MT-GD2

Interlock Switches Tongue Switches MT-GD2 Specifications Standards EN954-1, ISO13849-1, IEC/EN60204-1, NFPA79, EN1088, ISO14119, IEC/ EN60947-5-1, ANSI B11.19, AS4024.1 Cat. 1 Device per EN954-1 Dual channel interlocks suitable for Cat. 3 or 4 systems CE marked for all applicable directives, cULus and TUV Nord 2 N.C., 3 N.C., 4 N.C. direct opening action AC 15 600V 1.2A 600V 0.4A 10A 5V, 5mA DC (Ui) 500V 1 N.O. or 2 N.O. 6mm (0.24in) 12N (2.7lb) 1m/s 2 cycle per sec Painted zinc Stainless Steel IP67 1/2in NPT or M20 or Quick Disconnect -20°C to +80°C (-4°F to +176°F) 4 x M5 Any position 1,000,000 operations 520g (1.15lbs) Red Fixing Bolts 1.6Nm Lid Screws 16.Nm Terminal Screws 1.0Nm Note: The safety contacts of the Guardmaster switches are described as normally closed (N.C.) i.e., with the guard closed, actuator in place (where relevant) and the machine able to be started. Category Approvals Safety Contacts Utilization Rating Designation/Utilization Cat. A600/AC-15 (Ue) (Ie) N600/DC-13 (Ue) (Ie) Thermal Current (lth) Min Current Rtd. Insulation Voltage Auxiliary Contacts Actuator Travel for Positive Opening Break Contact Min Force Max Actuation Speed Max Actuation Frequency Case Material Actuator Material Protection Conduit Entry Operating Temperature Fixing Mounting Mechanical Life Weight Colour Torque Settings Description The MT-GD2 is a robust tongue actuated safety interlock switch designed to fit at the opening edge of sliding, hinged or lift-off guards. With its dual entry slots and rotatable head, the MT-GD2 can offer eight different options for actuator entry. The MT-GD2 features a compact housing of only 117mm x 40mm x 43mm with DIN 50041 standard fixing centres and includes forced guided contacts and a tamper-resistant mechanism. The MT-GD2 is available with a variety of contact configurations enabling it to be used as part of a system for higher-risk applications. The unit is sealed to IP67 and has 1 conduit entry. Operation of the switch is achieved by the insertion of the specially profiled stainless steel actuator which should be permanently fixed to the leading edge of the guard door. An optional flexible actuator allows the MT-GD2 to operate on smaller radii doors (≥60mm) and a flat actuator gives additional mounting options. A style incorporating a latch release mechanism allows manual retention of the actuator in the switch until the release mechanism is manually activated. 500V 240V 120V 1.4A 3A 6A 500V 250V 125V 0.55A 1.1A 2.2A Rtd. Impulse Withstand Volt. (Uimp) 2500V Features • • • • • • Strong and versatile, can be used in most applications Eight possible actuator entry points, easy to install Variety of contact configurations Optional latch release styles Industry standard fixing centres to DIN/EN50041 Conforms to EN1088, EN292, EN60947-5-1, EN60204-1, EN50041 MT -GD2 Latch Release Style 3-20 Interlock Switches Tongue Switches MT-GD2 Product Selection Contacts Type Safety Auxiliary BBM/MBB Actuator — 3 N.C. 1 N.O. BBM Standard Fully-Flexible — MT-GD2 2 N.C. 2 N.O. Standard Fully-Flexible 3 N.C. 2 N.C. 4 N.C. 