908-NM43300_11

NOTES: 1. MATERIAL AND FINISH: BODIES: BeCu, WHITE BRONZE PLATING CONTACT: BeCu, GOLD PLATING OVER WHITE BRONZE RETAINING RING: BeCu, GOLD PLATING OVER WHITE BRONZE CAP: BeCu, BeCu, WHITE BRONZE PLATING FERRULE: SEAMLESS COPPER TUBING, WHITE BRONZE PLATING INSULATOR : PTFE ELECTRICAL: A. IMPEDANCE: 50 OHM B. FREQUENCY RANGE: DC - 6 GHz C. VSWR(RETURN LOSS): 1.25:1 MAX. D. DIELECTRIC WITHSTANDING VOLTAGE: THIRD ANGLE PROJ. REV REVISIONS A B ADD TOL AND CONSISTANT LENGTHS TO MMCX ASSEMBLIES SEE SHEET 2. SEE SHEET 2 DESCRIPTION C D 7 # .2 E 10/24/06 9/20/10 4/8/10 9/20/10 DATE 48260 48017 48260 48339 46108 ECO KJC KJC APPR 7 #.2 WAS 7.01 REF SEE SHEET 1 4/14/11 3.5 CPM JTS RR 2. 500 VRMS, MIN. 5.26 REF THESE SURFACES MARKED "NM" TO SIGNIFY NON MAGNETIC CONNECTORS 3. MECHANICAL: A. DURABILITY: 500 CYCLES MIN. B. TEMPERATURE RANGE: -65 $C TO 165 $C C. CRIMP FERRULE WITH .128" HEX PACKAGING: A. QUANTITY: 100 PIECE BULK PACK B. MARKING: BAG TO BE MARKED "AMPHENOL, 908-NM43300 , DATE CODE, AND "NON MAGNETIC CONNECTORS"" 4. 4 11.0 REF VIEW SHOWN WITHOUT CAP OR FERRULE 7.24 5.97 4.32 RECOMMENDED CABLE STRIPPING DIMENSIONS 1.66 REF SCALE 4.000 NOTICE - These drawings, specifications, or other data (1) are, and remain the property of Amphenol corp. (2) must be returned upon requiest; and (3) arre confidential and not to be disclosed to any person other than those to whom they are given by Amphenol Corp. the funishing of these drawings, specifications, or other data by Amphenol Corp., or to any other person to anyone for any purpose is not to be regarded by implicatioin or otherwise in any manner licensing, granting rights to permitting such holder or any other sperson to manufacture, use or sell any product, process or design, patented or otherwsie, that may in any way be related to or disclosed by said drawings, specifications, or other data. UNLESS OTHERWISE SPECIFIED, DIMENSIONS ARE IN METRIC AND TOLERANCES ARE: 0.5 - 6mm ANGLES 6 - 30mm 30 - 120mm # 0.1mm # 0.3mm #$ 1 # 0.2mm MATERIAL REFERENCE EAR # 1952 CONFIGURATION LEVEL: DRAWN K. CAPOZZI ENGINEER K. CAPOZZI AND 908-7007 DATE 18-Jul-06 DATE 18-Jul-06 DATE 9/20/10 FINISH CAD FILE APPROVED B. C. GLEISSNER SCALE: 12.0:1.0 SHEET DWG SIZE TITLE ASSEMBLY MMCX R/A PLUG TO RG-316 NON MAGNETIC 2 OF 2 Danbury CT USA, Tainan, Taiwan, Shenzhen, China www.amphenolrf.com Amphenol RF DRAWING NO. ITEM NO. B CODE ID 74868 REV E 908-NM43300
