PA RT
PC Mount Common Mode Chokes
NU MB ER
Series CM9900
Physical Parameters Inches A 0.740 ± 0.025 B 0.840 ± 0.025 C 0.670 ± 0.025 D 0.900 Ref. E 0.040 ± 0.025 F 0.025 Sq. (Typ.) G 0.200 ± 0.010 H 0.175 ± 0.010 J 0.750 ± 0.025 K 0.200 ± 0.010 L 0.515 ± 0.010 All dimensions are typical
Millimeters 18.8 ± 0.64 21.3 ± 0.64 17.0 ± 0.64 22.9 ± 0.64 1.0 ± 0.64 0.64 Sq. (Typ.) 5.1 ± 0.3 4.4 ± 0.3 19.1 ± 0.64 5.1 ± 0.3 13.1 ± 0.3
CM9900-473 CM9900-563 CM9900-683 CM9900-823 CM9900-104 CM9900-124 CM9900-154 CM9900-184 CM9900-224 CM9900-274 CM9900-334 CM9900-474 CM9900-564 CM9900-684 CM9900-824 CM9900-105 CM9900-125 CM9900-155 CM9900-185 CM9900-225 CM9900-275 CM9900-335 CM9900-395 CM9900-475 CM9900-565 CM9900-685 CM9900-825 CM9900-106 CM9900-126 CM9900-156 CM9900-186 CM9900-226 CM9900-276 CM9900-336 CM9900-396 CM9900-476 CM9900-566 CM9900-686 CM9900-826 CM9900-107 CM9900-127
47 56 68 82 100 120 150 180 220 270 330 470 560 680 820 1000 1200 1500 1800 2200 2700 3300 3900 4700 5600 6800 8200 10000 12000 15000 18000 22000 27000 33000 39000 47000 56000 68000 82000 100000 120000
L (µ @ H), 1K L1 Hz or ± 2 L2 5% DC MA RES XI IST MU A M NC (O E HM S) CU RR MA E XI NT MU R M ATI (A NG MP LE S) AK MA A XI GE MU IN M D. (µ H)
0.016 0.018 0.019 0.023 0.025 0.028 0.030 0.038 0.044 0.051 0.058 0.078 0.091 0.115 0.131 0.194 0.219 0.278 0.306 0.431 0.469 0.531 0.669 0.760 0.853 1.24 1.40 1.61 1.98 2.24 2.45 3.49 4.60 5.21 7.19 7.80 8.69 9.69 13.10 14.60 16.00 3.5 3.5 3.5 2.8 2.8 2.8 2.8 2.2 2.2 2.2 1.7 1.4 1.4 1.1 1.1 0.88 0.88 0.70 0.70 0.55 0.55 0.55 0.44 0.44 0.44 0.35 0.35 0.35 0.27 0.27 0.27 0.22 0.17 0.17 0.13 0.13 0.13 0.13 0.10 0.10 0.10 4.0 4.0 5.0 5.5 6.0 6.5 7.5 8.0 9.0 10 11 16 18 20 25 35 47 49 59 76 91 101 135 158 196 257 296 362 410 503 602 730 870 1150 1300 1541 1875 2254 2702 3269 3456
TRANSFORMERS
Operating Temperature Range –55°C to +125°C Current Rating at 80°C Ambient 40°C rise Mechanical Configuration Tape wrapped winding sections; varnish impregnated assembly. Notes 1) Inductance in table is for either L1 or L2. 2) Leakage Inductance tested at L1 with L2 shorted or at L2 with L1 shorted. 3) Windings balanced within 1%. Packaging Bulk only
www.delevan.com E-mail: apisales@delevan.com 270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814
PAGE
2/ 2002
131
