10-100RV-S

Model RFP-10-XXXRV-S RoHS Compliant Half Flange Resistors 10 Watts General Specifications Resistive Element Substrate Cover Mounting flange Leads Thick film Beryllium oxide ceramic Alumina ceramic Copper, nickel plated per QQ-N-290 99% pure silver (.005” thick) Features: • See Chart • 10 Watts • BeO Ceramic • Non-Nichrome Resistive Element • Welded Silver Leads • 100% Tested • RoHS Compliant Electrical Specifications Resistance Range: Frequency Range; Power: Capacitance: See Chart, ± 5% See Chart 10 Watts .75 pF Tolerance is ±0.010”, unless otherwise specified. Designed to meet of exceed applicable portions of MIL-E-5400. Operating temperature is -55ºC to 150ºC (see chart for derating temperatures). All dimensions in inches. Specifications subject to change with out notice. Outline Drawing 10-XXXRV-S (097) Rev D Available on Tape and Reel For Pick and Place Manufacturing. USA/Canada: Toll Free: Europe: (315) 432-8909 (800) 544-2414 +44 2392-232392 Model RFP-10-XXXRV-S Resistor Value Chart: RoHS Compliant Part Number 10-20RV-S 10-25RV-S 10-75RV-S 10-100RV-S 10-150RV-S 10-180RV-S 10-200RV-S Power De-rating: Value 20 Ohms 25 Ohms 75 Ohms 100 Ohms 150 Ohms 180 Ohms 200 Ohms Frequency DC - 6.0 GHz DC - 2.0 GHz DC - TBD DC - 6.0 GHz DC - 3.0 GHz DC - 3.0 GHz DC - 2.0 GHz Tolerance ± 5% ± 5% ± 5% ± 5% ± 5% ± 5% ± 5% Mounting Footprint and Procedure: .025 MIN. (2 PLACES) BOARD LOWER THAN LEAD. BOARD EVEN WITH LEAD. BOARD LOWER THAN LEAD. BOARD HIGHER THAN LEAD. SUGGESTED STRESS RELIEF METHODS SCALE: NONE NOT RECOMMENDED APPLICATION SCALE: NONE 10-XXXRV-S (097) Rev D USA/Canada: Toll Free: Europe: (315) 432-8909 (800) 544-2414 +44 2392-232392 Available on Tape and Reel For Pick and Place Manufacturing.
