SF30-24-12S

VER : C_1 update : 98.04.09 Encapsulated DC-DC Converter SF30 SERIES KEY FEATURES Power Module for PCB Mountable High Efficiency Up To 87% 4:1 Wide Input Range Six-sided Continuous Shield Standard Package Screw Terminal for Optional 2 Years Product Warranty 30 Watts ELECTRICAL SPECIFICATIONS Model No. ( Single Output ) Max. Output Wattage (W) Input Voltage (V.DC.) Output Voltage (V.DC.) Efficiency (%) capacitor Load max SF30-24-2.5S 15W 24V (10-40V) 2.5V / 6000mA 80% 33000μF SF30-24-3.3S 19.8W 24V (10-40V) 3.3V / 6000mA 83% 19500μF SF30-24-5S 30W 24V (10-40V) 5V / 6000mA 85% 10200μF SF30-24-12S 30W 24V (10-40V) 12V / 2500mA 83% 820μF SF30-24-15S 30W 24V (10-40V) 15V / 2000mA 83% 420μF SF30-24-24S 30W 24V (10-40V) 24V / 1250mA 84% 180μF Model No. ( Single Output ) Max. Output Wattage (W) Input Voltage (V.DC.) Output Voltage (V.DC.) Efficiency (%) capacitor Load max SF30-48-2.5S 15W 48V (18-75V) 2.5V / 6000mA 81% 33000μF SF30-48-3.3S 19.8W 48V (18-75V) 3.3V / 6000mA 85% 19500μF SF30-48-5S 30W 48V (18-75V) 5V / 6000mA 87% 10200μF SF30-48-12S 30W 48V (18-75V) 12V / 2500mA 84% 820μF SF30-48-15S 30W 48V (18-75V) 15V / 2000mA 84% 420μF SF30-48-24S 30W 48V (18-75V) 24V / 1250mA 84% 180μF Model No. ( Dual Output ) Max. Output Wattage (W) Input Voltage (V.DC.) Output Voltage (V.DC.) Efficiency (%) capacitor Load max SF30-24-5D 30W 24V (10-40V) ±5V / ±3000mA 81% ±4800μF SF30-24-12D 30W 24V (10-40V) ±12V / ±1250mA 83% ±560μF SF30-24-15D 30W 24V (10-40V) ±15V / ±1000mA 83% ±470μF SF30-48-5D 30W 48V (18-75V) ±5V / ±3000mA 82% ±4800μF SF30-48-12D 30W 48V (18-75V) ±12V / ±1250mA 84% ±560μF SF30-48-15D 30W 48V (18-75V) ±15V / ±1000mA 83% ±470μF Model No. ( Single Output ) SF30-24-2.5S SF30-48-2.5S 15W SF30-24-3.3S SF30-48-3.3S 19.8W SF30-24-5S SF30-48-5S 30W SF30-24-12S SF30-48-12S 30W 12 2500 SF30-24-15S SF30-48-15S 30W 15 2000 SF30-24-24S SF30-48-24S 30W 24 1250 Max Output Wattage (W) Voltage (V.DC.) Voltage Accuracy Current (mA) max Line Regulation (LL-HL) (typ.) Load Regulation (10-100%) (typ.) Output Ripple Noise Trim Switching Frequency Over Power Protection Protection Over Voltage Protection Short Circuit Protection Voltage Isolation Resistance Capacitance Operating Temperature Storage Temperature Case Temperature Environment Temperature Coefficient Humidity MTBF Dimension (L x W x H) Case Material Physical Weight Cooling Method 2.5 3.3 5 ±2% 6000 6000 6000 ±0.5% ±1% 100 mV max. 100 mV max. ±10% 250KHz Works over 120% of rating and recovers automatically. Zener diode clamp Hiccup mode, auto-recovery 1600 VDC. ±1% max. ±1% max. 108 ohms 1000 pF -25°C…+70°C (with derating) -55°C…+105°C +100°C max. ±0.02% Per°C 95% RH >550,000 h @ 25°C (MIL-HDBK-217F) 2.0 x 1.6 x 0.47 Inches ( 50.8 x 40.6 x 11.9 mm ) Tolerance ±0.5 mm Nickel-Coated Copper with Non-Conductive Base, Six-side shielded. 58 g Free-air convection All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated. http://www.archcorp.com.tw TEL: +886-2-26989508 FAX: +886-2-26981319 -1- VER : C_1 update : 98.04.09 Encapsulated DC-DC Converter SF30 SERIES SF30-24-5D SF30-48-5D 30W π type ±5 ±12 ±2% ±3000 ±1250 ±0.5% ±1% ±1% ±1% ±10% 250KHz Works over 120% of rating and recovers automatically. Zener diode clamp Hiccup mode, auto-recovery 1600 VDC. 108 ohms 1000 pF -25°C…+70°C (with derating) -55°C…+105°C +100°C max. ±0.02% Per°C 95% RH >550,000 h @ 25°C (MIL-HDBK-217F) 2.0 x 1.6 x 0.47 Inches ( 50.8 x 40.6 x 11.9 mm ) Tolerance ±0.5 mm Nickel-Coated Copper with Non-Conductive Base, Six-side shielded. 58 g Free-air convection ±15 ±1000 SF30-24-12D SF30-48-12D SF30-24-15D SF30-48-15D 30 Watts Model No. ( Dual Output ) Max Output Wattage (W) Input Input Filter Voltage (V.DC.) Voltage Accuracy Current (mA) max Line Regulation (LL-HL) (typ.) Output Load Regulation (10-100%) (typ.) Ripple Noise Trim Switching Frequency Over Power Protection Protection Over Voltage Protection Short Circuit Protection Voltage Isolation Resistance Capacitance Operating Temperature Storage Temperature Case Temperature Environment Temperature Coefficient Humidity MTBF Dimension (L x W x H) Case Material Physical Weight Cooling Method All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated. OUTPUT NOISE The output noise is measured with 10μF tantalum capacitor and 0.1μF ceramic capacitor across output. MECHANICAL DIMENSION ( Top View ) PIN# 1 2 3 4 5 6 7 Single CTRL -DC IN +DC IN TRIM -DC OUT +DC OUT NO PIN Dual CTRL -DC IN +DC IN TRIM -DC OUT COMMON +DC OUT http://www.archcorp.com.tw TEL: +886-2-26989508 FAX: +886-2-26981319 -2- VER : C_1 update : 98.04.09 Encapsulated DC-DC Converter SF30 SERIES DERATING 30 Watts REMOTE ON/OFF CONTROL BLOCK DIAGRAM Output Voltage (V.DC) : 12V, 15V, 24V Single Output Output Voltage (V.DC) : 2.5V, 3.3V, 5V http://www.archcorp.com.tw TEL: +886-2-26989508 FAX: +886-2-26981319 -3- VER : C_1 update : 98.04.09 Encapsulated DC-DC Converter SF30 SERIES SCREW TERMINAL SF30-A2 30 Watts PIN# 1 2 3 4. 5 6 7 8 Single CTRL -DC IN +DC IN TRIM -DC OUT NO CONNECT +DC OUT NO CONNECT Dual CTRL -DC IN +DC IN TRIM -DC OUT NO CONNECT COMMON +DC OUT SF30-A5 PIN# 1 2 3 4. 5 6 7 8 Single CTRL -DC IN +DC IN TRIM -DC OUT NO CONNECT +DC OUT NO CONNECT Dual CTRL -DC IN +DC IN TRIM -DC OUT NO CONNECT COMMON +DC OUT http://www.archcorp.com.tw TEL: +886-2-26989508 FAX: +886-2-26981319 -4-
