12-002-101TL

Series 100 thru 111 DIP Jumpers FEATURES: • Aries offers a wide array of DIP jumper configurations and wiring possibilities for all your programming needs. • Reliable, electronically tested solder connections. • Protective covers are ultrasonically welded on and provide strain relief for cables. • 10-color cable allows for easy identification and tracing. • Consult factory for jumper lengths under 2.000 [50.80]. SPECIFICATIONS: • Header body and cover is black UL 94V-0 4/6 Nylon. • Header pins are Brass, 1/2 hard. • Standard Pin plating is 10 μ [.25μm] min. Gold per MIL-G-45204 over 50 μ [1.27μm] min. Nickel per QQ-N-290. • Optional Plating: “T” = 200 μ” [5.08μm] min. Matte Tin per ASTM B545-97 over 50 μ” [1.27μm] min. Nickel per QQ-N-290. Note: Aries specializes in custom design and production. In addition to the “TL” = 200 μ” [5.08μm] 90/10 Tin/Lead per MIL-T-10727 Type I over 50 μ” [1.27μm] standard products shown on this page, special materials, platings, sizes, min. Nickel per QQ-N-290. and configurations can be furnished, depending on quantities. Aries • Cable insulation is UL Style 2697 Polyvinyl Chloride (PVC). reserves the right to change product specifications without notice. ** • Laminate is clear PVC, self-extinguishing. • .050 [1.27] pitch conductors are 28 AWG, 7/36 strand, Tinned Copper per ASTM B 33 XX-XXXX-XXXXXX (.039 [.99] pitch conductors are 26 AWG, 7/34 strand). • Cable current rating=1 Amp @ 10°C [50°F] above No. of conductors Optional suffix: ambient. (see table) T=Tin plated header pins • Cable voltage rating=300 Volts. TL= Tin/Lead plated Cable length in inches: • Cable temperature rating=176°F [80°C]. Jumper header pins Ex: 2” = -002• Cable capacitance=13.0 pf/ft. [42.7pf/meter] nominal series TW=twisted pair cable 2.5” = -002.5@1 MHz.** ST=stripped and Tin (min. length=2.”[50.80mm]) • Crosstalk: 10’ sample, 5 ns rise time with 2 lines driven. Near end=4.7%; Dipped ends Far end=4.3% nominal.** (Series 106-111) • Propagation delay=1.5 ns/ft. [4.9 ns/meter] nominal.** STL= stripped and Centers “C” Dim. “D” Available Sizes 10 Ohms (10 ft. [3 meters] min.). • Insulation resistance=10 Tin/Lead Dipped Ends .300 [7.62] .395 [10.03] 4 thru 20 **Note: Applies to .050 [1.27] pitch cable only. (Series 106-111) MOUNTING CONSIDERATIONS: .400 [10.16] .495 [12.57] 22 •Suggested PCB hole size=.033 ± .002 [.86 ±.05]. ORDERING INFORMATION “L” ± .125 SERIES 100 .600 [15.24] .695 [17.65] 24, 28, 40 All tolerances ± .005[.13] All Dimensions: Inches [Millimeters] unless otherwise specified “A”=(NO. OF CONDUCTORS X .050 [1.27) + .095 [2.41] “B”=(NO. OF CONDUCTORS - 1) X .050 [1.27] HEADER DETAIL Numbers shown pin side for reference only. Note: 10, 12, 18, 20, & 28 conductor jumpers do not have numbers on covers. “L” ± .125 See Data Sheet No. 11007 for other configurations and additional information. SERIES 101 11006 http://www.arieselec.com • info@arieselec.com REV. H PRINTOUTS OF THIS DOCUMENT MAY BE OUT OF DATE AND SHOULD BE CONSIDERED UNCONTROLLED Bristol, PA USA TEL: (215) 781-9956 FAX: (215) 781-9845 abc
