PS-60

60W Single Output Industrial DIN Rail Power Supply F ea tures : PS-60 Series U nivers a l A C i nput/F ull ra nge P rotections :S hort circuit/O ver loa d/O ver v olta ge C ooling by f ree a ir c onvection C a n be i ns ta lled on D IN ra il T S -35/7.5 o r 1 5 U L 5 08(indus tria l c ontrol e quipment)a pproved Is ola tion c la s s L E D i ndica tor for power o n 100% f ull loa d burn-in tes t 3 y ea rs w a rra nty S PECIFICATION MODEL DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER OUTPUT VOLTAGE ADJ . R ANGE VOLTAGE TOLERANCE Note.3 LINE R EGULATION LOAD REGULATION SETUP, R ISE, HOLD TIME VOLTAGE R ANGE FREQUENCY RANGE INPUT EFFICIENCY (Typ.) AC CURRENT INRUSH CURRENT (max.) OVER L OAD PROTECTION OVER VOLTAGE WORKING TEMP. PS -6005 5V 6.5A 0 ~ 6.5A 32.5W 4.75 ~ 5.5V 2.0% 1.0% 1.0% 100ms, 30ms, 50ms/230VAC 88 ~ 264VAC 47 ~ 63Hz 76% 82% 83% 84% 1.2A/115V AC 0.8A/230V AC COLD START 18A/115V AC 36A/230V AC 105 ~ 160% rated output power Protection type : Fold back current limiting, recovers automatically after fault condition is removed 5.75 ~ 6.75V 13.8 ~ 16.2V 17.25 ~ 20.25V 27.6 ~ 32.4V Protection type : Shut down o/p voltage, re-power on to recover 1 24 ~ 370VDC PS -6012 12V 4.5A 0 ~ 4.5A 54W 120mVp-p 11.1 ~ 13.2V 1.0% 1.0% 1.0% PS -6015 15V 4A 0 ~ 4A 60W 120mVp-p 13.5 ~ 16.5V 1.0% 1.0% 1.0% PS -6024 24V 2.5A 0 ~ 2.5A 60W 150mVp-p 21.6 ~ 26.4V 1.0% 1.0% 1.0% RIPPLE & NOISE (max.) Note.2 80mVp-p 2 00ms, 30ms, 18ms/115VAC at full load -20 ~ + 60 (Refer to output load derating curve) 20 ~ 90% RH non-condensing WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY -40 ~ + 85 , 10 ~ 95% RH TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS WITHSTAND VOLTAGE SAFETY & (Note 4) 0.03%/ (0 ~ 50 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes UL60950-1, Design refer to EN50178, EN60950-1 I/P-O/P:3KVAC EMC ISOLATION RESISTANCE I/P-O/P:100M Ohms/500VDC EMI CONDUCTION & RADIATION Compliance to EN55011,EN55022 (CISPR22) Class B Compliance to EN61000-3-2,-3 HARMONIC CURRENT EMS IMMUNITY MTBF Compliance to EN61000-4-2, 3, 4, 5, 6, 8, 11, E NV50204, E N55024, E N61000-6-2, E N61204-3 Heavy industry level, criteria A 216.2K hrs min. MIL-HDBK-217F (25 ) 78*93*56mm (W*H*D) 0.3Kg; 48pcs/15.4Kg/1.02CUFT OTHERS NOTE DIMENSION PACKING 1. A ll parameters N OT s pecially mentioned a re measured a t 230VAC i nput, r ated load a nd 25 of ambient temperature. 2. R ipple & n oise a re measured a t 20MHz o f bandwidth by using a 1 2" twisted pair-wire terminated with a 0 .1uf & 4 7uf parallel capacitor. 3. T olerance : i ncludes s et up tolerance, line regulation a nd load regulation. 4. T he power s upply is c onsidered a c omponent which will be installed into a f inal equipment. T he final equipment must be re-confirmed that it still meets E MC d irectives. 35 Royal Road, Flemington, NJ 08822-6000 • (tel.) 908-806-9400 • (fax) 908-806-9490 • www.altechcorp.com 60W Single Output Industrial DIN Rail Power Supply PS-60 Series 68 45 Mec hanic al S pec ific ation 56 47 27. 4 Terminal Pin. No As s ignment P in No. 1 2 3, 4 As s ignment AC /N AC /L +V P in No. 5, 6 7 8 As s ignment -V LE D +V ADJ . 3 46. 5 93 46. 5 12. 2 5 5 5 78 37. 75 6 5 4 3 7 8 35 ADMI S S I B LE D I N-R AI L: T S 35/7. 5 OR T S 35/15 2 1 5 B loc k Diagram I /P E MI F I LT E R R E C T IF IE R S & F I LT E R P OWE R S WI T C HI NG R E C T IF IE R S & F I LT E R +V -V O. L. P. P WM C ONT R OL DE T E C T I ON C I R C UI T O. V. P. Output Derating 100 80 60 L OAD (%) 40 20 -20 0 10 20 30 40 50 60 70 (VE R TIC AL) AMB IE NT TE MP E R ATUR E ( ) 35 Royal Road, Flemington, NJ 08822-6000 • (tel.) 908-806-9400 • (fax) 908-806-9490 • www.altechcorp.com
