29-505-111

Series 505 PLCC-to-PGA JEDEC Type 0.050 [1.27] Pitch Adapter FEATURES • Convert surface mount PLCC packages to a PGA footprint • Pin polarization option also available • Consult factory for Panelized Form or for mounting of consigned chips GENERAL SPECIFICATIONS • ADAPTER BODY: FR-4, 0.062 [1.58] thick, with 1-oz. min. Cu traces • PADS: hot-air solder leveled • PINS: Brass 360 1/2-hard per UNS C36000 ASTM-B16-00 • PIN PLATING: 200µ [5.08µ] Sn/Pb 93/7 ASTM B579-73 over 100µ [2.54µ] Ni per ASE AMS-QQ-N-290 or 10µ [0.25µ] Au • OPERATING TEMPERATURE: 221°F [105°C] MOUNTING CONSIDERATIONS • SUGGESTED PCB HOLE SIZE: 0.028 ±0.003 [0.71 ±0.08] dia • STANDARD : will plug into PGA socket CUSTOMIZATION: In addition to the standard products shown on this page, Aries specializes in custom design and production. Special materials, platings, sizes, and configurations can be furnished, depending on the quantity. NOTE: Aries reserves the right to change product general specifications without notice. ALL DIMENSIONS: INCHES [MILLIMETERS] ALL TOLERANCES: ±0.005 [0.13] UNLESS OTHERWISE SPECIFIED CONSULT FACTORY FOR OTHER SIZES AND CONFIGURATIONS ORDERING INFORMATION XX-505-11 X X No. of Pins 28, 44, 52, 68, 84 or 29, 45, 53, 69, 85 with Polarization Pin Series Stand-offs w/Solder Pin Tail Optional Panelized Version Pin Plating 0 = Sn (standard) 1 = Au # Pins 28 or 29 44 or 45 52 or 53 68 or 69 84 or 85 Dim. “A” 0.600 [15.24] 0.800 [20.32] 0.875 [22.23] 1.100 [27.94] 1.300 [33.02] Dim. “B” 0.500 [12.70] 0.700 [17.78] 0.775 [19.69] 1.000 [25.40] 1.200 [30.48] Dim. “C” 0.448 [11.38] Dim. “D” 0.324 [8.23] Matching PGA P/N 29-PGM06002-30 44-PGM08002-30 52-PGM09018-30 68-PGM11032-30 84-PGM13042-30 0.648 [16.46] 0.524 [13.31] 0.760 [19.30] 0.625 [15.88] 0.948 [24.08] 0.824 [20.93] 1.148 [29.16] 1.024 [26.01] Bristol, PA 19007-6810 USA TEL (215) 781-9956 • FAX (215) 781-9845 WWW.ARIESELEC.COM • INFO@ARIESELEC.COM PRINTOUTS OF THIS DOCUMENT MAY BE OUT OF DATE AND SHOULD BE CONSIDERED UNCONTROLLED 18028 Rev. AA
