13-F40-10TL

Series F40 Thru-Hole .040 [1.02] Female DIP Strips FEATURES: • This female DIP strip is used in conjunction with Aries’ Shorting Plug SP200, available separately, for your programming needs. • ”Break” feature allows strips to be cut to the number of positions desired. SPECIFICATIONS: • Body material is black UL 94V-0 Glass-filled 4/6 Nylon. • Pin body is Brass Alloy 360 1/2 hard per UNS C36000 ASTMB16-00. • Pin body plating: -10 = 200 μ [5.08μm] min.Tin per ASTM B545 Type 1 over 100 μ [2.54μm] min. Nickel per SAE-AMS-QQ-N-290. -10TL = 200μ [5.08μm] min. 93/7 Tin/Lead per MIL-P-81728 over 100μ [2.54μm] min. Nickel per SAE-AMS-QQ-N-290. • 4-fingered collet contact is Beryllium Copper Alloy per UNS C17200 ASTM-B194-01. • Collet contact plating is 30 μ [.76μm] min. Gold per MIL-G-45204 over 50 μ [1.27μm] min. Nickel per SAE-AMS-QQN-290. • Contact current rating=8 Amps. • Operating temperature= -67° to 221°F [-55° to 105°C]. • Insertion Force=240 grams/pin; Withdrawal Force=130 grams/pin; Normal Force=210 grams/pin; based on a .040 [1.02] diameter test lead. • Accepts leads .032-.047 [.81-1.19] in diameter, .130-.180 [3.304.56] long. MOUNTING CONSIDERATIONS: • Suggested PCB hole size=.081 ± .002 [2.03 ± .05] dia. Note: Aries specializes in custom design and production. In addition to the standard products shown on this page, special materials, platings, sizes, and configurations can be furnished, depending on quantities. Aries reserves the right to change product specifications without notice. ORDERING INFORMATION XX - F40 - 10 XX No. of Pins: 2 - 20 (even # only) Ex. 02 = 2 pins 14 = 14 pins Series Plating Option: TL = Tin/Lead Tin Plating CONTACT DETAIL ALL DIMENSIONS: INCHES [MILLIMETERS] All tolerances ± .005 [.13] unless otherwise specified Consult Data Sheet No. 16007 for thru-hole male DIP strips. Mates with Aries’ Shorting Plugs, Part No. SP200. Consult Data Sheet No. 16009 for details. 16008 http://www.arieselec.com • info@arieselec.com REV. E PRINTOUTS OF THIS DOCUMENT MAY BE OUT OF DATE AND SHOULD BE CONSIDERED UNCONTROLLED Bristol, PAJ USA TEL: (215) 781-9956 FAX: (215) 781-9845 abc
