MB1WSN8H00

REVISIONS REV ECO DESCRIPTION DATE BY B1 - RELEASE NEW DWG FORMAT 05/10/14 DRACK B2 - ADDED PIN NUMBERS 08DEC15 MRF APPR 40.7 13.8 6.0 TITLE: 4 M23, PLUG, STRAIGHT, PANEL MOUNT, HYBRID, THREADED NOTES: UNLESS OTHERWISE SPECIFIED 2 1. MATERIAL: INSULATION INSERT:PBT,UL94 V0 SEAL: VITON HOUSING BODY: ZINC DIE CAST, NICKEL PLATED COUPLING NUT: COPPER ALLOY, NICKEL PLATED ø29.5 21.5 1 3 15/16-20 UNEF SH: M23*1.0 Ø23.4 B2 1 All dimensions are in metric(mm). Tolerances are as follows: PL DEC ±0.30 Fractions ±1/64 PL DEC ±0.15 Angles ±1° PL DEC ±0.08 3) Note reference = X SIGNATURES DRAWN: Drack ITEM 1 1) 2) 1 2 3 OF: 21.8 REV: SEE PART NUMBER CHART DESCRIPTION PART NUMBER MATERIALS LIST UNLESS OTHERWISE SPECIFIED Ø2 4 .0 MB1WSN8H00 3. ALL DIMENSIONS ARE FOR REFERENCE USE ONLY. QUANTITY SECTION A-A DWG NO: 2. SPECIFICATIONS: 2.1 CURRENT RATING: SIGNAL: 1 AMPS POWER: 18 AMPS QUAD ELEMENT:0.5 AMPS 2.2 VOLTAGE RATING: SIGNAL: 850V AC/DC POWER: 850V AC/DC QUAD ELEMENT: 30V AC/DC 2.3 OPERATING TEMPERATURE: -20°C TO +130°C 2.4 DIELECTRIC WITHSTANDING VOLTAGE: LESS THAN 2 MILLIAMPS CURRENT LEAKAGE @ SIGNAL: 1500 VOLTS AC. POWER: 6000 VOLTS AC. QUAD ELEMENT: 500 VOLTS AC. 2.5 DEGREE OF PROTECTION: IP67 ( MATED CONDITION ) 2.6 DEGREE OF POLLUTION: 3 PER UL840 2.7 OVERVOLTAGE CATEGORY: III PER UL840 2.8 MATING CYCLE DURABILITY: >500 CYCLES 2.9 RoHS COMPLIANT Amphenol DATE 05/10/14 CHECKED: Sine Systems - www.amphenol-sine.com 44724 Morley Drive Clinton Township, MI 48036 ENGINEER: APPROVAL: MATERIAL SPECIFICATIONS: CUSTOMER: M23, PLUG, ST, PANEL MOUNT, HYBRID, THRD'D PROCESS SPECIFICATIONS: MOUNTING HOLES THIS DRAWING IS SUPPLIED FOR INFORMATION ONLY. DESIGN FEATURES, SPECIFICATIONS AND PERFORMANCE DATA SIZE SHOWN HEREON ARE THE PROPERTY OF THE AMPHENOL CORPORATION. NO RIGHTS OF REPRODUCTION ARE IMPLIED. ALL DIMENSIONS ARE SUBJECT TO NORMAL SCALE: MANUFACTURING VARIATIONS. TYPE B C- NEXT ASS'Y: NONE DWG NO: REVISION MB1WSN8H00 SHEET B2 1 OF 1
