RFP-60-50TPR-S

Model RFP-60-50TPR-S Flanged Termination 60 Watts, 50 General Specifications Resistive Element Substrate Cover Mounting Flange Lead(s): Thick film Beryllium oxide ceramic Alumina Ceramic Copper, Nickel plated per QQ-N-290 99.9% pure silver (.006 thick) -55 to +150°C (see chart) Features: • DC – 6.0 GHz • 60 Watts • BeO Ceramic • Welded Silver Leads • Non-Nichrome Resistive Element • Low VSWR • 100% Tested Operating Temperature Electrical Specifications Resistance Value: Frequency Range: Power: V.S.W.R. 50 ohms, ± 5% DC – 6.0 GHz 60 Watts 1.25:1 Notes: Tolerance is ±0.010”, unless otherwise specified. Designed to meet of exceed applicable portions of MIL-E-5400. All dimensions in inches. Lead length 0.150” minimum. Specifications subject to change without notice. Outline Drawing 60-50TPR-S (097) Rev B USA/Canada: Toll Free: Europe: (315) 432-8909 (800) 544-2414 +44 2392-232392 Model RFP-60-50TPR-S Typical Performance Power Derating Suggested Mounting Procedures 60-50TPR-S (097) Rev B USA/Canada: Toll Free: Europe: (315) 432-8909 (800) 544-2414 +44 2392-232392
