AC3MAH-AU-PRE

1 LEGEND 2 3 5 4 6 7 8 REV 0 REVISION HISTORY DESCRIPTION DATE 28/10/2014 FIRST ISSUE KEY PRODUCT CHARACTERRISTICS BY MH CHG/No --- A A 2.70 [.106] 25.4 [1.000] 12.50 [.492] 9.90 [.390] 19.80 [.780] B 22.00 [.866] 25.40 [1.000] 25.40 [1.000] B 3.80 [.150] 8.90 [.350] 3.50 [.138] 4.06 [.160] 4.06 [.160] C 9.90 [.390] 12.90 [.508] 19.80 [.780] 17.80 [.701] C CHASSIS 17.78 [.700] PIN 1 9.90 [.390] 19.80 [.780] PIN 2 D 12.70 [.500] 3.20 [.126] 22.00 [.866] PIN 3 3.81 [.150] 3.81 [.150] 3.81 [.150] 8.89 [.350] 22.20 [.874] D G 2 3 2~ 1.60 [.063] 1 MATING SHELL 2~ 1.60 [.063] 2~ 1.20 [.047] SCALE 1:1 9.90 [.390] 19.80 [.780] E MIN 23.0 COMPONENT SIDE TOLERANCE: 0.05mm [.002"] PANEL CUT OUT REAR VIEW UNLESS OTHERWISE SPECIFIED TOLERANCE TO BE F LINEAR ANGULAR X X 1 0.5 X.X' 30' X.X 0.1 X.X'X " 15' X.XX 0.05 BREAK ALL SHARP EDGES AND REMOVE ALL BURRS MIN MOUNTING PITCH SCALE 1:1 DO NOT SCALE THIS DOCUMENT IS THE PROPERTY OF AMPHENOL AUSTRALIA PTY. LTD. . NO PART THEREOF MAY BE REPRODUCED AND USED WITHOUT THE PRIOR WRITTEN CONSENT OF THE OWNER MATERIAL: REFER TO COMPONENT FINISH: REFER TO COMPONENT DIMENSIONS IN MILIMETRES 1 2 3 E PCB-LAYOUT SCHEMATIC CHART 4 5 THIRD ANGLE PROJECTION 6 DRN: MH DATE: 28/10/14 CKD: M.H DATE: 28/10/14 APP'D: P.M DATE: 28/10/14 SCALE: 2:1 SIZE: A3 Amphenol Amphenol Australia Pty.Ltd, 22 Industry Blvd, Carrum Downs, VIC 3201 TITLE: PART No: AC3MAH-AU-PRE HORIZONTAL MALE CUSTOMER DRAWING CAD FILE: 7 55011047000210 AC3MAH-AU-PRE DRAWING NO. SHEET 55011047-000-2 2/2 8 F
