24-CERDIP

Altera Device Package Information 24-Pin Ceramic Dual In-Line Package (CerDIP) ■ ■ ■ All dimensions and tolerances conform to ANSI Y14.5M – 1994. Controlling dimension is in inches. N is the number of leads. Package Information Description Ordering Code Reference Package Acronym Lead Material Lead Finish JEDEC Outline JEDEC Option Weight Moisture Sensitivity Level D CerDIP Alloy 42 Solder dip (60/40 typical) MS-030 AF 4.1 g Printed on moisture barrier bag Package Outline Figure Reference Specification Symbol Min. A A1 A2 b b2 E2 e L θ D E E1 E3 N 0.125 0° 1.240 0.290 0.280 0.325 – 0.015 0.140 0.015 0.049 0.365 Inches Nom. – 0.028 – 0.018 0.057 0.380 0.100 BSC – – 1.260 0.305 0.295 – 24 – 15° 1.280 0.320 0.310 0.410 Max. 0.200 0.041 0.175 0.021 0.065 0.395 Maximum Lead Coplanarity N/A Package Outline B E 1 E1 0.005 Min E3 E 0.090 Max D Base Plane C 0 E2 Seating Plane b2 b A A1 L e NÐ2 Places A2 A 24 Altera Corporation Copyright © 2002 Altera Corp.
