150-150RL-S

RoHS Compliant Model RFP-150-XXXRL-S Flanged Resistors 150 Watts General Specifications Resistive Element Substrate Cover Mounting flange Leads Thick film Beryllium oxide ceramic Alumina ceramic Copper, nickel plated per QQ-N-290 99% pure silver (.005” thick) Electrical Specifications Features: • DC – 2.0 GHz • 150 Watts • BeO Ceramic • Non-Nichrome Resistive Element • Welded Silver Leads • 100% Tested • RoHS Compliant Resistance Range Frequency Range Power Capacitance See chart See chart 150 Watts See chart Tolerance is ±0.010”, unless otherwise specified. Designed to meet of exceed applicable portions of MIL-E-5400. Operating temperature is -55ºC to 155ºC (see chart for derating temperatures). All dimensions in inches. Specifications subject to change with out notice. Outline Drawing 150-XXXRL-S (097) Rev B Available on Tape and Reel For Pick and Place Manufacturing. USA/Canada: Toll Free: Europe: (315) 432-8909 (800) 544-2414 +44 2392-232392 Model RFP-150-XXXRL-S Specifications: Part number 150-50RL-S 150-100RL-S 150-150RL-S 150-200RL-S Frequency (GHz) 1.5 2.0 2.0 2.0 Resistance ( ) 50 100 150 200 Capacitance (pF) 2.9 2.9 3.2 3.2 Power De-rating: Mounting Footprint and Procedure: SUGGESTED MOUNTING PROCEDURES: 1. .025 MIN. (2 PLACES) 2. 3. BOARD LOWER THAN LEAD. BOARD EVEN WITH LEAD. BOARD LOWER THAN LEAD. BOARD HIGHER THAN LEAD. 4. SUGGESTED STRESS RELIEF METHODS SCALE: NONE NOT RECOMMENDED APPLICATION SCALE: NONE 5. MAKE SURE THAT THE DEVICES ARE MOUNTED ON FLAT SURFACES (.001" UNDER THE DEVICE) TO OPTIMIZE THE HEAT TRANSFER. DRILL & TAP THE HEATSINK FOR THE APPROPRIATE THREAD SIZE TO BE USED. COAT HEATSINK WITH A MINIMUM AMOUNT OF HIGH QUALITY SILICONE GREASE (.001" MAX. THICKNESS). POSITION DEVICE ON MOUNTING SURFACE & SECURE USING SOCKET HEAD SCREWS, FLAT & SPLIT WASHER. TORQUE SCREWS TO THE APPROPRIATE VALUE. MAKE SURE THAT THE DEVICE IS FLAT AGAINST THE HEATSINK. (CARE SHOULD BE TAKEN TO AVOID UPWARD PRESSURE OF THE LEADS TOWARDS THE LID). SOLDER LEADS IN PLACE USING APPROPROATE SOLDER WITH A CONTROLLED TEMPERATURE IRON. ** FOR MORE DETAILS CONTACT FACTORY ** 150-XXXRL-S (097) Rev B USA/Canada: Toll Free: Europe: (315) 432-8909 (800) 544-2414 +44 2392-232392 Available on Tape and Reel For Pick and Place Manufacturing.
