MBPC-400 Micro boxes Series MicroBox 5.25" Biscuit SBC Chassis and Power Supply Key Features  Built-in power supply  PC-104 card extension x 2 or PCI slot card x 1 plus PC-104 card x 1  2.5” HDD drive bay x 1  DRAM and HDD is easy accessible.  6 cm x 6 cm system cooling Fan  2U height for Rack installation  I/O Windows for easy and quick Customized I/O extension, such as IR, FDD, LPT Introduction The MBPC-400 Micro PC chassis is an ideal case for system integration; it can accept Advantech’s 5.25” Biscuit CPU boards with the best flexibility, offering potential extension with PCI interface cards and PC-104 extension cards. Its compact size allows it to be mounted in equipment such as an embedded PC controller. Chassis kit Ordering No Mating SBC boards  MBPC-400-COMM PCM-9550F-F0A1 PCM-9575F-J0A1 / M0A1 / Q0A1 PCM-9575F-00A1 PCM-9576FV-03A1with daughter board PCM-203 (LAN x 3, DIN x 2) assembled PCM-9577FG with Gigabit Ethernet cable kit PCM-9578F-04A1 PCM-9579F-J0A1/M0A1/R0A1 PCM-9580F-00A1 PCM-9581F-00A1  MBPC-400-9576      MBPC-400-9577FG MBPC-400-9578F MBPC-400-9579F MBPC-400-9580F MBPC-400-9581F Specifications Power Supply Part Number Power Rating Input Voltage Input Frequency 1757208000 80 W 100 - 240 VAC 47 ~ 63 Hz 5 V @ 16 A 12 V @ 1.5 A 0 ~ 50 °C 10% ~ 95% UL, CE Certificated MBPC-400-COMM MBPC-400-9577FG MBPC-400-9576 MBPC-400-9578F MBPC-400-9579F 1757000034 180 W 100 ~ 240 VAC 47 ~ 63 Hz 3.3 V @ Max. 16.8 A +5 V @ Max. 12 A +12 V @ Max. 10 A -12 V @ Max. 0.8 A +5 VSB @ Max. 2.0 A 0 ~ 50 °C 5% ~ 95% UL, CE Certificated MBPC-400-9580F 1757218000 180 W 100 ~ 240 VAC 47 ~ 63 Hz 3.3 V @ Max. 16.8 A +5 V @ Max. 12 A +12 V @ Max. 10 A -12 V @ Max. 0.8 A +5 VSB @ Max. 2.0 A 0 ~ 50 °C 5% ~ 95% UL, CE Certificated MBPC-400-9581F Optional Ordering No  PCM-110-00A3  PCM-120-00A3 Description Riser card for extension of one PCI slot Riser card for extension of two PCI slots Output Voltage Temperature Operation Humidity Safety Supported Model Dimensions Unit: mm Chassis Specification  Mechanical Dmension 290 W x 220 D x 90 H mm  Weight 2.5 kg. 6 R3 R 100 10 Ordering Information  MBPC-400-COMM normally contains the main chassis kit, power supply, Fan, harness connector for Com x 4, VGA x 1, Printer x 1, USB x 1 and a small I/O board For LAN and KB/Mouse, and an accessory package for HDD harness, screws and an identification sticker for each I/O port desription.  All special connections are additionally customized through the I/O windows. Please refer to the product specifications of SBC series for more extensions.  Optional support for DC power supply is available for selected models by special OEM ordering.  Refer to SBC catalogue description for more versatile extension and application. 312 330 4 I/O Windows Single Board Computers 220 170 25
