SKSCLBE010

TACT SwitchTM 1.25mm Height Low-profile SidepushTM (Surface Mount Type) SKSC Series Combination of excellent solder strength & size merit (3.5G3.55mm with hight of 1.25mm). Detector Push Slide Rotary Product Line Horizontal type Product No. SKSCLCE010 SKSCLAE010 SKSCLDE010 SKSCLBE010 Operating Operating Travel Rating Rating Operating life Initial contact force direction （mm） （max.） （min.）（5mA 5V DC） resistance 1.6N 2.2N Horizontal 1.6N 2.2N 0.2 50mA 12V DC 10BA 1V DC 100,000cycles 100mΩ max. Encoders Variety Without guide bosses 5,000 With guide bosses Minimum order unit （pcs.） Power Dual-in-line Package Type TACT SwitchTM CustomProducts With Ground Terminal type Product No. SKSCPCE010 SKSCPAE010 SKSCPDE010 SKSCPBE010 Operating Operating Travel Rating Rating Operating life Initial contact force direction （mm） （max.） （min.）（5mA 5V DC） resistance 1.6N 2.2N Horizontal 1.6N 2.2N 0.2 50mA 12V DC 10BA 1V DC 100,000cycles 100mΩ max. Variety Without guide bosses Minimum order unit （pcs.） 5,000 With guide bosses Specification of Embossed Taping Package (Taping Packaging for Auto-insertion) Reel Size Plastic Reel 1 reel Sharp Feeling Soft Feeling Tape width （mm） Snap-in Type Surface Mount Type Unit:mm Number of packages pcs.） （ 1 case /Japan 1 case /export packing 5,000 ¿380 13.5 50,000 50,000 12 Radial Type Dimensions Style 1.1 1.25 0.8 0.4 Push position Unit:mm PC board mounting hole and land dimensions （Viewed from switch mounting face） Ground terminal land FNot solderable type (refer to notes) 0.7 0.4 0.6 ¿0.6 0.7 0.5 3 4 2 0.4 2.2 0 2-¿ .8 Ho le 3.85 3.55 2.9 1.3 1.8 2.2 5 2.1 1 1.6 3.5 4.85 2 Ground terminal land pattern is applicable to Ground terminal type only. Circuit Diagram 3 1 4 2 Notes 1. Ground terminal is made of non-solderable material. In case extra solder paste is applied to the gap between land and ground terminal, the recommended pattern and 0.15mm stencil must be used. 2. For φ330mm diameter reel requirements, please contact us. 3. Please place purchase orders for taping products per minimum order unit (1 reel or a case). Refer to P.306 for soldering conditions. 1.8 289 TACT SwitchTM List of Varieties Sharp Feeling Type Series Detector Push Type Slide Features Rotary Encoders Power W Dual-in-line Package Type TACT SwitchTM H CustomProducts Operation force coverage 5N Ground terminal Operating temperature range Electrical performance Durability Insulation resistance Voltage proof Vibration Lifetime Cold Dry heat Damp heat Page 289 290 291 ― ● ● ● ｰ20℃ to ＋70℃ SKRV/QK ｰ30℃ to ＋85℃ 100MΩ min. 100V DC 250V AC for 1min. SKSC/RE/RV/RH : 100V AC for 1min. 10 to 55 to 10Hz/min., the amplitude is 1.5mm for all the frequencies, in the 3 direction of X, Y and Z for 2hours respectively Shall be in accordance with individual specifications. ｰ30±2℃ for 96h 80±2℃ for 96h 60±2℃, 90 to 95%RH for 96h 480 481 482 292 294 293 295 ― 1.25 1.5 3.3 4 5 7.1 4.3 5 7.1 13 3.5 3.9 3.55 4.5 6.45 6.4 7.35 □10 V6.2 □6.6 6.85 7.5 7.3 V9 Low–profile Horizontal type ― ● ● ● Surface mount Horizontal type 4–direction switch＋push switch ● ● ● ― Round terminal type ● ― ● Radial Round terminal Water–proof Horizontal type ― ● ● ― SKSC SKRE SKRT SKRV SKRH SKQU SKRG SKQK SKQN SKRC Photo Dimensions （mm） Operating direction Vertical Horizontal D 1N See the relevant pages for respective product descriptions Sharp Feeling Soft Feeling Snap-in Type Surface Mount Type Radial Type ● TACT SwitchTM Soldering Conditions ………………………………………………………………………………………306 ● TACT SwitchTM Cautions ………………………………………………………………………………………………………307 ● Product Line of Knob for TACT SwitchTM ……………………………………………………………………………………308 Note The automotive operating temperature range to be individually discussed upon request. Environmental performance W：Width. The most outer dimension excluding terminal portion. D ：Depth. The most outer dimension excluding terminal portion. H ：Height. The minimum dimension if there are variances. 250 TACT SwitchTM Soldering Conditions Condition for Reflow Available for Surface Mount Type. 1. Heating method: Double heating method with infrared heater. 2. Temperature measurement: Thermocouple 0.1 to 0.2φ CA K） CC T） solder joints copper foil surface） A heat resistive tape （ or （ at （ . Detector Push Slide Rotary Encoders Power should be used to fix thermocouple. 3. Temperature profile Temperature (˚C ) 260˚C max. 3 sec max. 180 150 Time 230˚C Dual-in-line Package Type TACT SwitchTM 120 sec max. pre-heating ） （ 3 to 4min. 40s max. CustomProducts Time inside soldering equipment Note 1. The above temperature shall be measured on the mounting surface of a PC board. There are cases where the PC board's temperature greatly differs from that of the switch, depending on the material, size, thickness of PC boards and others. The above-stated conditions shall also apply to switch surface temperatures. 2. Soldering conditions differ depending on reflow soldering machines. Prior verification of soldering condition is highly recommended. Sharp Feeling Soft Feeling Snap-in Type Surface Mount Type Radial Type Conditions for Auto-dip Available for Snap-in Type and Radial Type （Except SKHJ, SKHL, SKQJ, SKQK, SKEG series） Items Flux built-up Condition Mounting surface should not be exposed to fluk Ambient temperature of the soldered surface of PC board. 100℃ max. 60s max. 260℃ max. 5s max. 2times max. Manual Soldering（Except SKRT Series） Items Soldering temperature Duration of soldering Capacity of soldering iron Condition 350℃max. 3s max. 60W max. Preheating temperature Preheating time Soldering temperature Duration of immersion Number of soldering Notes 1. 2. 3. 4. 5. Consult with us for availability of TACT SwitchTM washing. Prevent flux penetration from the top side of the TACT SwitchTM. Switch terminals and a PC board should not be coated with flux prior to soldering. The second soldering should be done after the switch is stable with normal temperature. Use the flux with a specific gravity of min 0.81. （EC-19S-8 by TAMURA Corporation, or equivalents.） 306