1 N.O. 2 N.O. — — 3 N.C. 1 N.O. BBM Standard Fully-Flexible — MT-GD2 Latch Release 2 N.C. 2 N.O. Standard Fully-Flexible 3 N.C. 2 N.C. 4 N.C. 1 N.O. 2 N.O. — MBB — — MBB — M20 Conduit 440K-MT55002 440K-MT55074 440K-MT55075 440K-MT55005 440K-MT55076 440K-MT55077 440K-MT55004 440K-MT55006 440K-MT55093 440K-MT55039 440K-MT55078 440K-MT55079 440K-MT55063 440K-MT55080 440K-MT55081 440K-MT55082 440K-MT55083 440K-MT55084 Catalogue Number 1/2in NPT Conduit 440K-MT55085 440K-MT55022 440K-MT55029 440K-MT55086 440K-MT55026 440K-MT55087 440K-MT55088 440K-MT55089 440K-MT55090 440K-MT55062 440K-MT55041 440K-MT55045 440K-MT55065 440K-MT55050 440K-MT55051 440K-MT55091 440K-MT55092 440K-MT55060 Quick Disconnect 440K-MT55094 440K-MT55095 440K-MT55096 440K-MT55097 440K-MT55098 440K-MT55099 440K-MT55100 440K-MT55101 440K-MT55102 440K-MT55042 440K-MT55070 440K-MT55103 440K-MT55066 440K-MT55104 440K-MT55052 440K-MT55106 440K-MT55105 440K-MT55061 Mating cable 2m (6.5ft). See page 15-13 for details and additional lengths. 889M-F12X9AE-2 3-21 Interlock Switches Tongue Switches MT-GD2 Accessories Description For Dimensions refer to page Catalogue Number GD2 Standard Actuator 14-4 440G-A27011 Flat Actuator 14-5 440K-A11112 Fully-Flexible Actuator 14-4 440G-A27143 Sliding Bolt Actuator 14-4 440G-A27163 Extended Flat Actuator 14-5 440K-A17116 Typical Applications Note: Lift-off guards require good alignment when using tongue actuated interlock switches. IMPORTANT: It must not be possible to lift the guard without actuating the interlock. An interlock on either side may be required. 3-22 Interlock Switches Tongue Switches MT-GD2 Approximate Dimensions—mm (inches) Dimensions are not intended to be used for installation purposes. MT -GD2 4 x Fixing Holes Clearance for M5 60 (2.36) 40 (1.57) 30 (1.18) 5 (0.20) 11.5 (0.45) 8.75 (0.34) 38 (1.5) 20.5 (0.81) 40 (1.57) 30 (1.18) MT -GD2 Latch Release 119 (4.68) 118.5 (4.66) 22 (0.86) Dia. 10.5 (0.41) 116.5 (4.59) 43 (1.69) Front Entry 30.8 (1.21) 40.7 (1.6) End Entry 5 (0.20) 10.5 (0.41) 60 (2.36) 102.4 (4.03) 24.6 (0.97) 43 (1.69) 30.8 (1.21) 20.5 (0.81) 8.75 (0.34) 51 (2.0) 9.2 (0.36) 74.6 (2.93) 30.8 (1.21) 67.6 (2.66) 5 (0.20) 20.6 (0.81) 9.2 (0.36) Typical Wiring Diagrams (shown with guard closed, actuator inserted) 4 N.C. 3 N.C. + 1 N.O. 2 N.C. + 2 N.O. 41 42 31 32 21 22 11 12 41 42 31 32 21 22 11 12 41 42 31 32 21 22 11 12 4 N.C. Connector Pinout 1 3 4 6 7 8 9 10 12 Terminal 11 12 21 22 31 32 41 42 Contact N.C. N.C. N.C. N.C. 3 N.C. + 1 N.O. Terminal 11 12 21 22 31 32 43 44 Ground Contact N.C. N.C. N.C. N.O. 2 N.C. + 2 N.O. Terminal 11 12 21 22 33 34 43 44 Contact N.C. N.C. N.O. N.O. 8 7 6 5 12 9 11 1 10 2 3 4 Contact Action Contact Open Contact Closed 11/12 21/22 31/32 41/42 5.2 4 N.C. 20 15 10 5 0mm 3 N.C. + 1 N.O. (MBB) 20 11/12 21/22 31/32 43/44 5.2 15 10 5.6 0mm 2 N.C. + 1 N.O. (MBB) 20 11/12 21/22 33/34 43/44 5.2 15 10 5.6 0mm Actuator withdrawal distance from full insertion 3 N.C. + 1 N.O. (BBM) 20 11/12 21/22 31/32 43/44 5.6 15 10 5.2 0mm 11/12 21/22 33/34 43/44 2 N.C. + 1 N.O. (BBM) 20 15 10 5.2 0mm 5.6 3-23
