7-002-152FBP

Series 152FB Fusion Bonded Cable Jumpers FEATURES • Series 152FB fusion-bonded Cable Jumpers are flexible – plug them directly into PC boards or sockets. • Stranded wire conductors are fusion bonded with an overcoat of Sn for easy soldering or socketing. • Each jumper is shipped with protective tabs on both ends for maintaining proper conductor spacing. GENERAL SPECIFICATIONS • INSULATION: UL VW-1, Style 2651 Polyvinyl Chloride (PVC) with optional Polarization Stripe on one side • NOMINAL INSULATION: Thickness 0.009 [0.23] CUSTOMIZATION: In addition to the standard products shown • CONDUCTORS: 26-gauge, 7-strand Cu with Sn fusion-bonded overcoat on this page, Aries specializes in custom design and production. • OPERATING TEMPERATURE: -4°F to 221°F [-20°C to 105°C] Special materials, platings, sizes, and configurations can be furnished, depending on the quantity. NOTE: Aries reserves the • Voltage Rating: 300Vrms right to change product general specifications without notice. • DIELECTRIC WITHSTANDING VOLTAGE: 1500Vrms • INSULATION RESISTANCE: 10,000 mΩ per 10 feet [3.05 meters] • RESISTANCE: 40.3Ω per 1000 feet [304.8 ORDERING INFORMATION meters] XX-XXXXX-152FB X • PROPAGATION DELAY: 1.3ns/ft. No. of Conductors Option MOUNTING CONSIDERATIONS (4 thru 22) P = Polarization Stripe along • SUGGESTED PCB HOLE SIZE: 0.033 Cable Length one edge of cable* ± 0.002 [0.84 ±0.05] dia. Example: 2" = -002Jumper Series 2.5" = -002.5* Aries reserves the right to ship with 2.25" = -002.25or without polarization stripe unless 2.125" = -002.125specified by customer. ALL DIMENSIONS IN INCHES [MILLIMETERS] ALL TOLERANCES ±0.005 [±0.13] UNLESS OTHERWISE SPECIFIED “A” # CONDUCTORS x 0.100 [2.54] “B” (# CONDUCTORS -1) x 0.100 [2.54] ALL CABLES SHIP WITH Pb-FREE MATERIAL UNLESS SPECIFIED BY CUSTOMER WHEN ORDERING CONSULT FACTORY FOR OTHER SIZES & CONFIGURATIONS # Conductors 4 thru 8 9 and 10 11 thru 22 Min. Insulation Length 1.000 [25.40] 1.250 [31.75] 1.500 [38.10] Bristol, PA 19007-6810 USA TEL (215) 781-9956 • FAX (215) 781-9845 WWW.ARIESELEC.COM • INFO@ARIESELEC.COM PRINTOUTS OF THIS DOCUMENT MAY BE OUT OF DATE AND SHOULD BE CONSIDERED UNCONTROLLED 11001 Rev. AA
