RFP-100-100RW-S

Model RFP-100-100RW-S RoHS Compliant Full Flange Resistor 100 Watts, 100 General Specifications Resistive Element Substrate Cover Thick film Beryllium oxide ceramic Alumina Ceramic Copper, Nickel plated per QQ-N290 99.99% pure silver (.006” thick) -55 to +150°C (see chart) Features: • DC – 3.0 GHz • 100 Watts • BeO Ceramic • Welded Silver Leads • Non-Nichrome Resistive Element • 100% Tested • RoHS Compliant Mounting Flange Lead(s): Operating Temperature Electrical Specifications Resistance value: Frequency Range: Power: Capacitance: 100 Ohms ± 5% DC – 3.0 GHz 100 Watts 1.5 pF Notes: Tolerance is ±0.010”, unless otherwise specified. Designed to meet of exceed applicable portions of MIL-E-5400. All dimensions in inches. Lead length 0.150” minimum. Specifications subject to change without notice. Outline Drawing 100-100RW-S (097) Rev B USA/Canada: Toll Free: Europe: (315) 432-8909 (800) 544-2414 +44 2392-232392 Model RFP-100-100RW-S Typical Performance Suggested Mounting Procedure Power Derating 100-100RW-S (097) Rev B USA/Canada: Toll Free: Europe: (315) 432-8909 (800) 544-2414 +44 2392-232392
