AHDC34-24

REVISIONS REV ECO A1 -- DESCRIPTION RELEASE NEW DRAWING DATE BY APPR 19/OCT/18 ROOKIE TOMMY MAIN POLARIZING KEYWAY 41.5 12.8 2.6 Ø50.8 110°REF TITLE: ACCPET MAX. SIZE 10 SCREW 110°REF PROTECTIVE CAP FOR PLUG,AHDM,SIZE 24 Ø39.7 200(REF) 1 11/16-18 UNEF 2A THREAD DWG NO: AHDC34-24 Ø43.08±0.12 REV: A1 NOTES: UNLESS OTHERWISE SPECIFIED SH: RECOMMENDED PANEL MOUNTING HOLE 1) 2) 1 2 3 All dimensions are in metric(mm). Tolerances are as follows: PL DEC ±0.30 Fractions ±1/64 PL DEC ±0.15 Angles ±1° PL DEC ±0.08 3) Note reference = X SIGNATURES DRAWN: CHECKED: APPROVAL: CUSTOMER: PROCESS SPECIFICATIONS: 19/OCT/18 19/OCT/18 TOMMY 19/OCT/18 ITEM Amphenol DATE ROOKIE ORION Sine Systems - www.amphenol-sine.com 44724 Morley Drive Clinton Township, MI 48036 ENGINEER: MATERIAL SPECIFICATIONS: RECOMMENDED PANEL THICKNESS:1.6 TO 4.7MM PROTECTIVE CAP FOR PLUG,AHDM,SIZE 24 THIS DRAWING IS SUPPLIED FOR INFORMATION ONLY. DESIGN FEATURES, SPECIFICATIONS AND PERFORMANCE DATA SIZE SHOWN HEREON ARE THE PROPERTY OF THE AMPHENOL CORPORATION. NO RIGHTS OF REPRODUCTION ARE IMPLIED. ALL DIMENSIONS ARE SUBJECT TO NORMAL SCALE: MANUFACTURING VARIATIONS. TYPE B C- NEXT ASS'Y: OF: UNLESS OTHERWISE SPECIFIED 4. RoHS COMPLIANT. 5. ALL DIMENSIONS ARE FOR REFERENCE USE ONLY. AHDC34-24 DESCRIPTION PART NUMBER MATERIALS LIST QUANTITY 2. MATE WITH AHDM SERIES SIZE 24 PLUG ( AHDM06-24-**** , * = ALL MODIFICATION ) . 3. IP CLASS : IP67&IP69K ( MATED CONDITION ). 1 41.45 +0.2 -0 NONE DWG NO: REVISION AHDC34-24 SHEET A1 1 OF 1 1 1. MATERIAL: SHELL: ALUMINUM ALLOY, NICKEL PLATED; CHAIN: STAINLESS STEEL; SEAL: SILICONE RUBBER.
