3610 Isolated RS-232/422/ 485 Module u PCM-3612 Dual-port RS-422/485 Module u PCM-3640/3641 4-port RS-232 High-Speed Module Features • High speed transmission rate • Automatic RS-485 data flow control • Jumper selectable interrupt level • Supports Windows 95/98/NT/2000/ ME, Linux (ICOM utility), DOS/ Windows 3.1 Features • Long distance communication • Automatic RS-485 data flow control • Jumper selectable interrupt level • Supports Windows 95/98/NT/2000/ME, Linux (ICOM utility), DOS/Windows 3.1 Features • Transmission speeds up to 460 Kbps (PCM-3641) • Shared IRQ settings for each of 4 RS232 ports (PCM-3641) • Standard PC ports: COM1, COM2, COM3, COM4 compatible • Supports Windows 95/98/NT/2000/ME, Linux (ICOM utility), DOS/Windows 3.1 Specifications • Channel 1: R S-232,422,or 485 • Channel 2: R S-422, or RS-485 • Baud rate: 5 0 ~ 115,200 bps • Character length: 5 ,6,7, or 8 bits • Parity: E ven, odd, or none • Stop bit: 1, 1.5, or 2 • Interrupt level: IRQ 3, 4, 5, 6, 7, 9 • I/O connectors: Dual male DB-9 • Power consumption: +5 V @ 400 mA typical ±12 V @ 950 mA max • Isolation: 500 VDC Specifications • Channel 1 and 2: R S-422, or RS-485 • Baud rate: 5 0 ~ 115,200 bps • Character length: 5 ,6,7,or 8 bits • Parity: E ven, odd, or none • Stop bit: 1, 1.5, or 2 • Interrupt level: IRQ 3, 4, 5, 6, 7, 9, 10, 11, 12 or 15 • I/O connectors: dual male DB-9 • Power consumption: +5 V @ 400 mA typical ±12 V @ 950 mA max • LED: Red LED for TX Green LED for RX Specification: • • • • • • • • • • • Bus interface: PC/104 Number of ports : 4 I/O address: 0 x 0200 ~ 0 x 03F8 IRQ: 3, 4, 5, 6, 7, 9, 10, 11, 12, 15 Data bits: 5, 6, 7, 8 Stop bits : 1, 1.5, 2 Parity : none, even, odd Speed (bps) : 50 ~ 460 K (PCM-3641) 50 ~ 115.2 K (PCM-3640) Connectors: Four DB-9 male Data signals: TxD, RxD, RTS, CTS, DTR, DSR, DCD, RI, GND Power requirement : +5 V @ 200 mA (Typical) ; +5 V @ 250 mA (Max.) Operating Temperature: 0 ~ 65° C (refer to IEC-68-1-1, 2) Storage Temperature: -25 ~ 80° C • • Ordering Information u PCM-3610-A Isolated RS-232/422/485 module Ordering Information u PCM-3612-A Dual port RS-422/485 module Ordering Information u PCM-3641 4-port RS-232 High-Speed module u PCM-3640 4-port RS-232 module 7 -32 Industrial Communications PC/104 Jumperless Ethernet Module PC/104-plus Ethernet Module Dual-port Isolated CAN Interface Module u PCM-3660 Jumperless Ethernet Module u PCM-3662 PC/104-plus Ethernet Module u PCM-3680 Dual-port Isolated CAN Interface Module Features • Automatically detects 8-bit or 16-bit • AUI connector supports external MAUs • On-board 32 K byte buffer for mulipackage Features • Support IEEE 802.3u Ethernet standard • Support IEEE 802.3x Full Duplex Flow Control • Support 10/100 Base-T Ethernet • Support Wake-On-LAN function • Provide 4 modes LED definition Features • Operates two separate CAN networks at the same time • High speed transmission up to 1 Mbps • Direct memory mapping enables very fast access to the CAN controllers • C library and examples included • DOS Library, Utility and Win 3.1/NT DeviceNet DLL drivers included 7 PCM-3610 Specifications • I/O address : 200, 220, 240, 260, 280, 2A0, 2C0, 300, 320, 340, 380, 3A0 • Interrupt level: IRQ 3, 4, 5, 9, 10, 11, 12 or 15 • Boot ROM address: C 0000, C8000, D0000, or D8000H • Data bus: 8 -bit, 16-bit, or auto-sending • Connector: 1 6-bit PC/104 stackthrough connector RJ-45 connector for 10Base-T, 16-pin insulation displacement connector for AU1 • Standard: I EEE 802.3 10 Mbps CSMA/CD 10Base-T Transceiver • Power consumption : +5 V @ 400 mA max Specifications Hardware • PC-104 form-factor: 64 x 8 mm • Data bus: 3 2-bit Software Driver support • Windows 95/98/NT/2000 driver • Novell server driver • Windows for workgroups driver • Unixware 7.0 driver • WinCE driver for x86 platform • Novell ODI client driver • Novell ODI driverfor client32 • Linux driver General • Power: +5V @ 250 mA • Temperature: 0° C to 70° C (operating) -15° C to 80° C (storage) • Humidity: 10% to 90% (operating) Specifications • Port: 2 • • • • • • • • • • CAN controller : SIA-1000 CAN transceiver : SIA-1000 Signal aupport : CAN_H, CAN_L Memory segment base address : From C800H to EFOOI IRQ : 3, 4, 5, 6, 7, 9, 10, 11, 12 or 15 Isolation voltage: 1000 V DC Power consumption : +5V @ 400 mA typical, 950 mA Connectors : Dual DB-9 male connectors (cable included) Operating temperature: 32° F to 122° F (0 to 50°C) Dimmensions : 3.6" X 3.8" (90mm x 96 mm) Ordering Information u PCM-3660-C1 Jumperless ethernet module u PCM-3661-A 10Base-2 transceiver module Ordering Information u PCM-3662A PC/104- plus E themnt Module Ordering Information u PCM-3680 Dual-port Isolated CAN Interface Module Industrial Communications www.advantech.com 7 -33 Industrial Communications
