TPC-1780H TPC-1770H NEW 17" SXGA TFT LCD Core™ 2 Duo L7400 Touch Panel Computer 17" SXGA TFT LCD Celeron® M Touch Panel Computer Features ƒ Intel® Core™ 2 Duo L7400 processor up to 1.5 GHz on board/ Intel Celeron® M processor up to 1 GHz on board ƒ 17" SXGA TFT LCD ƒ Compact design with die-cast Al alloy front bezel ƒ Fanless cooling system ƒ NEMA4/IP65 compliant front panel ƒ Supports Microsoft® Windows® XP/XPe, Vista (TPC-1780H only) ƒ Downward I/O cabling ƒ Gigabit Ethernet and Fast Ethernet supported Introduction With a high quality TFT LCD display, TPC-1780H/TPC-1770H is designed with the Intel Core 2 Duo L7400/Intel Celeron M processor as its core. The Intel Core 2 Duo/Intel Celeron M has low power consumption and 1.5/1 GHz operating frequency. This system is fanless although the kernel is powerful. In addition, spindle-free storage makes the TPC-1780H/TPC-1770H a durable and reliable platform. For applications where spindle-free storage is not critical, a fast-access HDD module can be used. The rich I/O portfolio meets diverse requests. Specifications General ƒ ƒ ƒ ƒ ƒ ƒ ƒ ƒ ƒ ƒ ƒ BIOS Award® 4 MB Certifications BSMI, CCC, CE, FCC, UL Cooling System Fanless design Dimensions (W x H x D) 414 x 347.5 x 93 mm (16.3" x 13.68" x 3.66") Enclosure Front bezel: Die-cast Aluminum alloy Back housing: ABS + PC Mounting Desktop, Wall or Panel Mount OS Support Windows XP/XPe (Vista only for TPC-1780H) Power Consumption 100 W Typical Power Input 18 ~ 32 VDC Watchdog Timer 1 ~ 255 sec (system) Weight (Net) 8 kg (17.64 lbs) LCD Display ƒ ƒ ƒ ƒ ƒ ƒ ƒ ƒ Display Type Display Size Max. Resolution Max. Colors Luminance cd/m2 Viewing Angle (H/V°) Backlight Life Contrast Ratio SXGA TFT LCD 17" 1280 x 1024 16.7 M 300 160/160 50,000 hrs 800:1 Touchscreen ƒ ƒ ƒ ƒ Lifespan Light Transmission Resolution Type 1 million touches at single point Above 75% Linearity 8-wire, analog resistive System Hardware ƒ CPU ƒ Chipset ƒ Memory ƒ LAN ƒ Expansion Slots ƒ Storage ƒ I/O TPC-1780H: Intel Core™ 2 Duo L7400 1.5 GHz TPC-1770H: Intel Celeron M 1 GHz 512k cache TPC-1780H: Intel 945GME + ICH7 TPC-1770H: Intel 915GME + ICH6M TPC-1780H: 2GB SO-DIMM DDR2 SDRAM, Up to 4GB TPC-1770H: 1GB 240pin DIMM DDR2 SDRAM 10/100/1000Base-T x 2 PCI-104 (Up to 1unit, Optional) RS-422/485 (Optional) CompactFlash® slot x 1 2.5" SATA HDD x 1(optional) RS-232 x 3 (COM1, 3, 4) USB 2.0 x 4 (Host) PS/2 Keyboard x 1, PS/2 Mouse x 1 VGA x 1 MIC-in x 1, Line-in x 1, Line-out x 1 Environment ƒ ƒ ƒ ƒ ƒ Humidity Ingress Protection Operating Temperature Storage Temperature Vibration Protection 10 ~ 95% RH @ 40° C, non-condensing Front panel: NEMA4, IP65 0 ~ 45° C (32 ~ 113° F) -20 ~ 60° C (-4 ~ 140° F) With HDD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration) Touch Panel Computers TPC-1780H TPC-1770H Dimensions Unit: mm 414 340 93 7 399.8 Panel Cut-out Dimensions: 400.8 x 334.3 mm Ordering Information ƒ ƒ ƒ ƒ ƒ TPC-1780H-P3AE TPC-1770H-C2BE TPC-1770H-SMKE TPC-1770H-WMKE PWR-244-AE 17" SXGA Touch Panel PC, Core 2 Duo L7400, 2 GB 17" SXGA Touch Panel PC, Celeron M 1 GHz, 1 GB TPC-1770H/1780H Desktop Stand TPC-1770H/1780H Wallmount Kit 24V 110W AC-DC Power Adapter 272.5 347.5 Rear View a d i h b c e f g f. USB 2.0 g. Audio (Line-In, Line-Out, MIC) h. 2.5" SATA HDD Housing i. LAN (10/100/1000) a. Power Switch, Fuse b. Power Receptor c. PS/2 d. COM (RS-232) e. VGA Online Download www.advantech.com/products 333.3
