AC3FAVL1-AU-PRE

1 LEGEND 2 3 5 4 6 7 8 REV 0 REVISION HISTORY DESCRIPTION DATE 08/10/2014 FIRST ISSUE KEY PRODUCT CHARACTERRISTICS BY MH CHG/No --- 30.30 [1.193] 25.35 [.998] 9.9 [.390] 2.60 [.102] 9.9 [.390] 1.30 [.051] B 12.50 [.492] A 19.8 [.779] 24.00 [.945] 12.50 [.492] 25.35 [.998] 2~2.40 THRU 3.40 [.134] 19.8 [.779] A B C C > 22.00 [.866] 2~ 3.20 [.126] PIN 3 3.81 [.150] PIN 1 CHASSIS MATING SHELL 4.45 [.175] 2 9.90 [.390] 19.80 [.780] PIN 2 D 3.81 [.150] D 1+G 2~ 1.60 [.063] 3 1.20 [.047] ISO VIEW 9.90 [.390] E 23.0 [.906] 19.80 [.780] SCHEMATIC CHART COMPONENT SIDE TOLERANCE: 0.05mm [.002"] PANEL CUT OUT REAR VIEW F MIN MOUNTING PITCH UNLESS OTHERWISE SPECIFIED TOLERANCE TO BE LINEAR SCALE 1:1 ANGULAR X X 1 0.5 X.X' 30' X.X 0.2 X.X'X " 15' X.XX 0.1 BREAK ALL SHARP EDGES AND REMOVE ALL BURRS DO NOT SCALE THIS DOCUMENT IS THE PROPERTY OF AMPHENOL AUSTRALIA PTY. LTD. . NO PART THEREOF MAY BE REPRODUCED AND USED WITHOUT THE PRIOR WRITTEN CONSENT OF THE OWNER MATERIAL: REFER TO COMPONENT FINISH: REFER TO COMPONENT DIMENSIONS IN MILIMETRES 1 2 3 4 5 E PCB-LAYOUT THIRD ANGLE PROJECTION 6 Amphenol DRN: MH DATE: 08/10/2014 TITLE: CKD: M.H DATE: 08/10/2014 APP'D: P.M DATE: 08/10/2014 SCALE: 2:1 SIZE: A3 Amphenol Australia Pty.Ltd, 22 Industry Blvd, Carrum Downs, VIC 3201 PART No: AC3FAVL1-AU-PRE VERTICAL FEMALE CUSTOMER DRAWING CAD FILE: 7 55011040000220 AC3FAVL1-AU-PRE DRAWING NO. SHEET 55011040-000-2 2/2 8 F
