SH10-12-3.3S

VER : A_4 update : 98.04.09 Encapsulated DC-DC Converter SH10 SERIES KEY FEATURES Power Module for PCB Mountable High Efficiency and Reliability 2:1 Input Range Single and Dual Output Regulated Output Low Ripple and Noise 2-Years Product Warranty 10 Watts ELECTRICAL SPECIFICATIONS Model No. ( Single Output ) Input Voltage (V.DC.) Output Voltage (V.DC.) Efficiency (typ.) Capacitor Load (max) Model No. ( Single Output ) Input Voltage (V.DC.) Output Voltage (V.DC.) Efficiency (typ.) Capacitor Load (max) Model No. ( Single Output ) Input Voltage (V.DC.) Output Voltage (V.DC.) Efficiency (typ.) Capacitor Load (max) SH10-12-3.3S 12V (9-18V) 3.3V/2500mA 82% 2200μF SH10-24-3.3S 24V (18-36V) 3.3V/2500mA 82% 2200μF SH10-48-3.3S 48V (36-75V) 3.3V/2500mA 82% 2200μF SH10-12-5S 12V (9-18V) 5V/2000mA 83% 2200μF SH10-24-5S 24V (18-36V) 5V/2000mA 85% 2200μF SH10-48-5S 48V (36-75V) 5V/2000mA 85% 2200μF SH10-12-12S 12V (9-18V) 12V/830mA 86% 560μF SH10-24-12S 24V (18-36V) 12V/830mA 86% 560μF SH10-48-12S 48V (36-75V) 12V/830mA 86% 560μF SH10-12-15S 12V (9-18V) 15V/670mA 86% 470μF SH10-24-15S 24V (18-36V) 15V/670mA 86% 470μF SH10-48-15S 48V (36-75V) 15V/670mA 86% 470μF SH10-12-24S 12V (9-18V) 24V/416mA 86% 100μF SH10-24-24S 24V (18-36V) 24V/416mA 86% 100μF SH10-48-24S 48V (36-75V) 24V/416mA 86% 100μF SH10-12-3.3S Model No. ( Single Output ) SH10-24-3.3S SH10-48-3.3S Max Output Wattage (W) Input Input Filter Voltage (V.DC.) Voltage Accuracy Current (mA) max Line Regulation (LL-HL) (typ.) Output Load Regulation (10-100%) (typ.) Minimum Load Ripple Noise Switching Frequency Over Power Protection Protection Short Circuit Protection Voltage Isolation Resistance Capacitance Operating Temperature Storage Temperature Case Temperature Environment Temperature Coefficient Humidity MTBF Dimension (L x W x H) Case Material Physical Weight Cooling Method 10W SH10-12-5S SH10-24-5S SH10-48-5S SH10-12-12S SH10-24-12S SH10-48-12S SH10-12-15S SH10-24-15S SH10-48-15S SH10-12-24S SH10-24-24S SH10-48-24S π type 3.3 5 ±2% 2500 2000 ±0.5% ±3% ±1% 0% 50 mV max. 1% max. 50 mV max. 1% max. 300KHz Above 105% Rated Output Power Current limit, auto-recovery 1600 VDC. 12 830 ±1% 15 670 ±1% 24 416 ±1% 108 ohms 1000 pF -25°C…+60°C (at Full Load) -55°C…+105°C +100°C max. ±0.02% Per°C 95% RH >800,000 h @ 25°C (MIL-HDBK-217F) 1.25 x 0.8 x 0.44 Inches ( 31.8 x 20.3 x 11.2 mm ) Tolerance ±0.5 mm Nickel-Coated Copper with Non-Conductive Base, Six-side shielded. 20 g Free-air convection All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated. http://www.archcorp.com.tw TEL: +886-2-26989508 FAX: +886-2-26981319 -1- VER : A_4 update : 98.04.09 Encapsulated DC-DC Converter SH10 SERIES Model No. ( Dual Output ) Input Voltage (V.DC.) Output Voltage (V.DC.) Efficiency (typ.) Capacitor Load (max) Model No. ( Dual Output ) Input Voltage (V.DC.) Output Voltage (V.DC.) Efficiency (typ.) Capacitor Load (max) Model No. ( Dual Output ) Input Voltage (V.DC.) Output Voltage (V.DC.) Efficiency (typ.) Capacitor Load (max) SH10-12-5D 12V (9-18V) ±5V / ±1000mA 83% ±1200μF SH10-24-5D 24V (18-36V) ±5V / ±1000mA 83% ±1200μF SH10-48-5D 48V (36-75V) ±5V / ±1000mA 82% ±1200μF SH10-12-12D 12V (9-18V) ±12 / ±416mA 86% ±330μF SH10-24-12D 24V (18-36V) ±12 / ±416mA 87% ±470μF SH10-48-12D 48V (36-75V) ±12 / ±416mA 87% ±470μF SH10-12-15D 12V (9-18V) ±15 / ±333mA 86% ±120μF SH10-24-15D 24V (18-36V) ±15 / ±333mA 86% ±330μF SH10-48-15D 48V (36-75V) ±15 / ±333mA 86% ±330μF 10 Watts SH10-12-5D Model No. ( Dual Output ) SH10-24-5D SH10-48-5D Max Output Wattage (W) Input Input Filter Voltage (V.DC.) Voltage Accuracy Current (mA) max Line Regulation (LL-HL) (typ.) Output Load Regulation (10-100%) (typ.) Minimum Load Ripple Noise Switching Frequency Over Power Protection Protection Short Circuit Protection Voltage Isolation Resistance Capacitance Operating Temperature Storage Temperature Case Temperature Environment Temperature Coefficient Humidity MTBF Dimension (L x W x H) Case Material Physical Weight Cooling Method 10W SH10-12-12D SH10-24-12D SH10-48-12D SH10-12-15D SH10-24-15D SH10-48-15D L-C type ±5 ±12 ±2% ±1000 ±416 ±0.5% ±1% ±1% 0%
