UM-5

Specify UM-1 UM-5 & UM-4 Miniature Crystals Quartz Crystal Resonators 7.1 M ax 7.1 M ax 7.1 M ax 8.0 Max 6.0 Max 12.0 Min 12.0 Min 3.1 Max 3.1 Max 12.0 Min 3.8 Max 3.1 Max 0.3 0.3 0.3 3.75 11.3 Max UM-1 3.75 11.3 Max UM-5 3.75 11.3 Max UM-4 FEATURES Small Size Wide Frequency Range High Stability Fast Turnaround Options APPLICATIONS Pagers Radio Communications Telemetry Systems Automotive Electronics AVAILABLE OPTIONS * STANDARD SPECIFICATION o Frequency Range: Adjustment Tolerance at 25 C: Frequency Stability: Operating Temperature Range: Load Capacity: E.S.R: Drive level: Ageing: 4.00 MHz to 300.00 MHz ±30PPM Max. ±50PPM Max. -10 C to +60 C 30pF See Table 100 MicroWatt ±3PPM 1st Year Max. o o Frequency Range: Adjustment Tolerance Load Capacity: Shunt Capacity (C0): Dynamic Capacity (C1): 4.00MHz ~ 300 MHz ±5PPM ~ ±30PPM Series or 9pF ~ 50pF 4.5pF ~ 7pF (Typ.) 18fF ~ 20fF (Typ.) Also available with SMD Metal Clip (UM-1 & UM-5) (*UM-4/UM-5 From 10MHz) Frequency Range 4.00 MHz 5.00 MHz 6.00 MHz 7.00 MHz 8.00 MHz 10.00 MHz 16.00 MHz 23.00 MHz 40.00 MHz 50.00 MHz 100.0 MHz ~ 4.99 MHz ~ 5.99 MHz ~ 6.99 MHz ~ 8.99 MHz ~ 9.99 MHz ~ 15.99 MHz ~ 22.99 MHz ~ 39.99 MHz ~ 100.00 MHz ~ 150.00 MHz ~ 300.00 MHz E.S.R 200 W 150 W 120 W 100 W 90 W 40 W 30 W 60 W 60 W 90 W 150 W Mode Fund Fund Fund Fund Fund Fund Fund 3 O/T 3 O/T 5 O/T 7 O/T Frequency Stability vs Operating Temperature Range Operating Tempe rature Range +/ -3 PPM 0 to +50 -10 to +60 -20 to +70 -30 to +80 -40 to + 85 Tempe rature S tability +/ -5 PPM +/ -10 PPM +/ -15 PPM +/-20PPM +/-50PPM Value Added Services In addition, AEL Crystals Ltd are able to offer our customers the following value added services:Fitted Insulators Cropping Radial Taping Lead Earth Lead www.aelcrystals.co.uk quartz based frequency control components Order Hotline +44 1293 524245 9 www.aelcrystals.co.uk sales@aelcrystals.co.uk
