34-1033

NOTES: 1. MATERIALS AND FINISHES: BODY AND BAYONET SLEEVE - BRASS, NICKEL PLATING OUTER CONTACT - BeCu, NICKEL PLATING CONTACT - PHOSPHOR BRONZE, GOLD PLATING FERRULE - COPPER, NICKEL PLATING INSULATOR - PTFE ELECTRICAL: A. IMPEDANCE: 75 OHM B. FREQUENCY RANGE: DC - 3 GHz C. RETURN LOSS: 30 dB MIN. D. DIELECTRIC WITHSTANDING VOLTAGE: E. INSULATION RESISTANCE: 10,000 M MECHANICAL: A. DURABILITY: 500 CYCLES MIN. B. TEMPERATURE RANGE: -65 C TO +165 THIRD ANGLE PROJ. REV DESCRIPTION REVISIONS DATE ECO APPR 1 1,95 [0.077 ] DIELECTRIC 3,96 [0.156 ] 8,35 [0.329 ] BRAID & FOIL PROTOTYPE RELEASE 19-May-10 -- AAP 2. 1000 VRMS, MIN. MIN SCALE 3.000 3. C 4. ENVIRONMENTAL: A. THERMAL SHOCK PER MIL-STD-202 METHOD 107 TEST CONDITION B (EXCEPT HIGH TEMP @200 C) B. VIBRATION: MIL-STD-202 METHOD 204 TEST CONDITION B C. SHOCK: MIL-STD-202 METHOD 213 TEST CONDITION B D. CORROSION: MIL-STD-202 METHOD 101 TEST CONDITION B 5% SALT SOLUTION 5. PACKAGING: A. QUANTITY: SINGLE PACK B. MARKING: BAG TO BE MARKED: "AMPHENOLRF, 34-1033 DATE CODE" STUD LOCATING AND INSTALLATION/ REMOVAL TOOL GROOVES SCALE 5.000 RECOMMENDED CABLE STRIPPING DIMENSIONS 6. HIGH DENSITY INSTALLATION/REMOVAL TOOL: 227-T2000 7. CABLE ASSEMBLY INSTRUCTIONS: A. TRIM CABLE AS SHOWN. B. CRIMP CONTACT TO CABLE CENTER CONDUCTOR WITH .042" SQUARE DIE C. CRIMP FERRULE WITH 0.213" HEX. 8. SHOWS CABLE ENTRY DIMENSIONS. 32,64 REF [1.285 ] 6,80 REF [0.268 ] 8 5,60 [0.220 ] 7,75 REF [0.305 ] 8 3,70 [0.146 ] 6,35 [0.250 ] 8 PRELIMINARY ISSUE UNLESS OTHERWISE SPECIFIED, DIMENSIONS ARE IN METRIC AND TOLERANCES ARE:
