AM25EUW-7224SH30ZK

厂商：
AIMTEC
封装：
-
描述：
DC DC CONVERTER 24V 25W

数据手册：

下载AM25EUW-7224SH30ZK.pdf

立即购买

详情介绍
数据手册
价格&库存

AM25EUW-7224SH30ZK 数据手册

AM25EUW-Z DC-DC Converter Preliminary Click to ORDER AM25EUW-Z samples The new AM25EUW-Z is a brand-new 25 Watt DC/DC converter that offers much greater cost effectiveness due to material normalization and production automation also leading to improved reliability and performance. Offering a 10:1 ultra-wide input voltage range of 16-160 VDC and an output voltage range from 5-24V, this series will offer many benefits to your new system design. This new series has an inbuilt heat sink offering great operating temperatures, from -40℃ to 100℃ with full power up to 58℃. It also features an isolation of 3000VDC for improved reliability and system safety. Furthermore, a higher MTBF of 190,000h, output short circuit protection (OSCP), output over-current protection (OCP) and an output over-voltage protection (OVP) come standard with the series in an 2x1” package. The AM25CWR-Z is perfect for Railway applications. 2x1” Features • • • • • • • Summary Ultra-wide Input: 16 – 160VDC Operating Temp: -40 °C to +100 °C High isolation voltage: 3000VDC On/Off Control, soft start, no minimum load requirements Output short circuit, over-current, over-voltage protection Designed to meet EN50155 Built in EMI filter designed to EN50121-3-2 class A • • AM25EUW-Z 528 48 6000 1500 24 48 60 3000 200 85 125 3000 15 70 100 85 160 3.3 24 5 3.3 0.25 -24 Input voltage Output (VDC) voltage (VDC) Isolation (VDC) Power (W) 85 105 45 40 58 25 1000 1 16 Training 4000 264 -40 30 -40 -50 Temp. range Derating (°C) (°C) Applications Press Release Coming soon Coming Soon! Railway Product Training Video (click to open) F 052e R1 Industrial Application Notes www.Aimtec.com 1 AM25EUW-Z DC-DC Converter Preliminary Models & Specifications Single Output Model Input Voltage (VDC) Output Voltage (VDC) Input Current max (mA) Output Current max (A) Isolation (VDC) Maximum capacitive Load (µF) 72 (16 - 160) 72 (16 - 160) 72 (16 - 160) 72 (16 - 160) 5 12 15 24 409 413 409 408 5 2.08 1.67 1.04 3000 3000 3000 3000 6800 1000 820 470 AM25EUW-7205SH30Z AM25EUW-7212SH30Z AM25EUW-7215SH30Z AM25EUW-7224SH30Z Efficiency (%) 84 84 85 85 Input Specification Parameters Conditions Typical Voltage range Input under voltage lockout Filter Startup time Absolute maximum rating Peak input voltage time Input reflected ripple current Nominal 72 ON/OFF 16 – 160 13.8/12 Pi network 0.06 On/Off Control Nominal input and resistive load Duration 100mS Duration 100mS Maximum Units VDC VDC 176 20 ON – 3 to 12Vdc or open; OFF – 0~1.2Vdc or Short circuit Pin 2 and Pin 3, idle current 3mA typ. S VDC VDC mA pk-pk Isolation Specification Parameters Tested I/O voltage Resistance Capacitance Conditions Typical 60 sec 500Vdc 3000 >1000 2000 Conditions Typical Maximum Units VDC MOhm pF Output Specification Parameters Voltage accuracy Line regulation Load regulation Voltage adjustment Short circuit protection Over current protection F 052e R1 Maximum Units ±0.2 ±0.5 ±10 % % % %Vout ±1 Full load, main input range 0-100% load Continuous, Auto recovery 150 www.Aimtec.com % of Iout 2 AM25EUW-Z DC-DC Converter Preliminary Over voltage protection Zener diode clamp Output Specification (Continued) Parameters Conditions Temperature coefficient Ripple & Noise* Transient recovery time Transient response deviation * 20MHz bandwidth Typical Maximum ±0.02 100 25% load step change 25% load step change 500 ±4 Units %/ oC mV pk-pk µS % General Specifications Parameters Conditions Typical Switching frequency Operating temperature Storage temperature Maximum case temperature Over temperature protection Lead temperature Cooling Humidity Case material Base material Weight Dimensions (L x W x H) MTBF Full load See derating graph 250 -40 to +100 -55 to +125 At case 1.5mm from case 10 sec. 115 Maximum 105 260 Units KHz oC oC oC oC oC Free air convection Non-condensing 95 Aluminum Non-conductive black plastic (UL 94V-0 rated) 48 2.09 x 1.09 x 0.65 inches (53.00. x 27.60 x 16.6mm) > 230 000 hrs (MIL-HDBK -217F, t=+25oC)/Full Load % RH g All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity

下载 PDF

AM25EUW-7224SH30ZK

物料型号为AM25EUW-Z，是一款25瓦的DC-DC转换器，具有10:1超宽输入电压范围和多种输出电压选择。

器件简介： - 具有成本效益，由于材料标准化和生产自动化，提高了可靠性和性能。

- 内置散热器，能够在-40°C至100°C的温度范围内工作，最大功率下可达58°C。

- 3000VDC的高隔离电压，提高了可靠性和系统安全性。

- 标准保护功能包括输出短路保护、过流保护和过压保护。

引脚分配： - Pin 1: +V Input - Pin 2: -V Input - Pin 3: On/Off Ctrl - Pin 4: +V Output - Pin 5: -V Output - Pin 6: Trim

参数特性： - 超宽输入电压：16-160VDC - 输出电压：5-24VDC - 最大输入电流：根据型号不同而不同，范围从413mA到409mA - 最大输出电流：从1.04A到5A - 隔离电压：3000VDC - 最大电容负载：470μF到6800μF - 效率：84%到85%

功能详解： - 具有开/关控制、软启动和无最小负载要求。

- 符合EN50155标准，内置EMI滤波器符合EN50121-3-2标准。

应用信息： - 适用于铁路和工业应用。
