AC3FAH2-AU-PRE

1 LEGEND 2 3 5 4 6 7 8 REV 0 REVISION HISTORY DESCRIPTION DATE 20/08/2014 FIRST ISSUE KEY PRODUCT CHARACTERRISTICS A 12.85 [.506] 2~2.40 THRU 3.40 [.134] BY MH CHG/No --- 19.80 [.779] 12.50 [.492] 6.50 [.256] 19.50 [.768] A 9.90 [.390] 19.80 [.779] 9.90 [.390] 3.50 [.138] TYP 1.30 [.051] 12.50 [.492] B 25.35 [.998] 29.35 [1.156] 2.60 [.102] B ISO VIEW C C D 19.80 [.780] PIN 2 PIN 1 CHASSIS MATING SHELL 9.90 [.390] PIN 3 0.64 [.025] 12.70 [.500] 4.45 [.175] 3.81 [.150] 8.89 [.350] 2~ 3.20 [.126] 3.81 [.150] 3.81 [.150] 22.00 [.866] 7.00 [.276] (SCALE 1:1) G D 1 2 2~ 1.60 [.063] 2~ 1.60 [.063] 3 2~ 1.20 [.047] 8.25 [.325] 9.90 [.390] E 23.0 [.906] 19.80 [.780] SCHEMATIC CHART COMPONENT SIDE TOLERANCE: 0.05mm [.002"] PANEL CUT OUT REAR VIEW UNLESS OTHERWISE SPECIFIED TOLERANCE TO BE F LINEAR ANGULAR X X 1 0.5 X.X' 30' X.X 0.2 X.X'X " 15' X.XX 0.1 BREAK ALL SHARP EDGES AND REMOVE ALL BURRS MIN MOUNTING PITCH SCALE 1:1 DO NOT SCALE THIS DOCUMENT IS THE PROPERTY OF AMPHENOL AUSTRALIA PTY. LTD. . NO PART THEREOF MAY BE REPRODUCED AND USED WITHOUT THE PRIOR WRITTEN CONSENT OF THE OWNER MATERIAL: REFER TO COMPONENT FINISH: REFER TO COMPONENT DIMENSIONS IN MILIMETRES 1 2 3 4 5 E PCB-LAYOUT THIRD ANGLE PROJECTION 6 DRN: MH DATE: 20/08/14 CKD: M.H DATE: 20/08/14 APP'D: P.M DATE: 20/08/14 SCALE: 2:1 SIZE: A3 Amphenol Amphenol Australia Pty.Ltd, 22 Industry Blvd, Carrum Downs, VIC 3201 TITLE: PART No: AC3FAH2-AU-PRE HORIZONTAL FEMALE CUSTOMER DRAWING CAD FILE: 7 55011036000220 AC3FAH2-AU-PRE DRAWING NO. SHEET 55011036-000-2 2/2 8 F
